OWNER’S MANUAL
WASHING MACHINE
WS2212XM
MFL67737690 Made in Korea
www.lg.com
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the washer is installed
correctly and safely. Leave these instructions near the washer
after installation for future reference.

Contents
2
Contents....................................2
Product Features......................3
Important safety instructions
Important safety instructions..................4
Basic safety precautions........................5
Save these instructions..........................6
Specifications...........................8
Installation
Removing packing .................................9
Removing transit olts ...........................9
Installation place requirements............10
Connecting water supply hose.............12
Installation of drain hose......................14
Leveling ...............................................15
How to use washer
Operating washing machine ................17
Care efore washing............................18
Washing program ta le .......................19
Extra options........................................20
Control panel .......................................21
Options ................................................22
- Wash .................................................22
- Rinse .................................................22
- Temp. ...............................................22
- Spin ...................................................22
Other functions ....................................22
- Spin Only...........................................22
Additional program...............................22
- Time Delay ........................................22
- Tur o Wash.......................................22
- Add Load ...........................................22
- Steam ................................................22
Dry .......................................................23
Child Lock............................................25
Tu Clean ............................................26
Door Lock ............................................26
Tag On
Before using the Tag On function ......27
Turning on the NFC function of the
smart phone........................................27
The Tag On guide ...............................28
Tag On self-diagnosis using LG Smart
Laundry & DW application ..................29
Thank you for uying a LG Fully
Automatic Washing Machine.
Please read your owner’s manual
carefully, it provides instruction on safe
installation, use and maintenance.
Retain it for future reference.
Record the model and serial num er of
your washing machine.
Model No.
Serial No.
Date of Purchase
Tag On Smart Diagnosis.....................30
Tag On cycles download using LG
Smart Laundry & DW application........31
Adding detergent
Adding detergent and fa ric softener ..33
Maintenance
The water inlet filter.............................35
The drain pump filter ...........................36
Dispenser drawer ................................37
The washing drum...............................38
Cleaning your washer .........................38
Cold conditions....................................38
Troubleshooting guide
Diagnosing pro lems ..........................39
Error messages...................................41
Using SMARTDIAGNOSIS™..............42
Terms of warranty ..................43

Product Features
3
Inverter Direct Drive system
The advanced Brushless DC motor directly drives the drum without
elt and pulley.
More economical with Intelligent Wash system
Intelligent Wash System detects the size of load and water temperature,
and then determines the optimum water level and washing time to
minimize energy and water consumption.
Built-in heater
Internal heater automatically heats the water to the est temperature
on selected cycles.
Auto Restart
Auto Restart allows the program to restart all y itself in case of power
failure. It does from the stage where it stopped.
6 Motion
Washer is a le to perform various drum actions or a com ination of
different actions depending on the wash program selected.
Com ined with a controlled spin speed and the a ility of the drum to
rotate oth left and right, the wash performance of the machine is greatly
improved, giving you perfect results every time.
Low noise speed control system
By sensing the amount of load and alance, it evenly distri utes load
to minimize the spinning noise level.
Child Loc
The Child Lock prevents children from pressing any utton to change
the settings during operation.

4
Important safety instructions
For your safety, the information in this manual must e followed to minimize the risk of fire or
explosion, electric shock, or to prevent property damage, injury to persons, or death.
READ ALL INSTRUCTIONS AND EXPLANATION OF THE INSTALLATION
BEFORE USE.
ARNING
You can e killed or seriously injured if you don’t follow instructions.
Your Safety and the safety of others are very important.
We have provided many important safety messages in this manual and on your appliance.
Always read and o ey all safety messages.
This is the safety alert sym ol.
This sym ol alerts you to potential hazards that can kill or hurt you and others.
All safety messages will follow the safety alert sym ol and either the word DANGER,
WARNING or CAUTION.
These words mean:
ARNING
You may e slightly injured or cause damage to the product if you do not follow instructions.
All safety messages will tell you what the potential hazard is, tell you how to reduce the chance
of injury, and tell you what can happen if the instructions are not followed.
CAUTION
You will e killed or seriously injured if you don’t immediately follow instructions.
DANGER

5
Important safety instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
ARNING
• Before installation, check exterior
damages. If it has, do not install.
• Do not install or store the washer
where it will be exposed to the
weather.
• Do not tamper with controls.
• Do not repair or replace any part of
the washer or attempt any servicing
unless specifically recommended in
the user-maintenance instructions or
published user-repair instructions
that you understand and have the
skills to carry out.
• Keep the area underneath and around
your appliances free of combustible
materials such as lint, paper, rags,
chemicals, etc.
• The appliance is not intended for use
by young children or infirm persons
without supervision. Do not allow
children to play on, with, or inside this
or any other appliance.
• Keep small animals away from the
appliance.
• Do not leave the washer door open.
An open door could entice children to hang
on the door or crawl inside the washer.
• Never reach into washer while it is
moving. ait until the drum has
completely stopped.
• The laundry process can reduce the flame
retardant of fa rics. To avoid such a
result, carefully follow the garment
manufacturer’s wash and care
instructions.
• Do not wash or dry articles that have
been cleaned in, washed in, soaked
in, or spotted with combustible or
explosive substances (such as wax,
oil, paint, gasoline, degreasers, dry-
cleaning solvents, kerosene, etc.)
which may ignite or explode. Oil may
remain in the tu after a whole cycle resulting
in fire during drying.
So, do not load oiled clothes.
• Do not slam the washer door closed
or try to force the door open when
locked. This could result in damage to the
washer.
• hen the machine runs high
temperature, the front door may be
very hot. Don’t touch it.
• To minimize the possibility of electric
shock, unplug this appliance from the
power supply or disconnect the
washer at the household distribution
panel by removing the fuse or
switching off the circuit breaker
before attempting any maintenance or
cleaning.
• hen unplugging power cord, do not
pull out by grasping the cord.
Otherwise, the power cord may e damaged.
• Never attempt to operate this
appliance if it is damaged,
malfunctioning, partially
disassembled, or has missing or
broken parts, including a damaged
cord or plug.
■Basic safety precautions

6
Important safety instructions
■Basic safety precautions
■Save these instructions
To reduce the risk of fire, electric shock, or injury to persons when using the washer, follow asic
precautions, including the following:
ARNING
Improper connection of the equipment-grounding conductor can result in electric shock.
Check with a qualified electrician or serviceman if you are in dou t as to whether the appliance is
properly grounded. Do not modify the plug provided with the appliance - if it does not fit the
outlet, have a proper outlet installed y a qualified electrician.
GROUNDING INSTRUCTIONS
This appliance must e grounded. In the event of malfunction or reakdown, grounding will
reduce the risk of electric shock y providing a path of least resistance for electric current.
This appliance is equipped with a cord having an equipment-grounding conductor and
grounding plug. The plug must e plugged into an appropriate outlet that is properly installed
and grounded in accordance with all local codes and ordinance.
• Do not use an adapter this will defeat the grounding plug.
• If you don’t have the proper outlet, consult an electrician.
ARNING
• Before discarding an old machine
unplug it. Render the plug useless.
Cut off the cable directly behind the
appliance to prevent misuse.
• hen a product was under water,
Please call service center. There is a
risk of electric shock and fire.
• Appliance connected to the water
mains using new hose-sets. Old hose-
sets should not be reused.
• To reduce the risk of personal injury,
adhere to all industry recommended
safety procedures including the use
of long sleeved gloves and safety
glasses. Failure to follow all of the safety
warnings in this manual could result in
property, personal injury or death.
• Do not push down the door
excessively, when washer door open.
This could topple over the washer.
✽ A precaution indicates that the hands shall not e inserted into running water-extracting tu .
✽ A precaution indicates that the washing machine shall not e installed at a humid place.
✽ A precaution on the washing machine whose lid can e opened during water extraction,
that if it takes 15 s or more for complete stop of water-extracting cham er tu such a
case should e understood as a trou le.

7
Important safety instructions
To minimize the risk of fire in a tumble dryer, the following should be observed:
• Items that have een spotted or soaked with vegeta le or cooking oil constitute a fire
hazard and should not e placed in a tum le dryer.
Oil-affected items can ignite spontaneously, especially when exposed to heat sources
Such as in a tum le dryer. The items ecome warm, causing an oxidation reaction in the
oil. Oxidation creates heat. If the heat cannot escape, the items can ecome hot enough to
catch fire. Piling, stacking or storing oil-affected items can prevent heat from escaping and
so create a fire hazard.
If it is unavoida le that fa rics that contain vegeta le or cooking oil or have een
contaminated y hair care products e placed in a tum le dryer they should first e
washed in hot water with extra detergent-this will reduce, ut not eliminate, the hazard.
Washed in hot water with extra detergent-this will reduce, ut not eliminate, the hazard.
The ‘cool down’ cycle of tum le dryers should e used to reduce the temperature of the
items. They should not e removed from the tum le dryer or piled or stacked while hot.
• Items that have een previously cleaned in, washed in, soaked in or spotted with
petrol/gasoline, dry-cleaning solvents or other flamma le or explosive su stances should
not e placed in a tum le dryer.
Highly flamma le su stances commonly used in domestic environments include acetone,
denatured alcohol, petrol/gasoline, kerosene, spot removers (some rands), turpentine,
waxes and was removers.
• Items containing foam ru er (also known as latex foam) or similarly testured ru er. like
materials should not e dried in a tum le dryer on a heat setting. Foam ru er materials
can, when heated, produce fire y spontaneous com ustion.
• Fa ric softeners or similar products should not e used in a tum le dryer to eliminate the
effects of static electricity unless this practice is specifically recommended y the
manufacturer of the fa ric softener or product.
• Undergarments that contain metal reinforcements should not e placed in a tum le dryer.
Damage to the tum le dryer can result if metal reinforcements come loose during drying.
When availa le a drying rack could e used for such items.
• Plastic articles such as shower caps or a ies waterproof napkin covers should not e
placed in a tum le dryer.
• Ru er- acked articles, clothes fitted with foam ru er pads, pillows, galoshes and
ru er-coated tennis shoes should not e placed in a tum le dryer.
ARNING

8
Specifications
Name : Front loading washing machine
Power supply : 220 V~, 60 Hz
Size : 750 mm(W) x 820 mm(D) x 1055 mm(H)
Weight : 108 kg
Wash capacity / Max.Watt : 22 kg (2200 W)
Dry capacity / Max.Watt : 13 kg (2150 W)
Spin speed : Extra Low / Low / Medium / High / Extra High
Water consumption : 150
l
Permissi le water pressure : 1.0 - 10 kgf / cm
2
(100 - 1000 kPa)
IP No.(Degree of Protection) : IPX4
❋The appearance and specifications may vary without notice to improve the quality of the unit.
 Accessories
Drain Plug Drain Pump Filter
Door
Adjusta le Feet
Lower cover cap
Drain Hose
Control Panel
Drum
Power Plug
• If the supply cord is damaged,
it must e replaced y the
manufacturer or its service agents
or a similarly qualified person in
order to avoid a hazard.
Drawer
(For detergent and
fa ric softener)
Transit olts
Inlet hose (1EA) Spanner

9
Installation
■Removing pac ing
1. Remove the card oard ox and
styrofoam packing.
2. Lift the washing machine and remove
the ase packing.
3. Remove the tape securing the power
supply cord and drain hose.
4. Remove the inlet hose from the drum.
1. Unscrew the 4 olts with
the spanner supplied.
2. Take out the 4 olts along with the
ru er ungs y slightly twisting the
ung.
3. Close the holes with the caps supplied.
To prevent internal damage during transport, the 4 special olts are locked.
Before operating the washer, remove the olts along with the ru er ungs.
If they are not removed, it may cause heavy vi ration, noise and malfunction.
■Removing transit bolts
ARNING
• Packaging material (e.g. Films, Styrofoam) can e dangerous for children.
There is a risk of suffocation ! Keep all packaging well away from children.
NOTE
• Keep the spanner provided for
future use.
NOTE
• Keep the transit olts for future use.
Spanner
Washer
Base Packing

10
• Level floor :
Allowa le slope under entire washer is 1˚.
• Power outlet :
Must e within 1.5 meters of either side of location of washer.
Do not overload the outlet with more than one appliance.
• Additional Clearance :
For Wall, 10 cm : rear / 2 cm : right & left side
Do not place or store laundry products on top of washer at any
times.
They can damage the finish or controls.
■Installation place requirements
❿ Positioning
❿ Location
• Install the washer on a flat hard floor.
• Make sure that air circulation around the washer is not impeded y carpets, rugs, etc.
• Never try to correct any unevenness in the floor with pieces of wood, card oard or similar materials
under the washer.
• If it is impossi le to avoid positioning the washer next to a gas cooker or coal urning stove, an
insulating covered with aluminum foil on the side facing the cooker or stove, must e inserted
etween the two appliance.
• The washer must not e installed in rooms where the temperature can drop elow 0°C.
• Please ensure that when the washer is installed, it is easily accessi le for the engineer in the event
of a reakdown.
• With the washer installed, adjust all four feet using the transit olt spanner provided ensuring the
appliance is sta le, and a clearance of approximately 20 mm is left etween the top of the washer
and the underside of any work-top.
• This equipment is not designed for maritime use or for use in a mo ile installations such as caravans,
aircraft etc.
• Do not use an extension cord or dou le adapter.
• If the supply cord is damaged, it must e replaced y the manufacturer or its service agents or
similarly qualified person in order to avoid a hazard.
• Always unplug the machine and turn off the water supply after use.
• Connect the machine to an earthed socket in accordance with current wiring regulations.
• The appliance must e positioned so that the plug is easily accessi le.
• Repairs to the washing machine must only e carried out y qualified personnel.
Repairs carried out y inexperienced persons may cause injury or serious malfunctioning. Contact
your local service center
• Do not install your washing machine in rooms where temperature elow freezing may occur. Frozen
hoses may urst under pressure. The relia ility of the electronic control unit may e impaired at
temperatures elow freezing point.
• If the appliance is delivered in the winter months and temperatures are elow freezing : Place the
washing machine at room temperature for a few hours efore putting it into operation.
❿ Electrical connection
Installation
Washer
approx.
2cm

11
Installation
CAUTION
CAUTION concerning the Power cord
• Most appliances recommend they e placed upon a dedicated circuit; that is, a single
outlet circuit which powers only that appliance and has no additional outlets or ranch
circuits. Check the specification page of this owner's manual to be certain.
• Do not overload wall outlets. Overloaded wall outlets, loose or damaged wall outlets,
extension cords, frayed power cords, or damaged or cracked wire insulation are
dangerous. Any of these conditions could result in an electric shock or fire.
• Periodically examine the cord of your appliance, and if its appearance indicates
damage or deterioration, unplug it, discontinue use of the appliance, and have the cord
replaced with an exact replacement part y an authorized servicer.
• Protect the power cord from physical or mechanical abuse, such as eing twisted,
kinked, pinched, closed in a door, or walked upon. Pay particular attention to plugs,
wall outlets, and the point where the cord exits the appliance.
If the appliance is supplied from a cord extension set or an electrical porta le outlet
device, The cord extension set on electrical porta le outlet device must e positioned
so that it is not su ject to splashing or ingress of moisture.
CAUTION
• The appliance is not intended for use y young children or infirm persons without
supervision.
• Young children should e supervised to ensure that they do not play with appliance.

12
1. Unscrew the adapter ring plate and the 4
adapter retaining screws.
2. Push the adapter onto the end of the tap
so that the ru er seal forms a watertight
connection. Tighten the adapter ring plate
and the 4 screws.
3. Push the water supply hose vertically
upwards so that the ru er packing within
the hose can adhere completely to the
tap and then tighten it y screwing it to
the right.
• Water supply pressure must e etween 100 kPa and 1000 kPa (1.0 - 10.0 kgf / cm
2
).
• Do not strip or crossthread when connecting inlet hose to the valve.
• If the water supply pressure is more than 1000 kPa, a decompression device should e installed.
• Periodically check the condition of the hose and replace the hose if necessary.
Type-A : Connecting Screw-type hose to tap with thread
• Screw the hose connector onto water
supply tap.
■Connecting water supply hose
❿ Step1 : Chec rubber seal inlet hose
❿ Step2 : Connect hose to water tap
• Two ru er seals are supplied with the
water inlet hoses.
They are used for preventing water leaks.
Make sure the connection to taps is
sufficiently tight.
Upper
connector Ru er
packing
Plate
Water supply
hose
Fixing screw
Hose
connector
Ru er
seal
Type-B : Connecting Screw-type hose to tap without thread
Installation

13
Installation
1. Unscrew the adapter ring plate and the
4 adapter retaining screws.
2. Remove the guide plate if the tap is too
large to fit the adapter.
3. Push the adapter onto the end of the
tap so that the ru er seal forms a
watertight connection.
Tighten the adapter ring plate and the 4
screws.
4. Pull the connector latch plate down,
push the inlet hose onto the adapter,
and release the connector latch plate.
Make sure the adapter locks into place.
Please use the horizontal tap
Horizontal tap Extension tap Square tap
Ring plate
Guide plate
Latch plate
Type-C : Connecting one touch type hose to tap without thread
❿ Step3: Connect hose to washer
• Make sure that there are no kinks in the
hose and that they are not crushed.
NOTE
• After completing connection, if water leaks from the hose, repeat the same steps.
Use the most conventional type of faucet for water supply. In case the faucet is square or
too ig, remove the spacing ring efore inserting the faucet into the adaptor.
NOTE
• After connecting inlet hose to water
tap, turn on the water tap to flush
out foreign su stances (dirt, sand or
sawdust) in the water lines. Let
water drain into a ucket, and
check the water temperature.

14
Installation of drain hose
• Please the drain hose should e placed
0 cm (min) ~ 50 cm (max) a ove the
floor.
Water in the washer does not drain, dry
or drains slowly.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
• If the drain hose is too long, do not force
ack into the washer.
This will cause a normal noise.
• Do not install the drain hose higher than
50cm a ove the floor.
• Securing the drain hose correctly will
protect the floor from damage due to
water leakage.
• When the drain hose install, please
avoid on the threshold or something
like that.
Min : 0 cm
Max : 50 cm
Installation

15
Installation
•Diagonal Check
When pushing down the edges of the
washing machine top plate diagonally, the
machine should not move up and down at
all (Please, check oth directions). If
machine rocks when pushing the machine
top plate diagonally, adjust the feet again.
2. If the floor is uneven, turn the adjusta le feet
as required. (do not insert pieces of wood
etc. under the feet)
Make sure that all four feet are sta le and
resting on the floor and then check that the
appliance is perfectly level. (use a spirit
level)
1. Leveling the washing machine properly
prevents excessive noise and vi ration.
Install the appliance on a solid and level
floor surface, prefera ly in a corner of the
room.
■Leveling
•Once the washer is level, tighten the lock
nuts up towards the ase of the washer.
All lock nuts must e tightened.
Raise Lower
Lock
Nut
Tighten all 4
locknuts securely
NOTE
• Tim er or suspended type flooring
may contri ute to excessive
vi ration and un alance.
NOTE
• If the washing machine is installed on a raised platform, it must e securely fastened in
order to eliminate the risk of falling off.

16
❿ Concrete floors
❿ Wooden floors (Suspended floors)
• The installation surface must e clean, dry and level.
• Install washer on a flat hard floor.
❿ Tile floors (Slippery floors)
• Position each foot on the Tread Mate and level the machine to suit. (Cut Tread Mate into
70x70 mm sections and stick the pieces on to the dry tile where machine is to e placed.)
• Tread Mate is a self adhesive material used on ladders & steps that prevents slipping.
•Wooden floors are particularly suscepti le to vi ration.
•To prevent vi ration we recommend you place ru er cups under
each foot under washer at least 15mm thick, secured to at least
2 floor eams with screws.
•If possi le install the washer in one of the corners of the room, where the floor is more sta le.
• Fit the ru er cups to reduce vi ration.
• You can o tain the ru er cups (p/no.4620ER4002B) from the LG spares dept.
Ru er Cup
NOTE
•Proper placement and leveling of the washer will ensure long, regular and relia le
operation.
•The washer must e 100% horizontal and stand firmly in position.
•It must not “Seesaw” across corners under load.
•The installation surface must e clean, free from floor wax and other lu ricant coatings.
•Do not let the feet of the washer get wet. If feet of the washer get wet, slipping may occur.
Installation

17
How to use washer
Operating washing machine
2. Open the door and load laundry.
1. Sort Laundry.
(Refer to 18 page)
3. Press the Power utton.
4. Select a Program. (Refer to 19~20 page)
5. Add detergent.
(Refer to 33~.34 page)
6. Press the Start/Pause utton.
Select options at this time
(Refer to 22~26 page)
■Options
■Other functions
■Additional Program
■Dry
■Child Lock
■Tu Clean
■Door Lock

18
■Care before washing
3.Caring before loading
Com ine large and small items in a load. Load large items first.
Large items should not e more than half the total wash load.
Do not wash single items.
This may cause an out-of- alance load. Add one or two similar
items.
• Check all pockets to make sure that they are empty. Items
such as nails, hair clip, matches, pens, coins and keys can
damage oth your washer and your clothes.
• Close zippers, hooks and strings to make sure that these
items don’t snag on other clothes.
• Pre treat dirt and stains y rushing a little detergent dissolved
in water onto stains like collars and cuffs to help lift dirt.
• Check the folds of the flexi le gasket (gray) and remove any
small articles.
• Check inside of the drum and remove any item from a
previous wash.
• Remove any clothing or items from the flexi le gasket to
prevent clothing and gasket damage.
2.Sorting
To get the est results, sort clothes into loads that can e
washed with the same wash cycle.
Water temperature and spin speed and different fa rics
need to e washed in different ways.
Always sort dark colors from pale colors and whites.
Wash separately as dye and lint transfer can occur
causing discolouration of white etc. If possi le, do not
wash heavily soiled items with lightly soiled one.
• Soil (Heavy, Normal, Light)
Separate clothes according to amount of soil.
• Color (White, Lights, Darks)
Separate white fa rics from colored fa rics.
• Lint (Lint producers, Collectors)
Wash lint producers and lint collectors separately.
1.Care Labels
Look for a care la el on your clothes.
This will tell you a out the fa ric content of your garment
and how it should e washed.
Wash temperature
Normal machine wash
Permanent press
Hand wash
Sort laundry y...
Soiling
Colour
Wash
temperature
Fa ric type
Delicate
Do not wash
NOTE
• Before the first wash, select a cycle (Cotton 60°C, add a half load of detergent) allow the unit to
wash without clothing. This will remove residues and water from the drum that may have een
left during manufacturing.
How to use washer

19
How to use washer
Washing program table
• Recommended courses according to the laundry type.
Program Description Fabric type Proper
Temp.
Maximum
Load
Cotton Provides better performance by
combining various drum motions.
This wash cycle helps to remove
heavily soiled on laundry through
high temperature.
Hygiene
40°C
Cold, 30°C,
60°C)
70°C
Rating
Less than
3.0 kg
4.0 kg
Color fast garments shirts,
nightdresses, pajamas, etc) and
normally soiled cotton load
underwear).
Duvet This cycle is for large items such as
bed cover, pillows, sofa covers, etc.
Cold
30°C, 40°C)
1 single
size
Cotton bedding except special
garments delicates, wool, silk,
etc.) with filling: duvets, pillows,
blankets, sofa covers with light
filling.
Heavily soiled underwear, work
clothes, diapers, etc
Enables to wash wool fabrics.
Please use detergent for
machinewashable woolens).
Rinse and Spin
Rinse+
Spin
ool
This cycle is suitable for sports wear such
as jogging clothes and running wear.
Coolmax, Gore-tex, fleece and
Sympatex.
Sports
ear
4.5 kg
3 suits
Removes wrinkles within 25 mins
with steam.
Cotton mixed, Polyester mixed
Dress shirts, blouses.
Steam
Cleaning 5 times
Less than
3.0 kg
This cycle provides fast drying time
for a shirt which is finished spin.
Single
Shirt Dry –after spinning a shirt Less than
3.0 kg
This cycle is for duvet to remove
smell and make be fluffy.
Bedding
Care –
–
Cotton bedding except special
garments delicates, wool, silk,
etc.) with filling: duvets, pillows,
blankets,sofa covers with light
filling.
1 single
size
Remove solid and protein stain and
provide better rinse performance Lightly soiled baby wear
Baby
care
–
Allergy
Care
Removes allergens such as house
mites, pollen, and cat fur.
Cotton, underwear, pillow
covers, bed sheets, baby wear.
40°C
Cold, 30°C)
40°C
Cold, 30°C)
This cycle provides fast washing time
for small loads and lightly soiled clothes.
Speed
ash
Lightly soiled clothing and small
loads
10.0 kg40°CSpeed Wash and Dry
Speed
ash+Dry
A small amount of laundry
which can be dried in an hour.
Rating
Machine washable woolens
with pure new wool only.
Color fast garments shirts,
nightdresses, pajamas, etc) and
normally soiled cotton load
underwear).
This cycle provides some washing
courses through download with NFC
fuction. Default : Cold Wash)
Download
Cycle
Cold
flexible) Rating
Lightly soiled clothing. Use this
cycle to save energy, by using
cold water while ensuring
proper washing.
* Some programs automatically include steam option, please turn off steam function, if you want
to use water temperature option.
