LG CL65D Specification sheet

SIMPLE MANUAL
DVD MINI
HI-FI SYSTEM
Please read this manual carefully before operating your set and retain it for
future reference.
To view the instructions of advanced features, visit http://www.lg.com and
then download Owner’s Manual. Some of the content in this manual may differ
from your unit.
MODEL
CL65D
ENGLISH
www.lg.com
Copyright © 2019 LG Electronics Inc. All Rights Reserved.
1903_Rev01
MFL71181803
Additional Information
Specifications
Power Requirements Refer to the main label on
the unit.
Power Consumption Refer to the main label on
the unit.
Dimensions (W x H x D) Approx. 350.0 mm x
163.0 mm x 251.0 mm
Bus Power Supply (USB) 5 V 0500 mA
Amplier
(Total RMS output power) 950 W RMS
Design and specications are subject to change without
notice.
POWER: This unit operates on a mains supply of
200 - 240 V ~ 50 / 60 Hz.
Wiring: This unit is supplied with a BS 1363 approved
main plug. When replacing the fuse, always use a fuse of
the same rating approved to BS 1362. Never use this plug
with the fuse cover omitted. To obtain a replacement fuse
cover contact your dealer. If the type of plug supplied is
not suitable for the mains sockets in your home, then the
plug should be removed and a suitable type tted. Please
refer to the wiring instructions below:
Warning: A mains plug removed from the mains lead of
this unit must be destroyed. A mains plug with bared wires
is hazardous if inserted in a mains socket. Do not connect
either wire to the earth pin, marked with the letter E or
with the earth symbol 6or coloured green or green and
yellow. If any other plug is tted, use same rating of fuse in
the plug.
Important: The wires in this mains lead are coloured in
accordance with the following codes:
- BLUE: NEUTRAL, BROWN: LIVE: As the colours of the
wires in the mains lead of this unit may not correspond
with the coloured marking identifying the terminals in your
plug, proceed as follows: The wire which is coloured blue
must be connected to the terminal which is marked with
the letter N or coloured black. The wire which is coloured
brown must be connected to the terminal which is marked
with the letter L or coloured red.
Replacement of battery
(R03)
(R03)
Note
yDo not look directly at the light emitting part when the
LIGHTING is turned on.
yIf the illumination brightness is glaring, switch on the
room lights or turn off the LIGHTING of the unit.
Download the LG XBOOM App to your device.
(Android only)
For more information, download the online owner’s
manual. http://www.lg.com
LG Sound Sync (Wireless)
Controller App
CL65D-FB.DLKALLK_SIM_ENG.indd 2 2019-03-08  3:05:07

Front Panel
a
hijklmn
b c d e f
o
g
aUSB 1 Port
You can play sound files by connecting the USB device.
b1(Standby)
Turns the power on or off.
cDisplay window
d (Remote sensor)
e3TWIN
Connects two speakers for TWIN mode in WIRELESS
PARTY LINK.
fUSB 2 Port
You can play sound files by connecting the USB device.
g
VOLUME
-Adjust speaker volume.
- Adjusts microphone volume.
hMIC VOL (Microphone volume)
Selects microphone volume mode.
MIC (Microphone) ECHO
Selects ECHO mode.
VOICE CANCELLER
You can reduce the vocal tones during music playback
from various input sources.
VOCAL EFFECTS
Selects various vocal effects mode.
i
F (Function)
Selects the function and input source.
N(Play/Pause)
- Starts or pauses playback.
- Selects stereo/mono.
V(Skip/Scan)
- Skips forward.
- Scans for a section within a track/file/chapter.
- Selects the radio stations.
KEY CHANGER (L/l)
Changes the key to suit your vocal range.
j
Disc tray
k
USB REC / DEMO
- Records to USB.
- Stops Recording.
- In power off status, if you press USB REC / DEMO,
show DEMO mode.
Z(Stop)
Stops playback or cancels DELETE function.
C(Skip/Scan)
- Skips backward.
- Scans for a section within a track/file/chapter.
- Selects the radio stations.
B(Open/Close)
Opens and closes the disc tray.
AUTO DJ
Selects the AUTO DJ mode.
lLIGHTING
Selects the lighting mode.
SPECIAL EQ / BASS BLAST (or BASS BLAST+)
- Chooses special equalizer.
- Press and hold to select BASS (or BASS+) effect
directly.
SEARCH
Moves to folder or file in selection mode. (USB only)
OK
Selects a folder when searching a file.
m
MIC (Microphone) jack
n
AUX IN 1 jack
o
EQUALIZER / SEARCH & MULTI
- Chooses sound impressions.
- Searches a folder or a le. (USB only)
- Selects the lighting effects.
Rear Panel
ba c d e
100 100
gg
g f
aPower cord
bSPEAKERS terminals
cSPEAKER LIGHTING SYSTEM
Connect the speaker lighting cables.
dAUX IN 2 (L/R)
Connect an auxiliary device.
e
ANTENNA (FM)
f
HDMI OUT TO TV
Connect to TV.
gSERVICE ONLY
S/W download connector.
Speaker Connection
100100
100 100
TV Connection1
Home Menu2
Home menu appears on the TV screen. Enjoy various
functions on the player.
Home menu only appears on DVD/CD function.
HDMI Connection:
Connect with the unit and TV using HDMI .
aConnect the unit to the TV using HDMI cable.
bSet the input selector to HDMI on the TV.
cFollow the instructions on the TV screen using
remote control.
100 100
TV
