LG DM2520 User manual

DM2520 (DM2520, DMS2520V)
OWNER’S MANUAL
DVD Micro Hi-Fi System
Please read this manual carefully before operating
your set and retain it for future reference.
ENGLISH
Reg. No. I.35.LG1.01001.1012
DM2520-FP_AIDNLLK__ENG.indd 1 2013-04-17  3:15:43

1 Getting Started
Getting Started2
Getting Started
1
Safety Information
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK DO NOT REMOVE COVER (OR BACK) NO
USER-SERVICEABLE PARTS INSIDE REFER SERVICING
TO QUALIFIED SERVICE PERSONNEL.
This lightning ash with arrowhead
symbol within an equilateral
triangle is intended to alert the
user to the presence of uninsulated
dangerous voltage within the
product’s enclosure that may be of
sucient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within
an equilateral triangle is
intended to alert the user to the
presence of important operating
and maintenance (servicing)
instructions in the literature
accompanying the product.
WARNING: TO PREVENT FIRE OR ELECTRIC SHOCK
HAZARD, DO NOT EXPOSE THIS PRODUCT TO RAIN
OR MOISTURE.
WARNING: Do not install this equipment in a
conned space such as a book case or similar unit.
CAUTION: Do not block any ventilation openings.
Install in accordance with the manufacturer’s
instructions.
Slots and openings in the cabinet are provided for
ventilation and to ensure reliable operation of the
product and to protect it from over heating. The
openings shall be never be blocked by placing
the product on a bed, sofa, rug or other similar
surface. This product shall not be placed in a built-
in installation such as a bookcase or rack unless
proper ventilation is provided or the manufacturer’s
instruction has been adhered to.
CAUTION: This product employs a Laser System.
To ensure proper use of this product, please read
this owner’s manual carefully and retain it for future
reference. Shall the unit require maintenance,
contact an authorized service center.
Use of controls, adjustments or the performance of
procedures other than those specied herein may
result in hazardous radiation exposure.
To prevent direct exposure to laser beam, do not try
to open the enclosure. Visible laser radiation when
open. DO NOT STARE INTO BEAM.
CAUTION concerning the Power Cord
Most appliances recommend they be placed upon
a dedicated circuit;
That is, a single outlet circuit which powers only
that appliance and has no additional outlets or
branch circuits. Check the specication page of this
owner’s manual to be certain. Do not overload wall
outlets. Overloaded wall outlets, loose or damaged
wall outlets, extension cords, frayed power cords, or
damaged or cracked wire insulation are dangerous.
Any of these conditions could result in electric
shock or re. Periodically examine the cord of your
appliance, and if its appearance indicates damage
or deterioration, unplug it, discontinue use of the
appliance, and have the cord replaced with an
exact replacement part by an authorized service
center. Protect the power cord from physical or
mechanical abuse, such as being twisted, kinked,
pinched, closed in a door, or walked upon. Pay
particular attention to plugs, wall outlets, and
the point where the cord exits the appliance. To
disconnect power from the mains, pull out the
mains cord plug. When installing the product,
ensure that the plug is easily accessible.
DM2520-FP_AIDNLLK__ENG.indd 2 2013-04-17  3:15:44

Getting Started 3
Getting Started
1
This device is equipped with a portable battery or
accumulator.
Safety way to remove the battery or the
battery from the equipment: Remove the
old battery or battery pack, follow the steps
in reverse order than the assembly. To prevent
contamination of the environment and bring on
possible threat to human and animal health, the
old battery or the battery put it in the appropriate
container at designated collection points. Do
not dispose of batteries or battery together with
other waste. It is recommended that you use
local, free reimbursement systems batteries and
accumulators. The battery shall not be exposed to
excessive heat such as sunshine, re or the like.
CAUTION: The apparatus shall not be exposed to
water (dripping or splashing) and no objects lled
with liquids, such as vases, shall be placed on the
apparatus.
You have to set the disc format option to [Mastered]
in order to make the discs compatible with the LG
players when formatting rewritable discs. When
setting the option to Live File System, you cannot
use it on LG players.
(Mastered/ Live File System : Disc format system for
Windows Vista)
Copyrights
It is forbidden by law to copy, broadcast, show,
broadcast via cable, play in public, or rent
copyrighted material without permission. This
product features the copy protection function
developed by Macrovision. Copy protection signals
are recorded on some discs. When recording and
playing the pictures of these discs picture noise
will appear. This product incorporates copyright
protection technology that is protected by U.S.
patents and other intellectual property rights. Use
of this copyright protection technology must be
authorized by Macrovision, and is intended for
home and other limited viewing uses only unless
otherwise authorized by Macrovision. Reverse
engineering or disassembly is prohibited.
CONSUMERS SHOULD NOTE THAT NOT ALL
HIGH DEFINITION TELEVISION SETS ARE FULLY
COMPATIBLE WITH THIS PRODUCT AND MAY CAUSE
ARTIFACTS TO BE DISPLAYED IN THE PICTURE. IN
CASE OF 525 OR 625 PROGRESSIVE SCAN PICTURE
PROBLEMS, IT IS RECOMMENDED THAT THE USER
SWITCH THE CONNECTION TO THE ‘STANDARD
DEFINITION’OUTPUT. IF THERE ARE QUESTIONS
REGARDING OUR TV SET COMPATIBILITY WITH THIS
MODEL 525p AND 625p UNIT, PLEASE CONTACT
OUR CUSTOMER SERVICE CENTER.
DM2520-FP_AIDNLLK__ENG.indd 3 2013-04-17  3:15:44

Table of Contents4
Table of Contents
1 Getting Started
2 Safety Information
6 Unique Features
6 Accessories
6 Introduction
6 – Playable Discs
6 – About the &Symbol Display
7 – Symbol Used in this Manual
7 – Regional Codes
7 Playable file Requirement
7 – Compatible USB Devices
7 – USB device requirement
8 – MP3/ WMA music file requirement
8 – Photo file requirement
8 – DivX file requirement
9 Remote Control
11 Front Panel
12 Rear Panel
2 Connecting
13 Connecting to speakers
13 – Attaching the speakers to the unit
13 Connections to Your TV
14 – Video Connection
14 – Component Video Connection
15 Optional Equipment Connection
15 – USB Connection
15 – PORT. IN Connection
16 – Playing the iPod
16 – Compatible iPod
17 – Playing the OSD iPod
3 System Setting
19 Adjust the Setup settings
19 – To display and exit the Setup Menu
20 – LANGUAGE
20 – DISPLAY
21 – AUDIO
21 – LOCK (Parental Control)
22 – OTHERS
DM2520-FP_AIDNLLK__ENG.indd 4 2013-04-17  3:15:44

Table of Contents 5
1
2
3
4
5
6
4 Operating
23 Basic Operations
23 – Disc/USB Operations
24 Other Operations
24 – Displaying Disc Information on-screen
24 – To display the DVD Menu
24 – To display the DVD title
24 – Selecting a subtitle language
24 – 1.5 times speed playback
25 – Starting play from selected
time
25 – Last Scene Memory
25 – Changing the character set to display
DivX® subtitle correctly- optional
25 – Creating your own program
26 – Viewing a PHOTO file
26 – Viewing a PHOTO file as a slide show
26 – Turning off the sound temporarily
26 – Screen Saver
26 – System Select - Optional
26 – Displaying file information
(ID3 TAG)
27 – Setting the Clock
27 – Using your player as an alarm clock
28 – Sleep Timer Setting
28 – Dimmer
28 – Auto Power Down
28 Radio Operations
28 – Listening to the radio
28 – Presetting the Radio Stations
28 – Deleting all the saved stations
29 – Improving poor FM reception
29 Sound adjustment
29 – Setting the surround mode
30 Advanced Operations
30 – Listening to music from your external
device
30 – Recording to USB
5 Troubleshooting
31 Troubleshooting
6 Appendix
32 Specifications
34 Maintenance
34 – Handling the Unit
34 – Notes on Discs
35 Trademarks and Licenses
36 Language Codes
37 Area Codes
DM2520-FP_AIDNLLK__ENG.indd 5 2013-04-17  3:15:44

Getting Started6
Getting Started
1
Unique Features
USB Direct Recording
Records music to your USB device.
Portable In
Listens to music from your portable device. (MP3,
Notebook, etc)
Accessories
Please check and identify the supplied accessories.
Remote Control (1) Battery (2)
Video cable (1)
Introduction
Playable Discs
This unit plays DVD±R/RW and CD-R/RW that
contains audio titles, DivX, MP3, WMA and/or
JPEG les. Some DVD±RW/DVD±R or CD-RW/
CD-R cannot be played on this unit due to the
recording quality or physical condition of the disc,
or the characteristics of the recording device and
authoring software.
DVD-VIDEO (8 cm / 12 cm disc)
Discs such as movies that can be
purchased or rented.
DVD±R (8 cm / 12 cm disc)
Video mode and nalized only.
DVD-RW (8 cm / 12 cm disc)
Video mode and nalized only.
DVD+R: Video mode only
Supports the double layer disc also.
DVD+RW (8 cm / 12 cm disc)
Video mode and nalized only.
Audio CD: Music CDs or CD-R/CD-
RW in music CD format that can be
purchased.
About the &Symbol Display
“&” may appear on your TV display during
operation and indicates that the function explained
in this owner’s manual is not available on that disc.
DM2520-FP_AIDNLLK__ENG.indd 6 2013-04-17  3:15:46

Getting Started 7
Getting Started
1
Symbol Used in this Manual
DVD and nalized DVD±R/RW r
DivX les y
MP3/WMA les, Audio CDs u
JPG les i
Regional Codes
This unit has a regional code printed on the rear of
the unit. This unit can play only DVD discs labelled
same as the rear of the unit or “ALL”.
yMost DVD discs have a globe with one or more
numbers in it clearly visible on the cover. This
number must match your unit’s regional code or
the disc cannot play.
yIf you try to play a DVD with a dierent regional
code from your unit, the message“Check
Regional Code”appears on the TV screen.
, Note
Indicates special notes and operating features.
>Caution
Indicates cautions for preventing possible damages
from abuse.
Playable file
Requirement
Compatible USB Devices
yMP3 Player : Flash type MP3 player.
yUSB Flash Drive : Devices that support USB2.0 or
USB1.1.
yThe USB function of this unit does not support
all USB devices.
USB device requirement
yDevices which require additional program
installation when you have connected it to a
computer, are not supported.
yDo not extract the USB device while in operation.
yFor a large capacity USB, it may take longer than
a few minute to be searched.
yTo prevent data loss, back up all data.
yIf you use a USB extension cable or USB hub, the
USB device is not recognized.
yUsing NTFS le system is not supported. (Only
FAT(16/ 32) le system is supported.)
yThis unit is not supported when the total
number of les is 1 000 or more.
yExternal HDD, Card readers, Locked devices, or
hard type USB devices are not supported.
yUSB port of the unit cannot be connected to PC.
The unit cannot be used as a storage device.
DM2520-FP_AIDNLLK__ENG.indd 7 2013-04-17  3:15:46

Getting Started8
Getting Started
1
MP3/ WMA music file
requirement
MP3/ WMA le compatibility with this unit is limited
as follows :
ySampling Frequency : 32 - 48 kHz (MP3), 32 - 48
kHz (WMA)
yBit rate : 32 - 320 kbps (MP3), 40 - 192 kbps
(WMA)
ymaximum les : Under 999
yFile extensions : “.mp3”/ “.wma”
yCD-ROM le format : ISO9660 LEVEL 1/ JOLIET
yWe recommend that you use “Easy-CD Creator”,
which creates an ISO 9660 le system.
Photo file requirement
Photo le compatibility with this unit is limited as
follows :
yMax pixel in width :
Normal : 5120 x 3840
Progressive JPEG : 2043 x1536
yMaximum les : Under 999
ySome discs may not operate due to a dierent
recording format or the condition of disc.
yFile extensions : “.jpg”
yCD-ROM le format : ISO9660 LEVEL 1/ JOLIET
DivX file requirement
DivX le compatibility with this unit is limited as
follows :
yAvailable resolution:
up to 800 x 600 (W x H) pixels.
yThe le name of the DivX subtitle should be
entered 45 characters or less.
yIf there is a code impossible to express in the
DivX le, it may be displayed as a “ _ “ mark on
the display.
yIf the video and audio structure of recorded
les are not interleaved, either video or audio is
output.
yPlayable DivX le : “.avi”, “.mpg”, “.mpeg”, “.divx”
yPlayable Subtitle format : SubRip (*.srt/ *.txt),
SAMI (*.smi), SubStation Alpha (*.ssa/ *.txt),
MicroDVD (*.sub/ *.txt), SubViewer 2.0 (*.sub/
*.txt)
yPlayable Codec format : “DIVX3.xx”, “DIVX4.xx”,
“DIVX5.xx”, “MP4V3”, “3IVX”.
yPlayable Audio format : “AC3”, “PCM”, “MP3”, “WMA”.
yFor Discs formatted in Live le system, you can
not use it on this unit.
yIf the name of movie le is dierent from that of
the subtitle le, during playback of a DivX le,
subtitle may not be display.
DM2520-FP_AIDNLLK__ENG.indd 8 2013-04-17  3:15:47

Getting Started 9
Getting Started
1
Remote
Control
Battery Installation
Remove the battery cover on
the rear of the Remote Control,
and insert one (size AAA)
battery with 4and 5matched
correctly.
• • • • • • a • • • • •
1(POWER): Switches the unit
ON or OFF.
B(OPEN/CLOSE): Opens or
closes the disc tray.
FUNCTION: Selects the function
and input source.
SLEEP: Sets the system to turn
o automatically at a specied
time.
TITLE: If the current DVD
title has a menu, the title
menu appears on the screen.
Otherwise, the disc menu may
appear.
SETUP: Accesses or removes
setup menu.
• • • • • • b • • • • •
DISPLAY: Accesses On-Screen
Display.
MENU:
- Accesses the menu on a DVD
disc.
- Chooses an item on IPOD
mode.
PRESET (w/s): Selects
programme of Radio.
TUNING (-/+): Tunes in the
desired radio station.
w/s/a/d: (up/down/left/
right) : Uses to navigate on-
screen displays.
bENTER: Acknowledges menu
selection.
x BACK: Moving backward in
the menu.
XREC: Recording.
• • • • • • c • • • • •
Z(STOP): Stops playback or
recording.
zMONO/STEREO:
- Starts playback.
- Selects Mono/ Stereo.
M:
- Pauses playback.
- Plays title Frame-by-Frame.
(DVD, DivX only)
C/V:
- Goes to next or previous
chapter/ track/ le.
- Adjusts the hours or minutes
to set alarm and clock.
c/v:Searches backward
or forward.
• • • • • • d • • • • •
REPEAT: Selects a play mode.
9SOUND EFFECT: Selects a
sound eect mode.
VOL +/- (Volume): Adjusts
volume of speaker or head
phone.
@MUTE: Mutes the sound.
CLEAR :
- Removes a number when
setting the password.
- Removes a track number on
the Program List.
- Removes language code when
setting the disc language.
• • • • • • e • • • • •
0 to 9 numerical buttons :
Selects numbered options in a
menu.
S-TITLE : During playback, press
S-TITLE repeatedly to select a
desired subtitle language.
PROG./MEMO. :
- Stores radio stations.
- Creates a playlist you want to
listen to.
DM2520-FP_AIDNLLK__ENG.indd 9 2013-04-17  3:15:47

Getting Started10
Getting Started
1
Remote
Control
• • • • • • f • • • • •
TV Control buttons :Controls
the TV. (LG TV only)
You can control the sound lev
el, input source, and power
switching of LG TVs as well. Hold
POWER (TV) and press PR/CH
(ws)button repeatedly until
the TV turns on or o.
?: This button is not available.
CLOCK : You can set and check
the time.
TIMER : You can turn USB, CD
play and TUNER reception on or
o at a desired time.
SET : (Refer to the page 27)
- Conrms the setting
DM2520-FP_AIDNLLK__ENG.indd 10 2013-04-17  3:15:47

Getting Started 11
Getting Started
1
1 2 3 4
8
67910
5
Front Panel
a 1(POWER)
Switches the unit ON or OFF.
bDisc tray
c iPod dock
dDisplay window
Shows the current state of the unit.
eR(Open/Close)
Opens or closes the disc tray.
f USB Port
Connects an USB device.
g PORT.IN
The player can be used to play the music from
many types of portable player.
h PHONES
Headphone jack.
i F(FUNCTION)
Selects the function or input source.
T(PLAY / PAUSE)
Starts playback and pauses.
I (STOP)
Stops playback or recording.
Y/U (Skip/Search):
-Goes to next or previous le/track.
- Searches backward or forward (Press and
hold)
- Adjusts the hours or minutes to set alarm and
clock.
TUN. (-/+)
Tunes in the desired radio station.
j VOL. (+/-)
Adjusts volume of speaker or head phone.
DM2520-FP_AIDNLLK__ENG.indd 11 2013-04-17  3:15:48

Getting Started12
Getting Started
1
Rear Panel
1234
aCOMPONENT VIDEO (Y PB PR) OUTPUT
(PROGRESSIVE SCAN)
Connects to a TV with Y PB PR inputs.
VIDEO OUT
Connects to a TV with video inputs.
bANTENNA (FM)
c Speaker terminal
Connects the speaker cables.
dPower cord
DM2520-FP_AIDNLLK__ENG.indd 12 2013-04-17  3:15:48

2 Connecting
Connecting 13
Connecting
2
Connecting to
speakers
Attaching the speakers to the
unit
Connect connector on the speaker cable to speaker
terminal.Each speaker connector is colored. Use
matching color connector to each speaker terminal.
When connecting connector to the speaker
terminal, push the connector until it is perfectly
linked.
Speaker Color Position
R Red right
L White left
The speakers contain magnet parts, so color
irregularity may occur on the TV screen or PC
monitor screen. Please use the speakers far
away from either TV screen or PC monitor.
>Caution
Connections to Your
TV
Make one of the following connections, depending
on the capabilities of your existing equipment.
yDepending on your TV and other
equipment you wish to connect, there are
various ways you could connect the unit.
Use only one of the connections described
in this manual.
yPlease refer to the manuals of your TV,
Stereo System or other devices as necessary
to make the best connections.
yMake sure the unit is connected directly
to the TV. Tune the TV to the correct video
input channel.
yDo not connect your unit via your VCR.
The image could be distorted by the copy
protection system.
, Note
DM2520-FP_AIDNLLK__ENG.indd 13 2013-04-17  3:15:49

Connecting14
Connecting
2
Video Connection
Connect the VIDEO OUT jack on the unit to the
video in jack on the TV using a video cable.
You can hear the sound through the system’s
speakers.
Yellow
Yellow
Component Video Connection
Connect the COMPONENT VIDEO OUT
(PROGRESSIVE SCAN) jacks on the unit to the
corresponding input jacks on the TV using
component cables.
You can hear the sound through the system’s
speakers.
Green
Blue
Red
Green
Blue
Red
If your TV accepts progressive format signals,
you must use this connection and set
[Progressive Scan] in [Display] setup to [On]
(See page 20).
, Note
DM2520-FP_AIDNLLK__ENG.indd 14 2013-04-17  3:15:50

Connecting 15
Connecting
2
Optional Equipment
Connection
USB Connection
Connect the USB port of USB Memory (or MP3
player, etc.) to the USB port on the front of the unit.
Removing the USB Device from the unit
1. Choose a different function/mode press
Zon the remote control or Ion the
unit twice in a row.
2. Remove the USB device from the unit.
, Note
PORT. IN Connection
Connect an output of portable device (MP3 or PMP
etc) to the PORT. IN connector.
DM2520-FP_AIDNLLK__ENG.indd 15 2013-04-17  3:15:51

Connecting16
Connecting
2
Playing the iPod
You can enjoy the sound with your iPod. For details
about iPod, refer to the iPod User Guide.
1. Connect the iPod firmly.
If your iPod/iPhone is connected or docked, it
will automatically turn on and recharging will
start.
So iPod/iPhone is charged even when the
player is power o.
2. Press F. on the unit or FUNCTION on the
remote control to select iPod function. You can
operate your iPod through an iPod’s display
by using the supplied remote control and also
control on your iPod.
To
Do this
ON UNIT ON REMOTE
Pauses or
restart T M
Skip Y/U C/V
Search Press and hold
Y/U
Press and hold
c/v
Move to the
previous
menu
-a/MENU
Move to the
desired item -w/s
Chooses a
item -d/ bENTER
Compatible iPod
yWe recommend installing the latest software
version.
yThe unit supports the models as follows:
iPod nano 1 G, 2 G, 3 G, 4 G, 5 G, 6 G/
iPod classic/iPod touch 1G, 2 G, 3 G, 4 G/
iPhone 3 G, 3GS, 4.
For some models, the unit may not operate
depending on the rmware version.
yDepending on your iPod’s software version, you
may not control your iPod from the player.
yIf this unit displays an error message, follow
the message. An error message“ERROR”.
- Your iPod is not connected firmly.
- This unit recognizes your iPod as an
unknown device.
- Your iPod is exceptionally low in power.
/The battery needs to be charged.
/
If you charge the battery while iPod
is extremely low in power, it may take
longer to be charged.
yiPod does not support recording function
when connected.
yDepending on your iPod’s software version,
it may not be possible to control your iPod
from this unit. We recommed installing the
latest software version.
yIf you use an application, make a call, or
send and receive SMS text message, etc. on
iPod touch or iPhone, disconnect it from
iPod dock of this unit and then use it.
yIf you have a problem with your iPod, please
visit www.apple.com/support/ipod.
, Note
DM2520-FP_AIDNLLK__ENG.indd 16 2013-04-17  3:15:51

Connecting 17
Connecting
2
Playing the OSD iPod
You can enjoy the media les with your iPod. For
details about iPod, refer to the iPod’s User Guide.
Preparation
yTo view iPod’s Videos and Photos on the TV
screen.
-Be sure to use the video connection through
the VIDEO OUT jack on the rear panel of this
unit. Select the appropriate video input mode
on the TV.
-Depending on the iPod, make sure that select
Videos > Video settings, and then set TV Out
to Ask or On from your iPod.
For details about Video Settings, refer to the
iPod User Guide.
-The viewing photos is available only if this unit
is in OSD iPod mode and you can view photos
only as a slide show. You have to start a slide
show on your iPod to view a photo on a TV.
For details about a slide show, refer to the iPod
User Guide.
yBefore connecting the iPod, turn this unit o and
reduce the volume of this unit to its minimum.
Enjoying OSD iPod on the screen
You can operate your iPod by controlling menu on
the screen.
1. Connect the iPod firmly.
2. Select [Music] or [Video] using a/d, and press
bENTER
3. Select a content using w/s/a/d, and press
bENTER to play.
4. Operate iPod.
Refer to basic operation section.
yIf the iPod’s OSD language is selected to
simple chinese, the power scroll function is
not operated correctly.
yThe controls on your iPod are not
operational in this mode.
, Note
Enjoying the OSD iPod mode
You can operate your iPod by using the supplied
remote control and controls on your iPod.
1. Connect the iPod firmly.
2. Press FUNCTION to select OSD iPod mode.
w/s/a/d Selects an option in the menu.
dPLAY, MONO/
STEREO,
bENTER
Starts playback the music or
video.
M
To pause while it is playing. To
resume playing, press dPLAY,
MONO/STEREO again.
c/vFast-forward or rewind a song
or video
C/ V Skip the playback forward or
backward .
REPEAT
To select a desired repeat
mode: Track (), All ( ),
O (No display).
DM2520-FP_AIDNLLK__ENG.indd 17 2013-04-17  3:15:52

Connecting18
Connecting
2
yAn error message “CHECK IPOD” or
“Connected iPod model is not supported.”
appears when:
-your iPod is not available for the function
to be operated.
yAn error message “CHECK IPOD” or “Please
update iPod’s software.” appears when:
-your iPod has an old software version.
> Update your iPod software to latest
version.
yIf this unit displays an error message, follow
the message. An error message“CHECK
IPOD” or “Please check your iPod.” appears
when:
-the communication between this unit
and your iPod is failed.
> Undock & re-dock your iPod in this unit.
-your iPod is not connected rmly.
-this unit recognizes your iPod as
unknown device.
-your iPod is exceptionally low on power.
> The battery needs to be charged.
> If you charge the battery while iPod
is extremely low in power, it maytake
longer to charge.
yYou may use the dock adapter which should
be supplied with your iPod to the dock for
the stable use of the iPod. If you need an
adapter, consult your iPod dealer.
yCompatibility with your iPod may vary
depending on the type of your iPod.
yiPod touch and iPhone have any dierence
in operation other than iPod. You may need
any additional control to use them with this
unit. (e.g. “slide to unlock”)
yIf you use an application, make a call, or
send and receive SMS text message, etc. on
iPod touch or iPhone, disconnect it from
iPod dock of this unit and then use it.
yDepending on your iPod’s software version,
it may not be possible to control your iPod
from this unit. We recommend installing the
latest software version.
yThe video quality depends on the video
sources on your iPod.
yIf you have a problem with your iPod, please
visit www.apple.com/support/ipod.
, Note
DM2520-FP_AIDNLLK__ENG.indd 18 2013-04-17  3:15:52

3 System Setting
System Setting 19
System Setting
3
Adjust the Setup
settings
By using the Setup menu, you can make various
adjustments to items such as picture and sound.
You can also set a language for the subtitles and
the Setup menu, among other things. For details on
each Setup menu item.
To display and exit the Setup
Menu
1. Select the DVD/CD or USB function by pressing
FUNCTION on the remote control or F on the
unit.
2. Press SETUP.
Displays the [SETUP] Menu.
3. Press SETUP or x BACK to exit in the [SETUP]
Menu.
About help menu for Setup
Menu Buttons Operation
w/s
Move w/s Moving to another
menu.
a
Prev. aMoving to
previous level.
d
Select d
Moving to next
level or selecting
menu.
x
Close x BACK To exit the [Setup]
menu.
b
Enter bENTER To conrm menu.
DM2520-FP_AIDNLLK__ENG.indd 19 2013-04-17  3:15:52

System Setting20
System Setting
3
LANGUAGE
OSD
Select a language for the Setup menu and then on
screen display.
Disc Audio/Disc Subtitle/Disc Menu
Select the language you prefer for the audio track
(disc audio), subtitles, and the disc menu.
[Original]
Refers to the original language in which the disc
was recorded.
[Other]
To select another language, press numeric
buttons and then bENTER to enter the
corresponding 4-digit number according to the
language code list on the page 36. If you enter
the wrong language code, press CLEAR.
[O (for Disc Subtitle)]
Turns o Subtitle.
DISPLAY
TV Aspect
Select which screen aspect to use based on the
shape of your TV screen.
[4:3]
Select when a standard 4:3 TV is connected.
[16:9]
Select when a 16:9 wide TV is connected.
Display Mode
The Display Mode setting works only when the TV
Aspect mode is set to 4:3.
[Letterbox]
This displays a wide screen picture with black
bands at the top and bottom of the screen.
[Panscan]
This lls the entire 4:3 screen, cropping the
picture as necessary.
Progressive Scan
(For Component Video connections)
Selects whether the COMPONENT VIDEO OUT
(PROGRESSIVE SCAN) jacks output progressive
signal. If your TV accepts progressive format signals,
you will enjoy accurate color reproduction and high
quality image by selecting [On]. If your TV does not
accept progressive format signals, select [O ].
If you set Progressive Scan to [On] in error, you
must reset the unit. First, remove the disc from the
unit. Next, press and hold Zfor about ve seconds.
The video output will be restored to the standard
setting, and a picture will be visible on your TV.
DM2520-FP_AIDNLLK__ENG.indd 20 2013-04-17  3:15:52
