Liton DL340 Series User manual

Figure B
SAVE THESE INSTRUCTIONS
Tightening reflector (WFL only)
Page 1 of 3
12042018
5461 W. Jefferson Blvd. Los Angeles, CA 90016 •P. 800-515-4880 • F. 800-972-4880 •www.liton.com Product specifications subject to change without notice.
INSTALLATION INSTRUCTIONS
CATALOG # : DL340 , DL340J
INSTALLATION INSTRUCTIONS for DL340 series fixture
READ AND UNDERSTAND ALL INSTALLATION INSTRUCTIONS BEFORE INSTALLING FIXTURE!
Reflector
LED Holder
Notch
Slots
Fixture Installation: (For Covered Ceiling Mount)
Wiring Fixture:
WARNING: Check fixture for input voltage before connecting power to fixture.
1. Connect ground wire (green or bare copper/aluminum) from the supply circuit to
the ground wire (green or bare copper) /screw/connector from the luminaire.
2. Connect the neutral (common) wire from the power supply to the neutral wire from
the luminaire.
3. Connect the main voltage supply wire (line/lead) from the power supply to the line
(lead) wire from the luminaire.
4. Secure connection using UL Listed wire nuts/connectors and then with UL Listed
Electrical tape (by others), as required, appropriate for the connection.
5. For Dimming wiring see Liton web site.
Turn just under
1/8 turn
Turn just under 1/8 turn
Figure A
FIXTURE INSTALLATION
For Covered Ceiling Mount
Required Tools:
#2 Phillips Head Screwdriver
3-1/2”
DL340 Top View with Mounting Plate holes
with 4” Octangonal j-box orientation.
(4) HOLES FOR
8-32 FLAT HEAD
SCREWS
4“ OCTAGONAL
J-BOX
3-1/2” (For 4”
Octagonal
J-Box)
2-3/4”
(For 3-1/2”
Octagonal J-Box)
Ø1-1/4" HOLE
FOR WIRES
4" Octagonal J-Box
(Shown)
Housing
Faceplate
(2) M4 Phillips Flat
Head Screws
(in Housing)
2-3/4”
Figure C
Mounting Plate &
U Bracket
Assembled
(OR 3-1/2” Octagonal
J-Box (Not Shown)
(By others)
Holes for
U Bracket
U Bracket
U Bracket
Mounting Plate
(2) 8-32 Flat Head Screws
(BY OTHERS)
(2) 8-32 Pan Head
Screws
(2) 8-32 Nuts
Ø 4-3/4"
Mounting Plate
Tightening reflector (Wide Flood reflector only) (FIGURE B):
1. If reflector is loose in fixture remove faceplate from fixture by unscrewing faceplate.
2. Make sure reflector is sitting flat on LED holder. If reflector is off LED holder align
notch on reflector to slot on LED Holder and gently press reflector on LED holder.
3. Turn reflector gently to the right (just under 1/8 turn) on LED holder until reflector
is snug. Do not over tighten.
4. Replace faceplate by screwing back faceplate on fixture. Screw Faceplate on fixture
completely to prevent water entry.
Outdoor Installation for Covered Ceiling Mount only (Damp or Wet Location)
• Danger: Always disconnect power before wiring, or
maintenance. Fixture must be installed by a qualified electrician. Do not
install in locations where water collects and/or stands for prolonged periods of
time. Fixture must always be installed according to local and national electrical
codes, rules & regulations. Fixture must be installed on a circuit protected by
Ground Fault Circuit Interrupter (GFCI).
• Warning: The joint MUST be sealed between the mounting surface (e.g.,
wall, ground, ceiling, etc.) and the fixture with an appropriate sealing / caulking
compound to provide a watertight seal. Seal all conduit opening(s) and
opening(s) from water entry. Before service ensure fixture is cool to touch.
Always ensure that all gaskets and sealing surfaces are free of dirt and debris.
LED fixture(s), LED driver(s) and LED electrical components are more precise
electrically than standard non LED products (e.g. Incandescent, Compact Fluores-
cent, H.I.D., etc.). Please follow the following guidelines /requirements when
installing LED fixture(s)/LED driver(s).
1. Install LED fixture(s) and/or LED driver(s) only on their own circuit. Do
not mix any other non LED products/fixtures (e.g., Incandescent, Compact
Fluorescent, H.I.D., etc.) with LED fixture(s)/LED driver(s) on a single
circuit.
2. Do not use any other electrical equipment (e.g., surge protectors,
photocells, etc.) that is not (rated) for use with LED fixture(s)/LED driver(s)
on the same circuit as LED fixture(s)/LED driver(s).
3. Use GFCI's (by others) on each circuit (per installation instructions)
appropriate for the installation.
4. Install remote surge protector(s) (by others, goes on the circuit with
nothing between the surge protector and the LED fixture(s)/LED driver(s) ),
if the fixture in not already installed with a surge protector, to help remove
power surges that may harm LED fixture(s), appropriate for the installation.
Periodically check and make sure that your remote surge protector(s) are
in good working order.
Wires (by others, rated
minimum 90°C) 1. Make sure supply wiring is in place before mounting fixture.
2. Mounting Plate installs directly to a 4" or 3-1/2” octagonal j-box. Make sure that mounting
surface and/or j-box (etc.) can support fixture before installing fixture on mounting surface.
3. Remove U Bracket from Housing by removing (2) M4 Phillips Flat Head Screws in Housing
Top (FIGURE A).
4. Assemble Mounting Plate and U Bracket (FIGURE A) with supplied (2) 8-32 Pan Head
Phillips Screws and (2) 8-32 nuts (FIGURE A & FIGURE C).
5. Connect the fixture wiring through the assembled Mounting Plate and U Bracket to the
supply wiring (rated minimum 90°C) in the j-box. See "Wiring Fixture" instructions below.
6. Use existing holes in the Mounting Plate and mount assembled Mounting Plate to a 4" or
3-1-2" octagonal j-box (by others) with (2) 8-32 Flat Head screws (by others, FIGURE A) and
tighten securely. If drilling new holes in Mounting Plate to mount Mounting Plate directly to a
mounting surface (or to a different j-box, FIGURE A) make sure hardware (by others) does not
interfere with anything in the top of the Housing and Mounting Plate sits flat on the top of the
Housing when secured to Housing by (2) screws. Cover newly exposed metal on the Mounting
Plate with an outdoor paint to protect it from the elements (appropriate for the application).
7. Mount Housing securely on Mounting Plate and secure with two (2) M4 flat head screws in
Housing and tighten securely with screwdriver.
8. Seal all holes/openings from water entry to junction box, wires, and/or fixture (e.g.,
Mounting surface to Mounting Plate and Mounting Plate to Housing, etc.).
NOTE: DL340 and DL340J (with dimming) has the LED driver outside the fixture, the LED driver
installs only in a 4” octagonal j-box. The DL340 and DL340J (without dimming) has the LED
driver inside the fixture and installs on a 3-1/2“ or 4” octagonal j-box.

SAVE THESE INSTRUCTIONS
CATALOG # :
READ AND UNDERSTAND ALL INSTALLATION INSTRUCTIONS BEFORE INSTALLING FIXTURE!
Page 2 of 3
12042018
5461 W. Jefferson Blvd. Los Angeles, CA 90016 •P. 800-515-4880 • F. 800-972-4880 •www.liton.com Product specifications subject to change without notice.
INSTALLATION INSTRUCTIONS
LPCMDL4 (Shown with DL340)
INSTALLATION INSTRUCTIONS for LPCMDL4 with DL340 series fixture
(pages 2 and 3 of 3)
Important: Please read and understand all instructions completely
before installing this fixture.
WARNING: Fixture installation (and use) and all electrical connections must be in
accordance with local and National Electrical Codes (N.E.C.) rules, regulations
and standards. If you are unfamiliar with installing fixture(s), accessories and/or
electrical wiring have a qualified licensed electrician install this fixture for you.
Fixture should be installed by a qualified electrician.
WARNING: RISK OF SHOCK. House electric current can cause painful shock or serious injury.
WARNING: Always disconnect power before fixture installation, wiring, or maintenance.
WARNING: Before starting the wire connections, disconnect the power by turning
off the circuit breaker or removing the fuse at the fuse panel. Turning the power off
using the light switch is not sufficient to prevent electrical shock.
This luminaire must be connected with supply wire/conductors rated at 90°C.
Most dwellings built before 1985 have supply wire rated at 60°C; consult a
qualified electrician before installing.
WARNING: Before service insure fixture is cool to touch.
WARNING: Check fixture for input voltage before connecting power to fixture.
WARNING: RISK OF SHOCK. This fixture is suitable for dry and damp locations.
For covered ceiling mount only.
WARNING: Do not install any fixture or assembly (etc.) closer than 6" from any
curtain, or similar combustible material.
Fixture must be installed on a circuit protected by Ground Fault Circuit Interrupter
(GFCI).
Install LED fixture(s)/LED driver(s) only on their own circuit. Do not mix any other
products (Incandescent, Compact Fluorescent, H.I.D. products/fixtures, etc...)
with LED fixture(s)/LED driver(s) on a single circuit.
Do not use any other electrical equipment (example: surge protector photocell,
etc.) that is not (rated) for use with LED fixture(s)/LED driver(s) on the same circuit
as LED fixture(s)/LED driver(s).
Install remote surge protector(s) (by others, goes on the circuit with nothing
between the surge protector and the LED fixture(s)/LED driver(s)), if the fixture is
not already installed with a surge protector, to help remove power surges that
may harm LED fixture(s), appropriate for the installation. Periodically check and
make sure that your remote surge protector(s) are in good working order.
• Danger: Always disconnect power before wiring, or
maintenance. Fixture must be installed by a qualified electrician. Do not
install in locations where water collects and/or stands for prolonged periods of
time. Fixture must always be installed according to local and national electrical
codes, rules & regulations. Fixture must be installed on a circuit protected by
Ground Fault Circuit Interrupter (GFCI).
• Warning: The joint MUST be sealed between the mounting surface (e.g.,
wall, ground, ceiling, etc.) and the fixture with an appropriate sealing / caulking
compound to provide a watertight seal. Seal all conduit opening(s) and
opening(s) from water entry. Before service ensure fixture is cool to touch.
Always ensure that all gaskets and sealing surfaces are free of dirt and debris.
LED fixture(s), LED driver(s) and LED electrical components are more precise
electrically than standard non LED products (e.g. Incandescent, Compact Fluores-
cent, H.I.D., etc.). Please follow the following guidelines /requirements when
installing LED fixture(s)/LED driver(s).
1. Install LED fixture(s) and/or LED driver(s) only on their own circuit. Do
not mix any other non LED products/fixtures (e.g., Incandescent, Compact
Fluorescent, H.I.D., etc.) with LED fixture(s)/LED driver(s) on a single
circuit.
2. Do not use any other electrical equipment (e.g., surge protectors,
photocells, etc.) that is not (rated) for use with LED fixture(s)/LED driver(s)
on the same circuit as LED fixture(s)/LED driver(s).
3. Use GFCI's (by others) on each circuit (per installation instructions)
appropriate for the installation.
4. Install remote surge protector(s) (by others, goes on the circuit with
nothing between the surge protector and the LED fixture(s)/LED driver(s) ),
if the fixture in not already installed with a surge protector, to help remove
power surges that may harm LED fixture(s), appropriate for the installation.
Periodically check and make sure that your remote surge protector(s) are
in good working order.
Outdoor Installation for Covered Ceiling Mount only (Damp or Wet Location)
Indoor Installation for Covered Ceiling Mount only (Dry or Damp Location)
Components / Parts (LPCMDL4 only) Tools RequiredComponents Dimensions
LARGE HEX
NUT (1)
CANOPY MOUNTING
BRACKET (CMB) (1) 5“ ADJUSTABLE
CANOPY (1)
75° MAX.
TILT
STEM (1)
12" LONG (LPCMDL412)
18" LONG (LPCMDL418)
24" LONG (LPCMDL424)
36" LONG (LPCMDL436)
48" LONG (LPCMDL448)
CANOPY MOUNTING PLATE
DIMENSIONS ARE FOR J-BOX SCREWS
(ALL SLOTS ARE 0.196” WIDE)
1-7/8”
3-1/2”
• Phillips Head Screwdriver
• Wire Connectors/Cord
(Rated at 90°C minimum
temperature)
• Hardware (screws, nuts, etc.)
• DO NOT USE POWER TOOLS.
• ONLY USE HAND TOOLS.
3-1/4“ ROUND PLATE
(#P-LPCM-DL-4-RD) (1)
CAP NUT
(2)
LARGE HEX NUT (1)
FIG. 1 FIG. 2 FIG. 3
3/1/4” ROUND
PLATE
Stem Assy
(from FIG. 1)
Stem Assy (with 3-1/4”
Round Plate)
Stem Assy Detail
STEM
Stem Assy
1. Insert Stem in Adjustable Canopy
and tighten securely on stem.
2. Assemble the Stem in the Stem Assy (FIG. 1)
through 3-1/4” Round Plate threads making
sure that the stem does not go below the
threads in round plate (see above right detail).
Tighten securely using Large Hex Nut.
3. Insert wires/cord rated Minimum 90°C (by
others) through Stem Assy (and round plate).
Wires / Cord (by others)
STEM
5“ ADJUSTABLE
CANOPY

SAVE THESE INSTRUCTIONS
CATALOG # :
READ AND UNDERSTAND ALL INSTALLATION INSTRUCTIONS BEFORE INSTALLING FIXTURE!
Page 3 of 3
12042018
5461 W. Jefferson Blvd. Los Angeles, CA 90016 •P. 800-515-4880 • F. 800-972-4880 •www.liton.com Product specifications subject to change without notice.
INSTALLATION INSTRUCTIONS
INSTALLATION INSTRUCTIONS for LPCMDL4 with DL340 series fixture
(pages 2 and 3 of 3)
LPCMDL4 (Shown with DL340)
Important: Please read and understand all instructions completely
before installing this fixture.
WARNING: Fixture installation (and use) and all electrical connections must be in
accordance with local and National Electrical Codes (N.E.C.) rules, regulations
and standards. If you are unfamiliar with installing fixture(s), accessories and/or
electrical wiring have a qualified licensed electrician install this fixture for you.
Fixture should be installed by a qualified electrician.
WARNING: RISK OF SHOCK. House electric current can cause painful shock or serious injury.
WARNING: Always disconnect power before fixture installation, wiring, or maintenance.
WARNING: Before starting the wire connections, disconnect the power by turning
off the circuit breaker or removing the fuse at the fuse panel. Turning the power off
using the light switch is not sufficient to prevent electrical shock.
This luminaire must be connected with supply wire/conductors rated at 90°C.
Most dwellings built before 1985 have supply wire rated at 60°C; consult a
qualified electrician before installing.
WARNING: Before service insure fixture is cool to touch.
WARNING: Check fixture for input voltage before connecting power to fixture.
WARNING: RISK OF SHOCK. This fixture is suitable for dry and damp locations.
For covered ceiling mount only.
WARNING: Do not install any fixture or assembly (etc.) closer than 6" from any
curtain, or similar combustible material.
Fixture must be installed on a circuit protected by Ground Fault Circuit Interrupter
(GFCI).
Install LED fixture(s)/LED driver(s) only on their own circuit. Do not mix any other
products (Incandescent, Compact Fluorescent, H.I.D. products/fixtures, etc...)
with LED fixture(s)/LED driver(s) on a single circuit.
Do not use any other electrical equipment (example: surge protector photocell,
etc.) that is not (rated) for use with LED fixture(s)/LED driver(s) on the same circuit
as LED fixture(s)/LED driver(s).
Install remote surge protector(s) (by others, goes on the circuit with nothing
between the surge protector and the LED fixture(s)/LED driver(s)), if the fixture is
not already installed with a surge protector, to help remove power surges that
may harm LED fixture(s), appropriate for the installation. Periodically check and
make sure that your remote surge protector(s) are in good working order.
• Danger: Always disconnect power before wiring, or
maintenance. Fixture must be installed by a qualified electrician. Do not
install in locations where water collects and/or stands for prolonged periods of
time. Fixture must always be installed according to local and national electrical
codes, rules & regulations. Fixture must be installed on a circuit protected by
Ground Fault Circuit Interrupter (GFCI).
• Warning: The joint MUST be sealed between the mounting surface (e.g.,
wall, ground, ceiling, etc.) and the fixture with an appropriate sealing / caulking
compound to provide a watertight seal. Seal all conduit opening(s) and
opening(s) from water entry. Before service ensure fixture is cool to touch.
Always ensure that all gaskets and sealing surfaces are free of dirt and debris.
LED fixture(s), LED driver(s) and LED electrical components are more precise
electrically than standard non LED products (e.g. Incandescent, Compact Fluores-
cent, H.I.D., etc.). Please follow the following guidelines /requirements when
installing LED fixture(s)/LED driver(s).
1. Install LED fixture(s) and/or LED driver(s) only on their own circuit. Do
not mix any other non LED products/fixtures (e.g., Incandescent, Compact
Fluorescent, H.I.D., etc.) with LED fixture(s)/LED driver(s) on a single
circuit.
2. Do not use any other electrical equipment (e.g., surge protectors,
photocells, etc.) that is not (rated) for use with LED fixture(s)/LED driver(s)
on the same circuit as LED fixture(s)/LED driver(s).
3. Use GFCI's (by others) on each circuit (per installation instructions)
appropriate for the installation.
4. Install remote surge protector(s) (by others, goes on the circuit with
nothing between the surge protector and the LED fixture(s)/LED driver(s) ),
if the fixture in not already installed with a surge protector, to help remove
power surges that may harm LED fixture(s), appropriate for the installation.
Periodically check and make sure that your remote surge protector(s) are
in good working order.
Outdoor Installation for Covered Ceiling Mount only (Damp or Wet Location)
Indoor Installation for Covered Ceiling Mount only (Dry or Damp Location)
FIG. 4 FIG. 6
J-BOX
(by others) COVERED
CEILING
Stem Assy
(from FIG. 4)
DL340
HOUSING
Wires CANOPY MOUNTING
BRACKET (CMB)
J-BOX MOUNTING
HARDWARE (BY OTHERS)
CAP NUTS (2)
DL340 Housing
with Stem Assy
(from FIG. 5)
ADJ. CANOPY
8-32
THREADED
STUDS
M4 PHILLIPS
FLAT HEAD
SCREW (2)
WARNING: Check fixture
for input voltage (and
write/record input
voltage down) before
continuing to step #9
below.
9. Place fixture housing over
Mounting Plate (MP) and align both
holes in housing with tapped holes in
3-1/4” Round Plate.
10. Tighten Phillips head screw
through housing in 3-1/4” Round
Plate (with screwdriver) until screw is
tight in housing. Do not over tighten
screws.
WARNING: Check fixture for input voltage before
connecting fixture wires to wires in the stem.
4. Unscrew Housing (TOP) from Housing (BOTTOM).
5. Feed wires/cord from Stem Assy (FIG 3) through Plug in
Housing (TOP).
6. Connect wire/conductors in the stem assembly to the fixture
wires (ground wire green or bare copper to screw/connector from
the fixture, neutral (common) wire in the stem to the neutral wire
from the fixture and the line/lead wire in the stem to the line
(lead) wire from the fixture). For Dimming wiring see Liton web
site.
7. Secure connection using UL Listed wire nuts/connectors and
then with UL Listed Electrical tape (rated minimum 90°C) (by
others, as required), appropriate for the connection.
8. Screw Housing (TOP) back on Housing (BOTTOM) completely to
seal out water entry into fixture.
M4 PHILLIPS FLAT HEAD SCREW (2)
DL340 HOUSING (BOTTOM)
PLUG, WIRE ENTRY
DL340 HOUSING (TOP)
DL340 HOUSING (TOP), TOP VIEW
FIG. 5
75° MAX.
TILT
(DL340 SHOWN FOR CLARITY)
WARNING: Check fixture for input voltage before connecting power to fixture. Connect wiring in j-box.
11. Connect the power supply wiring (from j-box) to fixture wiring (in Stem Assy) in j-box. See 11a-11e below.
11a) Connect ground wire (green or bare copper/aluminum) from the supply circuit to the ground
wire (green or bare copper) /screw/connector from the luminaire.
11b) Connect the neutral (common) wire from the power supply to the neutral wire from the luminaire.
11c) Connect the main voltage supply wire (line/lead) from the power supply to the line (lead) wire
from the luminaire.
11d) Secure connection using UL Listed wire nuts/connectors and then with UL Listed Electrical tape
(by others), as required, appropriate for the connection.
11E). For Dimming wiring see Liton web site.
12. Secure Canopy Mounting Bracket (CMB) to Covered Ceiling J-BOX (by others) using J-BOX
hardware (by others).
13. Secure Stem Assy (with DL340 attached) to Canopy Mounting Bracket (CMB) by putting Adjustable
Canopy up through 8-32 threaded studs in Canopy Mounting Bracket (CMB) and secure tightly with
supplied two (2) Cap Nuts. Hang fixture straight down. J-box can be on a ceiling sloaped/tilted to 75°
maximum.
