Living & Co SUN9S User manual

INSTRUCTION MANUAL
Model SUN9S
UV LED Nail Lamp

CONTENTS
Overview............................................................................................. 2
Safety Instructions............................................................................. 2
Items Supplied and Product Overview ............................................. 4
Operation Procedure.......................................................................... 5
Application of Nail Coatings………………………………………......…6
Frequently Asked Questions............................................................. 7
Cleaning and Storage ........................................................................ 8
Disposal.............................................................................................. 9
Technical Data.................................................................................... 9
Troubleshooting............................................................................... 10
Warranty ........................................................................................... 11
2
13 00 886 649
A U
1

Overview
•The product is designed for fast curing of nail coatings which are
suitable for use with LED UV type lamps.
•The device is for personal domestic use only and is not intended for
commercial applications.
• The device should only be used as described in these instructions.
•The following are excluded from the warranty: all defects caused by
improper handling, damage or unauthorised attempts at repair. This
also applies to normal wear and tear.
Safety Instructions
■Never look directly at the UV light. Long term exposure may cause
damage to the eyes and skin.
■This appliance is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of
experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety.
■Children must be supervised to ensure that they do not play with the
device.
■The device must always be disconnected from the mains power when
left unattended and before cleaning it.
■In the interest of your own safety, you should inspect the device for
damage each time before you use it. It should only be used if it has
no visible signs of damage!
■If the device, the supply cable, or the mains adapter of the device
is damaged, it must be replaced by an authorized service centre, in
order to avoid any hazards.
5
A

DANGER – Danger of Electric Shock from Water!
■Do not allow the device to come into contact with liquids.
■Never immerse the device, mains cable or mains adapter in water
or other liquids and ensure that they cannot fall into water or
become wet.
■Should the device fall into water, switch off the power supply
immediately. Do not attempt to pull the device out of the water
while it is still connected to the mains power!
■Never touch the device, mains cable or mains adapter with wet
hands when these components are connected to the mains power.
WARNING – Danger of Electric Shock from Damage and
Inappropriate Use!
■The mains supply socket must be readily accessible so that the
connection to the mains can be isolated quickly in the event of a
fault or hazard.
■In the event of damage / faults (e.g. unusual noises, odour or
emission of smoke), switch the device off immediately and pull the
mains adapter out of the socket outlet.
■The device must be switched off when the mains adapter is pulled
out or inserted into the plug socket.
WARNING – Danger of Injury!
■Danger of strangulation! Make sure that the supply cable is
always kept out of the reach of small children and animals.
■The device should only be used and stored out of the reach of
children and animals.
■Protect the device from heat, naked flames, direct sunlight,
extreme temperatures, moisture and collisions.
2
13 00 886 649
A U

Items Supplied and Product Overview
PLEASE NOTE!
•Check the items supplied for completeness and possible transport
damage. If you find any damage to the components, do not use
them, contact our customer service department.
•Remove all packaging and protective coverings.
NOTE:
Due to continued product improvement, images and illustrations
in this manual may vary slightly from the product purchased. All
images in this manual are for reference purposes only. Parts are
not necessarily pictured to scale.
1 Power Indicator light
2 Lamp Status indicator light
3 Power adaptor connection socket
4 Digital timer display
5 Mains power adapter with output lead
2
3
1
4
5

Operation procedure:
1. Insert the mains power adapter into an easily accessible mains
socket outlet.
2. Connect the mains power adapter output to the connection socket
on the side of the Nail Lamp (ensure fully inserted).
3. Place the Nail Lamp on a suitable flat / level support surface such
as a bench or table-top.
4. When ready to use, simply place hand / nails under the arch, this
will activate the automatic sensor switching the LED Lamps on.
5. Upon automatic switch on, the digital timer display will start to count
in seconds to show time elapsed from commencement. The
maximum default operation time is 99 seconds, after which the unit
will automatically switch off.
6. If additional operation time is required, simply remove hand / nails
and place back into position.
7. When you have finished with the device, disconnect the mains
power adapter from the connection socket on the device.
8. Pull the mains power adapter out of the mains socket outlet.
2
13 00 886 649
A U

Application of Nail Coatings:
Prepare:
Preparing your nails properly will help the gel polish adhere to your nails.
Find a well-ventilated, clean working space for the Gel Polish application.
Do not apply outdoors or in direct sunlight as product is light sensitive.
Remove any existing polish from nails then wash and thoroughly dry
hands. Push back cuticles with the slanted edge of the manicure stick,
it's important that the cuticle area is clean and free from debris when you
apply the gel as it may stop the gel from adhering to the nail.
Tips & Tricks:
We recommend applying the gel first to both thumbs and cure them
together. Then apply the gel to the other four nails on one hand and cure.
Repeat the same steps on the other hand.
For best results, apply in thin precise layers. To remove excess product
from the brush, when opening the bottle, circle the inside neck of the
bottle with the brush.
DO NOT TOUCH NAILS AFTER CURING. The curing process will leave
a slight moisture layer on the nails at the end of each cure, but your nails
will be ready for the Colour Gel Polish or the Gel Base / Top Coat
application. The moisture layer will be removed with Gel Cleanser at the
end of the manicure. Alternatively use a lint free wipe with 91% alcohol
to wipe off the tacky layer on top of the gel polish.
Protect
Apply a thin layer of the gel base & Top coat. Make sure the gel does not
touch the cuticle or skin alongside the nails. Cap the free edge of the nail
by running the brush along the nail tip. If necessary, use a manicure stick
to clean the cuticle area before curing. Place nails into UV LED lamp and
cure for 30 seconds.
Remove the moisture layer using the gel cleanser or a lint free wipe with
91% alcohol to wipe off.
5
A

FREQUENTLY ASKED QUESTIONS:
Why Can't Nail Polish Dry Completely
A. It is normal for the primer to not dry when it is cured. It is the adhesive
between the nail and the glue and will dry on its own.
B. If too many layers have been applied or the coating is too thick this
may affect the drying time.
C.Short curing time will also lead to it not drying properly.
Why Does Nail Polish Fall Off Easily After Curing?
A.The polish is not correctly in place, which leads to weakening of the
adhesion gel.
B.After polishing, the fingernail is stained by grease or not clean
enough.
C.The gel coating is clogged and easy to become corrugated.
D.Nail adhesion is poor.
E. The metabolism of the nail causes the protective layer of grease to
fall off.
F. Improper use of the first or second layer of nail polish can also cause
it tofall off.
G. If the glue does not cover the edge of the nail, it will also cause the
nail polish to fall off.
Does This Nail Lamp Work For All Nail Polish Or JustGel?
UV and LED nail dryers only work with gel polishes. For regular nail
polish, it is suggested to use a quick-dry top coat and it leave it to air
dry.
Will This Nail Lamp Need To Have The Bulbs Replaced Over Time?
LED bulbs are not replaceable and have a lifespan of about 40,000
hours.
2
13 00 886 649
A U

Why Do You Feel Mild Pain When Drying Your Nails Using A UV
Nail Lamp:
A. The main reason is that nail polish burns during the curing process. If
you feel pain during the drying process, simply remove your fingers and
let the pain subside before putting them back under the lamp.
B. The second reason may be that if you are frequently applying nail
polish, due to the chemical reaction and curing process, this can reduce
the thickness of the nail, causing increased sensitivity.
C. Another possible reason is that some nail polish has stuck to the skin.
Cleaning and Storage
PLEASE NOTE!
■Do not use any caustic or abrasive cleaning agents for cleaning,
these can cause permanent damage to the materials.
■Keep the device in a dry location at temperatures of between 0 and
40°C.
■Make sure that the device is switched off and the mains adapter has
been removed from the socket outlet when not in use.
■Wipe down the device with a damp cloth if necessary. Then wipe it
down fully with a dry cloth.
■Keep the device in its respective packaging in a clean, dry place
which is protected from dust and sunlight and is not accessible to
children and animals.
5
A

Disposal
Dispose of the packaging material in an environmentally friendly
manner and take it to a recycling center.
Dispose of the device in an environmentally friendly manner, it
should not be added to general household waste. Dispose of it
at a recycling center for used electrical and electronic devices,
contact your local council for details if required.
Technical Data
Timer: 99 seconds Max
Power: max. 12 W
Mains Power Adaptor:
Model number: XH1200-1000LA
Input: 100–240 V ~ 50/60 Hz, 0.5 A
Output: 12V,DC, 1 A
2
13 00 886 649
A U

Troubleshooting
If the device does not work properly, check whether you are able to
rectify the problem yourself. If the problem cannot be solved with the
steps that are listed, then you may need to contact an authorized
appliance service centre.
Do not attempt to repair a defective electrical device
yourself!
Problem
Possible cause / solution
The device does
not work.
•Is the adaptor cable connector correctly
inserted into the UV lamp connection socket.
•Is the mains power adapter inserted correctly
into a socket outlet?
•Is the socket outlet defective? Try another one.
•The device has switched off automatically after
the maximum run time of 99 seconds.
Smoke emitted •Pull the mains power adapter out of the socket
outlet immediately and contact the customer
service department.
5
A

Warranty
We pride ourselves on producing a range
of quality home appliances that are both packed with features,
and completely reliable. We are so confident in our products,
we pack them up with a 1 year warranty.
Now you too can relax knowing that you are covered.
Customer Helpline NZ: 0800 422 274
This product is covered by a 1 year warranty when
Accompanied by proof of purchase.
IM Version 1.0 – June,2021
2
13 00 886 649
A U
