Lookee Pulsebit EX User manual

Customer Support:
Email: [e-mail]
Facebook Messenger: Search “LookeeTech”
Register Product and Claim One-Year Warranty at
www.LookeeTech.com
User Manual
Pulsebit EX
Personal ECG Tracker
Disclaimer
It’s not a medical device and should not be used for any
medical purpose or any medical condition. This product is
intended only for general wellness use.
Caution
This product is not for people wearing a pacemaker.
Unpacking
Main Unit; Quick Guide; Charging & Data USB Cable
ECG Cable; 5 sets Reusable ECG Electrodes, Carry Case
About the main unit
Charging
With the charging cable, connect the device to the USB port
of personal computer (PC) or standard USB charging
adapter.
Power ON/OFF
Press and hold the button for 1 second to power ON, Press
and hold 3 seconds to power OFF.
It will turn off automatically if no measurement or operation.
Important Setting
User Mode: Settings->Single User/Dual User
ECG Length: Settings->ECG Length, for 30s/60s/5 minutes
Note: only cable measure is supported in 5 minutes mode
Check the Heart - Internal
1) Touch <HeartCheck> to start a measure, select MODE
2) Hold the device as MODE I or MODE II, keep still and
wait until the process bar ended
MODE I (LEAD I) MODE II (LEAD II)
Check the Heart - External (by cable)
1) Touch <HeartCheck> to start a measure, touch the
icon at the bottom to switch to External mode.

2) Insert the ECG cable into the Micro D port, apply the
reusable electrodes onto your body accordingly.
About Reusable Electrodes
Please cover the white protective paper back and seal the
electrode pads into plastic bag after each use.
It’s recommended to replace the electrodes every 50
measures. The performance of the electrode will decrease
after an excessive use.
To purchase more electrodes, please visit
www.LookeeTech.com.
Understand the Result
Heart
Rate
The number of times your heart beats per minute
calculated from the ECG.
The reference range for adult is 60-100 beats per
minute in resting condition and higher in fitness.
Control your maximum heart rate during fitness or
exercise to avoid overload of the heart.
ECG
An electrocardiogram (ECG) is a test that records
the electrical activity of the heart.
Regular heart beat - the recorded ECG is in a
common regular pattern.
Irregular heart beat - the recorded ECG is in an
erratic pattern. It may be caused by overload of
heart or other conditions.
Review the history records
You can review the history results and replay the recorded
ECG waveforms in History menu.
Tap the arrow button on the left to scroll down/up the
records list.
Tap the icon can replay the ECG waveforms; and tap
the arrow button on the left side to adjust the scale of
waveform.
Work with PC App “Pulsebit Browser”
Download the latest version from:
https://www.lookeetech.com/pages/downloads
Install it on Windows PC. To export data:
1) Connect the device to PC with the USB cable
2) On device, Settings->To PC
3) Open the PC software, download data from the device
With the PC software, you can view and print report, which
can also be exported as PDF files.
Work with Mobile APP “ViHealth”
Install the latest APP “ViHealth” on your smartphone or
tablet (Bluetooth supported) from App Store (iOS) or Play
Store (Android).
1) Switch on the device Bluetooth in Setting->Bluetooth.
2) switch on the Bluetooth on your phone or tablet.
3) Run the APP, add the device in the APP. (don’t pair
the device in the phone Setting menu, only in the APP)
4) The data will be downloaded automatically.
Specifications
Size
88×56×13 mm
Weight
64 g (main unit)
Display
2.4” touch screen, color, backlit
Battery type
Rechargeable lithium-polymer battery
Battery run time
>500 checks
Charge time
2 -3 hours
Heart rate range
30 to 250 bpm
Storage
30s x 100, or 60s x 50, or 5mins x 10
User
Single or Dual
ECG length
30s, 60s, 5 minutes
Version: A Model: PB-20
