Librestream Onsight 2500 User manual

QUICK START GUIDE /
REGULATORY AND SAFETY GUIDE
YOUR ONSIGHT 2500 PACKAGE
• Onsight 2500
• External Power Adapter
• International Plug Set
• Stylus Screwdriver (2)
• Battery
• I/O Cover
• Power or I/O sled
• Lens Cover
• Screen Protector Film
• Wrist Strap

Viewnder
Navigation pad
Tripod mount
LED indicators
Speaker
I/O connector
Recording on/off
Menu
Focus
Function
Power
Stylus
Battery door
(SD slot inside)
Streaming indicator
Headset connector
Still image Capture
Microphone
Lens
Illumination ring
Streaming on/off
Antenna
ONSIGHT 2500 MAP
BASIC CONTROLS NAVIGATION PAD
TURN POWER ON
Press and release the button to turn the Onsight device on.
ENTER STANDBY
Press and release the button quickly to go to Standby mode. The
Viewnder will turn off to conserve power but the Power LED remains on.
NOTE: Standby mode is automatic if the device is not used for a specied
period (default is 2 minutes).
TURN POWER OFF
Press and hold the button for 2 seconds to turn the Onsight device off.
BUTTON
LED INDICATORS
LED NAME INDICATOR
Power Green = On or Standby
Network Green = Local Network available
Off = Local Network unavailable
Battery Orange = Battery is charging
Off = Battery not charging
FUNCTION
Start or accept call
End a call
Volume up
Mic mute
Volume down
Front illumination light on/off
Pause/Play/Enter
Zoom / Manual Focus
SESSION STATUS
Press the menu button once to see the call status, battery
life remaining and wireless signal strength.
STREAM STATUS
Press the menu button twice to see zoom, stream quality
and video settings.
MAIN MENU
Press the menu button three times to access the main menu.
CONTACTS DIRECTORY
Press the button to display the Contacts window.
STATUS/MENU SELECTION
START AN ONSIGHT CALL
Display Contacts and use the stylus or navigation pad to select a
name from the list. Then press to start the call. You will hear
outgoing rings or a busy signal.
ANSWER AN INCOMING CALL
To answer a call, press .
TURN VIDEO STREAM ON OR OFF
When in a call, press the green button on top of the device to start
streaming video. Press it again to stop.
END A CALL
To end a call, press the button.
RECORD A CALL
To record, press the button. SD card must be installed for local recording.
1
2
3

2
3
4
1
SLED SELECTION
Install either the Power or I/O Sled
using the stylus screwdriver.
POWER SLED
Used to charge the battery.
I/O SLED
For Power, Ethernet, USB, S-video,
and Secondary Audio.
I/O COVER
To seal the I/O slot (mandatory for use
in hazardous locations – see Regulatory
and Safety Guide).
INSTALL THE SD CARD
A properly installed SD memory card is
necessary to record locally.
Open the battery compartment door (Fig.1)
using the stylus screwdriver. Remove the
battery (if installed).
Open the SD Gate by lifting the metal
edge. Do not pull on the Foam spacer.
Insert the SD card lining up the
metal contacts
Press the SD gate down rmly (Fig.2)
(Continue and follow the Install
the Battery instructions)
FIGURE 2
FIGURE 1
FIGURE 4 FIGURE 5
INSTALL THE BATTERY
IMPORTANT: Before using this device for the rst time
you must install and charge the battery. The device will
not operate on the external adapter alone.
Open the battery compartment door (Fig. 1)
using the stylus screwdriver. Align the gold
contact pins (Fig. 3) in the compartment with
the contact holes on the battery. (Fig. 4)
Slide the battery towards the compartment
door and push forward to create a solid
connection. (Fig. 5)
Close the battery compartment and tighten
the screw, do not over tighten. (Note that the
door will not close if the battery is not fully
inserted, and the device will not start if the
door is not properly closed.
Attach the Power Sled or I/O Sled and use
the external power adapter to charge the
battery until the orange battery LED turns off.
CONTACT PINS FIGURE 3
4
5
6
Before you setup your Onsight device, you need the following:
• Network Access Information
• Security Certicates (if required)
• Username
• Password
• Battery (charged and installed)
• SD card (necessary to record locally) SETUP WIZARD
If this is a rst time setup you may
need to congure Network, Security,
Date and Time parameters before
logging in. You will be prompted to
follow the Setup Wizard (Fig.1).
FIGURE 1
LOGIN
To login you will need your Username
and Password. (Fig.2)
If you do not want to enter your User-
name and Password every time you
can congure the auto login feature.
FIGURE 2
IMPORTANT: When you are touching the Viewnder screen, always
use the stylus. Do not use other objects, as this could damage the
Viewnder screen.
WHAT YOU NEED TO BEGIN
FIGURE 2

LIBRESTREAM ONSIGHT 2500
REGULATORY AND SAFETY GUIDE
SCOPE
This manual applies to the following models.
References to MCD2500 in this manual, apply to
all the listed models below.
• MCD2500
• MCD2500
GENERAL SAFETY INFORMATION
•Do not attempt to service or dismantle this
equipment. All repairs must be done by an
authorized Librestream service depot.
•Contact support for an authorized Librestream
service depot.
•Do not block or insert objects into any openings
in the equipment. Doing so may damage internal
components and may cause re or shock hazards.
•Carefully read the Librestream Quick Start Guide
and the User manual before operating the Onsight
2500, paying special attention to “Operating
Environment” in section 10.
•Use only a Librestream-supplied power adapter
with the equipment. Use of other adapters may
cause re or explosion hazards.
•Operate the external power adapter in a well
ventilated area. Do not cover the power adapter
with papers or any other items as the adapter may
become hot.
This symbol appears within this manual,
as well as the User Manual, Quick
Start Guide, and on the product label.
The symbol means “Attention, consult
ACCOMPANYING DOCUMENTS”. This is
a critical symbol and the user must refer
to the accompanying documents.
1.1. BATTERY
CAUTION! RISK OF EXPLOSION IF BATTERY IS
REPLACED BY AN INCORRECT TYPE OR INSTALLED
INCORRECTLY.
•Observe the correct polarity when changing the
lithium battery. Install battery according to the
manufacturer’s product documentation.
•Replace battery only with the same type as
recommended by the manufacturer
•Dispose of used batteries according to the
manufacturer’s product documentation and local
disposal requirements
•Use only Librestream-supplied batteries with the
Onsight 2500. Use of other types may increase
the risk of re or explosion or damage to the
equipment.
•Do not store the battery in places where metallic
objects may come in contact with the battery
terminals (e.g. in a pocket with keys, in a drawer
with paper clips, etc.). The resulting short-circuit
can cause extremely high temperatures that may
damage the battery and cause burns or res.
•Do not attempt to disassemble the battery. The
battery poses a burn hazard if handled improperly.
Immediately dispose of a damaged or leaking
battery.
•Do not store or leave the Onsight 2500 or Onsight
2500 battery near a heat source (e.g. radiator,
stove, heater, automobile dashboard, etc.) as the
battery may explode or ignite.
1.2. BATTERY DISPOSAL
The Onsight 2500 uses a Lithium-Ion battery and
must be disposed of properly:
•The battery must not be disposed with household
or ofce waste.
•Do not dispose of the battery in a re as the
battery may explode.
•Contact your local waste disposal agency for the
address of the nearest battery disposal location.
1.3. SAFETY NOTICE
The Onsight 2500 mobile streaming camera (Model
MCD2500) was evaluated to IEC 60950-1:2001,
EN60950-1:2001, UL 60950-1:2003 and CSA C22.2
60950-1:2003 standards and found to be in
compliance with the standard requirements.
U8 09 09 61052 011
1.4. SAFETY NOTICE (FOR USE IN CANADA ONLY)
The Onsight 2500 mobile streaming camera (Model#
Onsight 2500), complies with UL60601-1:1st edition
and CAN/CSA C22.2 601.1-M90 ONLY when used
in conjunction with the power supply model no.
UE24WCP-120150SPA.
U8 09 10 61052 012
1.5. AC ADAPTER INFORMATION
This device is supplied with an AC Adapter for
charging the battery and powering the Onsight 2500.
The following labels identify the safety approvals for
the AC Adapter.
For use only in Canada
1.6. FCC RF EXPOSURE NOTICE
For body worn operation, this product has been tested
and meets RF exposure guidelines when used with an
accessory that contains no metal. Use of other
accessories may not ensure compliance with RF
exposure guidelines. No metallic accessories should
be used with this device and multiple devices should
not be co-located at a distance of less than 20 cm.
Warning: Changes or modifications not expressly
approved by the manufacturer could void the user’s
authority to operate this equipment.
1.7. INDUSTRY CANADA RF NOTICE
Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a
type and maximum (or lesser) gain approved for the
transmitter by Industry Canada. To reduce potential
radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent
isotropically radiated power (e.i.r.p.) is not more than
that necessary for successful communication.
Conformément à la réglementation d’Industrie
Canada, le présent émetteur radio peut fonctionner
avec une antenne d’un type et d’un gain maximal
(ou inférieur) approuvé pour l’émetteur par Industrie
Canada. Dans le but de réduire les risques de
brouillage radioélectrique à l’intention des autres
utilisateurs, il faut choisir le type d’antenne et son
Declares under sole responsibility, that the
product(s) as originally delivered:
Product Name:
Onsight Mobile Device
Model Number(s):
MCD2500-XXX
complies with the essential requirements of the
following applicable European Directives and
carries the CE marking accordingly:
Low Voltage Directive (2006/95/EC)
EMC Directive (2004/108/EC)
R&TTE Directive (1999/5/EC)
ATEX Directive (94/9/EC)
*this directive applies to Onsight 2500Ex only
and conforms to the following harmonized
standard(s):
EMC & RADIO: EN 55011:2007 CLASS B
EN61000-6-2:2005, EN61000-3-2:2006,
EN61000-3-3:2008
ETSI EN 300 328 V1.8.1:2012
ETSI EN 301 893 V1.7.1:2012
ETSI EN 301 489-1 V1.8.1:2008
ETSI EN 301 489-17 V1.2.1:2009
EN 50360 :2001, EN 50371:2002, EN 50392:2004
SAFETY:
EN 60950-1+A1:2010, IEC 60950-1+A1:2009
ATEX:
EN 60079-0:2006, EN 60079-11: 2012
EN 60079-15:2010 (Onsight 2500Ex only)
Supplementary Information /
Information Supplémentaire:
France :
L’utilisation de cet équipement (avec 2.4GHz
Wireless LAN) est soumise a certaines restrictions:
Cet équipement peut être utilisé à l’intérieur d’un
bâtiment en utilisant toutes les fréquences entre
2400 a 2483.5MHz (Chaîne 1-13). Pour l’utilisation
en environnement extérieur, toutes fréquences entre
2454-2483.5MHz doivent être désactivés. Voyer les
instructions inclus pour conguration extérieure de
cet équipement. Pour les dernières restrictions, voir
http://www.art-telecom.fr
For 2.4 GHz Wireless LAN operation of this product,
certain restrictions apply: This equipment may
be used indoor for the entire 2400-2483.5 MHz
frequency band (channels 1-13). For outdoor use,
the frequency band from 2454-2483.5 MHz must be
disabled. Please see included instructions on how to
congure the product for outdoor use in France. For
the latest restrictions, see http://www.art-telecom.fr
Place of Issue: Winnipeg MB. Canada
Date of Issue: May 23rd, 2013
gain de sorte que la puissance isotrope rayonnée
équivalente (p.i.r.e.) ne dépasse pas l’intensité
nécessaire à l’établissement d’une communication
satisfaisante.
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to
the following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie
Canada applicables aux appareils radio exempts
de licence. L’exploitation est autorisée aux deux
conditions suivantes : (1) l’appareil ne doit pas
produire de brouillage, et (2) l’utilisateur de
l’appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d’en
compromettre le fonctionnement.
LICENSE EXEMPT RADIO APPARATUS / APPAREILS
RADIO EXEMPTS DE LICENCE
The device for operation in the band 5150-5250
MHz is only for indoor use ONLY, this restriction is
to reduce the potential for harmful interference to
co-channel mobile satellite systems.
Les dispositifs fonctionnant dans la bande
5150-5250 MHz sont réservés uniquement pour
une utilisation à l’intérieur an de réduire les risques
de brouillage préjudiciable aux systèmes de satellites
mobiles utilisant les mêmes canaux.
High-power radars are allocated as primary users
(i.e. priority users) of the bands 5250-5350 MHz
and 5650-5850 MHz and these radars could cause
interference and/or damage to LE-LAN devices.
Les utilisateurs de radars de haute puissance sont
désignés utilisateurs principaux (c.-à-d., qu’ils ont
la priorité) pour les bandes 5250-5350 MHz et
5650-5850 MHz et ces radars pourraient causer
du brouillage et/ou des dommages aux dispositifs
LAN-EL.
The maximum antenna gain permitted for devices
in the bands 5250-5350 MHz and 5470-5725 MHz
shall complies with the e.i.r.p. limit.
Le gain maximal d’antenne permis pour les dispositifs
utilisant les bandes 5250-5350 MHz et 5470-5725
MHz conforme à la limite de p.i.r.e.
The maximum antenna gain permitted for devices
in the band 5725-5825 MHz complies with the
e.i.r.p. limits specied for point-to point and non
point-to-point operation as appropriate.
Le gain maximal d’antenne permis (pour les
dispositifs utilisant la bande 5725-5825 MHz)
conforme à la limite de p.i.r.e. spéciée pour
l’exploitation point à point et non point à point,
selon le cas.
CE DECLARATION OF CONFORMITY
CE Declaration of Conformity (DOC) is shown on
following page. The signed copy of the Declaration of
conformity is available; please contact Librestream
customer support if you require a signed copy.
DECLARATION OF CONFORMITY
According to ISO/IEC 17050-1:2004
Manufacturer’s Name:
Librestream Technologies Inc.
Manufacturer’s Address:
895 Waverley St. Suite 110
Winnipeg, MB. R3T 5P4
Canada. T: 204-487-0612, F: 204-487-0914

•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment to an outlet on a
circuit different from that to which the receiver
is connected.
•Consult the dealer or an experienced radio/TV
technician for help.
Caution: Changes or modifications that are not
expressly approved by the manufacturer could void
the user’s authority to operate this equipment.
1.9. INDUSTRY CANADA CLASS B NOTICE
This Class B digital apparatus complies with
Canadian ICES-003. Cet appareil numérique de
classe B est conforme à la norme NMB-003
du Canada.
HAZARDOUS LOCATION OPERATION MCD2500
(ONSIGHT 2500EX)
All user documentation and the
instructions within this section must
be read and understood before:
• Charging the battery;
• Operating on AC power;
• Insertion or removal of the:
- Battery
- SD card
- Headset
- I/O Cover
- Power Sled
- I/O Sled
•Operation with any accessory or peripheral.
The user must review the following information
and warnings before using the MCD2500 within
a hazardous environment:
HAZARDOUS LOCATION RATINGS:
•Please refer to the product label to determine the
product’s part number and hazardous location
rating.
•MCD2500 devices with part number 200416-01
or 200155-01 have the following hazardous
location ratings:
Class I Division 2, Groups A, B, C, D T5
Class I, Zone 2 AEx nA IIC T5
Class I, Zone 2 Ex nL IIC T5
Ta =-10ºC to +40ºC
•MCD2500 devices with part number 200416-02,
or 200155-02 have the following hazardous
location ratings:
IECEx FME 08.0008X
Ex iC nA IIC T5 Gc
Ta =-10ºC to +40ºC
FM08ATEX0077X
II 3 G Ex iC nA IIC T5
Ta = -10ºC to +40ºC
•If you are uncertain about the product’s rating
please contact the customer support department
for more information.
HAZARDOUS LOCATION GENERAL INFORMATION:
The MCD2500 is constructed with a Lexan
polycarbonate housing and is overmolded with
a thermoplastic polyurethane elastomer.
Evaluation for material compatibility of the MCD2500
to actual end-user service conditions is strongly
recommended.
WARNINGS
•Carefully read all the provided manuals and docu-
mentation.
•Observe the rated operating and storage environ-
ment specications.
•The I/O cover must be installed on the MCD2500
prior to entering the potentially hazardous envi-
ronment and it must remain installed at all times
while in the potentially hazardous environment.
Ensure that the I/O connector is clean and free
of debris prior to installing the I/O cover. Every
FRANCE - OUTDOOR CONFIGURATION
1. Starting from the default Viewnder display, press
the Display button three times to display the Main
Menu.
2. From the Main menu, tap the Conguration menu
option to display a Conguration window.
3. From the Conguration window, select the
Radio Tab.
4. Select the Checkbox “France – Outdoor Use”, and
click Accept. If Accept is not clicked the settings
will not take affect.
IMMUNITY FOR INDUSTRIAL ENVIRONMENTS
This product has been tested and found to comply
with EN 61000-6-2: Immunity for Industrial Envi-
ronments. When in the presence of high levels of
radio-frequency electromagnetic elds, the user may
notice interference within the video content present
on the equipment. If this occurs, the user should
re-orient the equipment or increase the separation
between the equipment and the interfering source.
If an external audio headset is being used and is the
receiving source of audio interference, the user may
experience improved performance by using a headset
which has been tested and found to comply with
EN61000-6-2: Immunity for Industrial Environments.
Radiated Emissions
1.8. FCC CLASS B NOTICE
This product has been tested and found to comply
with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These rules are designed
to provide reasonable protection against harmful
interference in a residential installation. This product
generates, uses, and can radiate radio frequency
energy, and if not installed and used in accordance
with the instructions, may cause harmful interference
with radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If the equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
on and off, the user is encouraged to try to correct
the interference by one or more of the following
measures:
time before entering the hazardous environment,
ensure that the I/O cover is fastened securely to
the MCD2500 by hand-tightening the I/O cover’s
retention screws.
•The MCD2500 cannot be used with the AC
power adapter or I/O sled within the hazardous
environment.
•WARNING - DO NOT OPEN BATTERY DOOR WHEN
ENERGIZED. The battery door must be securely
closed within the hazardous environment.
•WARNING – DO NOT REMOVE OR INSTALL
BATTERY IN THE HAZARDOUS ENVIRONMENT.
•WARNING - DO NOT CHARGE IN HAZARDOUS
AREA. Battery charging is not permitted within the
hazardous environment.
•AC power supply operation is not permitted within
the hazardous environment.
•WARNING - DO NOT REMOVE OR INSTALL SD
CARD IN HAZARDOUS AREA. The SD Memory Card
Insertion and/or Removal are not permitted within
the hazardous environment.
•Inspect the camera before each use. The
MCD2500 can not be used within a hazardous
environment if any damage is visible or if the
device appears to not operate correctly.
•At no time is the user allowed to use a device that
has been disassembled or assembled by anyone
other then an authorized service representative.
•Do not attempt to service or dismantle this
equipment. Service and maintenance must be
performed by an authorized service center.
•Librestream is the only approved authorized
service center of MCD2500 devices for
hazardous locations. For service please contact:
Librestream
895 Waverley St., Suite 110
Winnipeg, MB Canada
R3T 5P4
Phone: [phone]
Email: suppor[email protected]
ACCESSORIES IN HAZARDOUS LOCATION:
•The MCD2500 has been approved to work within
the hazardous environment with an approved head-
set, SD ash memory card and the built in battery.
All other accessories or peripherals are not allowed
in hazardous locations.
•The MCD2500 device shall only be used with
the approved Librestream battery P/N 100229,
LiIon, 7.2V nominal, 2400mAH capacity, discharge
duration 2.4hrs@1A. WARNING – DO NOT REMOVE,
INSTALL OR CHARGE BATTERY IN THE HAZARDOUS
ENVIRONMENT.
•The MCD2500 device shall only be used with an
approved headset in hazardous locations. Please
contact customer support for information on an
approved headset for hazardous locations.
•The MCD2500 device shall only be used with
an approved SD ash memory card in hazardous
locations. Please contact support for information
on an approved SD Memory Card.
WARNING - DO NOT REMOVE OR INSTALL
SD CARD IN HAZARDOUS AREA.
ASSOCIATED HAZARDOUS LOCATION STANDARDS:
Canada: C22.2 No. 212 1987
C22.2 No. 1010.1 1992
C22.2 No. 60529 2005
C22.2 No 60079-15 2002
USA: CLASS 3600 1998
CLASS 3611 2004
CLASS 3810 2005
NEMA 60529 2004
ISA 60079-15 2003
ATEX: EN 60079-0 2009
EN 60079-11 2012
EN 60079-15 2010
IECEX IEC 60079-0 Ed 5.0
IEC 60079-11 Ed 6.0
IEC 60079-15 Ed 4.0
JAPAN
This unit must be connected to the public internet via
a router/switch that has JATE approval.
This device is restricted to indoor use only when the
wireless radio is operated in the frequency range
5150-5350 MHz.
TAIWAN
經型式認證合格之低功率射頻電機，非經許可，公
司、商號或使用者均不得擅自變更頻率、加大功率或
變更原設計之特性及功能。低功率射頻電機之使用不
得影響飛航安全及干擾合法通信；經發現有干擾現象
時，應立即停用，並改善至無干擾時方得繼續使用。
前項合法通信，指依電信法規定作業之無線電通信。
低功率射頻電機須忍受合法通信或工業、科學及醫療
用電波輻射性電機設備之干擾。
WEE INFORMATION
Information on collection and recycling arrangements
for Librestream customers can be found at www.
librestream.com/recycling
Librestream Onsight 2500 Regulatory and Safety
Guide
Doc #: 400258-00 Rev A
September 2015
Information in this document is subject to change
without notice. Reproduction in any manner
whatsoever without the written permission of
Librestream is strictly forbidden.
Copyright © 2006 – 2015
Librestream Technologies Incorporated.
All rights reserved.
Name of Librestream Products:
Onsight 1000
Onsight 2000
Onsight 2500
Copyright Notice:
Copyright 2004 – 2015 Librestream Technologies
Incorporated. All Rights Reserved.
Patents Notice:
United States Patent # 7,221,386, together with
additional patents pending in Canada, the United
States and other countries, all of which are in the
name of Librestream Technologies Inc.
Trademark Notice:
Librestream, the Librestream logo, Onsight, Onsight
Expert, Onsight Connect, Onsight Mobile, Onsight
Enterprise, Onsight Account Manager, and Onsight
Management Suite are either registered trademarks
or trademarks of Librestream Technologies
Incorporated in Canada, the United States and/or
other countries. All other trademarks are the
property of their respective owners.
LIBRESTREAM CONTACT INFORMATION
Website www.librestream.com
Head Office Librestream Technologies Inc.
Suite 110, 895 Waverley St.
Winnipeg, Manitoba
Canada, R3T 5P4
General Inquiries:
Email [email protected]
Phone [phone]
Fax [phone]
Support:
Email suppor[email protected]
Phone (NA) 1 800 849 5507
Phone (Int’l) + 1 204 487 0612

WEBSITE: www.librestream.com
HEAD OFFICE: Librestream Technologies Inc.
Suite 110, 895 Waverley St.
Winnipeg, Manitoba
Canada, R3T 5P4
GENERAL INQUIRIES:
Email [email protected]
Phone [phone]
Fax [phone]
SUPPORT:
Email suppor[email protected]
Phone (NA) 1 [phone]
Phone (Int’l) + 1 [phone]
Information in this document is subject to change without notice. Reproduction in any manner whatsoever
without the written permission of Librestream is strictly forbidden.
Copyright © 2006 – 2016. Librestream Technologies Incorporated. All rights reserved.
For detailed information on operating the Onsight device or Onsight Connect software, refer to the manuals at
www.librestream.com/support/knowbase.html
