Lorex ACTIVE LSC005 User manual

FOR SUPPORT AND INFORMATION,
VISIT WWW.LOREXTECHNOLOGY.COM
1 x Mini-
Camcorder
1 x Velcro
Headband
1 x mini-USB
Cable
1 x Plastic Mount
and Rubber Strap
1 x Velcro
Mount
1 x Wraparound
Velcro Mount
3 x Double-stick
Tape
7 x Extra
O-rings
1 x Audio
End-cap
2 x Velcro
Tape
End-cap Power/Record Button
Back (End-cap removed)
mini-USB Port
Microphone
microSD
Card Slot
Front
Status LED
Camera
Lens
Reset button
Contents
Copyright © 2012 Lorex Technologies Inc.
As our products are subject to continuous improvement, Lorex reserves the right to modify product
design, specifications and prices, without notice and without incurring any obligation. E&OE
All trademarks belong to their respective owners. No claim is made to the exclusive right to use the
trademarkslisted, other than the trademarks owned by Lorex Technology Inc.
WATERPROOF HIGH DEFINITION
MINI-CAMCORDER
Quick Start Guide
English Version 2.0
LSC005
Safety
• Do not point the camera directly at the sun as this may
damage the camera.
• Product is waterproof only using video-only end-cap,
properly sealed with O-ring. Do not submerge more than
32ft / 10m deep.
• Do not use in temperatures colder than –4°F / –20°C or
warmer than 104°F / 40°C
• It is recommended to turn off the camera while charging.
Problem Solution
Camera fails to start •The camera battery is
discharged. Charge
the camera.
•The camera has
encountered an error.
Press the Reset button.
Camera shuts-off
immediately after
starting
•The camera battery is
discharged. Charge
the camera.
•MicroSD card has
not been inserted. A
microSD card (not
included) is required
for recording.
•The microSD card is
full. Remove the files
saved on the microSD
card or insert a fresh
microSD card. Note
that on Mac, you must
empty the Trash to
delete video files from
the camera.
Device is not
recognized by
computer
•Mini-USB cable is
broken. Replace the
cable.
•USB port is broken. Try
a different USB port.
Troubleshooting
Overview

Waterproof End-cap
(Video-only)
Audio End-cap
(has holes for microphone;
not waterproof)
+
Getting Started
1. Unscrew the End-cap.
2. Connect the mini-USB cable to the camera. Connect
the other end to your computer.
3. Charge the camera for 4 hours to fully charge.
4. Disconnect the USB cable from the camera and
insert a microSD card (not included) into the
camera and push it down until it clicks into place.
NOTE: The camera can support microSD cards up to a
maximum size of 32GB.
Camera
mini-USB Port
5. Ensure there is an O-ring around the thread at the
back of the camera. Screw on the End-cap tightly to
ensure a waterproof seal.
6. Press and hold the Power/Record button for 2
seconds to turn on the camera. The camera begins
recording immediately. The blue LED flashes to
indicate recording is active.
microSD slot
microSD card
7. To stop recording, press and hold the Power/Record
button for 5 seconds.
Power/Record button
Accessing/Saving Videos on your
Computer
1. Connect the mini-USB cable to the camera
and connect the other end to your computer.
The computer will recognize the camera and
automatically install drivers.
2. Windows: An Autorun window appears. Click
Open folder to view files. If Autorun does
not appear, open Computer and double-click
Removable Disk.
3. Double-click the DCIM folder then the
100MEDIA folder to access your videos.
4. Your videos are saved in .mov format. Double-
click videos to open. Copy videos to a folder
on your computer to save them to your hard
drive.
NOTE: You may need to install Quicktime Player to watch
videos. Quicktime Player is a free download from
www.apple.com
Removable disk folder
Autorun window
Click Open folder to
view files
OR
Mac: Double-click the removable disk folder on
the Desktop.
System Requirements
• PC: Windows 7
• Mac: OS 10.5 or higher
• Minimum 10GB free hard drive space to
save recordings
Thread
O-ring
End-cap Types
Mounting Options
Use the included accessories to mount the camera. See the
examples below:
Velcro Headband
and Velcro Mount
Wraparound Velcro
Mount Attach to goggles
Plastic Mount and
Rubber Strap
TIP: Make sure the Power/Record button is pointed upwards
for easy access.
Wrap around head or
a bike helmet
Wrap around head
for swimming
Stick to helmet
Velcro Tape
