Logitech QuickCam Express User manual

English
Getting Started with Logitech
®
QuickCam
®
Express
™
®
DeutschFrançaisItalianoEspañolPortuguêsNederlandsS enskaDanskNorskSuomi
Ελληνικά
По-русски
MagyarČeská verzePo polsku

ii
Copyright
© 2000 Logitech. All Rights Reser ed. Logitech, the Logitech logo, and other Logitech marks are owned by Logitech and may be registered. All other trademarks
are the property of their respecti e owners. Logitech assumes no responsibility for any errors that may appear in this manual. Information contained herein is
subject to change without notice.
Logitech QuickCam products are intended to be used in a lawful manner. Certain uses of digital PC camera products may be prohibited by local laws in some
countries or states, such as the surreptitious recording of audio and/or ideo communications for certain purposes. If you ha e any question about whether a
proposed use of your product is lawful, you should consult a local legal authority before proceeding.
Part Number:
622683-0914
English
Product: QuickCam Express
Warranty period: 2 Years
The contractual conditions as well as all other conditions and rele ant
information are included in the software pro ided with your Logitech
product. You must accept these conditions before starting to install
the software.
Deutsch
Produkt: QuickCam Express
Garantiedauer: 2 Jahre
Sie finden die ertraglichen und sonstigen Bedingungen sowie alle wichtigen
Informationen in der Software, die dem Logitech-Produkt beiliegt.
Sie müssen diesen Bedingungen zustimmen, be or Sie die Software
installieren.
Français
Produit: QuickCam Express
Durée de la arantie: 2 ans
Les conditions contractuelles ainsi que toutes autres conditions
et informations pertinentes sont incluses dans le logiciel li ré
a ec otre produit Logitech. Vous de ez accepter ces conditions a ant
d’installer le logiciel.
Italiano
Prodotto: QuickCam Express
Periodo di aranzia: 2 anni
Le informazioni contrattuali, unitamente a tutte le altre condizioni
e informazioni pertinenti, sono incluse nel software fornito con il prodotto
Logitech. Prima di iniziare l'installazione del software, è necessario accettare
queste condizioni.
Español
Producto: QuickCam Express
Periodo de arantía: 2 años
Las condiciones contractuales, así como el resto de condiciones
e información rele ante, se incluyen en el software suministrado
con el producto de Logitech. Debe aceptar esas condiciones antes de iniciar
la instalación del software.
Português
Produto: QuickCam Express
Período de arantia: 2 Anos
As condições contratuais, assim como outras condições e informações
relacionadas, estão inclusas no software fornecido com seu produto
Logitech. Você de e concordar com essas condições antes de instalar
o software.
Nederlands
Product: QuickCam Express
Garantieperiode: 2 jaar
De contractuele oorwaarden e enals alle andere oorwaarden en rele ante
informatie zijn opgenomen in de software die bij uw Logitech-product
gele erd wordt. U moet deze oorwaarden accepteren oordat u de
software gaat installeren.
Svenska
Produkt: QuickCam Express
Garantiperiod: 2 år
Licens illkor samt ö riga illkor och annan iktig information finns
i program aran som medföljer denna Logitech-produkt. Du måste godta
dessa illkor innan du kan installera programmet.
Dansk
Produkt: QuickCam Express
Garantiperiode: 2 år
De kontraktmæssige betingelser samt andre betingelser og rele ante
oplysninger findes på softwaren der fulgte med dit Logitech-produkt.
Du skal acceptere disse betingelser før du installerer softwaren.
Norsk
Produkt: QuickCam Express
Garantiperiode: 2 år
Kontraktforhold så el som alle andre forhold og rele ant informasjon
finnes inkludert i program aren som følger med ditt Logitech-produkt.
Du må godta disse betingelsene før du begynner å installere program aren.
Suomi
Tuote: QuickCam Express
Takuuaika: 2 vuotta
Sopimukseen liitty ät ehdot sekä muut edellytykset ja asiaan kuulu at
tiedot sisälty ät Logitech-tuotteen mukana toimitettuun ohjelmistoon.
Sopimusehdot on hy äksyttä ä ennen kuin ohjelmisto oidaan asentaa.
Ελληνικά
Προϊν: QuickCam Express
∆ιάρκια ισ ύοσ γγύησησ: 2 έτη
Οι συµβατικοί ροι καθώσ και οποιοιδήποτ άλλοι ροι και σ τικέσ
πληροφορίσ πριλαµβάνονται στο λογισµικ που συνοδύι το προϊν
Logitech. Πρέπι να αποδ θίτ αυτούσ τουσ ρουσ πριν ξκινήστ την
γκατάσταση του λογισµικού.
По русски
Нaименoвание: QuickCam Express
Гарантийный срок: 2 годa
Договорные условия, a также лю ые другие условия
и сопутствующая информация включены в программное
о еспечение, поставляемое в комплекте с изделием Logitech.
Устанавливая программное о еспечение, Вы принимаете на се я
эти о язательства.
Magyar
Termék: QuickCam Express
Garancia ideje: 2 év
A szerződéses feltételeket, az e yéb feltételeket és a kapcsolódó információkat
a Lo itech termékhez adott szoftver tartalmazza. Ezeket a feltételeket el kell
fo adnia mielőtt a szoftver installálását me kezdi.
Česká verze
Produkt: QuickCam Express
Záruční doba: 2 roky
Smluv ní podmínky stejně jako další podmínky a příslušné informace
jsou obsaženy v softwaru, který je přiložen k Vašemu produktu Lo itech.
Tyto podmínky je nutné přijmout před instalací tohoto softwaru
Po polsku
Produkt: QuickCam Express
Okres warancji: 2 lat
Warunki wynikające z umowy jak również wszystkie inne warunki oraz istotne
informacje są zawarte w opro ramowaniu dostarczonym wraz z produktem
Lo itech. Zanim przystąpisz do instalowania opro ramowania zaakceptuj
te warunki.

1
Congratulations!
English
1
Congratulations!
You ha e purchased the Logitech
®
QuickCam
®
Express Internet ideo camera, the latest
inno ation in con enient and exciting ideo communication. QuickCam Express gi es
you endless ways to ha e fun: send ideo e-mail, take instant snapshots, enjoy li e ideo
calls, or create exciting web albums. QuickCam Express comes with
• The QuickCam
®
Express Video Camera
• A camera base
• A software CD
• A How to Guide and Logitech literature
2
etting to Know Your Camera
Lens
Focusing ring
Base

2
Installing Your Camera
3
Installing Your Camera
Note Your computer must be running Microsoft
®
Windows
®
98 or Windows
®
95
4.00.950B or C (or later). To check your ersion of Windows 95,
• Right-click the “My Computer” icon on the Windows desktop.
• Click Properties.
• Verify that you ha e “System: Microsoft
®
Windows 95 4.00.950B or C”.
1. Install the software first! Insert the QuickCam Express software CD into
your computer’s CD-ROM dri e.
2. If the Setup screen does not display,
• Go to the Taskbar and click Start, then Run.
• Type D:\SETUP.EXE and press the Enter key, where D: is the dri e designation
of your CD-ROM dri e.
3. Follow the on-screen instructions.
4. Assemble the camera.
After you reboot your system
toward the end of software
installation, Setup will prompt
you to connect the camera cable
to your computer:
• Remo e the camera and
its base from the packaging.
• Mount the camera on its base.
• Remo e the protecti e cap
from the end of the camera
cable.
• Insert the camera cable into your computer’s USB port.
• Continue with software installation by following the on-screen prompts.
USB connector

3
Launching the Software
English
4
Launching the Software
You launch the QuickCam software and display its main dialog box by
• Clicking the QuickCam Express icon located on the Windows
®
98 Quick Launch Bar.
• Or, clicking the Start menu on the Windows
®
Taskbar, then selecting Programs,
Logitech QuickCam, then QuickCam software .
The main dialog box is where you create pictures, ideos, e-mail containing pictures
and ideos, web cams, and web albums. You can also post your web cams and web
albums to the SpotLife
™
web site. You can also send li e ideo to this site for others to see.
Refer to the online help for more information about using the QuickCam software .
After launching the QuickCam software , go to the How to Guide for simple step-by-
step instructions for using your camera.
5 Setting Up and Using Your Camera
The QuickCam
®
Express camera pro ides optimal eye contact when mounted on top
of your computer monitor. Try se eral positions before mounting the camera.
To get the most from your camera, follow these tips:
• Consider placing the camera in the middle of your monitor for optimal eye contact.
• To focus the camera, rotate the focusing ring (around the camera lens) back and
forth. View li e ideo in QuickCam software to guide your adjustments.
• Did you know that you can place your camera on a tabletop, or hold it in your hand?
For a flat surface, simply mo e the camera from the monitor to the tabletop.
To hold the camera in your hand, simply pick it up, base and all, and point it at
your subject.

4
Setting Up and Using Your Camera
6
Broadcasting Live on SpotLife
™
Now you can share that special occasion, as it happens. Create your own shows,
share hobbies, birthdays, or baby’s first steps with family, friends, or e en the world.
It’s easy with your Logitech
®
QuickCam
®
software, QuickCam
®
Internet Video camera,
and SpotLife.com
™
, the web site that lets anyone stream li e ideo o er the Net.
Your free* Spotlife
™
membership includes web space (password optional) for li e
broadcasts, web cams, and web albums (stills and ideo). You can also iew a constantly
updated list of SpotLife top ten shows or iew shows from a wide ariety of the most
inno ati e channels on the Internet. To learn more about SpotLife, refer to the SpotLife
online help system at www.spotlife.com.

5
Setting Up and Using Your Camera
English
Start a Show Today!
To broadcast, make sure you ha e installed the Quickcam
®
software and connected
the QuickCam
®
camera to your computer, then follow these easy steps to start a show:
1. To begin, launch the QuickCam software by clicking the QuickCam icon on
your Windows
®
desktop.
2. Click the “Broadcast Now” button for streaming audio and video.
3. Point the camera at a subject, then click the “Setup Show” button.
4. Click the “ o Live” button to begin broadcasting.
How to Register and Categorize Your Show
1. Complete the SpotLife
™
registration. Registration is required for free*
broadcasting on SpotLife.
2. Create a profile for your show. Profiling enables your friends to iew your show.
Connection Tips
If you are not able to connect to SpotLife
™
through the QuickCam software,
go to www.spotlife.com/support , or send e-mail to [email protected]
for the latest connection information.
Tell Your Friends
Spread the word about SpotLife
™
. Simply click the “Email a Friend” button at the top of
the SpotLife screen to send a link from your show to your friends and family, or the world!
* Free Charter Membership includes 15 MB of space for stored content and 240 streaming minutes per month
with a maximum of 25 simultaneous iewers.

6
Tips
7
Tips
Here are a few things to keep in mind that will help you get the most from
QuickCam
®
Express.
Versatility. Whether you hold it in your hand, place it on your monitor, or put it on
your desktop, QuickCam Express pro ides flexibility. Placing the camera on your monitor
usually pro ides excellent eye contact. But holding the camera makes it possible for you
to mo e up close to objects.
Lighting. QuickCam Express works well with all types of room lighting. But for good
ideo quality, try not to place bright light (e.g., sunlight through a window) behind your
subjects. In harsh, contrasty light, you will appear too dark or your subject will lack detail.
Software Updates. The Logitech
®
Internet Update software automatically checks
the Logitech web site, determines whether you ha e the latest ersion of the
QuickCam software , and if an update exists, downloads the newer ersion for you.
To check for new software updates, click the Help button on the QuickCam software
Taskbar, then click “Check for Software Updates”.
Logitech
®
Web Site. When you get the chance, come and isit us on the Internet
at www.Logitech.com/cam. We ha e lots of information about new products, special
offers, and customer support. You can also register your product online. Simply click
the Globe button on the QuickCam software Taskbar.
8 etting More Information — Important!
QuickCam
®
Express comes with an easy-to-use How to Guide and an extensi e online help
system. Both show you how to use all the features of QuickCam Express. You can access
the online help quickly ia the help menu in the QuickCam
®
software. To access the How
to Guide, do the following:
1. From the Windows
®
Taskbar, select Start, Programs, Logitech QuickCam,
then the “View How to uide”.
2. The How to uide displays automatically (if Adobe
®
Acrobat
®
is installed).
To iew a topic, click one of the bookmarks listed on the left side of the title page.
Or you can print the How to Guide by clicking “File” then “Print” in the menu bar
on the first page of the Guide.
Please take a minute to register your product on our website
at www.logitech.com: it entitles you to free Customer Support.
Furthermore, as a registered customer you may chose to be included in special
product offers and interesting information about new Logitech devices.

7
Herzlichen Glückwunsch!
Deutsch
1
Herzlichen lückwunsch!
Sie haben die Internet-Videokamera Logitech QuickCam Express erworben, die neueste
Errungenschaft auf dem Gebiet der Videokommunikation. QuickCam Express bietet
unbegrenzte Möglichkeiten: Video-Mails, Schnappschüsse, Videokonferenzen und Web-
Alben. Lieferumfang:
• Die Videokamera QuickCam Express
• Kamerafuß
• Software-CD
• Handbuch und andere Logitech-Dokumentation
2
Beschreibung
Objekti
Fokusring
Fuß

8
Installieren der Kamera
3
Installieren der Kamera
Note Auf dem Computer muss Microsoft Windows 95 4.00.950B bzw. C oder höher
bzw. Windows 98 installiert sein. So überprüfen Sie die Version on Windows 95:
•Klicken Sie mit der rechten Maustaste auf das Symbol “Arbeitsplatz” auf
dem Desktop.
•Klicken Sie auf “Eigenschaften”.
•Überprüfen Sie, ob unter “System” folgende Version angegeben ist: “Microsoft
Windows 95 4.00.950B oder C”.
1. Installieren Sie zuerst die Software! Legen Sie die QuickCam-Software -CD ein.
2. Wird das Setup-Dialogfeld nicht automatisch angezeigt:
• Wählen Sie im Startmenü den Befehl “Ausführen”.
• Geben Sie D:\SETUP.EXE ein (D: ist der Buchstabe des CD-ROM-Laufwerks),
und drücken Sie die Eingabetaste.
3. Folgen Sie den Anweisungen auf dem Bildschirm.
4. Setzen Sie die Kamera
zusammen. Nach Abschluss
der Software-Installation
und einem Neustart werden Sie
aufgefordert, das Kamerakabel
anzuschließen.
• Nehmen Sie Kamera
und Kamerafuß aus
der Verpackung.
• Setzen Sie die Kamera auf
den Fuß.
• Entfernen Sie die Schutzkappe
om Kamerakabel.
• Schließen Sie die Kamera an der USB-Schnittstelle an.
• Setzen Sie die Software-Installation fort, indem Sie die Anweisungen auf dem
Bildschirm befolgen.
USB-Stecker
