Lisheng DVB600 User manual

DIGITAL TV RECEIVER
User's manual

•
for your future reference.
Please read the manual carefully before use and keep it Safe
11
Important safety instructions:
• Thank you for purchasing this product.
DVB-T RECEIVER
•
•
•
•
• Design and specifications are subject to change without
notice.
• The illustrations in this manual may appear different from
the actual product due to printing conditions.
The power input is DC+10V~14V.
Do not place it near a heater.
Do not use liquid or aerosol cleaners.
Use a light damp cloth for cleaning.
Do not open or remove cover. Refer all servicing to qualified
service personnel.

11
Table of Content:
Main Features:
Front and Rear Panel: . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Remote Control Unit (RCU): . . . . . . . . . . . . . . . . . . . . .3
Basic Functions: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
DIGITAL TV: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
USB MEDIA PLAY: . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Games: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Trouble Shooting: . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
SPECIFICATIONS: . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
DVB-T RECEIVER

11
Main Features:
1
DVB-T RECEIVER
•
•
•
•
•
•
•
•
•
•
•
•
Fully compliant with MPEG-2 and DVB-T standards.
PIG(Picture in Graphic) support.
Channel editing function (Favorite, Moving. Locking. Delete).
Automatic and manual search.
Stores over 1000 channels.
Provide electronic program guide (EPG) (option)
Easy software upgrade.
Timer function automatically turns on/off by setting function.
OSD Teletext and VBI Teletext support.
Support language options (English, Deutsche, French,
Swedish, Portuguese, Finland, Netherlandish, Czech, Greece,
Danish, Turkish, Italian and Spanish total 13 Languages).
USB Supports the play of JPGE/MP3/MP4 play (AVI/MPG/
DAT/VOB) and software upgrade.
Remark some special USB and MP4 format can not fully
support.
The following have been packed in your receiver box:
• User's manual x 1
• Remote control unit x 1 (RCU)
• Extended R/C box x 1
• A/V wire x 1
• Power supply wire x 1
Features
Accessories

11
2
DVB-T RECEIVER
Front and Rear Panel:
EXTENDED
R/C BOX
USB AUDIO L/R
INPUT
VIDEO
INPUT
IR
RECEIVER
POWER
LED
ACC: Car Engine Key (Red)
BATT: +10~14V DC Power supply input (Yellow)
STANDBY: +10~14V DC, 2.5Amp output (Blue)
GND: Power supply ground (Black)
•
connect ACC wire to car ACC switch.
• For home use: Put BATT and ACC wire together and
connect to +10~14V DC.
• DC output ground, connect to the device GND with which use
the DC +10v~14V output.
For car use: Connect the BATT wire to car battery and

11
3
Remote Control Unit (RCU):
- POWER :
Switch the receiver between stand-by
& on modes
- MUTE :
Mute the audio output
- NUMERIC KEYS(0~9):
For direct entry of channel number or
input of alphanumeric characters
- TXT:
Display on the teletext contents of the
viewed channel, if teletext is transmitted
- TV/RADIO(GREEN):
Switch between TV and radio mode
- FAV (RED):
Select the favorite or all channels
- TV/AV:
No function
- MENU:
Access the main menu
- AUDIO:
Switch the audio language if
transmitting more then one language
and Select the different audio modes
- EXIT:
To return to previous status or exit
- CH( / ):
Change channels sequentially up or
down in viewing mode and move to the
next higher or lower item in the menu
SU B.
EP G TX T
AU DIO SCAN
FAV
PG DN
PG UP
TV-RADIO
TV-AV
INFO
BACK
MENU
CH+
VOL +VOL -
CH -
PAUSE
EXIT
OK
DVB-T RECEIVER

11
4
Remote Control Unit (RCU):
SU B.
EP G TX T
AU DIO SCAN
FAV
PG DN
PG UP
TV-RADIO
TV-AV
INFO
BACK
MENU
CH+
VOL +VOL -
CH -
PAUSE
EXIT
OK
- VOL( / ):
Alter the Audio output level up or down
in viewing mode or move to the left or
right item in the menu
- OK/LIST:
Select an item or confirm a choice.
A list will enter the channel in viewing
mode
- EPG (Electronic Program Guide):
Call up the EPG function
- INFO:
Display information on viewed channel
- PgUP/ PgDN:
Move up/down a page in the channel
list. Shower movie playing speed while
playing .
- BACK(YELLOW):
Go back to the previously viewed
channel
- PAUSE(BLUE):
Press once to pause the screen
picture, press once again to go to
the normal mode
-SUB. :
Switch the subtitle on if the subtitle is
transmitted on this channel
-SCAN:
Searching all channel quickly
DVB-T RECEIVER

11
Basic Functions:
5
1. Enter into DVB system
It will enter DVB mode as soon as system power on, shows the
system interface while none TV/RADIO programs in the database.
Enter into system and power on-off
It will continue to play the last est program before previous
power off if the database having and TV. or RADIO program.
2. Power on
When it is “STANDBY” mode, press “POWER” to power on.
3. Power off
When it is running, press “POWER” will enter into “STANDBY”
mode.
Volume adjustment and Mute
1.Press “VOL+/-”to adjust volume when system is in normal playing
mode: and it will show volume bar on the image.
2.Press“MUTE”to enter into the mode when normally playing and
repress“MUTE”to back the normal state.
DVB-T RECEIVER
TV/RADIO Programs switch
Press “TV/RADIO” to switch the programs when it is in full screen.
press key “INFO” to show the information of current programs
when it is in normal playing state. Press again to show more
detail information.
Display information of programs

11
6
1. Press number keys to input program number.
2. If there are some favorite programs that been set up, just press
“FAV” to enter into the favorite program list:
Press “CH+/-” to select favorite program, Press “OK” affirm the
selection, press “EXIT” to hide menu.
1. Press “CH+/-” to switch to the previous or next program.
2. Press “OK” to switch to the speediness program list, press
“VOL+/-” to select different program class; press “ CH+/-” to
select program.
Press “OK” to affirm program Selection, press “EXIT” to hide
menu.
Station switch
Press key “RECALL” under state of full-screen to return to the
previous program played.
Program return
Basic Functions:
DVB-T RECEIVER
Subtitle
1. Subtitle is defaulted to be off; to see the capitation information,
press the “SUB-TITLE” key on the remote controller to enter the
subtitle menu of the current programs.
2. Press “VOL+/-” key to choose whether to open Subtitle, press
“CH+/-” key move upward and downward to choose language.

11
7
1. You can press key “EPG” on the remote controller to enter into the
EPG page the bottom Line shows hint information for keys,
corresponding to the colors on the remote controller:
RED, GREEN, YELLOW, BLUE;
Press “VOL+/-” to switch between Tab 4 and Tab 5 .
2. Press “GREEN” key to enter into Weekly Mode to display the
programs and program information in different time ranges of the
currently program list within one week.
Electronic programs guide(EPG)
Basic Functions:
DVB-T RECEIVER
(1). Press “PGUP” & “PGDW” key to switch between Sunday—Saturday
in Tab 3;
(2). Press “CH+/-” key to move upward and downward to switch
between the different programs in Tab 5;
(3). Press “VOL+/-” key to choose to view the program information in
different time ranges in Tab 6.
(4). When the cursor stop in Tab 5. press the yellow key to choose the
detailed information corresponding to the current program.
(5). When the cursor stop on Tab 5 of Figure 3.6 and Tab 3.7 , press
the blue key to enter Wake up Timer menu to book programs.
(6). Press “EXIT” to exit from EPG.
