Logicube SCSI-NG User manual

Logicube SCSI-NG User’s Manual I
SCSI-NG User’s Manual
Logicube, Inc.
Chatsworth, CA 91311
USA
Phone: [phone]
Fax: [phone]
Version: 1.0
Date: 06/10/19
MAN-SCSI-NG

Logicube SCSI-NG User’s Manual I
Limitation of Liability and Warranty Information
Logicube Disclaimer
LOGICUBE IS NOT LIABLE FOR ANY INCIDENTAL OR CONSEQUENTIAL DAMAGES, INCLUDING, BUT NOT
LIMITED TO PROPERTY DAMAGE, LOSS OF TIME OR DATA FROM USE OF A LOGICUBE PRODUCT, OR ANY
OTHER DAMAGES RESULTING FROM PRODUCT MALFUNCTION OR FAILURE OF (INCLUDING WITHOUT
LIMITATION, THOSE RESULTING FROM: (1) RELIANCE ON THE MATERIALS PRESENTED, (2) COSTS OF
REPLACEMENT GOODS, (3) LOSS OF USE, DATA OR PROFITS, (4) DELAYS OR BUSINESS INTERRUPTIONS,
(5) AND ANY THEORY OF LIABILITY, ARISING OUT OF OR IN CONNECTION WITH THE USE OR
PERFORMANCE (OR FROM DELAYS IN SERVICING OR INABILITY TO RENDER SERVICE ON ANY) LOGICUBE
PRODUCT.
LOGICUBE MAKES EVERY EFFORT TO ENSURE PROPER OPERATION OF ALL PRODUCTS. HOWEVER, THE
CUSTOMER IS RESPONSIBLE TO VERIFY THAT THE OUTPUT OF LOGICUBE PRODUCT MEETS THE
CUSTOMER’S QUALITY REQUIREMENT. THE CUSTOMER FURTHER ACKNOWLEDGES THAT IMPROPER
OPERATION OF LOGICUBE PRODUCT AND/OR SOFTWARE, OR HARDWARE PROBLEMS, CAN CAUSE LOSS
OF DATA, DEFECTIVE FORMATTING, OR DATA LOADING. LOGICUBE WILL MAKE EFFORTS TO SOLVE OR
REPAIR ANY PROBLEMS IDENTIFIED BY CUSTOMER, EITHER UNDER WARRANTY OR ON A TIME AND
MATERIALS BASIS.
Warranty
DISCLAIMER
IMPORTANT - PLEASE READ THE TERMS OF THIS AGREEMENT CAREFULLY. BY INSTALLING OR USING
LOGICUBE PRODUCTS, YOU AGREE TO BE BOUND BY THIS AGREEMENT.
IN NO EVENT WILL LOGICUBE BE LIABLE (WHETHER UNDER THIS AGREEMENT, RESULTING FROM THE
PERFORMANCE OR USE OF LOGICUBE PRODUCTS, OR OTHERWISE) FOR ANY AMOUNTS REPRESENTING
LOSS OF PROFITS, LOSS OR INACCURACY OF DATA, LOSS OR DELAYS OF BUSINESS, LOSS OF TIME, COSTS
OF PROCUREMENT OF SUBSTITUTE GOODS, SERVICES, OR TECHNOLOGY, PROPERTY DAMAGE, OR
INDIRECT, CONSEQUENTIAL, OR PUNITIVE DAMAGES OF A PURCHASER OR USER OF LOGICUBE
PRODUCTS OR ANY THIRD PARTY. LOGICUBE’S AGGREGATE LIABILITY IN CONTRACT, TORT, OR
OTHERWISE (WHETHER UNDER THIS AGREEMENT, RESULTING FROM THE PERFORMANCE OR USE OF
LOGICUBE PRODUCTS, OR OTHERWISE) TO A PURCHASER OR USER OF LOGICUBE PRODUCTS SHALL BE
LIMITED TO THE AMOUNT PAID BY THE PURCHASER FOR THE LOGICUBE PRODUCT. THIS LIMITATION OF
LIABILITY WILL BE EFFECTIVE EVEN IF LOGICUBE HAS BEEN ADVISED OF THE POSSIBILITY OF ANY SUCH
DAMAGES.
LOGICUBE MAKES EVERY EFFORT TO ENSURE PROPER OPERATION OF ITS PRODUCTS. HOWEVER, THE
PURCHASER IS RESPONSIBLE FOR VERIFYING THAT THE OUTPUT OF A LOGICUBE PRODUCT MEETS THE
PURCHASER’S REQUIREMENTS. THE PURCHASER FURTHER ACKNOWLEDGES THAT IMPROPER
OPERATION OF LOGICUBE PRODUCTS CAN CAUSE LOSS OF DATA, DEFECTIVE FORMATTING, OR

Logicube SCSI-NG User’s Manual II
DEFECTIVE DATA LOADING. LOGICUBE WILL MAKE EFFORTS TO SOLVE OR REPAIR ANY PROBLEMS
IDENTIFIED BY PURCHASER, EITHER UNDER THE WARRANTY SET FORTH BELOW OR ON A TIME AND
MATERIALS BASIS.
LIMITED WARRANTY
FOR ONE YEAR FROM THE DATE OF SALE (THE “WARRANTY PERIOD”) LOGICUBE WARRANTS THAT THE
PRODUCT (EXCLUDING CABLES, ADAPTERS, AND OTHER “CONSUMABLE” ITEMS) IS FREE FROM
MANUFACTURING DEFECTS IN MATERIAL AND WORKMANSHIP. THIS LIMITED WARRANTY COVERS
DEFECTS ENCOUNTERED IN THE NORMAL USE OF THE PRODUCT DURING THE WARRANTY PERIOD AND
DOES NOT APPLY TO: PRODUCTS DAMAGED DUE TO PHYSICAL ABUSE, MISHANDLING, ACCIDENT,
NEGLIGENCE, OR FAILURE TO FOLLOW ALL OPERATING INSTRUCTIONS CONTAINED IN THE OPERATING
MANUAL; PRODUCTS WHICH ARE MODIFIED; PRODUCTS WHICH ARE USED IN ANY MANNER OTHER
THAN THE MANNER FOR WHICH THEY WERE INTENDED, AS SET FORTH IN THE OPERATING MANUAL;
PRODUCTS WHICH ARE DAMAGED OR DEFECTS CAUSED BY THE USE OF UNAUTHORIZED PARTS OR BY
UNAUTHORIZED SERVICE; PRODUCTS DAMAGED DUE TO UNSUITABLE OPERATING OR PHYSICAL
CONDITIONS DIFFERING FROM THOSE RECOMMENDED IN THE OPERATING MANUAL OR PRODUCT
SPECIFICATIONS PROVIDED BY LOGICUBE; ANY PRODUCT WHICH HAS HAD ANY OF ITS SERIAL NUMBERS
ALTERED OR REMOVED; OR ANY PRODUCT DAMAGED DUE TO IMPROPER PACKAGING OF THE
WARRANTY RETURN TO LOGICUBE. AT LOGICUBE’S OPTION, ANY PRODUCT PROVEN TO BE DEFECTIVE
WITHIN THE WARRANTY PERIOD WILL EITHER BE REPAIRED OR REPLACED USING NEW OR REFURBISHED
COMPONENTS AT NO COST. THIS WARRANTY IS THE SOLE AND EXCLUSIVE REMEDY FOR DEFECTIVE
PRODUCTS. IF A PRODUCT IS HAS BECOME OBSOLETE OR IS NO LONGER SUPPORTED BY LOGICUBE THE
PRODUCT MAY BE REPLACED WITH AN EQUIVALENT OR SUCCESSOR PRODUCT AT LOGICUBE’S
DISCRETION. THIS WARRANTY EXTENDS ONLY TO THE END PURCHASER OF LOGICUBE PRODUCTS. THIS
WARRANTY DOES NOT APPLY TO, AND IS NOT FOR THE BENEFIT OF, RESELLERS OR DISTRIBUTORS OF
LOGICUBE PRODUCTS. UNLESS OTHERWISE AGREED IN WRITING BY LOGICUBE, NO WARRANTY IS
PROVIDED TO RESELLERS OR DISTRIBUTORS OF LOGICUBE PRODUCTS.
IN ORDER TO RECEIVE WARRANTY SERVICES CONTACT LOGICUBE’S TECHNICAL SUPPORT DEPARTMENT
VIA PHONE OR E-MAIL. PRODUCTS RETURNED TO LOGICUBE FOR REPAIR UNDER WARRANTY MUST
REFERENCE A LOGICUBE RETURN MATERIAL AUTHORIZATION NUMBER (“RMA”). ANY PRODUCT
RECEIVED BY LOGICUBE WITHOUT AN RMA# WILL BE REFUSED AND RETURNED TO PURCHASER. THE
PURCHASER MUST CONTACT LOGICUBE’S TECHNICAL SUPPORT DEPARTMENT VIA E-MAIL
([e-mail]) OR VIA PHONE AT [phone] OPT. 3 TO OBTAIN A VALID RMA#. THE
PURCHASER MAY BE REQUIRED TO PERFORM CERTAIN DIAGNOSTIC TESTS ON A PRODUCT PRIOR TO
LOGICUBE ISSUING AN RMA#. THE PURCHASER MUST PROVIDE THE PRODUCT MODEL, SERIAL NUMBER,
PURCHASER NAME AND ADDRESS, EMAIL ADDRESS AND A DESCRIPTION OF THE PROBLEM WITH AS
MUCH DETAIL AS POSSIBLE. AT LOGICUBE’S SOLE AND ABSOLUTE DISCRETION, REASONABLE
TELEPHONE AND EMAIL SUPPORT MAY ALSO BE AVAILABLE FOR THE LIFE OF THE PRODUCT AS DEFINED
BY LOGICUBE.
EXCEPT AS OTHERWISE SPECIFICALLY PROVIDED IN THIS AGREEMENT, LOGICUBE PRODUCTS ARE
PROVIDED AS-IS AND AS-AVAILABLE, AND LOGICUBE DISCLAIMS ANY AND ALL OTHER WARRANTIES
(WHETHER EXPRESS, IMPLIED, OR STATUTORY) INCLUDING, WITHOUT LIMITATION, ANY WARRANTIES
OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, OR NONINFRINGEMENT OF THIRD PARTY
RIGHTS.
SOME JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, OR LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS, SO THE
ABOVE LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC

Logicube SCSI-NG User’s Manual III
LEGAL RIGHTS, AND YOU MAY HAVE OTHER RIGHTS WHICH VARY FROM JURISDICTION TO
JURISDICTION.
RoHS Certificate of Compliance
LOGICUBE PRODUCTS COMPLY WITH THE EUROPEAN UNION RESTRICTION OF THE USE OF CERTAIN
HAZARDOUS SUBSTANCES IN ELECTRONIC EQUIPMENT, ROHS DIRECTIVE (2002/95/EC).
THE ROHS DIRECTIVE PROHIBITS THE SALE OF CERTAIN ELECTRONIC EQUIPMENT CONTAINING SOME
HAZARDOUS SUBSTANCES SUCH AS MERCURY, LEAD, CADMIUM, HEXAVALENT CHROMIUM AND
CERTAIN FLAME-RETARDANTS IN THE EUROPEAN UNION. THIS DIRECTIVE APPLIES TO ELECTRONIC
PRODUCTS PLACED ON THE EU MARKET AFTER JULY 1, 2006.
Logicube Technical Support Contact Information
By website: www.logicube.com
By email: [e-mail]
By telephone: +1 - [phone] ext. 3 between the hours of 8 a.m. –5 p.m. PT, Monday
through Friday, excluding U.S. legal holidays.

Logicube SCSI-NG User’s Manual I
Table of Contents
SCSI-NG USER’S MANUAL ..............................................................................................I
LIMITATION OF LIABILITY AND WARRANTY INFORMATION.....................................................I
LOGICUBE DISCLAIMER....................................................................................................................................I
WARRANTY...................................................................................................................................................I
ROHS CERTIFICATE OF COMPLIANCE ...............................................................................................................III
LOGICUBE TECHNICAL SUPPORT CONTACT INFORMATION ...................................................................................III
TABLE OF CONTENTS ..............................................................................................................I
1: INTRODUCTION................................................................................................................ 1
1.0 INTRODUCTION TO THE SCSI-NG .............................................................................................................1
1.1 FEATURES.............................................................................................................................................1
1.2 IN THE BOX...........................................................................................................................................2
1.3 OPTIONS ..............................................................................................................................................2
1.4 SPECIFICATIONS .....................................................................................................................................2
2: GETTING STARTED............................................................................................................ 5
2.0 OVERVIEW OF THE SCSI-NG....................................................................................................................5
2.1 TURNING THE SCSI-NG ON AND OFF.........................................................................................................6
2.2 CONNECTING VARIOUS DRIVE TYPES ..........................................................................................................6
2.2.1 Connecting Master Drives .........................................................................................................6
2.2.2 Connecting Target Drives ..........................................................................................................7
2.3THE USER INTERFACE ..............................................................................................................................7
2.4 FRONT AND REAR PORTS .........................................................................................................................8
2.4.1 Front ports.................................................................................................................................8
2.4.2 Rear ports ..................................................................................................................................8
2.4.2.1 DC IN power port ...............................................................................................................8
2.4.2.2 Gigabit Ethernet port .........................................................................................................8
2.5 OPERATING SYSTEM AND SCSI-NG APPLICATION SOFTWARE........................................................................8
3: QUICK START ................................................................................................................... 9
3.0 QUICK START GUIDE...............................................................................................................................9
3.1.1 Blank Disk Check........................................................................................................................9
3.1 CLONE ...............................................................................................................................................10
3.1.1 Step-by-step instructions –Clone ...........................................................................................10
3.2 HASH.................................................................................................................................................11
3.2.1 Step-by-step instructions –Drive Hash ...................................................................................12
3.3 WIPE /FORMAT ..................................................................................................................................12
3.3.1 Step-by-step instructions –Wipe............................................................................................13
3.4 LOGS .................................................................................................................................................13
3.4.1 Step-by-step instructions –Viewing or exporting logs............................................................14

Logicube SCSI-NG User’s Manual II
3.4.2 Viewing and downloading Log Files from the web interface..................................................14
3.4.3 Deleting Log Files.....................................................................................................................15
3.4.4 Accessing the Logs Over a Network ........................................................................................15
3.5 STATISTICS..........................................................................................................................................17
3.6 MANAGE REPOSITORIES........................................................................................................................18
3.7 SYSTEM SETTINGS ................................................................................................................................18
3.8 NETWORK SETTINGS.............................................................................................................................18
3.9 SOFTWARE UPDATES ............................................................................................................................19
3.10 POWER OFF......................................................................................................................................19
4: CLONE............................................................................................................................ 20
4.0 CLONE –INTRODUCTION.......................................................................................................................20
4.0.1 Cloning to Smaller Capacity Drives..........................................................................................20
4.0.2 Mirror Copy Limitations...........................................................................................................21
4.0.3 Clever Copy Limitations...........................................................................................................22
4.1 MODE................................................................................................................................................22
4.2 MASTER/IMAGE FILE............................................................................................................................22
4.3 SETTINGS............................................................................................................................................22
4.3.1 Job Info ....................................................................................................................................23
4.3.2 HPA/DCO/ACS3........................................................................................................................23
4.3.3 Error Handling .........................................................................................................................24
4.3.4 Hash/Verification Method.......................................................................................................24
4.3.5 File Image Method Settings.....................................................................................................25
4.3.6 Clone Method Settings............................................................................................................25
4.4 TARGET..............................................................................................................................................26
4.4.1 Selecting Target drive or images .............................................................................................26
4.5 STARTING THE CLONING OPERATION.......................................................................................................28
5: TYPES OF OPERATIONS................................................................................................... 29
5.0 TYPES OF OPERATIONS -INTRODUCTION..................................................................................................29
5.1 CLONE ...............................................................................................................................................31
5.2 HASH.................................................................................................................................................31
5.2.1 Target.......................................................................................................................................32
5.2.2 Settings....................................................................................................................................32
5.2.2.1 Hash Settings....................................................................................................................32
5.2.2.1.1 Hash Method ................................................................................................................................................................... 33
5.2.2.1.2 Hash Values ...................................................................................................................................................................... 33
5.2.2.1.3 LBA........................................................................................................................................................................................ 33
5.2.3 Job Info ....................................................................................................................................34
5.3 WIPE /FORMAT ..................................................................................................................................34
5.3.1 Target.......................................................................................................................................34
5.3.2 Settings....................................................................................................................................34
5.3.2.1 Secure Erase.....................................................................................................................35
5.3.2.2 Wipe Patterns ..................................................................................................................35
5.3.2.2.1 Mode ................................................................................................................................................................................... 36
5.3.2.2.2 HPA/DCO/ACS3 .............................................................................................................................................................. 36
5.3.2.2.3 LBA........................................................................................................................................................................................ 36
5.3.2.2.4 PASSES................................................................................................................................................................................ 36
5.3.2.3 Format..............................................................................................................................37

Logicube SCSI-NG User’s Manual III
5.3.3 Job Info ....................................................................................................................................38
5.4 LOGS .................................................................................................................................................38
5.5 STATISTICS..........................................................................................................................................38
5.5.1 About.......................................................................................................................................38
5.5.2 Adv. Drive Statistics.................................................................................................................39
5.5.3 Options ....................................................................................................................................39
5.5.4 Network Interface Stats...........................................................................................................39
5.5.5 Debug Logs ..............................................................................................................................40
5.5.6 Help .........................................................................................................................................40
5.6 MANAGE REPOSITORIES........................................................................................................................41
5.6.1 Add/Remove............................................................................................................................41
5.6.2 iSCSI .........................................................................................................................................44
5.7 SYSTEM SETTINGS ................................................................................................................................45
5.7.1 Profiles.....................................................................................................................................45
5.7.2 Passwords................................................................................................................................47
5.7.2.1 Setting Key Passwords .....................................................................................................47
5.7.2.1.1 Config Lock Notes.......................................................................................................................................................... 48
5.7.2.1.2 Forgotten password for any keys ............................................................................................................................ 49
5.7.2.2 User Account Passwords..................................................................................................50
5.7.3 Language/Time Zone...............................................................................................................51
5.7.3.1 Language ..........................................................................................................................51
5.7.3.2 Time Zone.........................................................................................................................51
5.8 NETWORK SETTINGS.............................................................................................................................52
5.8.1 Interfaces.................................................................................................................................52
5.8.1.1 Configuring a Static IP address.........................................................................................52
5.8.1.2 Enabling/Disabling Network Services ..............................................................................53
5.8.2 HTTP Proxy...............................................................................................................................54
5.8.2.1 Server ...............................................................................................................................54
5.8.2.2 Username/Password........................................................................................................54
5.9 SOFTWARE UPDATE..............................................................................................................................54
5.10 POWER OFF......................................................................................................................................55
6: UPDATING/LOADING/RE-LOADING THE SCSI-NG SOFTWARE .......................................... 56
6.0 UPDATING/LOADING/RE-LOADING SOFTWARE –INTRODUCTION ................................................................56
6.1 REQUIREMENTS...................................................................................................................................56
6.2 UPDATING/LOADING/RE-LOADING SOFTWARE INSTRUCTIONS ....................................................................56
6.2.1 From Network (Over the Internet)..........................................................................................57
6.2.2 From USB Drive (Through a software file download)..............................................................58
6.3 FIRMWARE LOADING INSTRUCTIONS .......................................................................................................59
7: REMOTE OPERATION ..................................................................................................... 60
7.0 REMOTE OPERATION -INTRODUCTION ....................................................................................................60
7.1 WEB INTERFACE ..................................................................................................................................60
7.2 COMMAND LINE INTERFACE (CLI)...........................................................................................................60
7.2.1 Connecting via Telnet..............................................................................................................61
7.2.2 Connecting via SSH..................................................................................................................61
7.3 ZERO CONFIGURATION NETWORKING (ZEROCONF) ...................................................................................62

Logicube SCSI-NG User’s Manual IV
8: FREQUENTLY ASKED QUESTIONS.................................................................................... 63
8.0 FAQS.................................................................................................................................................63
9: INDEX ............................................................................................................................ 65
TECHNICAL SUPPORT INFORMATION...............................................................................................................66
SOFTWARE ATTRIBUTION..............................................................................................................................66

Logicube SCSI-NG User’s Manual 1
1: Introduction
1.0 Introduction to the SCSI-NG
The SCSI-NG is a compact portable SCSI hard drive duplicator. Efficient cloning makes it easy to copy SCSI
hard drives for back-up, drive testing and all your duplication tasks. The unit features a Gigabit Ethernet
network port to conveniently use the browser-based interface to manage all SCSI-NG operations.
Comprehensive log reports provide detailed information about each task performed. An optional Wipe
feature can securely erase hard drives using a SCSI format command, a custom pass, or a 7-pass DoD
specification wipe.
1.1 Features
Supports cloning of 68-pin SCSI hard drives. One master to one target. Optional adapters are
available to convert 50-pin or 80-pin drives.
Clones all operating systems including Windows 10, Linux and Unix®.
Use the browser-based user interface to manage all operations including software updates. The
unit has a Gigabit Ethernet port.
Multi-Image Master. This feature allows you to store multiple SCSI-NG-created images on a SCSI
master drive connected to the SCSI-NG or on a network repository and then clone to selected
targets.
Write-protected master port. The master port is automatically write-blocked to prevent any
alteration to sensitive data on the master drive.
Multiple Cloning Modes:
oMirror Copy, bit for bit copy. Supports all O/S including Windows and Linux.
oClever Copy: Copies only data areas, skips blank sectors, scales partitions to target.
Supports FAT16/FAT32/NTFS and Linux (EXT, EXT2, EXT3, EXT4) file systems
oFor multiple partition drives, SCSI-NG automatically selects the optimum cloning
method (Clever or Mirror)
Hash/Verification option (SHA1, SHA256 or MD5) allows the user to clone and verify the exact
replication of the master drive. Available with the purchase of an optional software activation
package.
Wipe option allows the user to securely erase target drives using a SCSI format command, a
custom pass or a 7-pass DoD specification wipe. Meets the NIST 800-88 guidelines. Available
with the purchase of an optional software activation package.
Audit trail/log reports provide detailed information on each task. A digital signature is included
in the report for authentication purposes.

INTRODUCTION
Logicube SCSI-NG User’s Manual 2
Bad sector handling. Scan for bad sectors on the source drive, abort or skip and log for review.
User Profiles. Create user profiles and save configurations for commonly used operations.
Features two USB 2.0 ports for keyboard, mouse, software updates
Additional features include HPA/DCO support, advanced drive statistics and a color touchscreen
with a built-in stylus.
1.2 In the Box
The following items are included with SCSI-NG:
Power supply & power cord
2 68-pin SCSI power & data cables
Users’ Manual on CD-ROM
1.3 Options
There are several options for the SCSI-NG (listed below). To purchase any of the following options,
please contact Logicube Sales: [email protected]om.
Wipe software option. Provides the ability to securely erase SCSI target drives using a SCSI
format command, a custom pass or a DoD 7 pass specification wipe, meets NIST 800-88
guidelines
Verification/Hash software option allows the user to clone and verify the exact replication of
the master drive during cloning
50-pin to 68-pin SCSI adapter
80-pin to 68-pin SCSI adapter
Extended warranties are available
1.4 Specifications
Power
Requirements
Power Supply
Voltage
(DC IN)
Output Voltage
(DC OUT)
Net Weight
Dimensions
Agency
Approvals
90 Watts
+12V DC @
7.5A
+5V DC @
2.5A,
12V DC @ 2.5A
5.2 lbs
(2.3 kg)
14.5” x 9.5” x
3.5”
(36.8 cm x 24.1
cm x 8.8 cm)
RoHs
compliant

INTRODUCTION
Logicube SCSI-NG User’s Manual 3
WARNINGS:
Avoid dropping the Logicube device or subjecting it to sharp jolts.
When in use, place it on a flat surface.
Keep the unit dry. If the Logicube device needs to be cleaned, use
a lightly damp, lint free cloth. Avoid using soap or other cleaning
agents particularly those containing bleach, ammonia, alcohol or
other harsh chemicals.
Do not attempt to service or open the Logicube device. Doing so
may void the warranty. If the unit requires service, please
contact Logicube Technical Support for assistance.

Logicube SCSI-NG User’s Manual 5
2: Getting Started
2.0 Overview of the SCSI-NG
Special Icons –Throughout this manual, there are two icons that can be seen.
Please pay close attention when any of these two icons are found. These icons
highlight additional information or important warnings on specific topics.

GETTING STARTED
Logicube SCSI-NG User’s Manual 6
5
2.1 Turning the SCSI-NG on and off
A 12V grounded, 7.5A (output DC) power supply that connects to the back of the unit is included. Attach
the power supply to the DC IN port located in the back of the unit.
To turn the unit on, press and immediately release the power switch located on the back of the unit.
There are two ways of turning the unit off:
1. Press and immediately release the power switch located on the back of the unit. The unit will
begin the shutdown process and after a few seconds, the display and fans will turn off.
2. Using the Graphical User Interface (GUI) either on the touch screen or via a browser through a
remote connection, navigate to the Power Off screen and tap or click the Power Off icon.
2.2 Connecting various drive types
Cables and adapters are available for the following drive types:
68-pin SCSI drives
80-pin Single Connector Attachment (SCA) SCSI drives
50-pin SCSI drives
When connecting/disconnecting drives using drive adapters, it is
recommended to keep the drive connected to the adapter and
cables, then connect/disconnect cables to/from SCSI-NG ports.
2.2.1 Connecting Master Drives
Master drives must be connected to the left bay of the unit. This bay is write-protected.

GETTING STARTED
Logicube SCSI-NG User’s Manual 7
The Master bay is hot swappable. Some drives are not hot swappable. Please check with the
drive manufacturer to find out if the drive being used does not support hot swapping.
Never connect a Master drive to the Target
bay of the unit. Data may be overwritten if
a drive is connected to the Target bay.
2.2.2 Connecting Target Drives
Target drives must be connected to the right bay of the unit.
The Target bay is hot swappable. Some drives are not hot swappable. Please check with the
drive manufacturer to find out if the drive being used does not support hot swapping.
When disconnecting drives, it is very important to make sure
the drives are not being used on any task. Disconnecting drives
while the unit is using the drive for a task may cause data loss.
2.3 The user interface
The user interface (UI) has been designed to quickly and easily input commands. It is simple and intuitive
showing common icons such as tasks, modes of operation, and scroll icons on the screen. The UI is
designed to be easily followed, going from left to right across the screen.
A –Operations/Tasks currently running (displays up to 5 total tasks)
B –Lock indicator/shortcut
C –Operations/Tasks

GETTING STARTED
Logicube SCSI-NG User’s Manual 8
D –Add or delete tasks
E –Types of Operations
F –Up and down scroll arrows
G –Operations options and settings
H –Status Bar
I –Start icon
2.4 Front and rear ports
The unit has two USB 2.0 host ports, one DC IN power port, and one Gigabit Ethernet port.
2.4.1 Front ports
There are two USB 2.0 host ports located on the front of the unit.
The left USB port is used for software updates (using the From USB option) and can be used with
peripherals (wired keyboard or mouse).
The right USB port is used for exporting log files and can also be used with peripherals (wired
keyboard or mouse).
2.4.2 Rear ports
There is one DC IN power port and one Gigabit Ethernet port located in the back of the unit.
2.4.2.1 DC IN power port
The unit has one DC IN port. Connect the included AC adapter/power supply to the DC
IN port to provide power to the unit.
2.4.2.2 Gigabit Ethernet port
There is one Gigabit Ethernet port. Some of the possible uses for this port include (but
are not limited to) the following:
Connect a work network to control the SCSI-NG remotely and allow access to a
server as a networked repository.
Connect to a NAS device.
2.5 Operating System and SCSI-NG Application Software
The SCSI-NG has a microSD storage drive that contains the operating system and software. This drive
does not store any data from master drives or target drives.

Logicube SCSI-NG User’s Manual 9
3: Quick Start
3.0 Quick Start Guide
This chapter gives a basic overview and steps on how to perform different types of operations using the
SCSI-NG (Clone, Hash, Wipe, etc.). Complete details on each operation, menu, or selection, and the
different screens can be found in Chapter 4: Cloning and Chapter 5: Types of Operation.
The passwords for built-in accounts can be changed.
Instructions on how to change the passwords to the two
built-in user accounts can be found in Section 5.7.2.2.
There are software options available such as:
-Verify option –allows verification of data copied during the clone task.
-Wipe option –allows the ability to wipe drives connected to the Target bay.
To find out if these options are enabled on the unit, tap the Statistics icon from
the navigation menu and select the Options tab.
To purchase any of these options, contact the Logicube Sales Department at
[email protected]m.
The SCSI-NG clone, hash, and wipe speeds are determined by
several factors including (but not limited to) the following:
The manufacturer specifications of the drive(s) being used
The age of the drive (manufactured date, not purchased date)
How often that drive has been used
3.1.1 Blank Disk Check
A blank disk check can be performed to see if a drive has been wiped by the unit. This check will
not be accurate if Secure Erase or Pattern Buffers was used to wipe the drive. To perform a
blank disk check:
1. Connect a drive to the unit.
2. Choose Clone, Hash, or Wipe/Format.
3. Go to Master or Target to see the list of connected drives.
4. Tap the More Info icon to the right of the drive to display information about the drive.
5. Tap or click the down arrow located to the right of the screen to scroll down to the
second page of information.

QUICK START
Logicube SCSI-NG User’s Manual 10
6. Locate the line that shows “Wiped”. This will either show True (drive is blank) or False.
3.1 Clone
This type of operation allows the imaging of a Master drive or image to a Target drive
or image. There are three different imaging modes and several settings to choose
from. Drives can be cloned using Mirror (bit-for-bit copy) or Clever (copies only data
areas, skips blank sectors, and partitions can be resized to fit larger capacity drives).
These selections should be performed in order from left to right.
Details on the different screens
found in the Imaging operation can
be found in Chapter 4: Cloning.
For details on cloning
drives to a smaller capacity
Target, see Section 4.0.1.
Drive to Drive –Performs a bit-for-bit copy of the Master producing an exact duplicate of the
Master drive. This is also known as a mirror clone.
Image to Drive –Restores an image created by the SCSI-NG to one or more Target drives.
Drive to Image –Creates a Logicube SCSI-NG image file to a network repository or Target drive.
This image file can be restored to a drive using the Image to Drive mode.
3.1.1 Step-by-step instructions –Clone
Details on each selectable
option on the Clone screen can
be found in Chapter 4: Cloning.
1. Select Clone from the types of operation on the left side.
2. Tap Mode and select one of the available modes, then tap the OK icon.

QUICK START
Logicube SCSI-NG User’s Manual 11
3. Tap the Master (or Image File)icon and choose the Master from the list of connected
drives then tap the OK icon.
4. Tap the Settings icon and adjust the settings as needed (Job Info, Clone Method
Settings, HPA/DCO/ACS3, Error Handling, Hash/Verification Method, etc.) then tap the
OK icon.
The Verify feature is an option. To find out if this option is
installed, go to the Statistics icon from the navigation menu
on the left and select the Options tab. To purchase the Verify
option, contact our sales team at [email protected].
The Settings screen may be different in each of the modes.
Details on the different Settings screens can be found in
Chapter 5: Types of Operations.
Log file names can be set in Settings in the Job Info screen by
entering a Job Name. See Section 4.3.1 for more information.
5. Tap the Target (or Image File)icon and select the Target or Image File then tap the OK
icon.
For Drive to Image, the SCSI-NG must be used to format
drives. If the Target drive is not formatted by the SCSI-NG,
the Format icon will appear in the Format column. Tap
the (Format) icon to format the Target drive.
6. Tap the Start icon to start the cloning task.
7. A progress bar will appear at the bottom of the screen showing the bytes processed, the
rate (speed), elapsed time, and time remaining.
8. When finished, the status will show “COMPLETED”. At this point, it is recommended to
tap Reset Task to reset the task, so the drive bays properly reset and not show as being
used or assigned for other tasks.
The number of bytes shown on the progress bar is
not the actual size of the drive. This is the actual
bytes being processed. When ‘Verify’ is set to
“Yes”, the reported number will double in size.
3.2 Hash
A hash or operation can be performed to any connected drive. Performing a hash task
will instruct the unit to calculate the hash for the specified drive or validate the hash

QUICK START
Logicube SCSI-NG User’s Manual 12
value for that drive.
Details on the different screens
found in the Hash operation can
be found in Section 5.2: Hash.
This mode will hash any connected drive on an active Master or Target port. This mode is Logical Block
Address (LBA) based and will hash a drive based on the number of LBAs.
3.2.1 Step-by-step instructions –Drive Hash
1. Select Hash from the types of operation on the left side.
2. Tap the Target icon and select the drive to be hashed then tap the OK icon.
3. Tap the Settings icon to choose the different settings based on the Mode. Details for
every setting can be found in Section 5.2.2.
4. Change any of the optional settings (LBA settings or percentage of the drive to be
hashed) if needed.
Optional: Tap Job Info to set the Job Name, Job ID, Operator, Other ID, or Job Notes.
5. Tap the Start icon to start the hash task.
6. When finished, the status will show “COMPLETED”. At this point, it is recommended to
tap Reset Task to reset the task, so the drive bays properly reset and not show as being
used or assigned for other tasks.
3.3 Wipe / Format
The drive connected to the Target bay (right side) can be wiped or formatted. Unless
formatted (with the SCSI-NG), when a drive is wiped, there will be no file system on
the Target drive. The following methods are available in the Wipe menu:
The Wipe/Format feature is an option. To find out if this feature
is installed, go to the Statistics icon from the navigation menu on
the left and select the Options tab. If you need to purchase the
Wipe option, contact our sales team at: [email protected]m.
Details on the different screens
found in the Wipe operation can be
found in Section 5.3: Wipe / Format.
Secure Erase –Sends the SCSI FORMAT command to the drive instructing it to wipe the drive
based on the hard drive manufacturer’s specifications for the SCSI FORMAT command.
Secure erase instructs the SCSI-NG to send a SCSI FORMAT
command to the drive. If the drive supports this command, it
will perform the task based on the manufacturer’s
