LSI GS026 User guide

WIRELESS TECHNOLOGY & CRANE INSTRUMENTATION
DIVISIONS
GS026
Radio Anemometer
Installer and user guide
WARNING'. Carefully read and understand this manual and the receiving
unit User's manual before proceeding.
IMPORTANT! Refer to the "GS320/GS550/GS820 Display & GS Series
Sensors - Installer and User's Manual" for complete information about
installation, operation, maintenance, certification and warranty.
LSI

-6
, Cotter pm
1. Overview
The GS026 is a battery powered radio
anemometer. The wind speed is calculated
from pulses of magnets inserted in the
rotor. No adjustment is necessary; the
anemometer never needs tobe calibrated.
The expected battery life with a lithium
battery is about 3 years.
Both the battery and rotor can be serviced
inthe field without tools.
2. Location
For optimal radio communication, mount
the anemometer on the same side of the
boom as the receiver unit, perpendicular to
the boom,andat the highest point possible.
3. Installation
<
Mast
Weld or screw the mast to the boom at the
selected position.
Note: Angle iron can be used to extend the
reach of the mast toclear theboomtip.
IMPORTANT/ Do not weld in
proximity to LSI sensor/transmitters.
The base of the mast can be used when
retrofitting the GS026 on a previously
installed GS020 anemometer rod. Make
sure the base of the mast is fully tightened
andadd the cotter pinat the rod tip.
The windspeed sensor mustpivot freely on
themounting mastat all boomangles.
The wind cupsmustbefully exposed tothe
windand spinfreely atallboomangles.
p H
/ rH/('""'"
Anemometer Cab '
There should be a clear and unobstructed
line of sight between the anemometer
sensor andthe cabin mounteddisplay unit.
Once the mast is secured in place the radio
anemometer can be inserted on the pivot
and secured in place by the washer and
hairpin.

FCC and IC —Instructions to
the User
This equipment has been tested and found to
comply with the limits for a class B digital device,
pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate
radiofrequency energy and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However, there is no guarantee that interference
will not occur in a particular installation. If this
equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the e9uipment off and on, the user is
encouraged to try to correct the interference by one
or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment
and receiver.
•Connect the equipment into an outlet on a circuit
different from that to which the receiver is
cOnnected.
•Consult the dealer or an experienced radio/TV
technician for help.
In order to maintain compliance with FCC
regulations, shielded cables must be used with this
equipment. Operation with non-approved
equipment or unshielded cables is likely to result in
interference to radio and TV reception.
This device complies with Industry Canada licence-
exempt RSS standard(s). Operation is subject to the
following two conditions: (1) this device may not
cause interference, and (2) this device must accept
any interference, including interference that may
cause undesired operation of the device.
This Class A digital apparatus complies with Canadian
ICES-003
IMPORTANT!
Changes or modifications to this equipment not
expressly approved by the pany responsible for
compliance could void the user’s authority to
operate the equipment.
FCC ID: QVBGS002 IC: 7076A-ICGS002
RF Exposure Warning:
This product complies with FCC/IC radiation
exposure limits set forth for an uncontrolled
environment. To comply with RF exposure
requirements, the unit must be installed and
operated with 20 cm (8 in.) or more between the
product and your body. This product may not be
collocated or operated in conjunction with any other
antenna or transmitter.

8. LSI Product Limited Warranty - IN EFFECT APRIL 1ST, 2013
LIMITED WARRANTY
LOAD SYSTEMS INTERNATIONAL INC. (hereafter “LSI”) warrants its products (the “Products”) will be free from
defects in materials and workmanship for a period as determined by the product family as indicated below (the
“Warranty Period“).
Warranty Duration
24 months
12 months
Product Family
GC Series Load Cells, GD Series Line Riders, GP Series Load Pins GS001, GS002,
GS003, GS004, GS005, GS007, GS010, GS011, GS012, GS020, GS030, GS031,
GS035, GS050, GS075, GS101, GS106, GS110, GS112, GS220, GS221, GS222,
GS224, GS550, GS820, LP Series Load Pins, LS051, LS055, PT00100
GS026, GS085,GS320,GS375
UnJess otherwise specified, the default Warranty Period for the Products is 12 months after delivery of such
product. Please consult LSI for any Product that is not listed in the above chart for further details.
The Warranty Period commences after delivery of such Products to the user (as evidenced on a LSI document)
subject to installation and use in accordance with specifications described in the LSI Installer and User’s Manual, as
amended from time to time, LSJ technical materials and any related writings published by LSI with respect with
such Products and any applicable industry standards.
During the Warranty Period, LSI or its designated service representative shall repair, or at its option, replace any
Product that is confirmed to be defective by LSI, in its sole discretion, in accordance with the Limited Warranty
Services Procedures described below.
WARRANTY SERVICES PROCEDURES
In order to benefit from this Limited Warranty, the purchaser must notify LSI’s customer service or LSI’s authorized
distributor or representative originally responsible for the sake of the Products within 10 days of the occurrence of
a Suspected defect in materials or workmanship, and in any case prior to the expiry of the Warranty Period. Timely
notification w’iII permit the purchaser to obtain a Return Authorization Number which will indicate return
procedures and terms and conditions of such returns. A proof of purchase of the Product, such as an invoice or a
receipt certifying the validity of the Warranty, must be presented in order to obtain Limited Warranty coverage. In
any event, even if a Return Authorization Number is provided to purchaser, LSI reserves the right to inspect the
damaged Product or part before its final decision to repair or replace the defective Product orpart.
The Product or part shall be returned to LSI or its designated service representative, accompanied by the Return
Authorization Number with prepaid shipping charges. The purchaser must insure the shipment or accept the risk of
loss or damage during the shipment. Purchaser shall also pay any tariff or duty applicable to the return of the
defective part or Product. LSI will, at its option, repair or replace the Product or part returned to LSI or to its
designated service representative. LSI owns all parts or Products replaced, repaired or removed from a repaired
Product. If LSI repairs a Product, the Product Warranty coverage Period is not extended and the Limited Warranty
shall expire as if uninterrupted at the end of the last month of the original Warranty Period from shipping from LSI.
If LII replaces a Product, the replaced Product is warranted for the remainder of the original term or sixty
consecutive (60) days, whichever is longer.
LSI reserves the right to require from the user or owner of the Products, prior to determining if the Limited
Warranty coverage is applicable, that LSI receive the data logging equipment used with the Products and that LSI
be authorized to retrieve all information from such data logging equipment in order to, among others, ensure that
the written instructions and applicable standards, including safety margins, were respected and not exceeded
during Product use. Failure by the owner or user of the Product to supply such information shall be deemed a
material default of the terms and conditions of this Limited Warranty and shall be irrevocablv construedas
