no!no! PR03 User manual

User Manual
PRO
3
LIT-00088 / Rev. A00 /Sep. 2012

Contents
Safety Instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Meet no!no! Hair (Model PRO3). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Before you no!no! . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Before You Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Treatment Summary. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Thermicon™ Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Treating Facial Hair . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Technical Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
3

Safety Instructions
WARNINGS – to reduce the risk of burns or injury
• Do not use this device on the genitals
or nipples.
• Do not use this device with the
Thermicon™ Tip on the sensitive skin
around the eyes, especially the area
under the eyes.
• Do not use this device on eyebrows.
• Do not use this device on sunburned
skin, open cuts, bruises, blisters, moles
or on raised areas such as scars.
• If you have any skin condition other
than those listed above, like cold sores,
herpes, severe acne,please consult
your physician before using this device.
• Keep out of reach of children.
• Do not use deodorants, lubricants,
liquids, creams, gels, alcohol, water
etc. before use.
• Do not allow the thermodynamic wire
inside the Thermicon™ Tip to touch
your skin.
• Only use this device for its intended
purpose as described in this manual.
4

CAUTIONS - to reduce the risk of fire, electric shock, etc.
• Do not reach for a device that has fallen
into water while it is plugged in.
• Unplug the power supply before
removing it from the water. Make sure
the device is completely dry before
turning it on.
• Do not place or store device near a sink
or a bathtub.
• This device should never be left
unattended when plugged in.
• Do not use the Thermicon™ Tip if the
wire is bent or damaged in any way.
• Turn off the device before changing the
Thermicon™ Tip.
• Do not use the power supply if the cord
or plug is damaged in any way.
• Do not use this device near, or rest it
on, flammable objects such as paper or
cloth, etc.
• Always unplug the power cord from
the electrical outlet immediately after
charging and before use, cleaning or
maintenance.
• Do not place this device near water or
other liquids.
• This device should only be used with
the supplied power supply.
• Always turn off this device when you
have finished working with it.
• Do not open the outer casing of the unit.
This might harm the unit and it will void
any warranty.
5

Meet no!no! Hair (Model PRO3)
You are about to experience a totally new approach to hair removal. The no!no!
PRO3 uses new patented Pulsed Thermicon™ technology to deliver a pain-
free and effective treatment for everyone, including all hair colors and skin
types. But this is science, not magic and you’ll need time, patience and a strong
commitment to the treatment procedure. Read the User Manual and Quick
Guide thoroughly before you start, and if you have more questions, just go to
www.howtonono.com. Soon, you’ll get the smooth, professional, salon-like
results you’ve been waiting for with at-home convenience.
6

Treatment Level Button
Status Screen
On/Off
Button
Power Supply
Connection
Tip’s Socket
Signal Light Posts
Roller
Cover
Buffer
no! no! Cleaning Brush
Power supply
User Manual
Quick Guide
Thermicon™ Tips
7
Clear Panel

Before you no!no!
Get the best results and performance by learning as much as you can before you
no!no!. Below is a brief description about what to expect, what to look out for and how
each of the parts work.
• Track your progress! Before you use
no!no! the first time, study the area you
want to treat. You might even want to
take pictures or choose a small area
and count the hairs. Then, once every 2
weeks, check your progress. After 4-6
weeks, you should be able to see initial
results.
• Aroma therapy – no!no! burns hair and
burnt hair smells. But that’s how you
know its working. Try aromatic candles
or other air fresheners. An after
treatment cream or moisturizer like
no!no! Smooth will help mask the smell
even further. As less hair grows back,
the smell will also decrease.
• Test Run – Before you use no!no! the
first time, and before treating new
areas, always test no!no! on a small
section at the lowest treatment level.
• That feels weird –Some people
experience a mild tingling sensation
when they first use no!no!, especially
around sensitive areas. This sensation
will fade away completely after a few
treatments.
• For the sensitive type – If your skin
feels uncomfortable during treatment,
reduce the treatment level and/or take
short breaks after repeatedly gliding on
8

any one area.
• Keep it Smooth – When you finish your
treatment, apply a non-alcoholic lotion
or cream like no!no! Smooth to keep
your skin moisturized.
• Patience is a virtue – Initial results
take 4-6 weeks to appear.
• The first 4-6 weeks – For best results,
use no!no! at least 2-3 times a week for
the first 4-6 weeks. You don’t have to
wait for a lot of hair to grow back. Just
1mm of stubble is enough to get the
smooth results you are looking for.
• After the first 4-6 weeks – You may
have noticed that your hair isn’t growing
in as fast or as thick. You can reduce
the treatments to once or twice a week.
• Check the Thermicon™ Tips – Always
make sure the thermodynamic wire
is completely intact before use. If it is
bent or torn, replace it before your next
treatment.
• Clean the Thermicon™ Tips – Clean
the tips frequently during treatment
with the enclosed cleaning brush,
especially when working on long hair.
This will help prolong the life of your
Thermicon™ Tips.
• Stay Safe! Do not use no!no! on
sunburned skin, open cuts, bruises,
blisters, large moles or on raised areas
such as scars.
• Stay Smart! Do not use no!no! on the
genitals, nipples or on and around the
eye.
• Stay protected! Your no!no! warranty
lasts for one year on parts and service.
Keep your receipt.
9

Before You Start
Charging no!no!
Before using it for the first time, charge no!no! for at least 5 hours.
When charging is complete,
the full battery icon on the
status screen will flicker
until no!no! is removed
from the power supply.
When recharging is
necessary, the empty
battery icon will flicker.
During charging, the bars
will alternately light up, one
after the other.
Battery Status
Full Charge
Partial Charge
Low Charge
Charge Immediately
10

Skin Preparation
Thoroughly clean and dry your skin. Do not use no!no! on any area where there
might be residual gels, oils, lotions, deodorant, etc.
Assembly
1. Make sure that no!no! is
charged and the power supply is
disconnected.
2. Remove the cover.
3. Install the Thermicon™ Tip.
11

• Select the right tip.
Wide Tip
Use the wide tip for large areas
like the arms, legs and back.
Narrow Tip
Use the narrow tip for small, sensitive
areas like the face, nape of the neck
underarms and bikini line.
• Hold no!no! in one hand and the tip of your choice in the other. Make sure the no!no!
logos are facing the same direction. Then line up the posts in the socket with the
holes in the Thermicon™ Tip and gently push into place.
Posts Holes
12

• Check to make sure the tip is pushed all the way into the socket.
improperly placed properly placed
When treating facial hair, please see the Facial Hair Tips section.
To remove the Thermicon™ Tip
• Turn off the device.
• Grasp the Thermicon™ Tip by both ends.
• Gently pull out and remove.
13

4. Turn it On
• Hold the On/Off button down for
a few seconds until the status
screen appears.
On/Off button Status
Screen
5. Adjust the Treatment Level
• For your comfort, there are 3
different treatment levels.
Treatment Level
Low Medium High
Treatment
Level Icon
14

5. Adjust the Treatment Level
• For your comfort, there are 3
different treatment levels.
Treatment Level
Low Medium High
Treatment
Level Icon
• Press the Treatment Level button to
adjust levels.
Treatment
Level Button
• When first using no!no! or when starting to treat a new area, test no!no! on a
small section of skin using the lowest treatment level.
• For optimal results, raise and work at the highest level possible while still
maintaining comfort.
• If your skin feels hot or uncomfortable at anytime, STOP immediately. Lower
the treatment level and try again.
• The default treatment level is low. When you turn it on again, it will display the
last used treatment level.
15

Master the no!no! Glide
Crucial to the treatment is the no!no! Glide. To master this technique:
1. Hold no!no! at a
90º angle with the
rollers flat against
the skin.
2. Gently glide no!no! over each section against
the grain of hair growth, with the no!no! logo
in the front.
3. Always glide in a slow, steady, smooth, even motion in one direction. Do not stop in
one place.
16

4. Keep the blue light steady. If it flickers, you may be going too slowly, or too
quickly, adjust your speed accordingly.
5. You may need to go over an area more than once – but don’t over do it, 3-4
passes is enough. If there is more hair left, wait a few minutes and return
to that area if necessary.
6. Do not press down too hard with the device.
7. If you are treating facial hair, please see the Facial Tips section.
Important Note:
Do not be alarmed when the number of bars
change on the Status Screen. When you first
start to glide, the Status Screen will automatically
switch from the Treatment Level display (q) to
the Thermicon™ Tip status display (w).
Check the icon to determine what information is
being displayed.
q
w
17

Rounded areas
To work on more difficult areas, go slowly and allow
no!no! to follow the natural curve of the body. We
recommend mastering the glide on arms and legs before
moving on to the knees, elbows, face and bikini line.
NOTE: The bikini line may be extra-sensitive to temperature. If it becomes
uncomfortably warm during treatment, lower the treatment level or work on a
different area for a while. Do not go further than the bikini line.
Watch the Light
The signal light by the Thermicon
TM
Tip will guide you throughout your no!no!
treatment. It lets you know when you are working at the right speed and warns
you if the Thermicon™ Tip is torn, damaged or no longer working. The Signal Light
is only visible while you are gliding the no!no!.
18

When working at the right speed, the light will remain steady. If the light flickers,
adjust your speed accordingly.
Meaning Blue Red
Correct gliding speed On and steady Off
No Thermicon™ Tip in socket Off On
Depleted Thermicon™ Tip Off On
Damaged Thermicon™ Tip Off On
Incorrect gliding technique Off On
Incorrect gliding speed Flickering Off
No movement Off Off
Charge no!no! Flickering
Table 2: Signal Light
19

Master the Buffer
You’ve tried everything but your skin still doesn’t feel smooth? Did you remember to
buff? Without buffing, crystallized hair remains in place, giving your skin a prickly
feel. These treated hairs will eventually fall out – but why wait? Buffing exfoliates
your skin, removes crystallized hair and leaves your skin feeling silky smooth.
To Buff:
1. Hold the Buffer by the flaps.
2. Firmly rub the buffer in either
a circular or back and forth
motion over the treated area.
20
