RECHARGEABLE
USB DC DESK FAN 15CM
INSTRUCTION MANUAL
Model: CL-F1570
(SAVE THESE INSTRUCTIONS)

CONTENTS
IMPORTANT SAFEGUARDS .................................................................... 2
FOR YOUR SAFETY .......................................................................... 2
PRODUCT OVERVIEW............................................................................. 5
OPERATION..................................................................................................... 5
Charging the Battery .......................................................................... 6
Safety Protection Device .................................................................... 6
Operating the fan................................................................................ 6
Adjusting angle of the fan.................................................................... 7
TECHNICAL SPECIFICATIONS................................................................. 8
CARE AND CLEANING ............................................................................. 8
PROTECTING THE ENVIRONMENT........................................................ 9
WARRANTY...............................................................................................10

IMPORTANT SAFEGUARDS
When using electrical appliances, in order to reduce the risk of fire,
electric shock and/or injury, these basic safety precautions should
always be followed:
FOR YOUR SAFETY
Read all instructions carefully, even if you are quite familiar with
the appliance.
This appliance is not intended for use by persons (including
children) with reduced physical, sensory and mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do not play with
the appliance.
Close supervision is necessary when any appliance is used by or
near children.
Take care when any appliance is used near pets.
Do not leave the charge cable connected continuously for more
than 4 hours.
Do not operate any appliance with a damaged charge cord /
connector plug; if the appliance malfunctions; or if it is dropped or
damaged in any manner.
Do not use outdoors.
Do not use any appliance for anything other than its intended use.
This product is intended for household use only.
Do not attempt to repair, disassemble or modify the appliance.
There are no user- serviceable parts.
Do not insert or allow foreign objects to enter the grille openings as
this may cause damage to the appliance and/or user.
To prevent fire or shock hazard, DO NOT expose this appliance to
rain or moisture.
Do not use fan near curtains, plants, window treatment, or where
other objects can become caught in the blades.
Do not operate with wet hands while in recharging the fan.
Do not let the charge cable hang over the edge of atable or
counter or let it come into contact with any hot surfaces.

The use of accessory attachments is not recommended by the
appliance manufacturer, apart from those supplied with this
product.
Do not operate fan in the presence of explosive and/or flammable
fumes. Do not place the fan near an open flame, cooking or other
heating appliance.
Do not place the fan close to an open window. Rain splashing on
the fan could cause an electric shock hazard.
Do not leave the appliance running or operable in a place where
young children or animals could have access to it without
supervision.
Do not use the fan without fully assembled. The fan must operate
standing upright.
To protect against fire, electrical shock and injury to persons, do
not immerse unit in water or spray with liquids.
Ventilation should not be impeded by covering the ventilation
openings. Slots and opening are provided for ventilation to ensure
reliable operation of the product and to protect it from overheating.
Do not immerse any part of the appliance in water or any other
liquid.
Place the fan on a stable level, even surface table when operating
to avoid overturning.
Switch off the appliance and unplug the USB before cleaning or
inspecting any part of the appliance.
Do not operate with a damaged charger or after the fan
malfunctions, has been dropped or damaged in any manner. DO
NOT operate the fan with a broken blade, safety guard or with any
obvious damage to the enclosure.
In the unlikely event the appliance develops a fault, stop using it
immediately and seek advice from the manufacturer.
Do not put heavy objects on the appliance.
Keep fingers, hair and clothing away from this appliance.
Do not put the unit close to heat-generating devices or near
flammable and dangerous materials.
For optimal airflow circulation, leave a distance of at least 30cm
around the appliance on every side.

Always direct the airflow in order to optimize cooling. Avoid
corners, small objects and other surfaces or objects which may
impede the airflow.
This fan includes an internal Lithium battery, do not position the fan
in a high temperature (more than 40ºC) environment or near fire.
Do not impact, squeeze the batteries.
Do not operate the fan continuously for more than 4 hours in order
to avoid overheating / permanent damage.
Warning: Do not operate without the fan grilles properly in place.
Do not use if grille becomes deformed, damaged or loosen to
avoid injury to persons.
Do not charge the fan on the carpet or flammable materials.
WARNING: Do not place the unit on or near a hot gas electric
burner.
WARNING: When using rechargeable lithium powered appliances,
basic safety precautions, should always be followed to reduce the
risk of fire, electric shock, personal injury and material damage.

PRODUCT OVERVIEW
What’s in box:
Desk fan
USB cable (not provided with power adapter)
Instruction manual
OPERATION
Remove the fan from the box, remove the packaging materials before
operation.
Set the fan base on a stable, firm desk.
Blade
Front Grille
Stand
ON/OFF - Speed Switch
Base
Fan charging
port (not shown)

Charging the Battery
You should charge the fan before using.
Connect the USB cable to a USB charging port (from a USB charging
adapter, power board or similar device - not provided) and the other
end to the fan charging port. Plug the USB charging adapter/power
board or similar device into a power outlet.
During charging, the Red LEDindicator light adjacent to the fan power
On/Off button will continually flash to indicate it is charging.
When battery is fully charged, the LEDIndicator light will change
colour and illuminate white, indicating that charging process is
completed.
Disconnect the USBcable from both the fan and charging device on
completion of the charging process, when battery is fully charged.
Safety Protection Device
The fan has a built-in Overcharging/Low voltage discharge device, that
protects the appliance against overcharging or short circuit.
In an over charging or low voltage battery discharge condition the
protection device willAuto Shut-Off the charging to the battery.
In this state, allow fan to rest for a few minutes, before switching it
back On.
Operating the fan
With the fan is fully charged, press the power On/Off/ Speed selection
button to turn the fan On.
Repeated pressing of this button will change the fan speed.
Battery charge port

Power Off/On-Speed button
Press power Off/On-Speed button Once = Low fan speed setting
Press power Off/On-Speed button Twice = Medium fan speed setting
Press power Off/On-Speed button Three times = High fan speed
setting
Press power Off/On-Speed button Four Times = Off
Adjusting angle of the fan
This fan allows for adjusting air flow angle, while tilting, Hold the fan
head with hand and gently lift or lower it to your desired angle. The
max. adjusting angle is approximately 35° from up to down.
Warning: Do not over force or press the fan head while adjusting the
angle of the fan. The fan head cannot be rotated left or right, only up or
down.

TECHNICAL SPECIFICATIONS
Rated Voltage 5V DC
Rated Power 5W
Recharge Current DC 5V 1.0A(Max.)
Capacity of Battery 1800 mAh Li-ion battery
Run Time 1-5hrs
Full Recharge Time 2.5-3h
Note: As a result of continual improvements, the design and
specifications of the product within may differ slightly to the unit
illustrated in the packaging.
CARE AND CLEANING
Always disconnect the USB cable from charging adapter, power
board or similar charging device before cleaning the fan.
Do not immerse any part of the fan, USB cable or adapter in liquids.
While cleaning the grille and fan blade, you should disassemble the
front grille and blade as below:
1. Remove the small safety screw in lower back of the grille.
2. With one hand hold the rear grille, the other hand hold front grille
and rotate the front grille in anti-clockwise to loosen it.
Loose Tight

You can use a damp-dry cloth to wipe the grille, base surface and fan
blade. Wait for the cleaned parts to completely dry before re-
installation in order to avoid water coming into contact with the fan
motor and micro USB charging port.
Avoid using detergent, spray, solvents or chemicals as these may
cause damage to the appliance.
After cleaning process is completed, re-install the front grille as per
installation method below:
1. Reposition the front grille to the back grille by aligning the locking
tabs.
2. With one hand on the rear grille and other on the front grille, rotate
the front grille to lock it in position until aligning with lock mark on
rear grille.
3. Re-tighten the small safety screw in back of rear grille.
4. Store the fan in a cool, dry place, ideally in its original packaging
while it is not in use.
PROTECTING THE ENVIRONMENT
This rechargeable desk fan incorporates a built-in a lithium battery.
The products and internal battery must not be disposed of with normal
household waste. Please recycle electrical products and batteries
according to local council regulations.
Do not put the battery in fire, do not drill or compact the battery.
CARE AND CLEANING (continued)

WARRANTY
We pride ourselves on producing a range
of quality home appliances that are both packed with features,
and completely reliable. We are so confident in our products,
we back them up with a one year warranty when accompanied by
proof of purchase.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
IM Version 1.0 – March.,2022
