WIRELESS DIGITAL SECURITY CAMERA
LW2175R SERIES
QUICK START GUIDE
NOTE: Avoid installing in a location which
requires the wireless signal to pass through
cement, concrete and metal structures. This will
reduce the transmission range.
Getting Started A. Camera Setup
B. Receiver Setup
Surveillance Recorder (DVR)
with BNC inputs:
Attach the BNC connector of the
receiver directly to a video input of the
DVR.
TV with RCA Inputs:
1. Attach the included BNC/RCA
adapter to the BNC cconnector on
the receiver.
2. Attach the receiver to a composite
video input of the TV.
1Connection Options:
Connect power adaptor to local
120V AC power outlet
Mount camera stand to the wall.
13Connect one end of the camera
Power Adapter to the camera
and the other end to an
electrical outlet.
2
NOTE: If the receiver is not able to directly attach to your TV or DVR because of space constraints
or blockage of wireless signal, use the included BNC extension cable to reposition the receiver.
This Wireless Digital Security
Camera System comes with the
following components:
• Digital Wireless Color Camera*
• Camera Stand*
• Wireless Receiver*
• Power Adaptors for camera*
and receiver*
•BNC/RCA Adapter*
• 3ft BNC extension cable
•Mounting Hardware*
• Instruction Manual
• 2-way Power Splitter
(LW2175RPK2B only)
* Number of items may
vary by model. Check your
package for specific content
information.
Secure Camera to the mounting
stand. Adjust the angle of the
camera until the desired view is
set (1). Tighten the thumbscrews
to secure the desired camera
position (2).
NOTE: Wireless cameras require a power
source to operate.
NOTE: Before you install a camera, carefully plan where and how it
will be positioned, and where you will route the cable that connects the
camera to the power adaptor. Before starting permanent installation,
verify its performance by observing the image on a monitor when the
camera is positioned where it will be permanently installed.
*
Powering Multiple Receivers (LW2175RPK2B only)
Connect power adaptor
to local 120V AC power
outlet.
Connect the
power adapter
to the power
splitter cable as
shown.
Connect the ends
of the power
splitter Cable to
the receiver.
Connect one end of the Power Adaptor to the
receiver and the other end to an electrical outlet. ATTENTION: Make sure to first connect and power on the camera before
powering on the receiver; this will ensure a proper connection.
12
a. b.
a. b. c.
C. Powering a Single Receiver
OR
OR
www.lorextechnology.com
LW2175R Series QSG_EN_R2 Page 1

It’s all on the Web
For detailed setup information, please refer to your
User’s Manual. For additional information and
accessory purchases, please visit our website
www.lorextechnology.com/support
REGISTER NOW!
TO RECEIVE 3 MONTHS
WARRANTY EXTENSION
www.lorextechnology.com/warranty
D. Receiver Overview
1. Wireless Antenna
2. Resolution* button: Press to switch
between VGA and QVGA video
resolutions.
3. Front LED: Lights up in green to indicate
power to the receiver.
4. Pair: See product manual for details on
this function.
5. BNC Connector: Connect the BNC
Connector to a DVR or BNC Extension
Cable.
©2011 Lorex Technology Inc.
As our product is subject to continuous improvement, Lorex Technology & subsidiaries
reserve the right to modify product design, specifications, prices & warranty without
notice and without incurring any obligation. E&OE
*VGA mode has a resolution of 640 X 480
pixels; QVGA mode has a resolution of
320 X 240 pixels. Use VGA mode for best
video performance. Use QVGA mode if
you need a higher video frame rate.
1
3
2 4 5
E. Multi Digital Wireless Camera Installation
When installing multiple digital wireless security cameras in the same environment (e.g. LW2175RPK2B – 2 pack
wireless cameras) maintain as much space as possible between the receivers using the included 3ft BNC extension
cables, to optimize camera performance. See illustrations below for examples of recommended 2 and 4 receiver
installations.
Scenario A: Two Wireless Cameras
• Plug one receiver directly into the back of the Digital Video Recorder. Connect the other receiver to the included
3ft BNC extension cable and plug into the Digital Video Recorder.
Scenario B: Four Wireless Cameras
• Plug one receiver directly into the back of the Digital Video Recorder. Connect the other receivers to the included
3ft BNC extension cables and plug them into the Digital Video Recorder.
NOTE: It is not recommended to install
more than 4 digital wireless security
cameras in the same environment to
maintain optimal video frame rate
performance.
BNC Ports
(Rear Panel)
Digital Video Recorder
1 2
3 4
BNC Extension Cable
BNC Ports
(Rear Panel)
Digital Video Recorder
1 2
3 4
BNC Extension Cables
Need to extend the wireless range?
Please visit www.lorexcctv.com and
search for “WL2110KIT” or check
the product manual for more details.
