LIMIT LICM25S User manual

MODEL / MODELE:
Handleiding
Mode d’emploi
Instruction Manual
LICM25S

SAVE THESE INSTRUCTIONS CAREFULLY
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
MODEL:LICM25S
EN-2

Rated Voltage:
Rated Input Power(Microwave):
Rated Output Power(Microwave):
Oven Capacity:
Turntable Diameter:
External Dimensions(LxWxH):
Net Weight:
Specifications
Rated Input Power(Grill):
Rated Input Power(Convection):
230V~50Hz
1500W
900W
25L
315mm
513
1400W
2400W
Model:
Approx. 16.65 kg
307mm401
(a) Do not attempt to operate this oven with the door
open since this can result in harmful exposure to
microwave energy. It is important not to break or tamper
with the safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to accumulate
on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
lifespan of the apparatus and lead to a dangerous situation.
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
EN-3
LICM25S

To reduce the risk of fire, electric shock, injury to
personsor exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including he following:
1. Warning: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
2. Warning: It is hazardous for anyone other than a
competent person to carry out any service or repair
operation that involves the removal of a cover which
gives protection against exposure to microwave energy.
3. This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been givensupervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved.Children shall not
play with the appliance.Cleaning and user maintenance
shall not be made by children unless they are older than
8 and supervised.
4. Keep the appliance and its cord out of reach of
children less than 8 years.
5. Only use utensils suitable for use in microwave ovens.
6. The oven should be cleaned regularly and any food
deposits should be removed.
7. Read and follow the specific:"PRECAUTIONS TO
AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
8. When heating food in plastic or paper containers,
keep an eye on the oven due to the possibility of ignition.
IMPORTANT SAFETY INSTRUCTIONS
WARNING
EN-4

9. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage purposes.
Do not store items, such as bread, cookies, etc. inside
the oven.
12. Remove wire twist-ties and metal handles from
paper or plastic containers/bags before placing them in
the oven.
13. Install or locate this oven only in accordance with the
installation instructions provided.
14. Eggs in the shell and whole hard-boiled eggs should
not be heated in microwave ovens since they may
explode, even after microwave heating has ended.
15.This appliance is intended to be used in household
and similar applications such as:
-staff kitchen areas in shops, offices and other working
environments;
-by clients in hotels, motels and other residential type
environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this appliance outdoors.
18. Do not use this oven near water, in a wet basement
or near a swimming pool.
19. The temperature of accessible surfaces may be high
when the appliance is operating. The surfaces are liable
to get hot during use.Keep cord away from heated
surface, and do not cover any vents on the oven.
EN-5

20. Do not let cord hang over edge of table or counter.
21. Failure to maintain the oven in a clean condition
could lead to deterioration of the surface that could
adversely affect the life of the appliance and possibly
result in a hazardous situation.
22.The contents of feeding bottles and baby food jars
shall be stirred or shaken and the temperature checked
before consumption, in order to avoid burns.
23. Microwave heating of beverages can result in
delayed eruptive boiling, therefore care must be taken
when handling the container.
24.The appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
25.Children should be supervised to ensure that they do
not play with the appliance.
26.The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
27.Accessible parts may become hot during use. Young
children should be kept away.
28.Steam cleaner is not to be used.
29.During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
30.Only use the temperature probe recommended for
this oven.(for ovens provided with a facility to use a
temperature-sensing probe.)
EN-6

31. WARNING: The appliance and its accessible parts
become hot during use.Care should be taken to avoid
touching heating elements. Children less than 8 years
of age shall be kept away unless continuously
supervised.
32.The microwave oven must be operated with the
decorative door open.(for ovens with a decorative door.)
33.The rear surface of appliance shall be placed against
a wall.
34.The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE
EN-7

To Reduce the Risk of Injury to Persons
Grounding Installation
DANGER
Electric Shock Hazard
Touching some of the
internal componentscan
cause serious personal
injury or death.Do not
disassemble this
appliance.
WARNING
Electric Shock Hazard Improper
use of the grounding can
result in electric shock.
Do not plug into an outlet
until appliance is properly
installed and grounded.
This appliance must be
grounded. In the event of
an electrical short circuit,
grounding reduces the
risk of electric shock by
providing an escape wire
for the electric current.
This appliance is equipped
with a cord having a
grounding wire with
a grounding plug. The
plug must be plugged into
an outlet that is properly
installed and grounded.
Consult a qualified
electrician or serviceman
if the grounding instructions
are not completely
understood or if doubt exists
as to whether the appliance
is properly grounded.
If it is necessary to use an
extension cord , use only
a 3-wire
1. A short power-supply cord
is provided to reduce the risks
resulting from becoming
entangled in or tripping over a
longer cord.2. If a long cord set
or extension cord isused:
1)The marked electrical rating
of the cordset or extension cord
should be at least as great as
the electrical rating of the
appliance.
2)The extension cord must be
a grounding-type 3-wire cord.
3)The long cord should be
arranged so that it will not drape
over the counter top or tabletop
where it can be pulled on
by children or tripped over
unintentionally.
EN-8

CLEANING
Be sure to unplug the
appliance from the power
supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for
anyone other than a
compentent person to
carry out any service
or repair operation that
involves the removal of
a cover which gives
protection against
exposure to microwave
energy.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
EN-9

Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.
Browning dish
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Dinnerware
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing and could cause a fire in the oven.
EN-10

A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
F
G
A
C B
ED
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Instruction Manual 1
Grill Rack( Only for Grill series )
Hub (underside)
Glass tray
Turntable ring assembly
a. Never place the glass tray upside down. The glass
tray should never be restricted.
b. Both glass tray and turntable ring assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glass tray for cooking.
d. If glass tray or turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable Installation
Turntable shaft
EN-11

Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Countertop Installation
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
Installation
1.Select a level surface that
provide enough open space
for the intake and/or outlet
vents.
(1) The minimum installation
height is 85cm.
(2) The rear surface of
appliance shall be placed
against a wall.
Leave a minimum clearance
of 30cm above the oven, a
minimum clearance of 20cm
is required between the oven
and any adjacent walls.
(3) Do not remove the legs
from the bottom of the oven.
(4) Blocking the intake and/
or outlet openings can
damage the oven.
(5) Place the oven as far
away from radios and TV
as possible. Operation of
microwave oven may
cause interference to your
radio or TV reception.
2. Plug your oven into a
standard household outlet.
Be sure the voltage and
the frequency is the same
as the voltage and the
frequency on the rating
label.
WARNING: Do not install
oven over arange cooktop
or other heat-producing
appliance. If installed near
or over a heatsource, the
oven could be damaged
and the warranty would be
void.
20cm
30cm
20cm
min85cm
0cm
The accessible
surface may be
hot during operation.
EN-12

Press " MICROWAVE"several times or press "MICROWAVE" once then turn " " to
select the function you want. Press "START/+30SEC./CONFIRM"to confirm the power.
Turn " " to adjust the cooking time. Press " START/+30SEC./CONFIRM" to start
cooking.
2. Microwave Cooking
Example: If you want to use 80% power to cook for 20 minutes, you can operate the
oven as the following steps.
OPERATION INSTRUCTION
When the microwave oven is electrified,the oven will display "0:00", buzzer will ring
once.
3) Press " CLOCK/PRE-SET ", the minute figures will flash.
5) Press "CLOCK/PRE-SET " to finish clock setting,":" will flash.
Note: 1) If the clock is not set, it would not function when powered.(Display "0:00")
2) During the process of clock setting, if you press " STOP/CLEAR", the
oven will go back to the previous status automatically.
4) Turn " " to adjust the minute figures, the input time should be within 0-59.
1) Press "CLOCK/PRE-SET " to select the time 12-hour or 24-hour.
2) Turn " " to adjust the hour figures, the input time should be within 0-23(24-hour)
or 1-12 (12 hour).
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
2) Press " MICROWAVE" once again or turn " " to choose 80%, the oven will
display "P80".
1) Press " MICROWAVE " once, the oven will display "P100".
4) Turn " " to adjust the cooking time until the oven display "20:00".
(The maximum cooking time is 95 minutes.)
5) Press "START/+30SEC./CONFIRM " to start cooking.
Microwave Power Chart
Press
Power
Display
Once Twice Thrice 4 times 5 times
80%
P80
50%
P50
30%
P30
10%
P10
100%
P100
3) Press "START/+30SEC./CONFIRM " to confirm the microwave power.
1.Clock Setting
EN-13

3. Grill & Combination Cooking
4. Convection Cooking(With preheating funtion)
5) Press the " START/+30SEC./CONFIRM " key to start cooking. ":" will be lighted.
4) Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
1) Press the " GRILL/COMBI. " key once.
2) Press the " GRILL/COMBI. " several times or turn " " until "G-1","C-1" "C-2",
"C-3" or "C-4" displays.
1) Press the "CONVECTION " key once, the LED will display "150"
3) Press the " START/+30SEC./CONFIRM " to confirm the temperature.
4) Press the "START/+30SEC./CONFIRM " to start preheating.When the preheating
temperature arrives, the buzzer will sound twice to remind you to put the food into
the oven. And the preheated temperature is displayed and flash.
5) Put the food into the oven and close the door.Turn " " to adjust the cooking time.
(The maximum setting time is 95 minutes.)
6) Press the "START/+30SEC./CONFIRM " key to start cooking.
3) Press the " START/+30SEC./CONFIRM" to confirm the power.
2) Keep pressing the same key or turn " " to select the convection temperature,the
temperature can be chosen from 150 degrees to 240 degrees.
The convection cooking can let you to cook the food as a traditional oven. Microwave is not
used. It is recommended that you should preheat the oven to the appropriate temperature
before placing the food in the oven.
Note: a. Cooking time cannot be input until the preheating temperature arrives.
If the temperature arrives, door must be opened to input the cooking time.
b. If the time not input in 5 minutes, the oven will stop preheating. The buzzer
sound five times and turn back to waiting states.
Note:1) If half the grill time passes, the oven sounds twice, this is normal.
But in order to have a better effect of grilling food, you should turn the food over,
close the door, and then press" START/+30SEC./CONFIRM" to continue cooking.
If no operation, the oven will not pause and continue working.
2) "C-1" refers to the combination of microwave and convection.
"C-2" refers to the combination of microwave and grill.
"C-3" refers to the combination of convection and grill.
"C-4" refers to the combination of microwave, grill and convection.
EN-14

7. Defrost by time
8. Pre-set Function
1) Set the clock first. (Consult the instruction of clock setting.)
be set in pre-set function.
6. Defrost by weight
1) Press "W.T/TIME DEFROST" pad twice,the LED will display "dEF2".
3) Press "START/+30SEC./CONFIRM "key to start defrosting.
2) Turn " " to adjust the cooking time. (The maximum cooking time is 95 minutes.)
1) Press "W.T/TIME DEFROST" pad once,the LED will display "dEF1".
3) Press "START/+30SEC./CONFIRM "key to start defrosting.
2) Turn " " to select the weight of food. The weight should be 100-2000g.
5) Press " CLOCK/PRE-SET ", the minute figures will flash.
8) When the pre-set time arrives, the buzzer will sound twice to remind you to start cook.
6) Turn " " to adjust the minute figures, the input time should be within 0-59.
3) Press "CLOCK/PRE-SET " the oven will display the current time.
4) Turn " " to adjust the hour figures, the input time should be within 0-23(24-hour)
or 1-12 (12 hour).
7) Press "START/+30SEC./CONFIRM" to finish the preset function.
Example: if you want to cook with 100% microwave power for 15 minutes.
a. Press "MICROWAVE" once to choose 100% microwave power;
b. Press "START/+30SEC./CONFIRM " to confirm the microwave power.
c. Turn " " to adjust the cooking time of 15 minutes;
d. Be careful! Do not press " START/+30SEC./CONFIRM" to start cooking.
5. Convection Cooking( Without pre-heating function)
1) Press the "CONVECTION " key once, the LED will display "150"
2) Turn " " to select the convection temperature,the temperature can be chosen from
150 degrees to 240 degrees.
3) Press the " START/+30SEC./CONFIRM " to confirm the temperature.
5) Press the "START/+30SEC./CONFIRM " key to start cooking.
Turn " " to adjust the cooking time.(The maximum setting time is 95 minutes.)
4)
2) Input the cooking program. 2 stagescan be set at most. Defrosting should not
EN-15

10.Speedy Cooking
12. Auto Menu
9.Multi-Stage Cooking
Two stages of cooking can be maximumly set. If one stage is defrosting, it should
be put in the first stage. The buzzer will ring once after each stage and the next stage will
begin. Preheat and auto menu cannot be set here.
11. Inquiring Function
(1) In cooking state, press"MICROWAVE"" CONVECTION"or "GRILL/ COMBI.", the current
power will be displayed for 2-3 seconds.
(2) In pre-set state, press " CLOCK/PRE-SET " to inquire the time for delay start cooking.
The pre-set time will flash for 2-3 seconds, then the oven will turn back to the clock display.
(3) During cooking state, press "CLOCK/PRE-SET" to check the current time. It will be
displayed for 2-3 seconds.
4) Press "START/ +30 SEC./CONFIRM" to start cooking.
1) In waiting state, turn " " right to choose the function wanted,the LED will
display "A1" "A2" "A3" "A4" ..."A9" "A10", "A1" in order.
2) Press "START/ +30 SEC./CONFIRM" to confirm the menu you need.
3) Turn " " to choose the weight of menu,and "g" indicator will light.
Example: if you want to cook with 100% microwave power for 10 minutes+ 80%
microwave power for 5 minutes. The steps are as following:
1) Press "MICROWAVE" once to choose 100% microwave power;
2) Press "START/+30SEC./CONFIRM " to confirm the microwave power.
3) Turn " " to adjust the cooking time of 10 minutes;
4) Press"MICROWAVE" twice to choose 80% microwave power;
1) In waiting state, press "START/+30SEC./CONFIRM" to start cooking with 100%
microwave power for 30 seconds, each added press will increase 30 seconds
cooking time up to 95 minutes.
2) In microwave,grill,combination and convection cooking state, each press
of "START/+30SEC./CONFIRM" can increase 30 seconds.
3) Time cannot be increased under defrost, multi-stage and auto menu function.
5) Press "START/+30SEC./CONFIRM " to confirm the microwave power.
6) Turn " " to adjust the cooking time of 5 minutes;
7) Press "START/+30 SEC./ CONFIRM" to start cooking.
EN-16

A5
A6
A7
SOUP
Menu Weight Display
A2
A4
150 g
250g
350g
450g
600g
1(approx.230g)
2(approx.460g)
3(approx.690g)
150g
300g
450g
600g
150g
350g
500g
150g
250g
350g
450g
650g
50g(with cold water 450ml)
100g(with cold water 800ml)
150g(with cold water 1200ml)
200ml
400ml
600ml
475g
200g
A1
A3
A8
150
250
350
450
600
1
2
3
150
300
450
600
150
350
500
150
250
350
450
650
50
100
150
200
400
600
475
200
300g
400g
500g
750g
1000g
A10
CHICKEN
POTATO
REHEAT
MEAT
VEGETABLE
FISH
PASTA
CAKE
A9
PIZZA
1200g
300
400
500
750
1000
1200
EN-17

13Lock-out Function for Children
Lock: In waiting state, press " STOP/CLEAR" for 3 seconds, there will be a long
beep denoting entering the lock state and the lock indicator will light.
The current time will display if the clock has been set, otherwise, the oven will
display " 0:00 ".
Lock quitting: In locked state, press "STOP/CLEAR " for 3 seconds, there will be a
long "beep" denoting that the lock is released.
14. Specifications
(1) Buzzer will sound five times when cooking finished;
(2) During cooking, if the door is opened and after closing the door,
" START/+30SEC./CONFIRM " must be pressed to continued cooking;
(3) Once the cooking program has been set, " START/+30SEC./CONFIRM " is not pressed
in five minutes, the previous setting will be cancelled.
(4) Buzzer will sound once by efficient pressing. No response by inefficient pressing.
You should preheat first following the auto menu operation, when the oven
reaches the temperature, it will stop working and sound to remind opening
the door to put cake in, then press "Start/+30Sec./Confirm" to start cooking.
Note: when cooking with cake menu, you should preheat the oven with 160 degrees first and
then cook with 160 degrees.
EN-18

Trouble shooting
According to Waste of Electrical and Electronic Equipment
(WEEE) directive, WEEE should be separately collected and
treated. If at any time in future you need to dispose of this
product please do NOT dispose of this product with household
waste. Please send this product to WEEE collecting points
where available.
It is forbidden to run the unit without any food inside.
It is very dangerous.
EN-19

WARNING!
Do not remove the light brown Mica cover that is attached to the oven cavity
to protect the magnetron. It’s sharp after removing the mica from the original
place !
the Mica cover
EN-20
