Wireless Home Audio

Stereo Speaker Kit

Wired Accessory

DMSPK50

Quick Installation Guide

Thank you for making a great decision and choosing to

purchase the Linksys by Cisco Stereo Speaker Kit.

The speakers can be used with most stereo audio amplifiers and

receivers, but are designed to be a perfect match for the

Linksys Director (DMC250).

Wireless Home Audio Product Family†

Conductor (DMC350) Director (DMC250)

Player

(DMP100)

Speakers (DMSPK50)

Controller

(DMRW1000)

Remote Control

(DMRIR500)

Docking

Station for iPod

(MCCI40)

Package Contents

2 Speakers 2 16 AWG Two-Wire

Speaker Cables

Quick Installation

Guide

Front

Tweeter

Woofer

Back

Vented Port

Opening

Red Coded Input

Terminal

(+)

Black Coded Input

Terminal

(-)

NOTE: Do not block the vented port opening, as it

will reduce the bass and/or create a rattling sound.

Introduction

This Quick Installation Guide will guide you through connecting each

two-wire cable to a speaker at one end, and your audio amplifier at

the other end. For each channel (Left and Right), you will connect the

red coded input terminal on the speaker to the red coded output

terminal of the audio amplifier, and equivalently the black to the

black.

Connecting the Speakers to the Director

To ensure proper operation and sound quality, the cables must be

connected to the speakers correctly. Do not allow any cable strands

to touch the other polarity or the rear panel of the amplifier. Make

sure that the speakers are connected to the correct Left and Right

outputs.

NOTE: If the colors are not matching at both ends, the

speakers will play out-of-phase, resulting in the reduction

of dynamics and bass and the elimination of the position

of the music or vocals in between the two speakers.

NOTE: The speakers are interchangeable and can be used

as either the left or right speaker. The terminals and the

cables are color coded for correct polarity.

Installation Overview

A Power off your Director (or other audio amplifier).

B Locate the two-wire speaker cables provided. Each two-wire

cable is color coded with a red line on one of the wires, so it is

easy to identify at both ends.

C Press down on the red coded input terminal on the back of the

speaker and insert the speaker wire with the red line.

D Press down on the black coded input terminal on the back of

the speaker and insert the speaker wire without a marking.

E Connect the other end of the speaker wire with the red line to

the appropriate L(left) or R(right) red coded output terminal

on the Director.

F Connect the other end of the speaker wire without any

marking to the L(left) or R(right) black coded output that

pairs up with the terminal used in the previous step.

G Repeat steps C-F to connect the other speaker.

1 Connecting the Speakers

The speakers can be placed on stands, in bookshelves or on cabinets. A larger stereo image can be created by separating the position of the

speakers. Ideally the speakers should be placed at listening height, in a symmetrical triangle with the listening position.

Place the speakers approximately 1 foot (0.3 m) from the rear wall or object. The speakers should be placed a minimum of 3 feet (1m) away from

the side walls and the ceiling above to reduce reflections.

1m/3ft

Minimum Clear Space to Ceiling and Side Walls

2 Enhancing Your Sound

Avoid sound reflections in front of the speaker by aligning the front edge of the speaker with the edge of the surface it has been placed on. The

back of the speakers have a vented port opening. Do not block the vented port opening, as it will reduce the bass and/or create a rattling sound.

An equal distance to the corners and side walls for both speakers will give the most natural and precise reproduction. Optimize the listening

distance to the speakers depending on the room acoustics and reflecting walls.

Optimizing High Frequencies

Adjust the angle of the speakers towards the center listening position for preferred high frequency level and soundstage depth.

Optimizing Bass Level

To increase your bass response, place your speakers closer to the walls and corners.

Notes on Speaker Terminals and Cabling

The input terminals on the speakers accept high performance cables with a thickness of up to 4 mm²/10AWG. Your speakers come with a pair of

1.5mm/16AWG speaker cables matching the speaker terminals and most amplifiers. If you need longer cables, consult your salesperson or retail

store for advice on which cables best match your listening environment.

NOTE: The Director accepts a maximum 1.5 mm²/16AWG cable.

The exposed wires at each end should be 1/3" (8 mm), and the strands may not be split up. The strands should all be inserted into the terminal.

Congratulations! Installation is complete.

2 Enhancing Your Sound

I am not hearing any sound.

•Make sure that the speaker wires are properly inserted into the speaker terminals and the amplifier connections.

•Verify that the amplifier is plugged in and powered on.

•Make sure that the amplifier is not muted and that the volume is up.

•Check the documentation for the amplifier for additional troubleshooting tips.

Sound is only coming out of one speaker.

•Make sure that the L/R balance on your amplifier is adjusted correctly.

•Check the cabling between the speaker and the amplifier.

The vocal or music positioning seems out of place.

•Make sure that the speaker cables are properly connected. They should be going from a red output terminal on the amplifier to a red input

terminal on the speakers and from a black output terminal on the amplifier to a black input terminal on the speakers.

•Make sure you’ve followed all of the guidelines for placement and positioning.

•Check the documentation for the amplifier for additional troubleshooting tips.

WEB: If you need additional support, contact us

on the web at www.linksys.com/support

Troubleshooting

Make your music fun again.

Thank you for purchasing the Linksys by Cisco Speaker Kit.

We hope you enjoy hours of rich, quality sound.

Phone Support (North America)

866-509-7452

Website

www.linksysbycisco.com

Support Site

www.linksysbycisco.com/support

RMA (Return Merchandise Authorization)

www.linksysbycisco.com/warranty

Sales Information

800-546-5797 (800-LINKSYS)

In an effort to save printed paper, User Guides are

available as a download at the following web address:

www.linksysbycisco.com/wirelesshomeaudio/ug

Refer to the User Guide for the Director or Conductor

for additional information and troubleshooting.

For additional information on the Linksys by Cisco

Wireless Home Audio products, visit the following

web address:

www.linksysbycisco.com/wirelesshomeaudio
