LG Signature SideKick UWD1CW User manual

OWNER'S MANUAL
WASHING MACHINE
Read this owner's manual thoroughly before operating the appliance and keep
it handy for reference at all times.
ENGLISH
UWD1CW
MFL71781391
Rev.00_061622
www.lg.com
Copyright © 2022 LG Electronics Inc. All Rights Reserved.

TABLE OF CONTENTS
2
3 IMPORTANT SAFETY
INSTRUCTIONS
3 READ ALL INSTRUCTIONS BEFORE USE
3 WARNING STATEMENTS
7 CAUTION STATEMENTS
8 PRODUCT OVERVIEW
8 Product Features
10 INSTALLATION
10 Before Installing
10 Choosing the Proper Location
11 Stacking Pedestal Washer and Front-Loading
Washer
13 Connecting the Water Inlet Hoses
15 Connecting the Drain Hose
16 Leveling the Washer
18 OPERATION
18 Before Use
19 Sorting Laundry & Loading the Washer
20 Adding Cleaning Products
22 Control Panel and Wash Cycles
25 Options
26 Settings
27 SMART FUNCTIONS
27 Using LG ThinQ Application
27 Smart DiagnosisTM Function
28 MAINTENANCE
28 Regular Cleaning
28 Periodic Maintenance
32 TROUBLESHOOTING
32 Before Calling for Service
39 LIMITED WARRANTY
39 USA

3IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
IMPORTANT SAFETY INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE USE
Safety Messages
Your safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance. Always read and
follow all safety messages.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance of injury,
and tell you what may happen if the instructions are not followed.
WARNING STATEMENTS
WARNING
• To reduce the risk of explosion, fire, death, electric shock, scalding or injury to persons when using this
product, follow basic precautions, including the following:
Installation
• Adhere to all industry recommended safety procedures including the use of long-sleeved gloves and
safety glasses.
• Never attempt to operate this appliance if it is damaged, malfunctioning, partially disassembled, or has
missing or broken parts, including a damaged cord or plug.
• Before use, the appliance must be properly installed as described in this manual.
• To reduce the risk of severe injury or death, follow all installation instructions.
• Refer to the INSTALLATION INSTRUCTIONS for detailed grounding procedures. Installation instructions
are packed with the appliance for the installer’s reference. If the appliance is moved to a new location,
have it checked and reinstalled by qualified service personnel.
• Moving or installation of the appliance requires two or more people.
• Do not install the appliance in humid spaces.
• Store and install the appliance where it will not be exposed to temperatures below freezing or exposed
to outdoor weather conditions.
• This appliance is not designed for maritime use or for mobile installations such as in RVs, trailers, or
aircraft.
• Keep packing materials out of the reach of children. Packaging material can be dangerous for children.
There is a risk of suffocation.
This is the safety alert symbol.
This symbol alerts you to potential hazards that can kill or injure you and others. All safety messages
will follow the safety alert symbol and either the word WARNING or CAUTION.
These words mean:
WARNING
You may be killed or seriously injured if you do not follow instructions.
CAUTION
You may be injured or cause damage to the product if you do not follow instructions.

4IMPORTANT SAFETY INSTRUCTIONS
• Destroy the carton, plastic bag, and other packing materials after the appliance is unpacked. Children
might use them for play. Cartons covered with rugs, bedspreads, or plastic sheets can become airtight
chambers.
• The appliance must be installed and electrically grounded by qualified service personnel in accordance
with local codes.
• When installing or moving the appliance, be careful not to pinch, crush, or damage the power cord.
• Connect to a properly rated, protected, and sized power circuit to avoid electrical overload.
• This appliance must be positioned near to an electrical power supply.
• Disconnect the power cord, house fuse or circuit breaker before installing or servicing the appliance.
• The power cord of this appliance is equipped with a 3-prong (grounding) plug which mates with a
standard 3-prong (grounding) wall outlet to minimize the possibility of electric shock from this appliance.
• Do not, under any circumstances, cut or remove the third (ground) prong from the power cord.
• Use new hoses when connecting the washer to the water supply. Do not reuse old hoses.
• If installing the pedestal washer with an LG front-loading washer and an LG gas dryer, and insufficient
outlets are available, an extension cord rated at no less than the branch circuit may be used.
• The pedestal washer is for installation and use only underneath an LG front-loading washer
manufactured after 2009. A special kit is also available to allow use under an LG top-load-matching dryer
manufactured in 2016 or later. Do not use the pedestal washer as a standalone unit, under an LG top-
loading washer, or under any other washer or dryer.
Operation
• Read all instructions before using the appliance and save these instructions.
• Use this appliance only for its intended purpose.
• If the product has been submerged in water, sitting in standing water, or waterlogged, do not come in
contact with the product and immediately contact an LG Electronics Customer Information Center for
instructions before resuming use.
• If you detect a strange sound, a chemical or burning smell, or smoke coming from the appliance, unplug
it immediately, and contact an LG Electronics Customer Information Center.
• Under certain conditions, hydrogen gas may be produced in a hot-water system that has not been used
for two weeks or more. HYDROGEN GAS IS EXPLOSIVE. If the hot-water system has not been used for
such a period, before using the appliance, turn on all hot water faucets and let the water flow from each
for several minutes. This will release any accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
• Do not reach into the washer if the tub or drum, agitator, or any interior parts are moving. Before
loading, unloading, or adding items, press Start/Pause and allow the tub or drum to coast to a complete
stop before reaching inside.
• This appliance is not intended for use by persons (including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning the use of the appliance by a person responsible for their safety.
• Do not allow children or pets to play on, in or with the appliance. Close supervision is necessary when the
appliance is used near children or pets.
• Keep laundry products out of children’s reach. To prevent injury to persons, observe all warnings on
product labels.
• Repair or immediately replace all power cords that have become frayed or otherwise damaged. Do not
use a cord that shows cracks or abrasion damage along its length or at either end.
• Never unplug the appliance by pulling on the power cord. Always grip the plug firmly and pull straight
out from the outlet.
• Do not use an extension cord or adapter with this appliance.
• Do not grasp the power cord or touch the appliance controls with wet hands.

5IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
• Do not modify or extend the power cord.
• If the electrical supply cord is damaged, it must only be replaced by the manufacturer or its service agent
or a similar qualified person in order to avoid a hazard.
• Do not put oily or greasy clothing, candles or flammable materials on top of the appliance.
• Keep the area underneath and around your appliances free of combustible materials (lint, paper, rags,
etc.), gasoline, chemicals and other flammable vapors and liquids.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
• Do not mix chlorine bleach with ammonia or acids such as vinegar. Follow package directions when
using laundry products. Incorrect usage can produce poisonous gas, resulting in serious injury or death.
• Never use harsh chemicals, abrasive cleaners, or solvents to clean the washer. They will damage the
finish.
• Do not wash laundry that has been previously cleaned in, washed in, soaked in, or spotted with gasoline,
dry-cleaning solvents, vegetable or cooking oil, or other flammable or explosive substances, as they give
off vapors that could ignite or explode.
• Do not add gasoline, dry cleaning solvents, or other flammable or explosive substances to the wash
water. These substances give off vapors that could ignite or explode.
• In the event of a gas leak (propane gas, LP gas, etc.), do not operate this or any other appliance. Open a
window or door to ventilate the area immediately.
• Fix the drain hose securely in place to avoid flooding.
• Always check the inside of the appliance for foreign objects.
• Do not allow water, bleach or other liquids to sit in the drum for extended periods. Doing so can corrode
the drum or cause mildew or odors.
• Do not wash rugs, mats, shoes, pet bedding, or any items other than clothes or sheets, in this washer.
• Do not tamper with controls and the stacking switch.
• Do not operate the pedestal washer with two or more pedestal washers stacked.
• Keep hands and foreign objects clear of the lid and latch area when closing the lid.
• To avoid breaking the lid glass, do not push too hard on the lid when closing.
• Do not open or close the lid by foot. Do not step on the pedestal washer.
Maintenance
• Do not repair or replace any part of the appliance. All repairs and servicing must be performed by
qualified service personnel unless specifically recommended in this owner’s manual. Use only authorized
factory parts.
• Disconnect this appliance from the power supply before cleaning and attempting any user maintenance.
Turning the controls to the OFF position does not disconnect this appliance from the power supply.
• Remove any dust or foreign matter from the power plug pins.
• Do not disassemble or repair the appliance by yourself.
• Remove the lid before the appliance is removed from service or discarded to avoid the danger of
children or small animals getting trapped inside.
Grounding Instructions
• Improper connection of the equipment-grounding conductor can result in a risk of electric shock. Check
with a qualified electrician or service personnel if you are in doubt whether the appliance is properly
grounded. Do not modify the plug provided with the appliance; if it will not fit the outlet, have a proper
outlet installed by a qualified electrician.

6IMPORTANT SAFETY INSTRUCTIONS
• The appliance must be grounded. In the event of a malfunction or breakdown, grounding will reduce the
risk of electric shock by providing a path of least resistance for electric current. The appliance is
equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must
be plugged into an appropriate outlet that is installed and grounded in accordance with all local codes
and ordinances.

7IMPORTANT SAFETY INSTRUCTIONS
ENGLISH
SAVE THESE INSTRUCTIONS
CAUTION STATEMENTS
CAUTION
• To reduce the risk of minor or moderate injury to persons, malfunction, or damage to the product or
property when using this product, follow basic precautions, including the following:
Installation
• Install the product on a firm and level floor.
Operation
• Do not place objects on top of the appliance.
• Turn off the water faucets and unplug the appliance if the appliance is to be left for an extended period
of time, such as during vacations.
• ALWAYS follow the fabric care instructions supplied by the garment manufacturer.
• Use fabric softeners or products to eliminate static only as recommended by the manufacturer.
• Do not combine laundry products for use in one load unless specified on the label.
• Do not touch draining water which may be hot.
• If the drain hose and the water inlet hose are frozen in winter, defrost them before using the appliance.
• Do not store or spill liquid detergents, cleaners, or bleaches (chlorine bleach, oxygen bleach) on the
appliance. Doing so may result in corrosion, discoloration or damage to the surface of the appliance.

8PRODUCT OVERVIEW
PRODUCT OVERVIEW
Product Features
The images in this guide may be different from the actual components and accessories, which are subject
to change by the manufacturer without prior notice for product improvement purposes.
WARNING
• For your safety and for extended product life, use only authorized components. The manufacturer is not
responsible for product malfunction, property damage or bodily injury caused by the use of separately
purchased unauthorized components, parts, or non-LG products.
Front View
aLint Filter
bDrum
cLid Open/Close Button
dLiquid Detergent Dispenser
eControl Panel
fLiquid Softener Dispenser
Rear View
aMain Washer Legs
bPower Plug
cLevelling Feet
dDrain Outlet
eCold Water Inlet
fHot Water Inlet
Accessories
Included Accessories
aConnecting Supply Hoses (2EA)
bWater Drain Hose
cWater Drain Hose Connector
dBand Clamps (3 EA)
eCable Ties (2 EA)
fFront Brackets (2 EA)
gBack Brackets (2 EA)
hWrench
iMachine Screws (37 EA)

9PRODUCT OVERVIEW
ENGLISH
jLong Sheet Metal Screws (18 EA)
kShort Sheet Metal Screws (5 EA)
lNon-skid Pads (2 EA)
mDetergent Dispenser
NOTE
• Contact LG Customer Service at 1-800-984-6306
if any accessories are missing or to purchase
accessories. For a list of LG front-loading
washers which are compatible with the pedestal
washer, visit the LG website at
www.LGSIGNATURE.com
Product Specifications
Model UWD1CW
Electrical Requirements 120 V~, 60 Hz
Min. / Max. Water Pressure 20 psi - 120 psi (138 kPa - 827 kPa)
Dimensions
(Width X Height X Depth) 23 5/8" x 14 3/8" x 26" (60.0 cm x 36.5 cm x 66.0 cm)
Maximum Depth with
Drawer Open 43 3/8" (110 cm)
Net Weight 96 lb (43.5 kg)
Max. Spin Speed 880 RPM

10 INSTALLATION
INSTALLATION
Before Installing
Tools Needed
aPliers
bFlat-Blade Screwdriver
cLevel
NOTE
• For instructions on stacking under a top-load-
matching dryer, see the instructions in the dryer
stacking kit which is available on LG.com.
Scan the QR code to link directly to an install
video tutorial.
Installation Overview
Please read the following installation instructions
first after purchasing this washer or transporting it
to another location.
aChoosing the Proper Location
bStacking Pedestal Washer and Front-Loading
Washer
cConnecting the Inlet Hoses
dConnecting the Drain Hose
eLeveling the Washer
WARNING
• Moving or installation of the appliance requires
two or more people. Failure to follow these
instructions may result in injury.
• Store and install the appliance where it will not
be exposed to temperatures below freezing or
exposed to outdoor weather conditions. Failure
to follow this warning can cause product or part
failure, serious injury, fire, electric shock, or
death.
• Properly ground the washer to conform with all
governing codes and ordinances. Failure to
follow this warning can cause serious injury, fire,
electric shock, or death.
• To ensure proper airflow, do not block the large
opening on the bottom of the washer with
carpeting or other materials.
• Do not remove the ground prong from the
power cord. Do not use an adapter or extension
cord. Plug into a grounded 3-prong outlet.
Failure to follow this warning can cause serious
injury, fire, electric shock, or death.
• Certain internal parts are intentionally not
grounded and may present a risk of electric
shock only during servicing. Service personnel-
Do not contact the following parts while the
appliance is energized: pump, valve, motor,
control board.
• The pedestal washer is for installation and use
only underneath an LG front-loading washer
manufactured after 2009. A special kit is also
available to allow use under an LG top-load-
matching dryer manufactured in 2016 or later.
Do not use the pedestal washer as a standalone
unit, under an LG top-loading washer, or under
any other washer or dryer.
NOTE
• The pedestal washer's width must match the
stacked LG appliance's width.
• The pedestal washer will not work as a
standalone unit.
• The pedestal washer must be stacked under an
LG brand appliance in order to operate properly.
Choosing the Proper
Location
Check the following requirements for the install
location before installing the washer.
• Allow for sufficient space between the walls and
the washer for installation.
• Make sure that the floor is clean, dry and free of
dust, dirt, water and oil so the leveling feet
cannot slide easily. Leveling feet that can move
or slide on the floor can contribute to excess
vibration and noise.

11INSTALLATION
ENGLISH
• If the floor has too much flex, reinforce it to
make it more rigid. If the floor is not solid, it may
cause severe vibration and noise.
Power Outlet
• The power outlet must be within 60 inches (1.5
m) of either side of the washer.
• Position the washer so that the outlet and plug
are easily accessible.
• Do not overload the outlet with more than one
appliance.
• The outlet must be grounded in accordance with
current electrical wiring codes and regulations.
• Use a time-delay fuse or circuit breaker.
• It is the personal responsibility and obligation of
the washer owner to have a proper outlet
installed by a qualified electrician.
Flooring
• To minimize noise and vibration, install the
washer on a level, solidly constructed floor
capable of supporting the washer without
flexing or bouncing.
• The washer must be installed on firm flooring to
minimize vibration during the spin cycle.
Concrete flooring is best, but a wood floor is
sufficient, provided it is built to FHA standards.
• The floor under the washer must not slope more
than 1 inch (2.5 cm) from front to back or side to
side.
• Installing on carpeting and soft tile surfaces is
not recommended.
• Never install the washer on a platform or weakly
supported structure.
Floor Installation
To ensure sufficient clearance for water inlet
hoses, drain hose and airflow, allow minimum
clearances of at least 1 inch (2.5 cm) at the sides
and 4 inches (10 cm) behind the washer. Be sure
to allow for wall, door, or floor moldings that may
increase the required clearances.
NOTE
• Refer to the instructions packaged with the
optional pedestal kit before stacking appliance
on pedestal.
• Do not use a drain pan with a pedestal or
pedestal washer installation as it can block the
drawer. Using a drain pan may result in
increased vibration and noise during operation.
Stacking Pedestal Washer
and Front-Loading Washer
Unpacking and Removing Packing
Materials
1 After removing the carton and shipping
material, lift the pedestal washer off the foam
base, keeping the 4 brackets on the foam
base.
• Make sure the plastic tub support comes off
with the base and is not stuck to the bottom
of the pedestal washer.
D’
D”
e
DW
c
H
aba
Dimensions and Clearances
W 23 5/8" (60 cm)
D 43 3/8" (110 cm)
D' 53 1/8" (135 cm)
D" 48 1/2" (123 cm)
H 49 1/4" (125 cm)
a2''(5cm)
b 4'' (10 cm)
c1/4''(0.5cm)
e1"(2.5cm)

12 INSTALLATION
2 Remove and save the foam block for future
use.
• If the pedestal washer must be moved in
the future, the foam block will help prevent
damage to the pedestal washer during
transportation.
• To prevent damage, do not remove the
foam block until the pedestal washer is at
the final location.
3 Turn the top cover about 180 degrees, cover
the opening in the top with the top cover and
install 4 short sheet metal screws.
4 Attach the two back brackets on the rear top
of the pedestal washer by inserting 4 machine
screws in each bracket.
Attaching Front Brackets on the
Front-Loading Washer
NOTE
• Do not use the front brackets provided with the
pedestal washer if the front-loading washer
already has front brackets installed or has a
stacking feature on the base.
1 Tilt and hold the front-loading washer.
2 Attach the two front brackets to the bottom of
the front-loading washer using 7 machine
screws in each bracket.
Stacking the Front-Loading Washer
on the Pedestal Washer
1 Place the pedestal washer in the final location
and adjust the leveling legs on the pedestal
washer to level it. Fully retract the legs of the
front-loading washer.
2 Place the front-loading washer on top of the
pedestal washer.
• Place the leveling feet of the front-loading
washer inside the bracket openings on the
pedestal washer, and align the bracket
screw holes.
3 Securely attach the two washers at the
corners using screws.
• Insert the screws at the sides of the washers
first, then insert the screws at the front and
back.

13INSTALLATION
ENGLISH
NOTE
• For best results, level the pedestal washer
before stacking the front-loading washer on top
of it, and insert the screws in the recommended
order.
4 Extend the feet of the front-loading washer
slightly until the two washers are snug up
against each other. To extend the adjustable
feet, turn them clockwise for a half turn with a
wrench. Then tighten the four lock nuts. All
lock nuts must be tightened.
NOTE
• The pedestal washer will not work as a stand-
alone unit.
Connecting the Water Inlet
Hoses
To avoid the risk of costly water damage, purchase
and install new water inlet hoses when installing
the washer.
WARNING
• Do not overtighten the hoses or cross-thread the
hose fittings. Overtightening or cross-threading
can damage the valves or couplings, resulting in
leaking and property damage.
• Do not reuse old hoses. Use only new hoses
when installing the washer. Old hoses could leak
or burst causing flooding and property damage.
Contact an LG Customer Information Center for
assistance in buying hoses.
NOTE
• Periodically check the hoses for cracks, leaks,
and wear, and replace the hoses every five years.
• Do not stretch the water hoses intentionally, and
make sure that they are not pinched, crushed or
kinked by other objects.
• Water supply pressure must be between 20 psi
and 120 psi (138 - 827 kPa). If the water supply
pressure is more than 120 psi, a pressure
reducing valve must be installed.
• Your hot water heater should be set to deliver
water at 120–135 °F (48–57 °C) to allow the
washer to properly control wash temperatures.
• Do not store or install the washer in a location
subject to freezing temperatures. Damage to the
water inlet hoses and internal mechanisms of
the washer can result. If the washer was
exposed to freezing temperatures prior to
installation, allow it to stand at room
temperature for several hours before use and
check for leaks prior to operation.
• Do not use flood-preventing hoses with auto
shut off devices. The devices can be tripped
during fill and prevent the washer from filling
properly.
Overview of Connections
† Required water inlet accessories

14 INSTALLATION
Front-Loading Washer and Pedestal
Washer with Dryer
aHot Water Tap
bCold Water Tap
cShort inlet hose (2 EA)†
dLong inlet hose (4 EA)†
Front-Loading Washer and Pedestal
Washer with Turbo Steam Dryer
aHot Water Tap
bCold Water Tap
cShort inlet hose (3 EA)†
dLong inlet hose (5 EA)†
eY-Connector (1 EA)†
How to Connect the Water Inlet
Hoses
1 Check the fittings and seals. Inspect the
threaded fitting on each hose and make sure
there is a rubber seal ain place in both ends
of each hose to prevent leaking.
2 Connect the water supply hoses.
• Connect the water inlet hoses to the hot
and cold water faucets tightly by hand and
then tighten another 2/3 turn with pliers.
• Connect the blue hose to the cold water
faucet and the red hose to the hot water
faucet.
3 Flush out the inlet hoses.
• After the hoses are connected, turn on the
water faucets and flush out any foreign
substances such as dirt, sand, or sawdust.
• Let the water drain into a bucket, and check
the water temperature to make sure you’ve
connected the hoses to the correct faucets.
4 Attach the inlet hoses to the back of the
washer.
• Attach the hot water inlet hose bto the hot
water inlet on the back of the washer.
Attach the cold water inlet hose cto the
cold water inlet on the back of the washer.
• Tighten the fittings securely. Turn on both
faucets all the way and check for leaks at
both ends of the hoses.

15INSTALLATION
ENGLISH
Connecting the Drain Hose
Overview of Connections
Connect the drain hose to either a standpipe or
laundry tub.
WARNING
• The drain hose should always be properly
secured. Failure to properly secure the drain
hose can result in flooding and property
damage.
NOTE
• The drain must be installed in accordance with
any applicable local codes and regulations.
• Make sure that the drain hose is not stretched,
pinched, crushed, or kinked.
• The end of the drain hose should be located a
minimum of 24 inches (61 cm) and a maximum
of 96 inches (244 cm) above the bottom of the
washer.
• For best results, locate the end of the drain hose
no higher than 66 inches (168 cm) above the
bottom of the washer. As the drain outlet is
raised beyond 66 inches (168 cm), the drain
function will be increasingly affected.
• Never create an airtight seal between the hose
and the drain with tape or other means. If no air
gap is present, water can be siphoned out of the
drum resulting in poor wash/rinse performance
or clothing damage.
Front-Loading Washer and Pedestal
Washer with Dryer
Front-Loading Washer and Pedestal
Washer with Hybrid Dryer
aBand Clamps
bTie Straps
Connecting the Drain Hose to the
Pedestal Washer
1 Insert the band clamp onto the drain hose
elbow. Pliers may be required to open the
clamp so it can be fitted to the rubber end of
the hose.
2 With the hose leading up from the elbow,
firmly insert the elbow onto the drain outlet
on the back of the pedestal washer.
3 Adjust the band clamp with pliers to keep the
hose securely in place and prevent leaking.

16 INSTALLATION
Connecting the Drain Connector
1 Insert the included band clamps on to the
ends of the two drain hoses.
2 Connect the drain hose of the front-loading
washer and the pedestal washer to the drain
connector.
3 Insert the end of the drain hose connector
into the laundry tub or standpipe. Use the
band clamps to keep it in place, if needed.
NOTE
• Depending on the installation environment, you
may have to purchase a separate drain hose
connector. The connector supplied will suit a
standard laundry tub-side standpipe.
Leveling the Washer
How to Level the Washer
1 Position the washer in its final location.
• Take special care not to pinch, strain, or
crush the water and drain hoses. If you have
a carpenter’s level a, you can use it to
check that the washer is level. The slope
beneath the washer should not exceed 1/2",
and all 4 leveling feet must rest firmly on
the floor.
2 Adjust the leveling feet on the pedestal
washer.
• Turn all 4 leveling feet in one direction to
raise the washer or the other direction to
lower it.
3 Check the level again.
• Push or rock the top edges of the washer
gently to make sure the washer does not
rock. If the washer rocks, readjust the
leveling feet.
4 Tighten the locknuts b
• Turn the locknuts counterclockwise and
tighten them when the washer is level.
Using Non-Skid Pads
If you install the washer on a slippery surface, it
may move because of excessive vibration.
Incorrect leveling may cause malfunction through
noise and vibration. If this occurs, install the non-
skid pads under the leveling feet and adjust the
level.
1 Clean the floor to attach the non-skid pads.
• Use a dry rag to remove and clean foreign
objects or moisture. If moisture remains,
the non-skid pads may slip.
2 Adjust the level after placing the washer in the
installation area.
3 Place the adhesive side cof the non-skid pad
on the floor.
• It is most effective to install the non-skid
pads under the front leveling feet. If it is
hard to place the pads under the front
1/2"

17INSTALLATION
ENGLISH
leveling feet, place them under the back
leveling feet.
aThis side up
bRemove backing
4 Recheck the washer’s levelness.
• Push or rock the top edges of the washer
gently to make sure the washer does not
rock. If the washer rocks, level the washer
again.

18 OPERATION
OPERATION
Before Use
WARNING
• To reduce the risk of fire, electric shock, or injury to persons, read the SAFETY INSTRUCTIONS before
operating this appliance.
Operation Overview
1 Sort laundry and load the washer.
• Sort laundry by fabric type, soil level, color
and load size as needed. Open the lid and
load items into the washer.
• For best results, do not use single-use
detergent packs, or gel or tablet detergents
in the pedestal washer.
CAUTION
• Do not load items higher than the top edge of
the tub. Failure to follow this caution can result
in leakage or damage to fabrics.
• Use the Bedding cycle in the full-size washer for
buoyant or nonabsorbent items such as pillows
or comforters. Refer to the owner's manual
included with the washing machine. Failure to
follow this caution can result in leakage.
2 Add cleaning products.
• Add the proper amount of HE (High-
Efficiency) detergent to the detergent
dispenser.
• If desired, add liquid fabric softener to the
softener dispenser.
• Do not place liquid or powdered detergent
packs, or gel or tablet detergents in the
dispenser.
3 Close the door and drawer.
• Press down gently on the lid handle until it
clicks and slide the drawer closed.
4 Turn on the front-loading washer.
• Press the Power button to turn on the
front-loading washer.
5 Select Pedestal Washer on the quick circle
display of the front-loading washer, then
choose the desired cycle.
• The default settings and options are
automatically selected. To change them,
press the Options button.
6 Begin the cycle.
•PresstheStart/Pause button to begin the
cycle. The lid locks, and the washer agitates
briefly without water to measure the weight
of the load.
•IftheStart/Pause button is not pressed
within a certain time, the washer shuts off
and all settings are lost.
7 End of cycle.
• When the cycle is finished, a melody
sounds. Immediately remove the clothing
from the washer to reduce wrinkling.

19OPERATION
ENGLISH
Sorting Laundry & Loading
the Washer
Grouping Similar Items
For the best washing results, and to reduce the
possibility of damage to clothing, sort clothing into
loads made up of similar items.
Mixing different fabric types and/or soil levels can
result in poor wash performance, color transfer,
discoloration, fabric damage or linting. Fabrics
should be sorted into groups as described below.
Colors
Sort articles by color. Wash dark clothes separately
from light colors or whites. Mixing dark clothes
with light clothes can result in dye transfer or
discoloration of the lighter clothes.
Soil Level
Wash heavily soiled clothing in the full-sized
washer. Washing lightly soiled clothing in the
same load with heavily soiled clothing could result
in poor wash performance for the lightly soiled
clothing. The pedestal washer is optimized for use
with lightly soiled and delicate items.
Fabric Type
Delicate articles should not be mixed with heavy or
sturdy fabric types. Washing heavy fabrics with
delicates can result in poor wash performance for
the heavy fabrics and possible damage to the
delicates.
Lint Type
Some fabrics attract and bind lint to them while
others give off lint in the laundry process. Avoid
mixing these lint collectors and lint producers in
the same load. Mixing these fabrics will result in
pilling and linting on the lint collectors. (For
example, lint collector - knit sweater; lint producer
- terry cloth towels.)
How to Sort Laundry
Fabric Care Labels
Many articles of clothing include a fabric care label. Using the chart below, adjust the cycle and option
selections to care for your clothing according to the manufacturer’s recommendations.
By Colors By Soil By Fabric By Lint
White Heavy Delicates Lint
Producer
Lights Normal Easy Care Lint
Collector
Darks Light Sturdy
Category Label Directions
Washing
Hand wash
Machine wash, Normal cycle
Perm Press/Wrinkle Resistant setting (which has a cool down or cold
spray before the slower spin)
Gentle/Delicate setting (slow agitation and/or reduced wash time)
Do not wash
Do not wring
Water Temperature
Hot
Warm
Cold/Cool
Bleach Symbols
Any bleach (when needed)
Only non-chlorine bleach (when needed)
Do not bleach

20 OPERATION
Loading the Washer
• Check and empty pockets. Paper clips, coins,
matches, etc. can damage clothing and the
washer.
• Close zippers and hooks, and tie drawstrings to
prevent snagging or tangling of clothes.
• Pretreat heavily stained areas for best results.
• Brush off heavy soil, dust, and hair from items
before washing. Excess dirt or sand can abrade
other fabrics and lead to poor wash
performance.
• For best performance, load clothes as shown.
• Do not overload the tub. Clothes should fit
loosely in the tub under the maximum fill line a.
Loading clothes over the fill line may result in
damage to clothing and the washer.
- Do not press down on items while stacking
them in the tub.
- Load clothes loosely, and do not overfill the
tub. Clothes need room to circulate in order to
get clean.
• The washer will not fill or operate with the lid
open.
CAUTION
• Do not wash rugs, mats, shoes, pet bedding, or
any items other than clothes or sheets, in this
washer.
• Press to open the lid. Do not force the lid of the
washing machine open. Doing so may damage
the machine.
Bulky Items
• Large, bulky items, such as a blanket, comforter,
or bedspread, should be washed individually in
the full-size washer.
Small Items
• Do not wash a single small item. Add enough
similar items to the load to prevent an out-of-
balance load.
Adding Cleaning Products
About Detergent Use
This washer is designed for use with only HE (High-
Efficiency) detergents.
• HE detergents produce fewer suds, dissolve
more efficiently to improve washing and rinsing
performance, and help to keep the interior of
the washer clean. Using detergent that is not HE
may cause oversudsing and unsatisfactory
performance which could result in error codes,
cycle failure, and washer damage.
• This machine requires very little detergent. For
proper wash performance, always use the
dispenser and measuring device provided with
the machine.
• The manual dispenser holds a maximum of 2
teaspoons (10 g / 10 cc) of HE detergent. Most
normal loads require only 1 teaspoon (5 g / 5 cc)
of detergent, or filling the dispenser to the
halfway line.
aMax load: 2 teaspoons (10 g / 10 cc)
bNormal loads: 1 teaspoon (5 g / 5 cc)
• For proper wash performance, always measure
detergent using the measuring device provided.
For an average load, use half of the
recommended maximum. Use less detergent for
soft water, light soil, or smaller loads.
• Never use more than the maximum amount of
detergent recommended. Using too much
detergent can lead to oversudsing, poor rinsing,
