LI-TIAN LIGHTING LT-XT-06 User manual

Housing
Screw
Wire Connecting Caps
Screw
Wall Mounting Box
Door Gasket
Gasket
Plastic stopper
IMPORTANT
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Fixtures must be wired in accordance with the Naonal Electrical Code and all applicable local codes. Proper
grounding is required for safety. THIS PRODUCT MUST BE INSTALLED IN ACCORDANCE WITH THE APPLICABLE
INSTALLATION CODE BY A PERSON FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT
AND THE HAZARDS INVOLVED.
WARNING: Make certain power is OFF before installing or maintaining fixture. No user serviceable parts inside.
ON-OFF WIRING METHOD:
Universal voltage driver permits operaon
at 120V through 277V, 50 or 60HZ.
Connect the GROUND wire from fixture to supply ground.
Connect the white fixture lead to the (-)COMMON supply lead
Connect the black fixture lead to the (-)LINE supply lead
INSTALLATION PREVIEW
CM
USC
Intertek
BLACKLINE
WHITECOMMON
GREENGROUND
LIGHT
FIXTURE
LED Outdoor Security Light
LT-XT-06 Installaon Instrucons

1) Loosen the Surface Screw and open the Housing. Knock out appropriate Slots
when mounng to Juncon Box. (Not supplied)
2) Using the Leveling Bubble in the Wall Mounng Box and level it.
3) Feed supply wires through Juncon Box, Gasket and Wall Mounng Box. Check
the Gasket is fully sealed.
4) As the picture shows，fix the Housing on the Wall Mounng Box for
hands free wiring.
5) Wire the Power Wire on the Housing using provided wire connectors.
INSTALLATION STEPS
LED Outdoor Security Light
LT-XT-06 Installaon Instrucons
①
②

Note: These instrucons do not cover all details or variaons in equipment nor do they provide for every
possible situaon during installaon, operaon or maintenance.
IMPORTANT
Do not aempt to service the LED driver for reduce the risk of electric shock. The use of accessory equipment may
cause an unsafe condion. Do not use this product for other than intended use. Refer any servicing indicated by
these checks to a Qualified Service Personnel.
TROUBLESHOOTING
1. Check that the line voltage at fixture is correct. Refer to wiring direcons.
2. Be sure the fixture is grounded properly.
CLEANING
CAUTION: Be sure fixture temperature is co ol enough to touch. Do not clean or maintain while fixture is energized.
1. Lens should be washed in a soluon of warm water and any mild, non abrasive household detergent, rinsed with
clean water and wiped dry. Do not use chemicals to clean fixture.
2. Do not open fixture to clean the LED. Do not touch the LED.
6) Place the Wired Housing over the Wall Mounng Box, close and ghten the
Surface Screw and Plasc stopper. Check Door Gasket.
LED Outdoor Security Light
LT-XT-06 Installaon Instrucons
③
