Light4CE LEDForce 18 RGB User manual

1

2
User manual
LEDForce 18 RGB
1.Safety instructions
- Every person involved with the installation, operation and maintenance of this device has to :
 bequalied
follow the instructions of this manual
- CAUTION! Be careful with your operations. With a dangerous voltage you can suffer a dangerous electric
shock when touching the wires!
- This device has left our premises in absolutely perfect condition. In order to maintain this condition and
to ensure a safe operation, it is absolutely necessary for the user to follow the safety instructions and
warning notes written in this user manual.
- Important: Damages caused by the disregard of this user manual are not subject to warranty.
The distributor will not accept liability for any resulting defects or problems.
- Keep away from heaters and other heating sources!
-Ifthedevicehasbeenexposedtodrastictemperatureuctuation(e.g.aftertransportation),donotswitchit
on immediately. The arising condensation water might damage your device. Leave the device switched off
until it has reached room temperature.
- Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and
the power-cord from time to time.
-Iftheexternalexiblecableorcordofthisluminaireisdamaged,itshallbeexclusivelyreplacedby
themanufacturerorhisserviceagentorasimilarqualiedpersoninordertoavoidahazard.
- shields, lenses or ultraviolet screens shall be changed if they have become visibly damaged to such
an extent that their effectiveness is impaired, for example by cracks or deep scratches.
- Never let the power-cord come into contact with other cables! Handle the power-cord and all connections
with the mains with particular caution!
- Make sure that the available voltage is not higher than stated in this manual.
- Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle
the power-cord by the plug. Never pull out the plug by tugging the power-cord.
- During the initial start-up some smoke or smell may arise. This is a normal process and does not
necessarily mean that the device is defective.
- DANGER OF BURNING! Never touch the device during the operation! The housing heats up to the housing
temperature.
- Don't switch the device on and off in short intervals as this would reduce the lamp's life.
- HEALTH HAZARD! Never look directly into the light source, as sensitive persons may suffer an epileptic
shock(especiallymeantforepileptics)!
- Always disconnect from the mains, when the device is not in user or before cleaning it.
-Pleasenotethatdamagescausedbymanualmodicationsonthedeviceorunauthorizedoperation
byunqualiedpersonsarenotsubjecttowarranty.
- Keep away children and amateurs from the device!
- There are no serviceable parts inside the device. Maintenance and service operations are only to be
carriedoutbyauthorizeddealers.
2.Operating instructions
1. This system has DMX Online mode and Stand-alone Mode. Online mode can link other units and be
controlled by the DMX controller. And Stand-alone Mode has the functions of Sound, Auto Mixcolor
and Strobe and so on.
2. If a DMX signal is present under Online mode, the DMX LED will blink very fast to indicate.While under
Master/Slave mode, Master´s LED indicator will light and Slave´s ona will blink to indicate.
3. Button Function Description:
Press MODE button to select your desire mode.
And press UP or Down button to select DMX address,
switch AUTO MODE,adjust the speed value and select
color. Up key is to add value. Down key is to reduce value.
(Note:IfyoupressUPorDOWNkeymorethanseconds,
youcanselectquickly.)

3
Button mode Function description
Mode Select your desire mode
Up DMX: select address, run AUTOMODE, adjust MODE SPEED, MACRO: select
colour
Down DMX: select address, run AUTOMODE, adjust MODE SPEED, MACRO: select
colour
NO. MODE DISPLAY INTRODUCTION
1DMX mode 1 (1CHS) 1XXX(XXX=001-511) Macro
2DMX mode 2 (2CHS) 2XXX(XXX=001-511) Macro(CH1)+Luminance(CH2)
3DMX mode 3 (3CHS) 3XXX(XXX=001-511) R(CH1),G(CH2),B(CH3)
4DMX mode 4 (7CHS) 4XXX(XXX=001-511) DMX MODE
5 Red manual mode (sta-
tic)
D1XX(XX=00-99) redluminanceadjust,00-99:0-100%lumianceadjust
6 Green manual
mode(static)
D2XX(XX=00-99) green luminance adjust, 00-99: 0-100% lumiance
adjust
7Bluemanualmode(sta-
tic)
D3XX(XX=00-99) blue luminance adjust, 00-99: 0-100% lumiance
adjust
8 Strobe D4XX(XX=00-99) Strobe,00-99:non-strobe-fasteststrobe
9Auto-mix color FXX(XX=01-15) Automixcolorspeedadjust:01fastest,15slowest
10 7color strobe CXX(XX=01-15) 7colorstrobe:1fastest,15slowest
11 Sound mode SO 7 sound mode
1.DMXMode1(1CH,display:1XXX;XXX=DMXaddress,pressup/downchangeDMXaddress.
1CH1(0-255) Function 2CH1(0-255) CH2(0-255) Function
DMX mode 1 Macro 3 5 c o l o r
setting+black
DMX mode 2 Macro Luminence 36 color setting
+luminance
2.DMXMode2(2CH,display:2XXX;XXX=DMXaddress,pressup/downchangeDMXaddress.
3.DMXMode3(3CH,display:3XXX;XXX=DMXaddress,pressup/downchangeDMXaddress.
3CH10-255) CH1 CH1 Function
DMX mode 3 R G B R/G/B luminance
setting
4.DMX mode 4(7CHS,display:4XXX;XXX=DMX address.Pressing UP/DOWN change DMX address.)
CH6 CH1 CH2 CH3 CH4 CH5 CH6 CH7
mode R G B Macro Speed/strobe Mode MASTER DIM. Function
1
(0-35)settingcolor
0 0 0 0-13(off) strobe
(0-35) color
adjust)
Dimmer
0-255:min-max
No out
1-255 1-255 1-255
14-255
Macro
0-15:static
16-255:16steps
RGB/strobe
NA NA NA macro (PRI)
(36-71)
0-7OFF
8-255JOININ
NA Setting Speed
0-255:16steps
(36-71) light mode
(72-107) (72-107) dim mode
(108-143) (108-143) dim& light mode
(144-179)
NA NA NA
(144-179) auto mix color
(180-251) (180-215) 3 color strobe
7 color sound
control(252-255) NA NA
(216-251) 7 color strobe
7 color sound
control
luminance change as
sound intensity

4
3.Technical specications
Inputvoltagerange:90-260V,50/60Hz
Powerconsumption:61W/123VA(powerfactor=0.49)
LED device: 18 x 3 Watt Tri Color RGB LEDs
Expectedlifetime:50,000hours
BeamAngle:25°,(10°optionalkitavailable)
Operational modes: Sound Active, Macro, Auto, DMX
ControlprotocolDMX512
DMX modes:4
Control channels: 1,2,3,7
Setting and addressing: LED control display
DMXIN/OUT:5-pinXLR
Dimensions:(LxWxH)292x216x216mm/11,5”x8,5”x8,5”(withouthangingbracket)
Weight:4.9kg
Version:1.1
April 19, 2010
Specications are subject to change without specication
