Lincoln Electric K1669-4 User manual

Ope ato ’s Manual
Autho ized Se vice and Dist ibuto Locato :
www.lincolnelectric.com/locator
IM10366-B | Issue D ate Nov-21
© Lincoln Global, Inc. All Rights Reserved.
For use with product having Product Numbers:
For Wall Mount:
K1669-4 (for Prism 2400 Fan)
K1669-10 (for Prism 4200 Fan)
AD1221 (for wall mount systems)
Save fo futu e efe ence
Date Purchased
Code: (ex: 10859)
Serial: (ex: U1060512345)
Lamp Kit with Arc Sensor

THANK YOU FOR SELECTING
A QUALITY PRODUCT BY
LINCOLN ELECTRIC.
PLEASE EXAMINE CARTON AND EQUIPMENT FOR
DAMAGE IMMEDIATELY
When this equipment is shipped, title passes to the purchaser
upon receipt by the carrier. Consequently, claims for material
damaged in shipment must be made by the purchaser against the
transportation company at the time the shipment is received.
SAFETY DEPENDS ON YOU
Lincoln arc welding and cutting equipment is designed and built
with safety in mind. However, your overall safety can be increased
by proper installation ... and thoughtful operation on your part.
DO NOT INSTALL, OPERATE OR REPAIR THIS EQUIPMENT
WITHOUT READING THIS MANUAL AND THE SAFETY
PRECAUTIONS CONTAINED THROUGHOUT. And, most importantly,
think before you act and be careful.
This statement appears where the information must be followed
exactly to avoid serious personal injury or loss of life.
This statement appears where the information must be followed
to avoid minor personal injury or damage to this equipment.
KEEP YOUR HEAD OUT OF THE FUMES.
DON’T get too close to the arc.
Use corrective lenses if necessary
to stay a reasonable distance
away from the arc.
READ and obey the Safety Data
Sheet (SDS) and the warning label
that appears on all containers of
welding materials.
USE ENOUGH VENTILATION or
exhaust at the arc, or both, to
keep the fumes and gases from
your breathing zone and the general area.
IN A LARGE ROOM OR OUTDOORS, natural ventilation may be
adequate if you keep your head out of the fumes (See below).
USE NATURAL DRAFTS or fans to keep the fumes away
from your face.
If you develop unusual symptoms, see your supervisor.
Perhaps the welding atmosphere and ventilation system
should be checked.
WEAR CORRECT EYE, EAR &
BODY PROTECTION
PROTECT your eyes and face with welding helmet
properly fitted and with proper grade of filter plate
(See ANSI Z49.1).
PROTECT your body from welding spatter and arc
flash with protective clothing including woolen
clothing, flame-proof apron and gloves, leather
leggings, and high boots.
PROTECT others from splatter, flash, and glare
with protective screens or barriers.
IN SOME AREAS, protection from noise may be appropriate.
BE SURE protective equipment is in good condition.
Also, wear safety glasses in work area
AT ALL TIMES.
SPECIAL SITUATIONS
DO NOT WELD OR CUT containers or materials which previously
had been in contact with hazardous substances unless they are
properly cleaned. This is extremely dangerous.
DO NOT WELD OR CUT painted or plated parts unless special
precautions with ventilation have been taken. They can release
highly toxic fumes or gases.
Additional precautionary measures
PROTECT compressed gas cylinders from excessive heat,
mechanical shocks, and arcs; fasten cylinders so they cannot fall.
BE SURE cylinders are never grounded or part of an
electrical circuit.
REMOVE all potential fire hazards from welding area.
ALWAYS HAVE FIRE FIGHTING EQUIPMENT READY FOR
IMMEDIATE USE AND KNOW HOW TO USE IT.
WARNING
CAUTION
Safety 01 of 04 - 10/08/2021

SECTION A:
WARNINGS
CALIFORNIA PROPOSITION 65 WARNINGS
WARNING: Breathing diesel engine exhaust
exposes you to chemicals known to the State
of California to cause cancer and birth defects,
or other reproductive harm.
• Always start and operate the engine in a
well-ventilated area.
• If in an exposed area, vent the exhaust to the outside.
• Do not modify or tamper with the exhaust system.
• Do not idle the engine except as necessary.
For more information go to
www.P65 warnings.ca.gov/diesel
WARNING: This product, when usedfor welding or
cutting, produces fumes or gases which contain
chemicals known to the State ofCalifornia to cause
birth defects and, in some cases, cancer.(California
Health & Safety Code § 25249.5 et seq.)
WARNING: Cancer and Reproductive Harm
www.P65warnings.ca.gov
ARC WELDING CAN BE HAZARDOUS. PROTECT
YOURSELF AND OTHERS FROM POSSIBLE SERIOUS
INJURY OR DEATH. KEEP CHILDREN AWAY.
PACEMAKER WEARERS SHOULD CONSULT WITH
THEIR DOCTOR BEFORE OPERATING.
Read and understand the following safety highlights. For
additional safety information, it is strongly recommended
that you purchase a copy of “Safety in Welding & Cutting -
ANSI Standard Z49.1” from the American Welding Society,
P.O. Box 351040, Miami, Florida 33135 or CSA Standard
W117.2. A Free copy of “Arc Welding Safety” booklet E205
is available from the Lincoln Electric Company, 22801
St. Clair Avenue, Cleveland, Ohio 44117-1199.
BE SURE THAT ALL INSTALLATION, OPERATION,
MAINTENANCE AND REPAIR PROCEDURES ARE
PERFORMED ONLY BY QUALIFIED INDIVIDUALS.
FOR ENGINE POWERED
EQUIPMENT.
1.a. Turn the engine off before troubleshooting
and maintenance work unless the
maintenance work requires it to be running.
1.b. Operate engines in open, well-ventilated areas or vent the engine
exhaust fumes outdoors.
arc or when the engine is running. Stop the
engine and allow it to cool before refueling to
prevent spilled fuel from vaporizing on contact
tank. If fuel is spilled, wipe it up and do not start engine until
fumes have been eliminated.
1.d. Keep all equipment safety guards, covers
and devices in position and in good repair.
Keep hands, hair, clothing and tools away
from V-belts, gears, fans and all other
moving parts when starting, operating or
repairing equipment.
1.e. In some cases it may be necessary to remove safety guards to
perform required maintenance. Remove guards only when
necessary and replace them when the maintenance requiring
their removal is complete. Always use the greatest care when
working near moving parts.
1.f. Do not put your hands near the engine fan. Do not attempt to
override the governor or idler by pushing on the throttle control
rods while the engine is running.
1.g. To prevent accidentally starting gasoline engines while turning
the engine or welding generator during maintenance work,
disconnect the spark plug wires, distributor cap or magneto wire
as appropriate.
1.h. To avoid scalding, do not remove the radiator
pressure cap when the engine is hot.
ELECTRIC AND
MAGNETIC FIELDS MAY
BE DANGEROUS
causes localized Electric and Magnetic Fields (EMF).
and welding machines
welders having a pacemaker should consult their physician
before welding.
which are now not known.
2.d. All welders should use the following procedures in order to
2.d.1. Route the electrode and work cables together - Secure
them with tape when possible.
2.d.2. Never coil the electrode lead around your body.
2.d.3. Do not place your body between the electrode and work
cables. If the electrode cable is on your right side, the
work cable should also be on your right side.
2.d.4. Connect the work cable to the workpiece as close as pos-
sible to the area being welded.
2.d.5. Do not work next to welding power source.
SAFETY
Safety 02 of 04 - 10/08/2021
1.c. Do not add the fuel near an open ame welding
with hot engine parts and igniting. Do not spill fuel when lling
2.a. Electric current owing through any conductor
Welding current creates EMF elds around welding cables
2.b. EMF elds may interfere with some pacemakers, and
2.c. Exposure to EMF elds in welding may have other health effects
minimize exposure to EMF elds from the welding circuit:
1.i. Using a generator indoors CAN KILL YOU IN
MINUTES.
1.j. Generator exhaust contains carbon monoxide. This is a poison
you cannot see or smell.
1.k. NEVER use inside a home or garage,
EVEN IF doors and windows are open.
1.l. Only use OUTSIDE and far away from
windows, doors and vents.
1.m. Avoid other generator hazards. READ
MANUAL BEFORE USE.

ELECTRIC SHOCK
CAN KILL.
3.a. The electrode and work (or ground) circuits are
electrically “hot” when the welder is on. Do
not touch these “hot” parts with your bare skin or wet clothing.
Wear dry, hole-free gloves to insulate hands.
3.b. Insulate yourself from work and ground using dry insulation.
Make certain the insulation is large enough to cover your full area
of physical contact with work and ground.
In addition to the normal safety precautions, if
welding must be performed under electrically
hazardous conditions (in damp locations or while
wearing wet clothing; on metal structures such as
floors, gratings or scaffolds; when in cramped
positions such as sitting, kneeling or lying, if there
is a high risk of unavoidable or accidental contact
with the workpiece or ground) use the following
equipment:
• Semiautomatic DC Constant Voltage (Wire) Welder.
• DC Manual (Stick) Welder.
• AC Welder with Reduced Voltage Control.
3.c. In semiautomatic or automatic wire welding, the electrode,
electrode reel, welding head, nozzle or semiautomatic welding
gun are also electrically “hot”.
3.d. Always be sure the work cable makes a good electrical
connection with the metal being welded. The connection should
be as close as possible to the area being welded.
3.e. Ground the work or metal to be welded to a good electrical (earth)
ground.
3.f. Maintain the electrode holder, work clamp, welding cable and
welding machine in good, safe operating condition. Replace
damaged insulation.
3.g. Never dip the electrode in water for cooling.
3.h. Never simultaneously touch electrically “hot” parts of electrode
holders connected to two welders because voltage
between the
two can be the total of the open circuit voltage of both
welders.
3.i. When working above floor level, use a safety belt to protect
yourself from a fall should you get a shock.
3.j. Also see Items 6.c. and 8.
ARC RAYS CAN BURN.
4.a. Use a shield with the proper filter and cover plates to protect your
eyes from sparks and the rays of the arc when welding or
observing open arc welding. Headshield and filter lens should
conform to ANSI Z87. I standards.
4.b. Use suitable clothing made from durable flame-resistant material
to protect your skin and that of your helpers from the arc rays.
4.c. Protect other nearby personnel with suitable, non-flammable
screening and/or warn them not to watch the arc nor expose
themselves to the arc rays or to hot spatter or metal.
FUMES AND GASES
CAN BE DANGEROUS.
5.a. Welding may produce fumes and gases
hazardous to health. Avoid breathing these
fumes and gases. When welding, keep your head out of the fume.
Use enough ventilation and/or exhaust at the arc to keep fumes
and gases away from the breathing zone. When welding
hardfacing (see instructions on container or SDS)
or on lead or cadmium plated steel and other
metals or coatings which produce highly toxic
fumes, keep exposure as low as possible and
within applicable OSHA PEL and ACGIH TLV limits
using local exhaust or mechanical ventilation
unless exposure assessments indicate otherwise.
In confined spaces or in some circumstances,
outdoors, a respirator may also be required.
Additional precautions are also required when
welding
on galvanized steel.
5. b. The operation of welding fume control equipment is affected by
various factors including proper use and positioning of the
equipment, maintenance of the equipment and the specific
welding procedure and application involved. Worker exposure
level should be checked upon installation and periodically
thereafter to be certain it is within applicable OSHA PEL and
ACGIH TLV limits.
5.c. Do not weld in locations near chlorinated hydrocarbon vapors
coming from degreasing, cleaning or spraying operations. The
heat and rays of the arc can react with solvent vapors to form
phosgene, a highly toxic gas, and other irritating products.
5.d. Shielding gases used for arc welding can displace air and
cause
injury or death. Always use enough ventilation, especially in
confined areas, to insure breathing air is safe.
5.e. Read and understand the manufacturer’s instructions for this
equipment and the consumables to be used, including the
Safety Data Sheet (SDS) and follow your employer’s safety
practices. SDS forms are available from your welding
distributor or from the manufacturer.
5.f. Also see item 1.b.
SAFETY
Safety 03 of 04 - 10/08/2021

WELDING AND CUTTING
SPARKS CAN CAUSE
FIRE OR EXPLOSION.
6.a. Remove fire hazards from the welding area. If
this is not possible, cover them to prevent the welding sparks
from starting a fire. Remember that welding sparks and hot
materials from welding can easily go through small cracks and
openings to adjacent areas. Avoid welding near hydraulic lines.
Have a fire extinguisher readily available.
6.b. Where compressed gases are to be used at the job site, special
precautions should be used to prevent hazardous situations.
Refer to “Safety in Welding and Cutting” (ANSI Standard Z49.1)
and the operating information for the equipment being used.
6.c. When not welding, make certain no part of the electrode circuit is
touching the work or ground. Accidental contact can cause
overheating and create a fire hazard.
6.d. Do not heat, cut or weld tanks, drums or containers until the
proper steps have been taken to insure that such procedures
will not cause flammable or toxic vapors from substances inside.
They can cause an explosion even though they have been
“cleaned”. For information, purchase “Recommended Safe
Practices for the Preparation for Welding and Cutting of
Containers and Piping That Have Held Hazardous Substances”,
AWS F4.1 from the American Welding Society
(see address above).
6.e. Vent hollow castings or containers before heating, cutting or
welding. They may explode.
6.f. Sparks and spatter are thrown from the welding arc. Wear oil free
protective garments such as leather gloves, heavy shirt, cuffless
trousers, high shoes and a cap over your hair. Wear ear plugs
when welding out of position or in confined places. Always wear
safety glasses with side shields when in a welding area.
6.g. Connect the work cable to the work as close to the welding area
as practical. Work cables connected to the building framework or
other locations away from the welding area increase the
possibility of the welding current passing through lifting chains,
crane cables or other alternate circuits. This can create fire
hazards or overheat lifting chains or cables until they fail.
6.h. Also see item 1.c.
6.I. Read and follow NFPA 51B “Standard for Fire Prevention During
Welding, Cutting and Other Hot Work”, available from NFPA, 1
Batterymarch Park, PO box 9101, Quincy, MA 022690-9101.
6.j. Do not use a welding power source for pipe thawing.
CYLINDER MAY EXPLODE IF
DAMAGED.
7.a. Use only compressed gas cylinders containing
the correct shielding gas for the process used
and properly operating regulators designed for
the gas and pressure used. All hoses, fittings,
etc. should be suitable for the application and
maintained in good condition.
7.b. Always keep cylinders in an upright position securely chained to
an undercarriage or fixed support.
7.c. Cylinders should be located:
• Away from areas where they may be struck or subjected
to physical damage.
• A safe distance from arc welding or cutting operations
and any other source of heat, sparks, or flame.
7.d. Never allow the electrode, electrode holder or any other
electrically “hot” parts to touch a cylinder.
7.e. Keep your head and face away from the cylinder valve outlet
when opening the cylinder valve.
7.f. Valve protection caps should always be in place and hand tight
except when the cylinder is in use or connected for use.
7.g. Read and follow the instructions on compressed gas cylinders,
associated equipment, and CGA publication P-l, “Precautions for
Safe Handling of Compressed Gases in Cylinders,” available from
the Compressed Gas Association, 14501 George Carter Way
Chantilly, VA 20151.
FOR ELECTRICALLY
POWERED EQUIPMENT.
8.a. Turn off input power using the disconnect
switch at the fuse box before working on
the equipment.
8.b. Install equipment in accordance with the U.S. National Electrical
Code, all local codes and the manufacturer’s recommendations.
8.c. Ground the equipment in accordance with the U.S. National
Electrical Code and the manufacturer’s recommendations.
Refer to
http://www.lincolnelectric.com/safety
for additional safety information.
SAFETY
Safety 04 of 04 - 10/08/2021

2
SAFETY
LAMP KIT WITH ARC SENSOR
As a rule of thumb, for many mild steel electrode, if the air is visibly
clear and you are comfortable, then the ventilation is generally
adequate for your work. The most accurate way to determine if the
worker exposure does not exceed the applicable exposure limit for
compounds in the fumes and gases is to have an industrial hygienist
take and analyze a sample of the air you are breathing. This is
particularly important if you are welding with stainless, hardfacing or
Special Ventilation products. All incoln MSDS have a maximum fume
guideline number. If exposure to total fume is kept below that
number, exposure to all fume from the electrode (not coatings or
plating on the work) will be below the T V.
There are steps that you can take to identify hazardous substances in
your welding environment. Read the product label and material safety
data sheet for the electrode posted in the work place or in the
electrode or flux container to see what fumes can be reasonably
expected from use of the product and to determine if special
ventilation is needed. Secondly, know what the base metal is and
determine if there is any paint, plating, or coating that could expose
you to toxic fumes and/or gases. Remove it from the metal being
welded, if possible. If you start to feel uncomfortable, dizzy or
nauseous, there is a possibility that you are being overexposed to
fumes and gases, or suffering from oxygen deficiency. Stop welding
and get some fresh air immediately. Notify your supervisor and co-
workers so the situation can be corrected and other workers can
avoid the hazard. Be sure you are following these safe practices, the
consumable labeling and MSDS to improve the ventilation in your
area. Do not continue welding until the situation has been corrected.
N TE: The MSDS for all Lincoln consumables is available on Lincoln’s web-
site: www.lincolnelectric.com
Before we turn to the methods available to control welding fume
exposure, you should understand a few basic terms:
Natural Ventilation is the movement of air through the
workplace caused by natural forces. Outside, this is usually
the wind. Inside, this may be the flow of air through open
windows and doors.
Mechanical Ventilation is the movement of air through the
workplace caused by an electrical device such as a portable
fan or permanently mounted fan in the ceiling or wall.
Source Extraction ( ocal Exhaust) is a mechanical device
used to capture welding fume at or near the arc and filter
contaminants out of the air.
The ventilation or exhaust needed for your application depends upon
many factors such as:
• Workspace volume
• Workspace configuration
• Number of welders
• Welding process and current
• Consumables used (mild steel, hardfacing, stainless, etc.)
• Allowable levels (T V, PE , etc.)
• Material welded (including paint or plating)
• Natural airflow
Your work area has adequate ventilation when there is enough
ventilation and/or exhaust to control worker exposure to hazardous
materials in the welding fumes and gases so the applicable limits for
those materials is not exceeded. See chart of T V and PE for Typical
Electrode Ingredients, the OSHA PE (Permissible Exposure imit), and
the recommended guideline, the ACGIH T V (Threshold imit Value),
for many compounds found in welding fume.
Ventilation
There are many methods which can be selected by the user to
provide adequate ventilation for the specific application. The following
section provides general information which may be helpful in
evaluating what type of ventilation equipment may be suitable for
your application. When ventilation equipment is installed, you should
confirm worker exposure is controlled within applicable OSHA PE
and/or ACGIH T V. According to OSHA regulations, when welding and
cutting (mild steels), natural ventilation is usually considered
sufficient to meet requirements, provided that:
1. The room or welding area contains at least 10,000 cubic feet
(about 22' x 22' x 22') for each welder.
2. The ceiling height is not less than 16 feet.
3. Cross ventilation is not blocked by partitions, equipment, or
other structural barriers.
4. Welding is not done in a confined space.
Spaces that do not meet these requirements should be equipped with
mechanical ventilating equipment that exhausts at least 2000 CFM of
air for each welder, except where local exhaust hoods or booths, or
air-line respirators are used.
Important Safety ote:
When welding with electrodes which require special
ventilation such as stainless or hardfacing (see
instructions on container or MSDS) or on lead or
cadmium plated steel and other metals or coatings which
produce hazardous fumes, keep exposure as low as
possible and below exposure limit values (PEL and TLV)
for materials in the fume using local exhaust or
mechanical ventilation. In con ned spaces or in some
circumstances, for example outdoors, a respirator may
be required if exposure cannot be controlled to the PEL
or TLV. (See MSDS and chart of TLV and PEL for Typical
Electrode Ingredients.) Additional precautions are also
required when welding on galvanized steel.

3
SAFETY
LAMP KIT WITH ARC SENSOR
BIBLIOG APHY AND SUGGESTED EADING
ANSI Z87.1, Practice for Occupational and Educational Eye and Face
Protection, American National Standards Institute, 11 West 42nd
Street, New York, NY 10036.
Arc Welding and Your Health: A Handbook of Health Information for
Welding. Published by The American Industrial Hygiene Association,
2700 Prosperity Avenue, Suite 250, Fairfax, VA 22031-4319.
NFPA Standard 51B, Cutting and Welding Processes, National Fire
Protection Association, 1 Batterymarch Park, P.O. Box 9146, Quincy,
MA 02269-9959.
OSHA General Industry Standard 29 CFR 1910 Subpart Q. OSHA
Hazard Communication Standard 29 CFR 1910.1200. Available from
the Occupational Safety and Health Administration at
http://www.osha.org or contact your local OSHA office.
The following publications are published by The American Welding
Society, P.O. Box 351040, Miami, Florida 33135. AWS publications
may be purchased from the American Welding society at
http://www.aws.org or by contacting the AWS at 800-443-9353.
ANSI, Standard Z49.1, Safety in Welding, Cutting and Allied
Processes. Z49.1 is now available for download at no charge at
http://www.lincolnelectric.com/community/safety/ or at the AWS
website http://www.aws.org.
AWS F1.1, Method for Sampling Airborne Particulates Generated by
Welding and Allied Processes.
AWS F1.2, aboratory Method for Measuring Fume Generation Rates
and Total Fume Emission of Welding and Allied Processes.
AWS F1.3, Evaluating Contaminants in the Welding Environment: A
Strategic Sampling Guide.
AWS F1.5, Methods for Sampling and Analyzing Gases from Welding
and Allied Processes.
AWS F3.2, Ventilation Guide for Welding Fume Control
AWS F4.1, Recommended Safe Practices for the Preparation for
Welding and Cutting of Containers and Piping That Have Held
Hazardous Substances.
AWS SHF, Safety and Health Facts Sheets. Available free of charge
from the AWS website at http://www.aws.org.
Supplemental Information:
(*) Not listed. Nuisance value maximum is 10 milligrams per cubic
meter. PEL value for iron oxide is 10 milligrams per cubic meter.
TLV value for iron oxide is 5 milligrams per cubic meter.
(**) As respirable dust.
(*****) Subject to the reporting requirements of Sections 311, 312,
and 313 of the Emergency Planning and Community Right-
to-Know Act of 1986 and of 40CFR 370 and 372.
(b) The PEL for chromium (VI) is .005 milligrams per cubic meter as
an 8 hour time weighted average. The TLV for water-soluble
chromium (VI) is 0.05 milligrams per cubic meter. The TLV for
insoluble chromium (VI) is 0.01 milligrams per cubic meter.
(c) Values are for manganese fume. STEL (Short Term Exposure
Limit) is 3.0 milligrams per cubic meter. SHA PEL is a ceiling
value.
(****) The TLV for soluble barium compounds is 0.5 mg/m3.
TLV and PEL values are as of ctober 2013. Always check Safety
Data Sheet (SDS) with product or on the Lincoln Electric website at
http://www.lincolnelectric.com
LISTED BELOW A E SOME TYPICAL ING EDIENTS IN WELDING ELECT ODES AND
THEI TLV (ACGIH) GUIDELINES AND PEL (OSHA) EXPOSU E LIMITS
ING EDIENTS CAS No. TLV mg/m3PEL mg/m3
Aluminum and/or aluminum alloys (as AI)***** 7429-90-5 1.0 15
Aluminum oxide and/or Bauxite***** 1344-28-1 1. 0 5**
Barium compounds (as Ba)***** 513-77-9 0.5 0.5
Chromium and chromium alloys or compounds (as Cr)***** 7440-47-3 0.5(b) 0.5(b)
Hexavalent Chromium (Cr VI) 18540-29-9 0.05(b) .005(b)
Copper Fume 7440-50-8 0.2 0.1
Cobalt Compounds 7440-48-4 0.02 0.1
Fluorides (as F) 7789-75-5 2.5 2.5
Iron 7439-89-6 10* 10*
Limestone and/or calcium carbonate 1317-65-3 10* 15
Lithium compounds (as Li) 554-13-2 15 10*
Magnesite 1309-48-4 10 15
Magnesium and/or magnesium alloys and compounds (as Mg) 7439-95-4 10* 10*
Manganese and/or manganese alloys and compounds (as Mn)***** 7439-96-5 0.02 5.0(c)
Mineral silicates 1332-58-7 5** 5**
Molybdenum alloys (as Mo) 7439-98-7 10 10
Nickel***** 7440-02-0 0.1 1
Silicates and other binders 1344-09-8 10* 10*
Silicon and/or silicon alloys and compounds (as Si) 7440-21-3 10* 10*
Strontium compounds (as Sr) 1633-05-2 10* 10*
Zirconium alloys and compounds (as Zr) 12004-83-0 5 5

4
LAMP KIT WITH ARC SENSOR
TABLE OF CONTENTS
PAGE
Installati n ..................................................................................................................................................................
Technical Specifications................................................................................................................................................5
Safety Precautions........................................................................................................................................................ 6
General Description.......................................................................................................................................................6
Installing the amp Kit...................................................................................................................................................7
Operati n ..................................................................................................................................................................
Safety Instructions...................................................................................................................................................... 11
Operating Instructions.................................................................................................................................................11
Maintenance.................................................................................................................................................................
Cleaning/Replacing the Spatter Guard......................................................................................................................... 12
Replacing the Halogen Bulb........................................................................................................................................ 12
Tr ublesh ting............................................................................................................................................................
Troubleshooting Chart.................................................................................................................................................13
Wiring Diagrams...........................................................................................................................................................
Wiring Diagram for Prism 2400 Fan with K1669-2 amp Kit......................................................................................14
230V Wiring Diagram for Wall Mounted Systems using K1750-1 230V Conversion Kit.................................................15
PARTS LIST ............................................................................................................... PARTS.LINCOLNELECTRIC.COM
CONTENT/DETAI S MAY BE CHANGED OR UPDATED WITHOUT NOTICE. FOR MOST CURRENT INSTRUCTION MANUA S, GO
TO PARTS. INCO NE ECTRIC.COM.

5
INSTALLATIONLAMP KIT WITH ARC SENSOR
TECHNICAL
SPECIFICATIONS
TECHNICAL SPECIFICATIONS -
K1699-4 - Lamp Kit with Arc Sensor for Prism 2400
K1699-10 - Lamp Kit with Arc Sensor for Prism 4200
AD1221 - Lamp Kit with Arm Control Box for wall
mounted systems
NOTE: Technical Specifications are subject to change without prior notice. Specifications and guarantees are
valid only when specified spare parts and filters are used.
LAMP KIT
Operatin
Volta e 24 VAC
Bulb HA OGEN, 35W
K1669-4
Operatin
Volta e/Current
115 V, 1~, 60 Hz, 16 A
230 V, 1~, 50 Hz, 8 A
K1669-10
Operatin
Volta e/Current 230 V, 3~, 50 Hz, 6.8 A
AD1221
Operatin
Volta e/Current 115 V / 230 V, 50/60 Hz, ~1 A
WEIGHT
K1669-4
K1669-10 12 BS. (5.5 KG)
AD1221 15 BS. (6.8 KG)
AMBIE T CO DITIO S
Min.
Temperature 41°F (5°C)
Max.
Temperature 104°F (40°C)
Max. Rel.
Humidity 80%

6
INSTALLATIONLAMP KIT WITH ARC SENSOR
Read this entire installation section before you start
installation.
Safety Precautions
Do not attempt to use this equipment until you have
thoroughly read all installation, operating and maintenance
information supplied with your equipment. They include
important safety precautions and detailed operating and
maintenance instructions.
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts such as
internal wiring.
• Turn the input power off at the fuse box
before working on this equipment.
• Have a qualified person install and service this equipment.
MOVI G PARTS can injure.
• Do not operate without extraction arm
installed.
• Keep away from moving parts.
Select Suitable location
• Inspect the product and check it for damage. Verify the
functioning of the safety features.
• During use, always use Personal Protective Equipment (PPE)
to avoid injury. This also applies for persons who enter the
work area.
• Check the working environment. Do not allow unauthorized
persons to enter the working environment.
• Protect the product against water and humidity.
• Make sure the room is always sufficiently ventilated; this
applies especially to confined spaces.
The installer is responsible for following local
safety codes and regulations.
Before drilling, verify locations of existing gas, water, or
electrical conduits.
GeneRal DeScRiPtion
The amp Kit incorporates a work lamp with hood-mount switches
for both the lamp and the Stationary Extraction Fan. The 35W
lamp fits in the hood of the arm, to provide a convenient,
positionable light at the workspace. The switch for the lamp is
hood-mounted, for accessibility. The amp Kit also includes a
switch at the hood for the Extraction Fan.
The Automatic Start/Stop Arc Sensor provides automatic switching
on and off of the Fan when the sensor detects the arc flash.
This manual includes information on installation of the amp Kit
with Auto Start/Stop Arc Sensor. The amp Kit is to be installed
after the Arm is completely assembled and mounted with the Wall
Bracket and Fan.
For information on installation of a complete wall-mounted system,
refer to the Prism 2400 and/or Prism 4200 Fan manual.
The amp Kit with Arc Sensor for Wall-Mounted Systems includes:
• amp Kit
• Cable
• Control Box
• Instruction Manual
WA NING
WARNING

7
INSTALLATIONLAMP KIT WITH ARC SENSOR
Only qualified personnel should install, use or service this
equipment.
inStallinG tHe laMP Kit witH aRc SenSoR
The K1669-4 amp Kit with Arc Sensor can be installed with:
• K1656-9 Prism 2400 Stationary Fan with a
• K1655-8 FA 3.1, 10 ft. Arm, a
•K1655-9 FA 4.1, 13 ft. Arm, or a
• K1655-10 TA 2.0, Telescopic Arm
• K1655-12 FA 2.0
• K1655-13 FA 4.1 C Fume Extraction ow Ceiling Arm
• K1655-14 TA 2.0-CW Telescopic
The K1669-10 amp Kit with Arc Sensor can be used when one of
the following extension cranes is installed, along with Prism
4200 Fan and appropriate arm:
• K1671-1 Extension Crane, 7 ft.
• K1671-2 Extension Crane, 14 ft.
Instructions in this section apply to all available combinations of
the above equipment.
See Figure A.1 Pop out the sealing plate (Item 1) on the top of the
hood with a screwdriver. Remove the screws (Item 2) and the
airflow (Item 3). Open the airflow throttle valve (Item 4).
FIGU E A.1
INSTALLING THE LAMP IN THE HOOD - See Figure A.2 Feed
the lamp and/or sensor cable(s) (Item 1) through the hole (Item 2)
in the top of the hood, and snap the lamp holder (Item 3) into
place, top end first.
FIGU E A.2
inStallinG tHe SwitcH boX anD MaKinG con-
nectionS
Feed the connecting cable through the hole in the hood. Remount
the airflow focus vanes in the open end of the hood.
See Figure A.3.
FIGU E A.3
Have a qualified electrician connect the connecting cable, lamp
cable, and sensor cable to the control board as shown in Figure
A.4. Snap the board (Item B) onto the bottom of the remote switch
(Item C). Snap the switch box (Item A) into the hood by squeezing
the front and back.
FIGU E A.4
1
2
3
WA NING
1
2
3
4
1
2
3
BK/BN
BK/BN
BK BK
RD/GN
RD/GN
WH
WH
A
B
C
TO: Auto
Sensor TO:
Lamp
TO:
Control
Box

8
INSTALLATIONLAMP KIT WITH ARC SENSOR
RoutinG tHe connectinG cable
Roll back the rubber bands on each flexible hose joint in the arm,
to allow access to the arm mechanism.
If installing with arm:
See Figure A.5 Route the connecting cable through the four cable
holders in the arm (Item A). eave plenty of slack at each hinge
(Item B) (22 in. at the middle hinge). The cable routes through
Center Bracket (Item C) between the bolt and edge protector. Wire
exits below square tube. Secure the cable in the cable holders
(Figure A.5-Inset), and use wire ties at the hinge as shown in
Figure A.6. Exit the arm through the cable hole in the rotating
hinge; use a knife to cut a small X-pattern in the grommet (Item D)
as shown in Figure A.5 Inset.
Zip Tie to this side of
square tube
(keeps wire above
spring cable)
Zip Tie to Center
Bracket Flange
Press into
Barbed Slot
in Tube Holder
A A
BD C
B
A
A
4x
FIGU E A.5
FIGU E A.6
Figure A.5 Inset
D

RoutinG tHe connectinG cable
(continued)
If installing with an LTA 2.0 Telesc pic Arm:
Route the connecting cable through the arm,
securing it to the telescopic mechanism in
two places with cable ties as shown in Figure
A.7. Exit the grommet through the hole near
the rotating hinge (Item A); use a knife to cut
an X-pattern in the grommet (Item B) as
shown in Figure A.7. oosely secure the cable
to the post of the mounting bracket (Item C)
as shown in Figure A.7.
After securing the cable to the arm
mechanism, reseal all hose joint connections
with the rubber seals.
A
9
INSTALLATIONLAMP KIT WITH ARC SENSOR
C
A
B
FIGU E A.8
FIGU E A.7
If installing with an Extensi n Crane:
After feeding the connecting cable
through the inside of arm and out the
rotating hinge (Item A), run the cable
through the extension hoses and out,
through the grommet on Prism
4200 Fan (Not Shown). See Figure
A.8.
Cable must be routed thru this
section of the aluminum part.
Failure to do so, could result in
pinching and/or damage to cable
due to arm movement.
CAUTION

10
INSTALLATIONLAMP KIT WITH ARC SENSOR
inStallinG tHe contRol boX; K1669-4 anD
K1669-10
Make sure Prism 2400 60Hz (K1656-9) is connected with
60Hz 115/230V power supply. Similarly Prism 2400 50Hz
(K2497-13) is connected to 50Hz 115/230V power supply.
ever connect 50Hz supply to 60Hz Fan and vice versa.
Mount the connection box to the wall using four screws (not
included) as shown in Figure A.9.
Have a qualified electrician make the remaining connections
inside the Control Box per the wiring diagram in this manual.
(NOTE the orientation of the control box when referencing Figure
A.10, and the wiring diagram).
Connect the mains, power cord, motor cable and the lamp kit
cable as per the wiring diagram in this manual. (Motor cable and
power cord is not included in the kit)
Make sure the transformer tapping to match with the power
supply voltage.
Make sure the overload / thermal relay is set to following limits,
Prism 2400 115V 1ph : 11A
Prism 2400 230V 1ph : 5.75A
Prism 4200 230V 3ph : 6.3A
FIGU E A.9
FIGU E A.10
WA NING
7.086 in (180.00 mm)
11.023 in (280.00 mm)

11
OPERATION
OPERATION
Read and understand this entire section before operating
your Lamp Kit with Arc Sensor.
Safety Precautions
Do not attempt to use this equipment until you have
thoroughly read all operating and maintenance manuals
supplied with your equipment and any related welding
machine it will be used with. They include important safety
precautions, operating and maintenance instructions and
parts lists.
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts such as
output terminals or internal wiring.
• Insulate yourself from the work and
ground.
• Always wear dry insulating gloves.
WELDI G SPARKS can cause fire
or explosion.
• Keep flammable material away.
• Do not weld upon containers which have
held combustibles.
ARC RAYS can burn.
• Wear eye, ear and body protection.
FUMES A D GASES can
be dangerous.
Although the removal of the particulate
matter from welding smoke may reduce
the ventilation requirement, concentrations
of the clear exhausted fumes and gases
may still be hazardous to health. Avoid breathing concen-
trations of these fumes and gases. Use adequate
ventilation when welding. See A SI Z49.1, "Safety in
Welding and Cutting", published by the American Welding
Society.
Only qualified personnel should operate this equipment.
ADDITIO AL SAFETY PRECAUTIO S
Always operate this equipment with the filter and arm
installed and all covers in place as these provide maximum
protection from moving parts and insure proper vacuum
operation and cooling air flow.
oPeRatinG inStRuctionS
Refer to Figure B.1:
A. Switch - Control Panel.
B. Switch with amp Symbol - Operates amp.
C. Switch with 0/I- Operates Prism 2400/Prism 4200 Fan.
FIGU E B.1
To operate fan using the item C or for the arc sensor to function,
item A shall be in ON (I) position always. However for operating
light (item B), item A can be in any position.
For optimum fume-capture, position hood within 10-15 inches
(250-400mm) of the arc.
For the arc sensor operation, keep the 0/I switch (Item C) in the 0
(OFF) position. When the sensor detects an arc, it will turn on the
fan automatically. When the sensor stops sensing an arc, the
sensor will shut down the fan after around 50 seconds.
WA NING
I
O
BC
A
LAMP KIT WITH ARC SENSOR

12
INSTALLATIONLAMP KIT WITH ARC SENSOR
inStallinG tHe contRol boX - wall MounteD
SySteMS (aD1221)
Make sure the transformer tapping to match with the power
supply voltage.
Mount the connection box to the wall using four screws (not
included) as shown in Figure A.11.
Have a qualified electrician make the remaining connections
inside the Control Box per the wiring diagram in this manual.
(NOTE the orientation of the control box when referencing Figure
A.11, and the wiring diagram).
NOTE: IF15 power shall be connected to control box only if it is
mounted next to IF15.
Connect the mains, power cord, damper control cable, IF15 Cable
and the lamp kit cable as per the wiring diagram in this manual.
(Power cord is not included in the kit)
FIGU E A.11
FIGU E A.12
WA NING
6.00 in (152.50 mm)
10.75 in (273.5 mm)

13
OPERATION
LAMP KIT WITH ARC SENSOR
OPERATION
Read and understand this entire section before operating
your Lamp Kit with Arc Sensor.
Safety Precautions
Do not attempt to use this equipment until you have
thoroughly read all operating and maintenance manuals
supplied with your equipment and any related welding
machine it will be used with. They include important safety
precautions, operating and maintenance instructions and
parts lists.
ELECTRIC SHOCK can kill.
• Do not touch electrically live parts such as
output terminals or internal wiring.
• Insulate yourself from the work and
ground.
• Always wear dry insulating gloves.
WELDI G SPARKS can cause fire
or explosion.
• Keep flammable material away.
• Do not weld upon containers which have
held combustibles.
ARC RAYS can burn.
• Wear eye, ear and body protection.
FUMES A D GASES can
be dangerous.
Although the removal of the particulate
matter from welding smoke may reduce
the ventilation requirement, concentrations
of the clear exhausted fumes and gases
may still be hazardous to health. Avoid breathing concen-
trations of these fumes and gases. Use adequate
ventilation when welding. See A SI Z49.1, "Safety in
Welding and Cutting", published by the American Welding
Society.
Only qualified personnel should operate this equipment.
ADDITIO AL SAFETY PRECAUTIO S
Always operate this equipment with the filter and arm
installed and all covers in place as these provide maximum
protection from moving parts and insure proper vacuum
operation and cooling air flow.
oPeRatinG inStRuctionS
Refer to Figure B.2:
A. Switch with amp Symbol: operates lamp
B: Switch with 0/1: Turn on fan motors and open dampers
FIGU E B.2
Mains power shall be always connected to arm control box. By
using the 0/1 switch on the arm hood, fan motor can be turned on
along with opening the damper.
WA NING
I
O
BC

14
MAINTENANCE
MAINTENANCE
This product has been designed to function without problems for a
long time with a minimum of maintenance.
cleaninG/RePlacinG tHe SPatteR GuaRD
A glass spatter guard is positioned in front of the long-life halogen
bulb to prevent spatter build-up on the face of the bulb. When the
spatter guard becomes dirty with spatter and fume, it is necessary
to clean or replace it.
• Remove holding spring by squeezing on the loose ends and
pulling it out; the glass spatter guard will drop out.
• Clean the spatter guard with glass cleaner or a mild abrasive.
If the glass becomes excessively dirty or damaged, replace it.
• Wipe the lamp housing and the plastic face of the halogen
bulb with a soft, damp cloth.
• Replace the glass spatter guard over the bulb and secure with
the holding spring.
RePlacinG tHe HaloGen bulb
When the halogen bulb burns out, it is necessary to replace it.
• Disconnect from input power before servicing this
equipment.
• Have a qualified person install and service this
equipment.
• Remove holding spring by squeezing on the loose ends and
pulling it out; the glass spatter guard will drop out.
• Push on one of the side tabs (that hold the bulb in) with a
screwdriver until the bulb assembly pops loose.
• With one finger, push through the hole directly behind the
bulb to push the bulb assembly out the front of the lamp
housing.
• Detach the bulb from the cable base.
• Push new bulb onto cable base (polarity doesn’t matter).
• Push bulb assembly past the side tabs.
• Set the spatter guard back over the bulb and secure with the
holding spring.
WA NING
LAMP KIT WITH ARC SENSOR

15
TROUBLESHOOTING
LN-25 PLC
Observe all Safety Guidelines detailed throughout this manual
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Lincoln Authorized Service Facility for technical troubleshooting assistance before you proceed.
WWW.LI COL ELECTRIC.COM/LOCATOR
PROBLEM
(SYMPTOMS)
POSSIBLE AREAS OF
MISADJUSTME T(S) RECOMME DED COURSE OF ACTIO
amp does not illuminate. Connection cable damaged or defective. Check and repair or replace if necessary.
Bulb loose or burned out. Tighten the bulb or replace it if necessary.
amp cable damaged or defective. Check and repair or replace if necessary.
amp switch damaged or defective. Check and repair or replace if necessary.
Transformer damaged or defective. Check and replace if necessary.
Fuse defective or blown. Check the fuse and replace if necessary.
Fuse Clip connections loose. Check and repair or replace fuse holder if necessary.
Control board (under switch box) loose,
damaged or defective.
Tighten board; replace if necessary.
Connection cable damaged or defective. Check and repair or replace if necessary
Fan does not start when
hood-mounted switch to “I”.
Remote I/0 switch damaged or defective. Check and repair or replace if necessary.
Fuse defective or blown. Check the fuse and replace if necessary.
Fuse Clip connections loose. Check and repair or replace fuse holder if necessary.
Control board (under switch box) loose,
damaged or defective.
Tighten board; replace if necessary.
Transformer damaged or defective. Check and replace if necessary.
Contactor damaged or defective. Check and replace if necessary.
Thermal Relay tripped (motor overload
protection).
Allow the machine to cool down for a few minutes. Reset
the Thermal Relay in the Control Box. (Check that the
Thermal Relay is set as per wiring diagram.)
Control Panel switch turned off. Turn on Control Panel switch.

16
DIAGRAMS
LAMP KIT WITH ARC SENSOR
THE LINCOLN ELECTRIC COMPANY
World's Leader in Welding and Cutting Products
Sales and Service through Subsidiaries and Distributors Worldwide
Cleveland, Ohio 44117-1199 U.S.A.
D
FC7900010440PRINT
CODE COLOR BN BROWN BL BLUE BK BLACK GN GREEN WH WHITE GND GREEN/YELLOW
RD RED
COLORCODE(IFF.APP.)
IEC60757
NOTES: N.A. MOUNTING ON DIN RAIL N.B. FIELD WIRING SHALL USE UL RATED 3C MIN 14 AWG CABLE
WITH OUTER DIAMETER BETWEEN 0.27 IN TO 0.51 IN (7.00 mm to 13.00mm)
N.C. 201,208,202B,205 SHALL BE BLACK AND 14AWG
CONTROL BOX
DISCONNECTINGMEANSANDBRANCHCIRCUIT PROTECTIONSHALLBEPROVIDEDBYTHEINSTALLER
LN
205
204B
L1 L2 L3 13 A1
CONTACTOR
OVERLOAD
RELAY
SET AT 9.25A +/-0.25A
T1 T2 T3 A2
BK
WH
TRANSFORMER
N24V
2A
G
WH
BK/BR RD/GN
ARC SENSOR
WH BL
RD
BK
BK
WH
CONN-PCB
YE/GN
BK
WH
GND
S2
S3
START CAPACITOR
201
201
207
206
N.A.
205
203
207
204A
204B
WIRING
3 CORE CABLE NOT SUPPLIED
20AWG 3 CORE CABLE
SUPPLIED
S1
209
203
209
FAN MOTOR
115VAC, I~, 60 Hz, 1HP
MOTOR
Z2
U2 U1
V2
Z1
V1
BK/BR RD/GN
134222
10 6
5
202A
202B
208
N.B.
N.B.
RD
RD
WH
BK
BK BK
BK
BK
BK
BK
202
TB
N.A.
GN
N.A.
GND
TIGHTENINGTORQUE:0.6Nm
MOTOR LAMP CONTROLLER PRISM 2400, 115V, 1~, 60Hz, 1HP
SCHEMATIC
115VAC, 60Hz, 1~
2A
A1A1 CC
OL
A2
FAN ON/OFF
ENABLE
24V
FAN MANUAL ON/OFF
ARC SENSOR
FLOOD LIGHT
C1 OL1
BK
BK
FAN MOTOR
L
N
S1
S2
S3
GND
610
N
2
13
45
TR1
X1
C1
OL1
F1
TR1
F1
