Livoo DOS167 User manual

User manual
WWW.LIVOO.FR
Reference: DOS167
Version: 1.4
Language: English
Rechargeable epilator

User manual
1
Thank you to have purchased a product brand LIVOO. We take great care in design,
ergonomics and simple use of our products. We hope that this product will give you complete
satisfaction.
This user manual is also available on www.livoo.fr
General Instructions
PLEASE, TAKE TIME TO READ WELL THE INSTRUCTIONS FOR USE
PARTICULARLY BEFORE THE FIRST USE.
A misuse of the appliance can damage it or hurt the user. Assure
that you use the appliance for the use for which it is designed;
we refuse any responsibilities as for the damages by an incorrect
use or a bad manipulation.
1. The appliance is only intended for the purpose described in
these operating instructions. The manufacturer cannot be
held liable for damage occurring as a result of inappropriate
or careless use.
2. This appliance is intended for household use only, not for
commercial applications.
3. This appliance can be used by children aged from 8 years and
above and by persons with reduced physical, sensory or
mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning
use of the appliance in a safe way and understand the
hazards involved.
4. Children shall not play with the appliance.
5. Cleaning and user maintenance shall not be made by
children without supervision.

User manual
2
6. Do not use this appliance nearby water!
WARNING : Do not use this appliance near bathtubs,
showers, basins or other vessels containing water.
7. Not immerse the appliance.
8. The appliance is not suitable for cleaning under an open
water tap.
9. WARNING : Keep the appliance dry.
10. The appliance is only to be used with the unit provided.
11. WARNING: For the purposes of recharging the battery, only
use the detachable supply unit provided with this appliance
reference “LW-030100EU”.
12. This appliance contains batteries that are non-replaceable.
WARNING
13. Keep children away from the packaging materials.
Risk of suffocation.
CAUTION
14. This appliance must only be supplied at safety extra low
voltage corresponding to the marking on the appliance.
15. Do not stretch, twist or kink the power cord.
16. Do not position the power cord on or pull it over sharp or
pointed objects.
17. Plug the power cable into a correctly installed mains outlet.
18. Do not open the case under any circumstances.
19. Switch the appliance off and unplug it from the power supply
after each use and before cleaning.

User manual
3
WARNING: Electric shock
20. As with every electrical appliance, use this appliance
carefully and cautiously, in order to avoid hazards due to
electric shock.
For this reason, the appliance must only be operated as
follows:
With the mains voltage specified on the appliance only
21. Switch the appliance off immediately if it is defective or nor
working properly and disconnect it from the power supply.
Do not pull the power cord or the appliance to disconnect
the power supply unit from the socket. Never hold or carry
the appliance by the power cord.
22. Keep the cables away from hot surfaces
23. Ensure that the charger, the plug and the cable do not come
into contact with water or other liquids. Therefore, use the
charger in the following conditions:
• Only inside and in dry rooms
• Only with dry hands
• Never in the bath, in the shower or near a filled basin
• Never in swimming pools, whirlpools or in the sauna
• Never outside
24. Never reach for a charger that has been submerged in water.
Disconnect it from the mains immediately.
WARNING: Fire hazard
25. There is a risk of fire if the appliance is used incorrectly or if
it is not used according to these operating instructions.

User manual
4
• Never leave the appliance unsupervised, particularly if
children are around.
• Never use the appliance under covers, such as blankets or
pillows.
• Never use the appliance in the vicinity of petrol or other
easily flammable materials
26. If the adaptor supply cord is damaged, it must be replaced
by the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard (*)
27. This appliance is intended for household use and similar
applications such as:
–staff kitchen areas in shops, offices and other working
environments
–farm houses
–by clients in hotels, motels and other residential type
environments
–bed and breakfast type environments
(*)Competent qualified electrician: after sales department of the producer or importer or any person who is
qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case
you should return the appliance to this electrician.
TECHNICAL INFORMATION
Rechargeable epilator: 3V , 1.0A. Battery: 2 x DC1.2V
Adapter: Input: 100-240V~ 50-60Hz 0.2A Max. Output: 3.0V 1.0A 3.0W
Information published
Value and precision
Unit
DELTA
BP61071
67452 Mundolsheim –France
-
-
Model identifier
DOS167P
-
Input voltage
100-240
V

User manual
5
Input AC frequency
50-60
Hz
Output voltage
3.0
V
Output current
1.0
A
Output power
3.0
W
Average active efficiency
71.59
%
Efficiency at low load (10 %)
N/A
N/A
No-load power consumption
0.052
W
CARE AND CLEANING
Clean the epilating head after each use.
Use the included brush to clean the epilating discs.
Note: do not turn the unit on while using brush.
Never immerse the appliance in water.
Do not use scouring agents, aggressive cleaners to clean the
housing.
Never try to remove epilating discs from the head.
DESCRIPTION
Epilating head cap for
Sensitive areas
Epilating head
Epilating head
Epilating head
for normal areas
as legs
Switch button
Socket and plug
cord
Main
plug
Light indicator

User manual
6
Before use:
Make sure your skin is clean, dry and free of grease.
Epilating is better after a bath or shower.
When you use the epilator for the first time. We advise you to try it on a zone of growth of hairs to familiarize
you in the process of removal of hair.
As hairs are removed from the root, the removal of hair can cause discomfort of the skin the first time as
you use the hair remover. The more you will use the epilator, the more this embarrassment will disappear.
USE
1. Insert the appliance plug into the appliance socket (1) and then the main plug into wall socket (2) but
you can use it without power cord by charging it before use (check below paragraph “charging”).
2. You have two sort of epilating head, one for sensitive zone (as armpits) and another one for normal
zone (as legs).
You can change the head by pressing the both sides button (3) and remove the head you don‘t want
to use (4).
Remove the head cap by pulling up the two sides clips, put the cap on the head you want to use by
pushing it down (until you hear a “clip”). Then you can install the head by pushing downward (5) on
the appliance.
3. Stretch your skin, place the epilator perpendicularly onto the skin.
4. Slide the button to the one or second speed (6) :
First speed is for areas with little hair growth and where there are bones such as knees.
Second speed is for areas with stronger hair growth
5. Move the epilator slowly over the skin against the direction of hair growth (7).
6. Switch off after use by sliding the button (8).
1
2
3
4
5

User manual
7
7. After you can apply a cream or lotion to reduce possible skin irritation.
8. After use and cleaning, you can store your appliance and its accessories in the storage pouch.
Charging:
Turn off the switch and connect the main plug (transformer) with the appliance, then connect the main plug
to the wall socket (the light indicator will illuminate) for 8 hours to charge the epilator completely,
It can be charged when fully released only.
Advises:
Using an epilator may cause reddening or irritation of the skin. This is a normal reaction that quickly
disappear. However, you should consult your doctor if the irritation has not disappeared within
three days.
Do not use the epilating head on face, irritated skin or skin with varicose veins, rashes, spots, moles
(with hairs) or wounds without consulting your doctor first. People with a reduced immune
response, e.g. during pregnancy, or people who suffer from diabetes mellitus, hemophilia or
immunodeficiency should also consult their doctor first.
In case of use on the zone bikini, this appliance is to be only used for the external outline. Do not
use on the most intimate zones (pubic lips).
For reasons of hygiene, we recommend you not to lend your appliance in your close environment.
Procedure to observe for battery’s end of life
The appliance batteries must be removed before discarding the equipment. Please follow the procedure
below:
Ensure that your appliance is disconnected so as to reduce any risk of electrical shock. Discharge the batteries
fully.
Remove the protection cover situated in a location where you connect the mains voltage adapter and it is
removed so as to access the batteries compartment. Carry a screwdriver to remove the screw.
Remove the batteries from the equipment. Cut the cables and tab connecting the batteries in the printed
circuit and remove them.
ATTENTION: THESE NI-MH CELLS MUST BE RECYCLED OR ELIMINATED IN ACCORDANCE WITH THE
EQUIPMENT SCRAPPING.
Do not burn, dismantle, crush or break out the batteries because they can release toxic substances.
Do not expose them to extreme temperatures.
Drop them in the batteries recycling bins designed for this purpose or return them to your retailer.
6

User manual
8
Correct Disposal of this product
(Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection systems)
The European Directive 2012/19/EU on Waste Facilities Electrical and Electronic (WEEE)
This marking shown on the product or its literature, indicates that it should not be disposed with other
household wastes at the end of its working life.
To prevent possible harm to the environment or human health from uncontrolled waste disposal, please separate this from
other types of wastes and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product or their local authority office, for details
of where and how they can take this item for environmentally safe recycling.
Photo no contractual.
Worried about the quality of his products the manufacturer reserves the right to make modifications without advance
notice.
LIVOO
BP 61071
67452 Mundolsheim - FRANCE
