LG LMV2075SB User manual

MICROWAVE OVEN
OWNER’S MANUAL
LMV2075SB
LMV2075SS
LMV2075SW
website : http://www.lg.ca
PLEASE READ THIS OWNER’S MANUAL
THOROUGHLY BEFORE OPERATING.
P/NO.: MFL32268304
Printed in Korea

2
TABLE OF CONTENTS
TABLE OF CONTENTS ........................................... 2
SAFETY ................................................................... 3
Important Safety Instructions ................................ 3
Precautions to Avoid Possible
Exposure to excessive Microwave
Energy ................................................................... 4
UNDERSTANDING YOUR MICROWAVE OVEN ....... 5
Location of Model Number .................................... 5
Oven Specifications .............................................. 5
Electrical Requirements ........................................ 5
Grounding Instructions .......................................... 5
Microwave Oven Features .................................... 6
Installing Glass Tray .............................................. 7
Installation Instructions for Glass Tray .................. 8
Using Oblong Dish ................................................ 8
Control Panel Features ......................................... 9
USING YOUR MICROWAVE OVEN ...................... 11
Learn About Your Microwave Oven .................... 11
Clock ................................................................... 11
Timer ................................................................... 11
Vent Fan ............................................................. 11
Vent Auto Time Set ............................................. 11
Light Hi/Low/Off ................................................... 11
Child Lock ........................................................... 12
Custom Cook ....................................................... 12
EZ-ON ................................................................. 12
Hold Warm .......................................................... 12
Custom Set ......................................................... 13
More/Less ........................................................... 13
Cooking at High Power Levels ............................ 13
Microwave Power Levels .................................... 13
Multi Stage Cooking ............................................ 13
Cooking Guide for Lower Power Levels .............. 14
Sensor Operating Instructions ............................. 15
Sensor Cooking Guide ........................................ 15
Sensor Popcorn .................................................. 15
Sensor Cook ....................................................... 16
Sensor Reheat .................................................... 16
Chicken Choices ................................................. 16
Sensor Cook Table ............................................. 17
Sensor Reheat Table .......................................... 17
Chicken Choices Table ....................................... 18
Soften .................................................................. 19
Melt ..................................................................... 19
Soften Table ........................................................ 20
Melt Table ........................................................... 20
Auto Defrost ........................................................ 21
Quick Defrost ...................................................... 21
Time Defrost ....................................................... 22
Defrost Tips ......................................................... 22
Metal Rack .......................................................... 22
COOKING .............................................................. 23
Getting the Best Cooking Results ....................... 23
Fish and Shellfish ................................................ 23
Fish and Shellfish Cooking Table ........................ 23
Appetizers /Sauces /Soups ................................. 24
Meat .................................................................... 24
Meat Cooking Table ............................................ 25
Chicken ............................................................... 26
Chicken Cooking Table ....................................... 26
Pasta and Rice .................................................... 27
Pasta Cooking Table ........................................... 27
Rice Cooking Table ............................................. 27
CARING FOR YOUR MICROWAVE OVEN .......... 28
Caring for Your Microwave Oven ........................ 28
Metal Rack .......................................................... 29
Cleaning the Grease Filters ................................ 29
Charcoal Filter Replacement ............................... 30
Cooktop/Night Light Replacement ...................... 30
Oven Light Replacement ..................................... 30
COOKING UTENSILS ........................................... 31
Microwave Utensil Guide .................................... 31
TROUBLESHOOTING ........................................... 32
Before Calling for Service ................................... 32
Questions and Answers ...................................... 33
LIMITED WARRANTY ........................................... 34

SAFETY
3
IMPORTANT SAFETY INSTRUCTIONS
The safety instructions below will tell you how to use your oven and avoid harm to yourself or
damage to your oven.
WARNING - To reduce the risk of burns,
electric shock, fire, injury to persons, or exposure to
excessive microwave energy.
• Read all the instructions before using your oven.
• Do not allow children to use this oven without
close supervision.
• Read and follow the specific PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE ENERGY found
on page 4.
• Do not use corrosive chemicals or vapors, such as
sulfide and chloride, in this appliance. This type of
oven is specifically designed to heat, cook, or dry
food. It is not designed for industrial or laboratory
use.
• Do not use or store this appliance outdoors. Do not
use this product near water - for example, near a
kitchen sink, in a wet basement, or near a swimming
pool, and the like.
• Do not use the cavity for storage purposes. Do not
leave paper products, cooking utensils, or food in
the cavity when not in use.
• Clean the ventilating hood frequently. Do not
allow grease to accumulate on the hood or the
filters.
• Use care when cleaning the vent hood filters.
Corrosive cleaning agents such as lye-based oven
cleaners may damage the filters.
• Do not tamper with the built-in safety switches
on the oven door. The oven has several built-in
safety switches to make sure the power is off when
the door is open.
• When food flames under the hood, turn the fan on.
• Suitable for use above both gas and electric cooking
equipment 36 inches wide or less.
• Do not use this oven for commercial purposes.
It is made for household use only.
• When cleaning the door and the surfaces that
touch the door, use only mild, non-abrasive
soaps or detergents and a sponge or soft cloth.
• If your oven is dropped or damaged, have it
thoroughly checked by a qualified service technician
before using it again.
• To avoid a fire hazard:
- Do not severely overcook food. Severely
overcooked foods can start a fire in the oven.
Watch the oven carefully, especially if you have
paper, plastic, or other combustibles in the oven.
- Do not store combustible items (bread,
cookies, etc.) in the oven, because if lightning
strikes the power lines it may cause the oven to
turn on.
- Do not use wire twist-ties in the oven. Be sure
to inspect purchased items for wire twist-ties and
remove them before placing the item in the oven.
- If materials inside the oven ignite, keep the oven
door closed, turn the oven off and disconnect the
power cord, or shut off power at the fuse or circuit
breaker panel. If the door is opened, the fire may
spread.
• If a fire should start:
- Keep the oven door closed.
- Turn the oven off.
- Disconnect the power cord or shut off the
power at the fuse or circuit breaker panel.
• To avoid electric shock:
- This appliance must be grounded. Connect it
only to a properly grounded outlet. See the
electrical GROUNDING INSTRUCTIONS
on page 5.
- Do not operate this appliance if it has a
damaged cord or plug, if it is not working
properly or if it has been damaged or dropped.
- Do not immerse the electrical cord or plug in
water.
- Keep the cord away from heated surfaces.

4
SAFETY
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY...
SAVE THESE INSTRUCTIONS
(a) Do not attempt to operate this oven with the
door open since open-door operation can
result in harmful exposure to microwave
energy. It is important not to defeat or tamper
with the safety interlocks.
(b) Do not place any object between the oven
front face and the door or allow soil or
cleaner residue to accumulate on sealing
surfaces.
(c) Do not operate the oven if it is damaged. It is
particularly important that the oven door
closes properly and that there is no
damage to the:
(1) Door (bent),
(2) Hinges and latches (broken or loosened),
(3) Door seals and sealing surfaces.
(d) The oven should not be adjusted or repaired
by anyone except properly qualified service
personnel.
• To avoid improperly cooking some foods.
- Do not heat any types of baby bottles or baby
food. Uneven heating may occur and possibly
cause personal injury.
- Do not heat small-necked containers, such as
syrup bottles.
- Do not deep-fat fry in your microwave oven.
- Do not attempt home canning in your
microwave oven.
- Do not heat the following items in the
microwave oven: whole eggs in the shell, water
with oil or fat, sealed containers, or closed glass
jars. These items may explode.
• Do not cover or block any openings in the oven.
• Use your oven only for the operations described in
this manual.
• Do not run the oven empty, without food in it.
• Do not let cord hang over edge of table or counter.
• Preserve the oven floor:
- Do not heat the oven floor excessively.
- Do not allow the gray film on special microwave-
cooking packages to touch the oven floor. Put the
package on a microwavable dish.
- Do not cook anything directly on the oven floor or
turntable. Use a microwavable dish.
- Keep a browning dish at least 3/16 inch above floor.
Carefully read and follow the instructions for the
browning dish. If you use a browning dish
ncorrectly, you could damage the oven floor.
• Install or locate this appliance only in accordance
with the provided installation instructions.
• This appliance should be serviced only by qualified
service personnel. Contact the nearest authorized
service facility for examination, repair, or adjustment.
• As with any appliance, close supervision is
necessary when used by children.

UNDERSTANDING YOUR MICROWAVE OVEN
Please read this owner’s manual. It will tell you how
to use all the fine features of this microwave oven.
LOCATION OF MODEL NUMBER
To request service information or replacement parts,
the service center will require the complete model
number of your microwave oven. The number is on the
oven front as shown in the illustration below.
OVEN SPECIFICATIONS
Output Power 1000W (IEC60705)
Outer Dimensions 2915/16” x 167/16” x 155/8”
Cavity Volume 2.0 Cu.ft
Net Weight 60 lbs.
ELECTRICAL REQUIREMENTS
The oven is designed to operate on a Standard
120V/60Hz household outlet. Be sure the circuit is at
least 15A or 20A and the microwave oven is the only
appliance on the circuit. It is not designed for 50Hz
or any circuit other than a 120V/60Hz circuit.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If an electrical
short circuit occurs, grounding reduces the risk of
electric shock by providing an escape wire for the
electric current. The cord for this appliance has a
grounding wire with a grounding plug. Put the plug into
an outlet that is properly installed and grounded.
WARNING - If you use the grounding
plug improperly, you risk electric shock.
Ask a qualified electrician if you do not understand the
grounding instructions or if you wonder whether the
appliance is properly grounded.
Because this appliance fits under the cabinet, it has a
short power-supply cord. See the separate Installation
Instructions for directions on placing the cord properly.
Keep the electrical power cord dry and do not pinch or
crush it in any way.
If it is necessary to use an extension cord, use only a
3-wire extension cord that has a 3-blade grounding
plug, and a 3-slot receptacle that will accept the plug
on the appliance. The marked rating of the extension
cord shall be equal to or greater than the electrical
rating of the appliance.
For a permanently connected appliance:
This appliance must be connected to a grounded,
metallic, permanent wiring system, or an equipment
grounding conductor should be run with the circuit
conductors and connected to the equipment grounding
terminal or lead on the appliance.
5
MODEL NUMBER LABEL
