LG F1496TD2 User manual

DWG.
No.
TRIG.
DR COMPLETED
도면 DR 완료
완료일 :
LG 전자 (주)
LG Electronics Inc.
UNIT SCALE NS mm
REVIEWEDDESIGNED
RELATED DWG.
CHECKED APPROVED
이 현 식
15.06.05 15.06.05
양 진 호
15.06.05
김 영 수
MODELING I
T
L
E
T
APPROVED
승인자
PREPARED
시방자
DATE
년/월/일
REF. NO.
시방 번호
REV. NO.
기호
REVISION DESCRIPTION
변경 사항
1
2
3
4
RELEASING THIS DRAWING
WITHOUT PERMISSION LG
Electronics SHOULD BE
ACCUSED ACCORDING TO THE
LAWS AND COMPANY RULES.
이 도면은 LG전자의 자산으로 불법
유출시 관계법과 회사규정에 의해 처벌됨.
PDF
ILLUSTRATOR
MFL67645645
MANUAL,OWNER’S
DRUM-EXPORT 1/1
MFL67645645
<< 주기 >>
1. 재질, 인쇄방법, 인쇄도수, 외곽치수등은 작업표에 준한다.
2. 인쇄내용, 문자크기 및 형상, 선의 굵기 등은 설계에서 제시된 FILM에 준함.
3. 외곽치수는 절단후 치수임.
4. 양산전에 설계 한도를 득할 것.
<< NOTES >>
1. Material, printing and exterier size are refer to work tables.
2. Printing, text size and line are based on LG design film.
3. Exterier size on the drawing is cutting line.
4. Before product controlled by criteria sample.
WORK
가
BRAND
LG
45
F1496TD2(1~9)
F1296TD2(1~9)
FH496TD2(1~9)
FH496TD2(1~9)
나
MODEL
MFL67645645
다
P/NO.
MATERIAL AND PRINTING DESCRIPTION
1
PRINTING DEGREE
LG MODEL 명
A**QEUK
SUFFIX
ENGLISH
LANGUAGE
40
PAGE
Mega2 Refresh,
(LED, 550)-PJT,
NON STEAM, POST DD
WASHER
DATA 작업처 : 가람기획
REMARK
SEC.
5. 본 부품에 금지물질이 포함되지 않도록 하고, 상세내용은 LG(63)-A-5501-34를 만족할 것
5. The part should not contain prohibited substances(Pb,Cd,Hg,Cr+6,PBB,PBDE)and details
should comply with LG standard of LG(63)-A-5501-34
SNOW WHITE 80g OFFSET 인쇄
150 150
210
가
P/NO. 다
<FRONT> <BACK>
나
전 종 묵
15.06.05

OWNER’S MANUAL
WASHING MACHINE
MFL67645645 www.lg.com
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the washer is installed
correctly and safely. Leave these instructions near the washer
after installation for future reference.
F1496TD2(1~9)
F1296TD2(1~9)
W961436TC
W961446TC
W961236TC
W961246TC

Contents
2
Contents....................................2
Product Features......................3
Important safety instructions
Important safety instructions .................4
Basic safety precautions .......................5
Save these instructions.........................6
Specifications...........................7
Installation
Removing packing ................................8
Removing transit olts ..........................8
Installation place requirements .............9
Connecting water supply hose............11
Installation of drain hose .....................13
Leveling...............................................14
How to use washer
Operating washing machine ...............16
Care efore washing...........................17
Washing program ta le.......................18
Extra options .......................................19
Operating data ....................................20
Control panel.......................................21
Options................................................22
- Medic Rinse ......................................22
- Pre Wash ..........................................22
- Intensive ..........................................22
- Crease Care .....................................22
- Time Delay........................................22
- Spin...................................................23
- Rinse Hold .......................................23
- Temp. ...............................................23
Other functions....................................23
- Spin Only .........................................23
Child Lock ...........................................24
Beep On/Off ........................................24
Tu Clean ...........................................25
Door Lock & Detecting ........................25
Thank you for uying a LG Fully
Automatic Washing Machine.
Please read your owner’s manual
carefully, it provides instruction on safe
installation, use and maintenance.
Retain it for future reference.
Record the model and serial num er of
your washing machine.
Model No.
Serial No.
Date of Purchase
Adding detergent
Adding detergent and fa ric softener..26
Maintenance
The water inlet filter.............................28
The drain pump filter ...........................29
Dispenser drawer................................30
The washing drum ..............................31
Cleaning your washer .........................31
Cold conditions ...................................31
Troubleshooting guide
Diagnosing pro lems ..........................32
Error messages...................................34
Using Smart Diagnosis™....................35
Terms of Warranty.................36

Product Features
3
Inverter Direct Drive system
The advanced Brushless DC motor directly drives the drum without
elt and pulley.
More economical with Intelligent Wash system
Intelligent Wash System detects the size of load and water temperature,
and then determines the optimum water level and washing time to
minimize energy and water consumption.
Built-in heater
Internal heater automatically heats the water to the est temperature
on selected cycles.
Protection against creases
With the alternating rotation of the drum, creasing is minimized.
추가선택 예약
Low noise speed control system
By sensing the amount of load and alance, it evenly distri utes load
to minimize the spinning noise level.
Child Lock
The Child Lock prevents children from pressing any utton to change
the settings during operation.
6 Motion
Washer is a le to perform various drum actions or a com ination of
different actions depending on the wash program selected.
Com ined with a controlled spin speed and the a ility of the drum to
rotate oth left and right, the wash performance of the machine is greatly
improved, giving you perfect results every time.
uto Restart
Auto Restart allows the program to restart all y itself in case of power
failure. It does from the stage where it stopped.

4
Important safety instructions
For your safety, the information in this manual must e followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, injury to persons, or death.
READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION
BEFORE USE.
WA NING
You can e killed or seriously injured if you don’t follow instructions.
Your Safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and o ey all safety messages.
This is the safety alert sym ol.
This sym ol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert sym ol and either the word DANGER,
WARNING or CAUTION.
These words mean:
WA NING
You may e slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
CAUTION
You will e killed or seriously injured if you don’t immediately follow instructions.
DANGE

5
Important safety instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
• Before installation, check exterior
damages. If it has, do not install.
• Do not install or store the washer
where it will be exposed to the
weather.
• Do not tamper with controls.
• Do not repair or replace any part of
the washer or attempt any servicing
unless specifically recommended in
the user-maintenance instructions or
published user-repair instructions
that you understand and have the
skills to carry out.
• Keep the area underneath and around
your appliances free of combustible
materials such as lint, paper, rags,
chemicals, etc.
• The appliance is not intended for use
by young children or infirm persons
without supervision. Do not allow
children to play on, with, or inside this
or any other appliance.
• Keep small animals away from the
appliance.
• Do not leave the washer door open.
An open door could entice children to hang
on the door or crawl inside the washer.
• Never reach into washer while it is
moving. Wait until the drum has
completely stopped.
• The laundry process can reduce the flame
retardant of fa rics. To avoid such a
result, carefully follow the garment
manufacturer’s wash and care
instructions.
• Do not wash or dry articles that have
been cleaned in, washed in, soaked
in, or spotted with combustible or
explosive substances (such as wax,
oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.)
which may ignite or explode. Oil may
remain in the tu after a whole cycle resulting
in fire during drying.
So, do not load oiled clothes.
• Do not slam the washer door closed
or try to force the door open when
locked. This could result in damage to the
washer.
• When the machine runs high
temperature, the front door may be
very hot. Don’t touch it.
• To minimize the possibility of electric
shock, unplug this appliance from the
power supply or disconnect the
washer at the household distribution
panel by removing the fuse or
switching off the circuit breaker
before attempting any maintenance or
cleaning.
• When unplugging power cord, do not
pull out by grasping the cord.
Otherwise, the power cord may e damaged.
• Never attempt to operate this
appliance if it is damaged,
malfunctioning, partially
disassembled, or has missing or
broken parts, including a damaged
cord or plug.
■Basic safety precautions

6
Important safety instructions
■Basic safety precautions
■Save these instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
WA NING
Improper connection of the equipment-grounding conductor can result in electric shock.
Check with a qualified electrician or serviceman if you are in dou t as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance - if it does not fit the
outlet, have a proper outlet installed y a qualified electrician.
G OUNDING INST UCTIONS
This appliance must e grounded. In the event of malfunction or reakdown, grounding will
reduce the risk of electric shock y providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-grounding conductor and
grounding plug. The plug must e plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinance.
• Do not use an adapter this will defeat the grounding plug.
• If you don’t have the proper outlet, consult an electrician.
WA NING
• Before discarding an old machine
unplug it. ender the plug useless.
Cut off the cable directly behind the
appliance to prevent misuse.
• When a product was under water,
Please call service center. There is a
risk of electric shock and fire.
• Appliance connected to the water
mains using new hose-sets. Old hose-
sets should not be reused.
• To reduce the risk of personal injury,
adhere to all industry recommended
safety procedures including the use
of long sleeved gloves and safety
glasses. Failure to follow all of the safety
warnings in this manual could result in
property, personal injury or death.
• Do not push down the door
excessively, when washer door open.
This could topple over the washer.

7
Specifications
■ Accessories
(For detergent and
fabric softener)
Drawer
Power plug
Control panel
Drain pu p filter
Lower cover cap
• If the supply cord is da aged,
it ust be replaced by the
anufacturer or its service agents
or a si ilarly qualified person in
order to avoid a hazard.
Dru
Door
Drain plug
Adjustable feet
Lower cover
Inlet hose (1EA) ❈ Option : Hot / Cold (2EA) Spanner
■Na e : Front loading washing achine
■Power supply : 220 - 240 V~, 50 Hz
■Size : 600 (W) ✕550 (D) ✕850 (H)
■Weight : 59 kg
■Max.Watt : 2100 W
■Wash capacity : 8 kg
■Per issible water pressure : 100 - 1000 kPa (1.0 - 10.0 kgf / c
2
)
󳢮The appearance and specifications ay vary without notice to i prove the quality of the unit.

8
Installation
■Removing packing
1. Remove the card oard ox and
styrofoam packing.
2. Lift the washing machine and remove
the ase packing. This will require 2 or
more people or a lifting device.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hoses from the drum.
1. Unscrew the 4 olts with
the spanner supplied.
2. Take out the 4 olts along with the
ru er ungs y slightly twisting the
ung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 4 special olts are locked.
Before operating the washer, remove the olts along with the ru er ungs.
If they are not removed, it may cause heavy vi ration, noise and malfunction.
■Removing transit bolts
Transit bolt
WA NING
• Packaging material (e.g. Films, Styrofoam) can e dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
NOTE
• Keep the spanner provided for
future use.
NOTE
• Keep the transit olts for future use.
Spanner
Washer
Base Packing

9
Installation
Washer
approx.
2cm
• Level floor :
Allowa le slope under entire washer is 1˚.
• Power outlet :
Must e within 1.5 meters of either side of location
of washer. Do not overload the outlet with more
than one appliance.
• Additional Clearance :
For Wall, 10cm:rear / 2cm : right & left side
Do not place, store or use laundry products on top
of washer at any time.
They can damage the finish or controls.
■Installation place requirements
❿ Positioning
❿Location
• Install the washer on a flat hard floor.
• Make sure that air circulation around the washer is not impeded y carpets, rugs, etc.
• Never try to correct any unevenness in the floor with pieces of wood, card oard or similar
materials under the washer. Do not uild the machine into a closed cup oard.
• If it is impossi le to avoid positioning the washer next to a gas cooker or coal urning
stove,an insulating(85x60cm) covered with aluminum foil on the side facing the cooker or
stove,must e inserted etween the two appliance.
• The washer must not e installed in rooms where the temperature can drop elow 0°C.
• Please ensure that when the washer is installed, it is easily accessi le for a Service
Technician in the event of a reakdown.
• With the washer installed, adjust all four feet using the transit olt spanner provided
ensuring the appliance is sta le, and a clearance of approximately 20mm is left etween
the top of the washer and the underside of any work-top.
• This equipment is not designed for maritime use or for use in a mo ile installations such as
caravans, aircraft etc.
• It is also not intended for commercial or outdoor applications, or washing of items such as
foot ware, mats etc.

10
Installation
CAUTION
CAUTION concerning the Power cord
• Most appliances recommend they e placed upon a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or ranch
circuits. Check the specification page of this owner's manual to be certain.
• Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in an electric shock or fire.
• Periodically examine the cord of your appliance, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part y an authorized servicer.
• Protect the power cord from physical or mechanical abuse, such as eing twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the appliance.
If the appliance is supplied from a cord extension set or an electrical porta le outlet
device, The cord extension set on electrical porta le outlet device must e positioned
so that it is not su ject to splashing or ingress of moisture.
CAUTION
• The appliance is not intended for use y young children or infirm persons without
supervision.
• Young children should e supervised to ensure that they do not play with appliance.
• Do not use an extension cord or dou le adapter.
• If the supply cord is damaged, it must e replaced y the manufacturer or its service agents or
similarly qualified person in order to avoid a hazard.
• Always unplug the machine and turn off the water supply after use.
• Connect the machine to an earthed socket in accordance with current wiring regulations.
• The appliance must e positioned so that the plug is easily accessi le.
• Repairs to the washing machine must only e carried out y qualified personnel.
Repairs carried out y inexperienced persons may cause injury or serious malfunctioning.
Contact your local service center
• Do not install your washing machine in rooms where temperature elow freezing may occur.
Frozen hoses may urst under pressure. The relia ility of the electronic control unit may e
impaired at temperatures elow freezing point.
• If the appliance is delivered in the winter months and temperatures are elow freezing : Place
the washing machine at room temperature for a few hours efore putting it into operation.
❿ Electrical connection

11
Installation
1. Unscrew the adapter ring plate and the
4 adapter retaining screws.
2. Push the adapter onto the end of the
tap so that the ru er seal forms a
watertight connection. Tighten the
adapter ring plate and the 4 screws.
3. Push the water supply hose vertically
upwards so that the ru er packing
within the hose can adhere completely
to the tap and then tighten it y
screwing it to the right.
• Water supply pressure must e etween 100 - 1000 kPa (1.0 - 10.0 kgf / cm2).
• Do not strip or crossthread when connecting inlet hose to the valve.
• If the water supply pressure is more than 1000 kPa, a water pressure reduction device
should e installed.
• Periodically check the condition of the hose and replace the hose if necessary.
Type-A : Connecting Screw-type hose to tap with thread
• Screw the hose connector onto water
supply tap.
■Connecting water supply hose
❿ Step1 : Check rubber seal inlet hose
❿ Step2 : Connect hose to water tap
• Two ru er seals are supplied with the
water inlet hoses.
They are used for preventing water
leaks. Make sure the connections to
taps are sufficiently tight.
• Do not use pliers,multi grips or leverage
tools to tighten. Hand tighten only.
Use a cloth if necessary.
Upper
connector Ru er
packing
Plate
Water supply
hose
Fixing screw
Hose
connector
Ru er
seal
Type-B : Connecting Screw-type hose to tap without thread

12
Installation
1. Unscrew the adapter ring plate and
the 4 adapter retaining screws.
2. Remove the guide plate if the tap is
too large to fit the adapter.
3. Push the adapter onto the end of
the tap so that the ru er seal forms
a watertight connection.
Tighten the adapter ring plate and
the 4 screws.
4. Pull the connector latch plate down,
push the inlet hose onto the adapter,
and release the connector latch plate.
Make sure the adapter locks into place.
Please use the horizontal tap
Horizontal tap Extension tap Square tap
Ring plate
Guide plate
Latch plate
Type-C : Connecting one touch type hose to tap without thread
❿ Step3: Connect hose to washer
• Make sure that there are no kinks in the
hose and that they are not crushed.
❿ When your washer has two inlet
valves
• The Inlet hose which has red connector
is for the hot water tap.
• When using warm or hot washes, Energy
can e saved y connecting the hot
water hose to a hot water supply.
• After connecting inlet hose to water
tap, turn on the water tap to flush
out foreign su stances (dirt, sand or
sawdust) in the water lines. Let
water drain into a ucket, and
check the water temperature.
• After completing connection, if water leaks from the hose, repeat the same steps.
NOTE
NOTE

13
Installation of drain hose
• The drain hose should not e placed
higher than 100 cm a ove the floor.
Water in the washer does not drain or
drains slowly if a ove this height.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
• If the drain hose is too long, do not force
it ack into the washer.
This will cause a normal noise, possi le
water leakage and malfunction.
• When installing the drain hose to a sink,
secure it tightly with string.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
a out 100 cm
a out 145 cm
a out 105 cm
max. 100 cm
Hose
Retainer
Tie strap
Laundry tu
max. 100 cm
max. 100 cm
Installation

14
•Diagonal Check
When pushing down the edges of the
washing machine top plate diagonally,
the machine should not move up and down
at all (Please, check oth directions). If
machine rocks when pushing the machine
top plate diagonally, adjust the feet again.
2. If the floor is uneven, turn the adjusta le feet
as required. (do not insert pieces of wood
etc. under the feet)
Make sure that all four feet are sta le and
resting on the floor and then check that the
appliance is perfectly level. (use a spirit
level)
1. Leveling the washing machine properly
prevents excessive noise and vi ration.
Install the appliance on a solid and level
floor surface, prefera ly in a corner of the
room.
■Leveling
•Once the washer is level, tighten the lock
nuts up towards the ase of the washer.
All lock nuts must e tightened.
Raise Lower
Lock
Nut
Tighten all 4
locknuts securely
Installation
NOTE
• Tim er or suspended type flooring
may contri ute to excessive
vi ration and un alance.
NOTE
Do not install the machine on a raised platform.

15
❿ Concrete floors
❿ Wooden floors (Suspended floors)
• The installation surface must e clean, dry and level.
• Install washer on a flat hard floor.
❿ Tile floors (Slippery floors)
• Position each foot on the Tread Mate and level the machine to suit. (Cut Tread Mate into
70x70 mm sections and stick the pieces on to the dry tile where machine is to e placed.)
• Tread Mate is a self adhesive material used on ladders & steps that prevents slipping.
• Wooden floors are particularly suscepti le to vi ration.
• To help reduce vi ration we recommend you place ru er cups
under each foot under washer at least 15mm thick, secured to at
least 2 floor eams with screws.
• If possi le install the washer in one of the corners of the room, where the floor is more
sta le.
• Fit the ru er cups to reduce vi ration.
• You can o tain the ru er cups (p/no.4620ER4002B) from the LG spares dept.
• If vi ration persists with ru ers fitted. The flooring structure or rigidity may e inadequate
for proper operation.
Ru er Cup
Installation
NOTE
• Proper placement and leveling of the washer will ensure long, regular and relia le
operation.
• The washer must e 100% horizontal and stand firmly in position.
• It must not “Seesaw” across corners under load.
• The installation surface must e clean, free from floor wax and other lu ricant coatings.
• Do not let the feet of the washer get wet. If feet of the washer get wet, slipping may
occur.

16
How to use washer
Operating washing machine
2. Open the door and load laundry.
1. Sort Laundry.
(Refer to 17 page)
3. Press the Power utton.
4. Select a Program.
(Refer to 18 ~ 20 page)
5. Add detergent.
(Refer to 26 ~ 27 page)
6. Press the Start/Pause utton.
Select options at this time
(Refer to 22 ~ 25 page)
■Additional Program
■Temperature
■Spin Speed
■Other functions

17
■Care before washing
3.Caring before loading
Com ine large and small items in a load. Load large items first.
Large items should not e more than half the total wash load. Do
not wash single items.
This may cause an out-of- alance load. Add one or two similar
items.
• Check all pockets to make sure that they are empty. Items such
as nails, hair clip, matches, pens, coins and keys can damage
oth your washer and your clothes.
• Close zippers, hooks and strings to make sure that these items
don’t snag on other clothes.
• Pre treat dirt and stains y rushing a little detergent dissolved in
water onto stains like collars and cuffs to help lift dirt.
• Check the folds of the flexi le gasket (gray) and remove any
small articles.
• Check inside of the drum and remove any item from a previous
wash.
• Remove any clothing or items from the flexi le gasket to prevent
clothing and gasket damage.
2.Sorting
To get the est results, sort clothes into loads that can e
washed with the same wash cycle.
Water temperature and spin speed and different fa rics need to
e washed in different ways.
Always sort dark colors from pale colors and whites. Wash
separately as dye and lint transfer can occur causing
discolouration of white etc. If possi le, do not wash heavily
soiled items with lightly soiled one.
• Soil (Heavy, Normal, Light)
Separate clothes according to amount of soil.
• Color (White, Lights, Darks)
Separate white fa rics from colored fa rics.
• Lint (Lint producers, Collectors)
Wash lint producers and lint collectors separately.
1.Care Labels
Look for a care la el on your clothes.
This will tell you a out the fa ric content of your garment and
how it should e washed.
Wash temperature
Normal machine wash
Permanent press
Hand wash
Sort laundry y...
Soiling
Colour
Wash
temperature
Fa ric type
Delicate
Do not wash
How to use washer
NOTE
• Before the first wash, select a cycle (Cotton 60°C, add a half load of detergent) allow the unit to
wash without clothing. This will remove residues and water from the drum that may have een
left during manufacturing.

18
Washing program table
• Recommended courses according to the laundry type.
How to use washer
Cotton
Large
Easy Care
Mix
Provide optimized washing
performance with less energy
consumption.
This cycle is suita le for casual
shirts that do not need ironing after
washing.
Ena les various fa rics to e
washed simultaneously.
Program Description Fabric type Proper
Temp.
Maximum
Load
Cotton Provides etter performance y
com ining various drum motions. Color fast garments (shirts,
nightdresses, pajamas, etc) and
normally soiled cotton load
(underwear).
Polyamide, Acrylic, Polyester.
Various kind of fa rics except
special garments. (Silk/delicate,
sports wear, dark clothes, wool,
Duvet/Curtains).
Baby care Remove solid and protein stain and
provide etter rinse performance Lightly soiled a y wear
inse+Spin
Use for laundy that need rinsing
only or to add rinse-added fa ric
softener to laundry.
Normal fa rics which can e
washa le.
Skin Care Remove efficiently detergent
residue in clothes
Fa rics which will e in direct contact
with the skin, e.g. underwear,
nappies, towelling, ed linen, pillow
and mattress covers
Duvet This cycle is for large items such as
ed cover, pillows, sofa covers, etc.
Cotton edding except special
garments (delicates, wool, silk, etc.)
with filling: duvets, pillows, lankets,
sofa covers with light filling.
Sports
Wear
This cycle is suita le for sports
wear such as jogging clothes and
running wear.
Coolmax, Gore-tex, fleece and
Sympatex.
Delicate This cycle is for delicate clothes
such as underwear, louse, etc. Delicate, easily damaged laundry.
Ena le to wash wool fa rics.
(Please use detergent for
machinewasha le woolens).
Machine washa le woolens with
pure new wool only.
Quick 30
This cycle provides fast washing
time for small loads and lightly
soiled clothes.
Colored laundry which is lightly
soiled fast.
Intensive 60
Within 60mins provide etter
washing performance and
energy efficiency.
Cotton and mix fa rics.
(Special PROGRAM within 60 mins
for normally soiled laundry).
40°C
(Cold to 95°C)
60°C
(Cold to 60°C)
40°C
(Cold to 60°C)
40°C
(Cold to 40°C)
60°C
(95°C)
40°C
(Cold to 60°C)
_
40°C
(Cold to 40°C)
20°C
(Cold to 40°C)
40°C
(Cold to 40°C)
20°C
(Cold to 40°C)
60°C
(Cold to 60°C)
Rating
Less then
3.0 kg
Rating
Less then
2.0 kg
Less then
4.0 kg
Rating
Less then
6.0 kg
1 single
size
Wool

19
• Water Temperature: Select water temperature to suit wash cycles.
Always follow garment manufacture’s care label or instructions when washing.
How to use washer
NOTE
• Neutral detergent is recommended.
• The wool cycle features gentle tumbling and low-speed spin for garment care.
Extra options
: This option is automatically included in the cycle and can not be deleted.
: This option is automatically included in the cycle and can be deleted.
Time Delay Intensive
Program Medic Rinse Pre Wash Crease Care
Cotton
Cotton Large
Easy Care
Mix
Ba y Care
Skin Care
Duvet
Sports Wear
Delicate
Wool
Quick 30
Intensive 60
Rinse+Spin
