lifelong HOME LL4DR500RG User manual

Terms and Conditions:
1.This warranty is void if:
a. The completely filled warranty card is not presented
at the time of servicing the product.
b. The product is not operated according to the
instructions given under the user manual.
C. Damages are caused by lightning, abnormal
voltage, water or other liquid intrusion, fire, flood,
accident, negligence or improper handling.
d. Product has been damaged due to installation,
repairs, alterations or modifications by unauthorized
service organizations or persons.
e. Product label specifying the model number, serial
number and production code has been removed
and altered.
f. Defects or parts requiring replacement due to
ordinary wear and tear, corrosion, rust or stains,
scratches, dents on the casing or paintwork of the
product.
g. Claims damaged and/or missing parts
(accessories) after 7 days from the original date of
goods received.
h. Defects or faults in product which have been used
for commercial/industrial purposes or which have
been rented/leased or have been otherwise subject
to non-household/non-domestic use.
2. Repairs or replacements will be carried out by
authorized service provider.
3. During the limited warranty period, Lifelong or its
authorized service provider will repair without charge
the defective unit inclusive of labor and parts and
restore the unit to its optimum working condition. All
defective parts used for the warranty repair should be
surrendered to Lifelong and/or its authorised servicer.
4. All expenses incurred in collecting the unit (s) or
part(s) thereof from authorised service provider as
will as any other expenses and incidentals will be
borne by the consumer.
5. Lifelong obligations are limited to the repair and
replacement of the defective product. Except as set
forth above, there are no other express or implied
warranty and all warrantied, conditions or other terms
implied by statute or common law (including any
warranty of satisfactory quality, merchantability or
fitness for a particular purpose) are excluded to the
fullest extent permitted by the lass.
6. Lifelong total liability for damages relating to or arising
out of the purchase or use of the product regardless of
the type or cause of such damage of the form of
characterization of the claim asserted (e.g. contract or
tort) shall not exceed the original purchase price paid
for the product.
7. However in no event shall Lifelong and Lifelong
authorized distributors be liable for any punitive, special
incidental, indirect or consequential losses or damages
whatsoever (including without limitation, damages for
the loss of revenue, business, profits, goodwill, or
contracts, business interruptions, loss of business
information or any other pecuniary loss.) Whether or
not Lifelong has been advised of the possibility of such
damages.These limitations shall apply not with
standing the failure of the essential purpose of any
limited warranty. This limited warranty does not affect
consumer's statutory rights under the law.
8. No carrier, dealer or employee is thereof authorized to
make modifications to this warranty and you should not
reply on any such representation. Lifelong reserves the
right to amend the terms and conditions if necessary.
Manufactured for & Marketed by :
Lifelong Online Retail Private Limited
For queries and complaints:
please contact: [email protected]
www.lifelongindiaonline.com
4 Door Refrigerator
Electronic
Temperature
Control
Smart
Mode
Fast
Freezing
Holiday
Mode
Adjustable
Leg
1 YEAR
COMPREHENSIVE WARRANTY
10 YEAR
COMPRESSOR WARRANTY

ABOUT THE PRODUCT
SAFETY PRECAUTIONS
Welcome to the Lifelong family
Dear Customer,
Congratulations on purchasing 4 Door refrigerator (500L) and a warm welcome to
the Lifelong family.
At Lifelong, we take pride in developing quality products for your home, health and
happiness. Through constant innovation in our products, we have been able to
develop a wide spectrum of products across Home, Kitchen, Grooming and
Wellness categories.
We strive to enrich the lives of the modern consumer every day. Keeping that in
mind, we have offered all our products at a fair and honest price.
We hope that the Refrigerator serves you and your family’s needs without any
hassles. Thanks again for becoming a part of the Lifelong family. Enjoy using the
product!
Warm Regards,
Team Lifelong
- Keep the plug clean and firmly connected. Don't damage the
power cord. Don't let the power cord be close to compressor to
avoid failure of insulation.
- If the power cord is damaged, do not use it. Please get it
replaced
- If there is gas leakage from compressor , close the gas valve
& open the window for ventilation. Spark may generate if the
power plug is immediately plugged out.
- Do not disassemble the refrigerator by yourself. Please
contact service center.
- Plug out the power cord for cleaning, repairing or in case it is
not used for a long time.
LIFELONG 4 Door Refrigerator allows you to maximize your storing space, with
large freezer & refrigerator compartments. The all
around cooling system, ensures that food in the refrigerator is cooled, evenly, in both
fridge and freezer compartments. The Inverter Compressor saves energy. While the
counter depth design, is seamless to blend well with your interiors, giving it a modern
look.
Please carefully read the following precautions before using.

INTRODUCTION
1 2
- If fluctuating electricty, abnormal sound, peculiar smell,
smoke and other abnormalities are found during usage,
immediately disconnect the power and stop using. Stop using
refrigerator & contact service center.
- Don't use the refrigerator outdoor or expose it to rain.
- Never store the flammable, explosive and corrosive
goods in the refrigerator. It isn't recommended to store the
drugs and chemicals which have strict temperature
requirement.
- If the light is blinking, don’t dismantle by yourself. Contact
service center.
- If the light is abnormal, don't dismantle by yourself. Contact
the after-sales service center.
- If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in
1. Overturning beam
2. Interior light and
temperature thermostat
3. Refrigerator
compartment frame
4. Crisper drawer
cover
5. Crisper drawer
6. Upper shelf of fridge
compartment
7. Component of cooling
room ventilating duct
8. Freezer compartment
rack bar
9. Freezer glass shelf
10. Lower drawer of
freezer compartment
11. Adjusting foot
This figure is only schematic diagram. The actual product may be upgraded
From time to time to improve the performance of the product.
- If the supply cord is damaged, it must be replaced by the manufacturer, its service
agent or similarly qualified persons in order to avoid a hazard.
- This appliance can be used by children aged from 8 years and above if they have
been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved.
- Children shall not play with the appliance, cleaning and user maintenance shall
not be made by children without supervision.
REFRIGERATOR COMPONENTS
Fridge Temp Freezer Temp

USAGE
34
USAGE AND PRECAUTIONS OF DIFFERENT
COMPARTMENTS
TIPS FOR USE OF REFRIGERATOR COMPARTMENT
- Please use 220-240V/50HZ single-phase AC power supply and use the independ-
ent socket equipped with 10A fuse. If the refrigerator is used in a place with high
humidity, connect the grounding wire and install the leakage protection switch. Don't
lengthen the power cord. The socket shall be equipped with grounding wire.
- Heavy items or container with water should not be placed on top of the refrigerator
to avoid falling caused by vibration due to opening of the door.
- Try not to install it in a place with high humidity because electricity leakage and rust
may occur due to humidity.
- The tilting angle of the refrigerator during moving shall not be higher than 45°.
- The refrigerator shall not be installed outdoor or exposed to rain.
- The refrigerator cannot be should not be installed near the gas, gasoline, alcohol,
paint and other flammables. Those dangerous goods cannot should not be stored
in the refrigerator.
- The floor shall be flat and firm. Otherwise, noise and vibration may generate. If the
floor isn't flat, properly adjust height of the adjusting foot.
- If any abnormal smoke or sound occurs, immediately plug out the power plug and
contact the after-sales service personnel.
- After cutting power supply, the refrigerator may operate normaly for at least 7 min.
This measure is used to protect refrigerator from damage. Therefore, after
disconnecting power supply, please wait at least 7 min to recover it.
- At the beginning, the refrigerator may have slight peculiar smell which will
disappear gradually.
To avoid contamination of food, please respect the following instructions:
- Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
- Regularly clean surfaces that can come in contact with food and drainage
systems.
PREPARATION
- Clean water tanks if they have not been used for 48 h; flush the water system
connected to a water supply if water has not been drawn for 5 days.
- Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or spills onto other food.
- Frozen-food compartments are suitable for storing pre-frozen food, storing or making
ice-cream and making ice cubes.
- If the refrigerating appliance is left empty for long periods, switch off, defrost, clean,
dry, and leave the door open to prevent smell developing within the appliance.
WARNING: When positioning the appliance, ensure the supply cord is not
trapped or damaged.
WARNING: Do not put multiple portable socket-outlets or portable power
supplies at the rear of the appliance.
WARNING: Food needs to be packed in bags before putting into the refrigerator,
and liquids need to be packed in bottles or containers.
1. The common refrigerating temperature of food stored in refrigerator is from 4°C to
8°C. In this environment, cooked meat can not be stored for more than 4 days, and
fruits and vegetables should not exceed one week at most.
2. The common temperature of the chilling room is from -1 to 4°C, and meat can not
be stored for more than 7 days.
3. Meat and seafood need to be packed in different containers and stored for not more
than 3 days.
4. Raw food and cooked food need to stored in different containers. In order to prevent
bacterial contamination, raw vegetables and fruits should not be exposed to raw meat
or fish. Vegetables and fruits should be wrapped by film and stored in the crisper.

5 6
REFRIGERATOR HANDLING
5. Before freezing, the food should be, wrapped tightly with fresh-keeping film, and
placed in different containers. The temperature of freezing room is - 18°C. Meat should
be kept in fresh and fish in deep-frozen. In order to make the taste fresh and delicious,
and to lock up the nutrition of food, the food in the refrigerator should not be stored for
more than three months.
- If the heavy bottles or foods are stored in the refrigerator, the left door and the right
door may not be aligned. In such situation, adjust the door position again after 2 or 3
days after placement of the refrigerator.
Turn left for refrigerator rising;
turn right for refrigerator downwards. It may
be easier to adjust with slotted screwdriver.
- Plug the power plug out for disconnecting the power. Fix the plug on the body by
adhesive tape to avoid it from dragging on the ground.
- All interiors shall be fixed by adhesive tape.
- Close the refrigerator door and fix by adhesive tape to avoid opening while moving.
- Move the refrigerator in tilted position. (The bottom is designed with the handle for
NOTICE
- Try to adjust the adjusting foots at bottom of refrigerator to the highest level (turn left)
to avoid the bottom touching grounding during pushing.
- During handling, the refrigerator tilts backward, so residual water in the evaporating
dish of machine chamber may spill out. Don't worry. Be careful to avoid dirtying and
slipping the floor.
- It is prohibited to lay down the refrigerator. The tilting angle during handling shall not
be more than 45°.
- After tilting handling, power on the refrigerator after at least 2 hours.
The refrigerator shall be placed in the ventilated place, avoid direct sunlight and keep
it away from heat source. In addition, heat dissipation is required during operation, so
a certain space shall be reserved around the refrigerator.
Enough space between
refrigeration and wall Avoid direct sunlight

7 8
- “Fridge” button: Press this button to adjust the temperature of refrigerating chamber
- “Freeze” button: Press this button to adjust the temperature of freezing chamber
- “Select” button: With each click (within 5 seconds), the corresponding function icon
flickers, and then switches among vacation or holiday mode - quick freezing- smart
or intelligent mode successively (press down is effective).
- No operation within 5 seconds will end the operation.
- The LED display turns bright when the door is open. Push the “Fridge” button. The
buzzer rings. Then the refrigerating room turns into the setting condition. The
temperature patterns starts to flash and the temperature of the refrigerating room
increases.
1. The temperature will vary as “01”—“02” —“03”—“04”—“05”—“06”—“07”—
“——”—“01”. When the temperature turns “07”, push the “Fridge” button , then the
refrigerator turns into the condition of pre-closing the refrigerating room and the LED
display turns “——” with flashing light.
- The LED display turns bright when the door is open. Push the 'freezer' button. The
buzzer rings. Then the freezing room turns into the setting condition. The tempera-
ture flashes and the temperature of the freezing room increases by 1. It will move
from “-15” to “-22”.
- The LED display turns bright when the door is open. Push the “Select” button.
Then it changes to setting functions.
- Entering the holiday or vacation mode: Push the “Select” button. When the
holiday or vacation pattern turns bright, it is in the holiday or vacation mode.
- Exiting the holiday mode: Push the “Select” button. When the holiday pattern
disappears, it is exiting the holiday mode.
- Note: In holiday or vacation mode, the temperature of cooling room is fixed at
“-17°C”, and the temperature cannot not be regulated.
- Entering the quick freezing mode: Push the “Select” button. When the quick
freezing pattern turns bright, it is in the quick freezing mode.
- Exiting the quick freezing mode: Push the “Select” button. When the quick
freezing pattern disappears, it is exiting the quick freezing mode.
- Note: In quick freezing mode, the temperature of freezer room is fixed at low
temperature, and it cannot be regulated. It will exit the quick freezing mode within 24
hours after finishing freezing.
- Entering the smart mode: Push the “Select” button. When the smart
pattern turns bright, it is in the smart mode.
- Exiting the smart mode: Push the “Select” button. When the smart pattern
disappears, it is exiting the smart mode.
- The below picture is a schematic diagram of an electronic display.
Warning: The temperature will be set successfully and the flash will disappear if
setting is not done in 5 seconds.
Button instruction
The setting of the freezing room
The setting of the functions
BUTTON INSTRUCTIONS
OPERATIONAL GUIDANCE OF DISPLAY
Warning: The temperature will be set successfully and the flash will disappear if
setting is not done in 5 seconds.
Flashi ng 5 times
Flash ing 5 times
Disappe ar
Disappe ar
Disappe ar
Fridge Temperature
Display
Freezer Temperature
Display
Function Mode
Area Display
Fridge Button Select ButtonFreezer Button

9 10
- When the door of refrigerating chamber opens, the LED light turns on.
- When the lighting is damaged, please remove the lampshade first and then replace
the LED lighting.
- The specific operations are shown in the following diagram:
- The refrigerator compartment is mainly for storage of foods which are stored for
short term.
- According to ambient temperature and setting temperature, temperature in the
refrigerator compartment shall be maintained within 1°C~ 7°C . It cannot keep the
food fresh in long term, but is only used for storage in short term.
- The hot food shall not be placed in the refrigerator compartment before cooling.
- The food can be placed in different boxes by classification.
- The food with dirt and other foreign matters shall not be placed in the refrigerator
compartment without cleaning to avoid contamination of the refrigerator.
- Wall of the refrigerator compartment is equipped with temperature sensor. Don't
cover the sensor by foods.
1. Please move the lampshade and the thermostat out 3-5mm in the direction of
the arrow.
2.Take out the lamp shade and thermostat downwards the arrow.
Note: In the smart mode, the temperature of cooling room and freezer room change
with the change of the environmental temperature and it regulates the temperature
automatically.
Warning: Push the “Select” button, exit the smart mode, and all selected pattern
disappear, then it exits the setting of modes. And will regulate the temperature
automatically.
3.Pull the connection terminal, use the screwdriver to remove the LED light board and
replace it.
Fridge Temp
Precautions for using refrigerator compartment
USE METHOD AND PRECAUTIONS OF DIFFERENT COMPARTMENTS
LIGHTING AND ITS REPLACEMENT
Warning: As for the holiday, quick freezing and smart modes, the refrigerator
cannot work in two or three modes but only one mode.
Warning: The temperature of the refrigerating room cannot be regulated in
holiday or smart mode; while the temperature of the freezing room cannot be
regulated in smart or quick freezing mode.
Note: If the LED lamp is abnormal, it should be replaced by professionals. Do not
dismantle and replace it yourself in order to avoid damage.
Temperature senor
(concealed below duct cover)

11 12
- When the overturning beam is as shown in Figure 1, the door is unable to close
normally, it must press the top guide block of the overturning beam as shown in Figure
2, firstly close the top guide block, then close the door. Prohibit turning the overturning
beam to the state as shown in figure 1, otherwise the overturning beam may be
damaged.
1. Firstly, remove the left-side fixed clasp and firmly grasp the right side of the door
shelf with your right hand. Press the left side of the door shelf with your left hand and
then press towards the middle direction until the clasp is separated with the slot of
door lining. Keep pressing and then pull outwards slowly until the door shelf gets rid
of the clasp.
Once it gets rid of clasp, stop pulling outward.
2. Place the disassembled side away.
3. Remove the other clasp in the same way as above.
- Excessive food in the refrigerator may cause poor air circulation and keep temper-
ature at a high value.
- Try to reduce the door opening and closing frequency.
Door Shelf , Bottle Shelf
- Disassembly:
Overturning beam
USE METHOD AND PRECAUTIONS FOR EACH ROOM
Notice: in order to prevent condensation, the overturning beam is provided with
heater for heating. Overturning beam heating is normal phenomenon and has
no effect on frozen food.
Press
Pull outward
On the steps
Press
Press
Orientation
1.Press both sides to the middle position and parallelly push the door shelf into the
step.
2. Press the inner side so that the clasp is fastened, and the side buckle is in the
stop block.
3. Assemble both sides in the same way as above.
Installation

13 14
1. Vegetables
Potato--normal temperature preservation, please do not use cold storage (it may
promote starch turn into sugar).
Potato shall be stored separately from other food(moisture and gas diffused from
potato will speed up rotting); apple may prevent potato from sprouting when stored
together.
Onion- Before peeling the onion, preserve it under normal temperature; after
peeling it, put it into sealed container for cold storage.
Radish- Choose refrigerated preservation after removing soil and leaves
(prevent nutrition from being absorbed by leaves).
Garlic, fresh ginger, water chestnut, rhizome, and radish store them at room
temperature, do not choose cold storage (when room temperature is high, radish shall
be firstly wrapped with paper before using cold storage).
Cucumber- Firstly wrap them with newspaper then apply cold storage.
Green pepper and pepper--Wash them with water and put them into sealed container
or freshness protection package for storage.
Tomato--After they get squashy at room temperature, put them into refrigerator for cold
storage.
3. Others
Honey- Preserve them at room temperature, do not use cold storage (low temperature
will make it solidify).
Bread- Preserve them at room temperature, do not choose cold storage (water loss
will make them taste hard).
Coffee bean- Preserve them at room temperature, do not choose cold storage
(foreign taste will cause them change flavor).
Salad dressing- Room temperature preservation (lipolysis during cold storage will
make it easier to rot).
Olive oil- Preserve at room temperature (cold storage will make it freeze into butter
shape).
Tofu put it in salt water and keep it in cold storage.
2. Fruits
Watermelon - Uncut ones shall be stored at room temperature and cut ones shall be
put in sealed container or plastic bag for preservation.
Banana and kiwi fruit -- They will get mature naturally amid normal temperature
preservation and cold storage will make them soft rotten. Apple will accelerate their
ripening when they are stored together.
Apple- Put them in plastic bag for cold storage (ethylene gas diffused by apple may
accelerate metamorphism of other foods).
Pineapple- Use cold storage with root upward (root has the highest sugar content
which may transmit downward).
Strawberry--Do not clean and do not remove stalk, directly put them into plastic bag for
cold storage and eat them up within one week as far as possible.
(Strawberry stalk may evaporate and take away water content, put them in water no
more than 3 seconds as far as possible when cleaning them).
Peach- Preserve them at room temperature, cold storage will reduce their sweetness.
Muskmelon and pawpaw store them at room temperature.
- Low temperature of freezer compartment, it may store foods for long but not exceed-
ing the valid period indicated on food package.
- Tips For Use Of Refrigerator Compartment
Freezer Temp
General use method of freezer compartment
- Foods shall be packed separately or packed as per dosage per time and stored.
- There shall not be too much food stored in freezing drawer.
- Unfrozen food shall not be frozen repeatedly.
- Hot food must cool down to room temperature before being put into freezer
compartment.
- Do not store bottled or canned foods.
- Do not put in liquid food contained in plastic bag.
Precautions for use of freezer compartment
USE METHOD AND PRECAUTIONS OF DIFFERENT COMPARTMENTS
USE METHOD AND PRECAUTIONS OF DIFFERENT COMPARTMENTS

CLEANING
15 16
- Refrigerator shall be installed at well-ventilated places far away from heat source
as far as possible, and it shall be protected from direct sunshine.
- Reduce door opening/closing to avoid energy loss.
- Food shall be sorted and stored according to category so as to reduce the times of
opening/closing door.
- Hot food shall be put in refrigerator only after it cools down.
- To ensure smooth air circulation, the refrigerator shall not be filled to the full by
food.
- Food to be unfrozen may be firstly put in refrigerator compartment, which will
prolong unfreezing time but is helpful to reduce temperature of the refrigerator
compartment.
- The heating of both sides of the cabinet and the frame around the door of freezing
chamber: The heating will be obvious in starting and summer. This is the normal and
there is no effect on the food in the cabinet.
- Long-term operation of compressor: When the refrigerator is first used, it takes
a long time to work to reduce the temperature to a set value, and the compressor will
run intermittently after the stable operation of refrigerator.
- Surface heating when the compressor is running: When the compressor works
normally, the surface temperature is high, which is a normal phenomenon. Do not
touch it with your hands.
- The sound of flowing water: It is a normal phenomenon for the sound of refrigerant
flowing in the pipeline.
- Condensation of appearance: When the humidity of the surrounding of refrigerator
is large, the condensation on the surface of the cabinet is a normal phenomenon.
- The sound of evaporator and piping: When the refrigerator runs, with changeable
temperature, evaporator and pipe will make a sound due to thermal expansion and
contraction.
- Overheat alarm of freezing room: It is caused by high temperature inside the cabinet
for the first electrification. The alarm will be automatically cancelled when the temper-
ature drops.
- Please pull out power plug before cleaning.
- Take out all interior trim parts.
- Parts taken out shall be wiped with wet cloth dipped in neutral detergent, then
washed with water, next wipe them dry with dry cloth and place them at ventilated
place and wait for it to dry naturally.
- Use the same method to clean interior of the refrigerator.
- Door seal shall be firstly taken down and cleaned with neutral detergent and after
getting dry in the air it shall be embedded into door again. Firstly fix the four corners..
NON-FAULT PHENOMENON
Energy saving method
Cleaning method
- It is required to regularly clean refrigerator according to usage condition.
- Oil stains adhered onto door seal surface must be removed, otherwise door seal
will harden, which will reduce refrigerator airtightness and result in temperature rise
inside the compartment.
- It is forbidden to clean refrigerator with boiled water, gasoline, diluent, ethyl alcohol
and other organic solvents. They will make plastic material surface deformation and
cause fracture.
Precautions for cleaning
Notice: freezing will increase volume of liquid foods, therefore glass bottle
including liquid food or sealed plastic bag packing foods may crack.
- Glass bottles having alcoholic/ non-alcoholic aerated drinks shouldn't be left for
more than sustainable hours in freezer. As there is likelihood of breakage and spill over.

TROUBLESHOOTING
17 18
Problems and solutions
Problems Reason analysis and solution
Defrosting method
- Do not wash refrigerator with water directly so as to prevent rusting and electrical
insulation reduction which may lead to electric shock..
- If refrigerator is to be left unused for long, please pull out power plug, and when
closing refrigerator door after interior cleaning, ensure certain gap is reserved.
- Keep interior with smooth air circulation and place refrigerator at well-ventilated
place.
- Refrigerator surface shall be wiped with soft cloth, do not use gasoline, diluent, ethyl
alcohol or other organic solvent because they may cause damage to refrigerator
surface. Refrigerator fails to work or has
bad refrigerating effect, and
control panel fails to display
Refrigerator exterior is hot (top,
front face and two sides)
Refrigerator exterior is hot (top,
front face and two sides)
There is water flow sound inside
the refrigerator
- Check whether the power supply is
connected.
- Check if voltage is too low.
- Check if socket is electrified.
- Check if hot food items are stored in
refrigerator.
- If refrigerator is placed directly under
sunshine, please move it to other place.
- Whether there is heat dissipation space
around the refrigerator. Please maintain
enough space around the refrigerator.
- Refrigerator interior is designed with
condenser pipe for heat dissipation, this is
normal phenomenon.
- If refrigerator is near to heat source and has
high ambient temperature, please move it to
other place.
- If door is closed or if door seal is fully sealed
and has leakage point, it is a must to ensure
that door is closed and door seal is well
sealed.
- Flow of refrigerator's refrigerating fluid and
defrosting water will make sound, this is
normal.
- This refrigerator is air-cooled, automatic defrosting product and requires no
operation by users.
- Water produced after defrosting will flow into evaporation pan behind the refrigera-
tor and evaporate there.

PRECAUTIONS FOR REFRIGERATOR OUT OF SERVICE
19 20
- For 2〜3 h power outage, stored foods will not be significantly affected if refrigerator
door is not opened.
- After power outage, please do not put in food, reduce door opening to the greatest
extent
- If power outage is known in advance, prepare some ice cubes and put them in plastic
bag or plastic case which shall be placed on top of freezer compartment and refrigera-
tor compartment to help maintain refrigerator interior temperature.
Power outage
1. Pull out power plug to disconnect power supply.
2. Take out food in refrigerator and clean the interior.
3. For long time storage, in order to prevent interior peculiar smell, please keep door
slightly opened.
Cease to use (refrigerator will be left unused for long)
- After cutting power supply, the refrigerator may operate normaly for at least 7 min.
This measure is used to protect refrigerator from damage. Therefore, after disconnect-
ing power supply, please wait at least 7 min to recover it.
- Please do not frequently open/close refrigerator, which may shorten refrigerator's life.
- When refrigerator suffers some damage and shall be scraped, please contact special
personnel for treatment. To avoid environment damage or leading to other hazard, do
not discard it at will.
Notice
Use and precautions
Notice: Refrigerating fluid and foaming agent left in refrigerator are combusti-
bles, when maintaining the refrigerator, please contact specialized company for
treatment so as to avoid fire disaster.
Problems Reason analysis and solution
There is abnormal noise amid
refrigerator operation
There is peculiar smell inside the
refrigerator
There is condensation on
refrigerator surface
There is sound similar to "click"
inside the refrigerator
- Check if refrigerator is placed at flat place
and move it to flat places.
- Whether articles producing noise are placed
on top of refrigerator.
- Check if the left and right of refrigerator is at
the same level after installation, if not, please
use adjusting foot to regulate refrigerator
height.
- Peculiar smell existing at initial use stage of
refrigerator will disappear slowly; peculiar
smell produced by interior pollution amid use
shall be eliminated by regular cleaning.
- Foods having strong flavor shall be well
packed before storage.
- When refrigerator has high ambient
moisture, condensation is normal, and it is
only required to wipe it dry with cloth.
- Such sound is caused by interior shrinkage
or expansion of refrigerator and this
phenomenon is normal.
Noise is large at early opening
stage
The refrigerating and freezing
temperature display area of
control panel fails to display
digital but displays letter
- At opening stage large noise is normal, and
noise will automatically reduce after stable
running.
- When it displays no digital but English
letters, the refrigerator is suffering some
damage, ask for after-sale maintenance as
soon as possible even it may operate
continuously.

TECHNICAL PARAMETERS
PACKING LIST
21 22
Climate type
Anti-electric shock protection type
Fridge compartment volume (L)
Freezer compartment volume (L)
Freezing capacity (kg/24h)
Rated voltage (V)
Rated frequency (Hz)
Rated current (A)
Noise [dB (A)]
Energy consumption (kW.h/24h)
Refrigerant type/ Refrigerant charge (g)
Net weight (kg)
Temperature of fridge compartment (°C)
Temperature of freezer compartment (°C)
Upper shelf of fridge compartment
Bottle shelf of fridge compartment
Fridge compartment frame
Crisper drawer cover
Crisper drawer box
freezer glass shelf
Lower drawer of freezer compartment
4
2
2
1
2
4
2
Instruction 1 copy
Accessories
Inside
package
SN/N/ST/T
I
335
150
10
220-240
50
1.6
<42
0.85
R600a/72
89
1~7
-15~-22
825
673
1903
Printing
attachment
Width
Depth
Height
Dimension
Model
Name Pcs
LL4DR500RG
- For cleaning method applicable to long time storage, please refer to contents
described in the column of "cleaning".
Reference
- We reserve the right to change parts of different models of refrigerators along
with continuous research and improvement without further notice.

23
1 copy
Consumer Warranty Card
Dear Customer,
Thank you for choosing a Lifelong consumer product. All Lifelong Consumer
products are designed and manufactured to the highest standards to deliver high
quality performance, as well as easy installation and use. At Lifelong, we believe in
providing not only service, but adding value to your purchase. The warranty has
therefore been designed especially for you with your interest at heart.
Warranty Service
All Lifelong consumer products are covered against manufacturing defects from
them date of purchase.
Name of the product:
Model:
Warranty coverage: 1 year warranty on Product, 10 year warranty on Compressor
Please note: Purchase receipt is necessary for warranty verification.
Customer Care: [email protected]
Customer Details
Name:
Address:
Home Number:
Office Number:
E-mail Address:
Product Details
Model No.:
Serial No.:
Purchase Date:
Invoice Number:
Online Site:
Please log onto to www.lifelongindiaonline.com and complete the online warranty form with your
personal and product details within 14 days.
