Owner’s Handbook
Right hand drive diesel models

CONTENTS
2
Page nos.
Foreword 3
General precautions 4
Vehicle locking and security 5
Driver's compartment - instruments and controls 12
Driver's compartment - heating and air conditioning 24
Driver's compartment - general equipment 27
Driving the vehicle 31
Passenger compartment - motion door locks 36
Passenger compartment - equipment 37
Passenger compartment - seats and seat belts 38
Passenger compartment - special facilities 41
Emergency procedures - flat tyres, vehicle recovery , jump starting etc. 47
Maintenance requirements 52
Replacements of bulbs and fuses 67
General information 74
Detailed index 76
Vehicle details inside rear cover
Warranties and service records, maintenance record ii-xvi

FOREWORD
3
This handbook describes the instruments,
switches, controls and equipment fitted to your
new vehicle and the way in which they are
designed to operate. Because this handbook
covers all right hand drive diesel models, some
items covered may not apply to your particular
vehicle. Recognised LTI Vehicles Dealers have
information about the latest specification of the
various models available.
Please read through this booklet before
operating your vehicle as it also includes
information essential to maintain the vehicle's
safety, reliability and economy. Take particular
note of the General Precautions on page 4.
Retain the booklet with the vehicle so that it is
available for reference when required.
Care and regular maintenance will prolong the
life of the vehicle. We strongly recommend that
the maintenance operations and replacements
scheduled at regular intervals and shown in
detail in this book are never overlooked and are
carried out by an Authorised LTI Dealer.
The back sections of this book contain details
of the vehicle and parts warranties, and a
section to record the maintenance services
(pages i to xii).
LTI Vehicles reserve the right to change their
servicing recommendations in the light of
operating experience. Having this work
performed by an Authorised Dealer will ensure
that any work performed will be in line with the
latest information issued by the manufacturer.
Certain notes in the text are highlighted as
follows:
WARNING: This information or
procedure should be carefully
followed to avoid the possibility of
personal injury or damage.
CAUTION: This information or
procedure should be carefully noted
to avoid damage to components.
Note: This information makes the job easier or
provides additional information.

GENERAL INFORMATION AND PRECAUTIONSGENERAL INFORMATION AND PRECAUTIONS
4
RADIO AND TELECOMMUNICATIONS
EQUIPMENT
Auxiliary electrical power connections are
provided to assist the fitting of radio
telecommunication equipment. These are three
two-pin connectors inside the driver's
compartment on the fuse board immediately
behind the fascia fuse box cover. One is
controlled by the ignition switch and two are fed
from the battery and controlled by a battery
protection relay (see later text for information
concerning the battery protection and warning
system). Note: whilst positions are provided for
these auxiliary power connections in the
underbonnet fuse box, fuses are not installed.
Whoever fits auxiliary equipment will need to
supply and fit the relevant fuses to the fuse box.
A 12 volt, 10 Amp power outlet is provided in
the front compartment for use with portable
equipment.
ALWAYS ENSURE RADIO TELEPHONE
COMMUNICATIONS EQUIPMENT IS FITTED
BY COMPETENT PERSONNEL AND DRAW
THEIR ATTENTION TO THIS FACILITY BUILT
INTO YOUR VEHICLE
TAXIMETER
You should be aware that defects which arise in
the operation of the taximeter and the related
vehicle electrical and electronic systems may
not be covered by warranty.
VEHICLE ELECTRICAL SYSTEMS
WARNING:
The electrical systems fitted to your
vehicle incorporates equipment and
electronic devices which are adequately
protected by fuses and other forms of
electrical protection to minimise any risk of
overheating or damage to components of the
vehicle. To prevent the risk of fire or noxious
fumes resulting from incorrect electrical
modifications or the fitting of additional
equipment, modifications or additions should
only be made by a competent and suitably
qualified auto electrician, so that vehicle
wiring is not overloaded and any additional
equipment is positioned with adequate
wiring and fuses. LTI Vehicles accepts no
responsibility for any damage caused by
incorrectly installed additional equipment.
LTI Vehicles recognises that taxis often stand
with the engine off, but with exterior and interior
lights and auxiliaries switched on and this can
quickly discharge the battery. In order to assist
the operator in routine taxi operation your
vehicle is fitted with a protection and warning
system that will turn off the auxiliary electrical
power connections 30 minutes after the vehicle
is vacated. This will prevent any auxiliaries that
might be left on from discharging the battery
any further. You will also be notified with an
audible signal one minute before the auxiliaries
are switched off. See the information on
automatic switching-off of the interior lights on
page 20 which also limits the risk of battery
discharge.
WARNING:
If additional equipment is installed on
the vehicle and it is not connected via
the auxiliary outputs provided, the vehicle
battery may become discharged to the point
where the vehicle will not start.
Always fit fuses of the capacity indicated on
the label fitted to the fascia fuse box and
electrical relay access cover and the plan of
underbonnet fuses and electrical relays
shown later in this book.Noxious fumes from
overheating electrical components can be
dangerous when inhaled. Never continue to
operate a vehicle which is suspected of
having an electrical failure.
OILS, FLUIDS AND SOLVENTS
Prolonged and repeated contact with used
engine oils may cause serious skin disorders
including dermatitis and cancer. Excessive
contact with used oils should be avoided -
always use barrier cream and wash thoroughly
after contact.
Many liquids and other substances used in
motor vehicles are poisonous and should under
no circumstances be consumed, or allowed to
come into contact with open wounds. These
substances, among others, include anti-freeze,
brake fluid, fuel, windscreen washer additives,
vehicle cleaning materials, all lubricants and
adhesives. Keep all such substances out of the
reach of children.
Always dispose of used oils and solvents etc. at
an approved Public Waste Disposal facility.
Never pour such material into the public
drainage system or allow them to seep into the
soil.
SERVICE INTERVALS
Your vehicle is designed to operate on a 10,000
mile service interval. Information on vehicle
servicing is included later in this book.

VEHICLE LOCKING & SECURITY
5
WARE 146B
A
Security systems.
The Anti Theft Systems fitted to the vehicle are
designed to minimise the risk of unauthorised
operation without using a correctly coded
remote key or ignition key. On all models the
remote key operates the central door locking
system. Each ignition key contains a
transponder which the security system
recognises.
An alarm upgrade system, fitted to some
models, provides perimeter protection of the
vehicle by switches covering the doors, bonnet
and boot, and interior ultrasonic detection of
movement in the driver’s compartment. When
this system is armed, if someone breaks into the
vehicle, opens the bonnet, boot or a door, the
hazard warning lights will flash and an alarm will
sound at full power for 30 seconds and then
stop, re-arming itself against any further
intrusion. However, the engine immobiliser will
continue to prevent the vehicle from being
driven away.
How to turn off ultrasonic detection
If required, the ultrasonic sensors may be
temporarily switched off - press lock button 4
times within 30 seconds, they will be re-enabled
next time alarm is set.
Remote key fobs
The battery operated, remote key fob emits a
coded radio signal which operates the security
and locking system when the key buttons are
pressed while adjacent to the vehicle. Whilst the
key buttons are pressed a small light (A) in the
key will illuminate to confirm the remote key is
operating.
Note: Avoid inadvertent and repeated pressing
of the remote key buttons, as ultimately this
could stop the security system responding
without being reprogrammed.
Keep remote keys clean and dry (shake off any
water which does get onto a key before
operating it), and never expose the keys to a
temperature exceeding 60°C (140°F).
Do not suspend or swing about your key ring
from the remote key fob. Take care not to trap,
crush or squash the remote key fob. Keep it dry
and do not immerse in liquid of any sort. Any
damage caused in this way may not be covered
by warranty.
If the battery in the remote key fob becomes
discharged the small light (A) will flash when the
key buttons are pressed. When this happens,
replace the battery in the remote key
(see page 7) before the battery becomes
fully discharged.
Remote key replacement
A maximum of four remote keys can be
programmed to operate the vehicle security
system. When a new or replacement remote key
is required it will be necessary for your dealer to
reprogramme all the remote keys at the same
time.

VEHICLE LOCKING & SECURITY
6
Arming and disarming the system
To lock the vehicle and arm the security system,
close the windows, vacate the vehicle and
ensure the doors, bonnet and boot lid are fully
closed before pressing the remote key button
(A) while adjacent to the vehicle. The light (B) in
the key will illuminate to confirm the key is
operating.
The hazard lights will flash once and any door
operated interior lights will go out.
If any door or the boot is open, hazard lights will
flash 5 times and the central door locking will
not operate.
To unlock the vehicle press the button (C) on
the remote key. The hazard lights will flash
twice, the doors will unlock and the interior
lights will come on.
WARE 395
B
A
C

VEHICLE LOCKING & SECURITY
7
Remote key batteries
Replace 23A 12V battery by removing the screw
in the back cover (A). Remove the battery (B)
from the terminals. Insert the new battery
ensuring the “+” positive marking is as shown.
Screw the cover back on tightly. Always use an
LTI specified battery.
CAUTION: Carefully dispose of the old
battery. Battery may explode if
recharged, incinerated or short
circuited.
WARE 396
B
A

VEHICLE LOCKING & SECURITY
8
Security system fault diagnosis
The security system installed in your vehicle
should give satisfactory service providing the
key fobs and ignition keys are treated with
reasonable care.
The following diagnosis chart may assist the
resolution of any unusual events which may
occur when using the system. Any problems
with the system which cannot be overcome by
following the procedures shown should be
referred to your Dealer for attention at the
earliest possible opportunity.
Remote key fails
to lock/unlock
the vehicle doors
Vehicle will not
start
Alarm upgrade
(where fitted)
activates with no
apparent cause
Symptom Check Remedy
Remote key may be wet Shake the remote key dry and re-try
Possible interference from high powered
local radio equipment Press the remote key a few times until the system activates
Check function of remote key (see page 5) If the battery is discharged replace the
battery in the remote key. If still inoperative,
try another remote key.
Use a multimeter to check the vehicle
battery is not below 9 volts Charge/replace the vehicle battery
Check vehicle ignition is switched off Turn off the vehicle ignition
Inertia switch has tripped Press top of it
Check above two items, if vehicle still fails
to start
Check Security LED is not flashing rapidly
Use another key
If still fails to start contact Dealer or recovery
organisation
Check all doors, bonnet, boot, centre
partition, windows (and sunroof) are fully
closed
Close the opening and re-arm the system
Check for moving objects in vehicle, air
fresheners etc. hanging from mirror Remove item and re-arm the system
People, pets etc. in vehicle Use the option to turn off the ultrasonic
detection system while vehicle is occupied
see page 5
Check all doors/boot and bonnet open Close the opening
5 Flashes on
Direction Indicators

VEHICLE LOCKING & SECURITY
9
Vehicle keys
The vehicle is supplied with two keys. Each key
operates the ignition/starter switch and steering
lock, driver’s door lock and luggage door lock,
the boot lid lock and the fuel filler cap lock. Each
key contains a transponder which the security
system recognises. Your Main Dealer can
provide and programme more keys to your
vehicle as required.
Note: When taking delivery, make a record of
the security number on the tab attached to the
Keys. This information is required should you
need to replace this key if it becomes lost or
damaged in service.
Important: When starting the engine do not use
the key with other transponder keys in close
proximity, even the spare key or transponder
keys from other vehicles.
Do not use the key with the key ring resting on
the key grip.
Central locking system
The remote key is used to operate the central
locking system. It will lock and unlock all four
doors. However, if the remote key is inoperative
or lost, the ignition key may be used in either
front door to unlock that door.
Note: Unlocking the vehicle doors with the
ignition key will not unlock the rest of the
vehicle. Neither front door lock is electrically
linked to the central locking system. When the
vehicle has been entered the rear doors may be
unlocked using the door mounted switch shown
overleaf. Only the remote key carries out the
central door locking function.
When the doors are unlocked by using the
remote key, both front and rear doors are
opened by lifting the outer door handles (C).
Small indicator lights (D) behind the rear door
handles illuminate when the taximeter is in the
'for hire' mode and the vehicle is travelling
below walking pace or stationary.
Important Note: Locking the vehicle doors with
the ignition key will not arm the security system.
However, the engine immobiliser will
automatically arm when the vehicle key is
removed from the ignition/starter switch and
steering lock.
Where an LTI alarm upgrade system is fitted,
and the security system was armed before
leaving the vehicle, the alarm will sound when
the vehicle doors are opened with an ignition
key.
Security feature 1
If the vehicle has been locked by use of the
remote key, using the ignition key in any front
door will unlock that door only.
Security feature 2
When leaving the driver’s compartment to assist
a passenger with the swivel seat and additional
step or wheelchair installation use the ignition
key to lock the driver’s door.
C
EURO 51
EURO 2 EURO 3
C
D
A
C

EIV 0004
VEHICLE LOCKING & SECURITY
10
WARE 34
A
B
C
D
Door locks
When the remote key is operated, or the door
key is turned, the interior locking catch (A) on
the front doors will move back to the unlocked
(catch out and orange marker showing) or
locked (catch in) position. When the door
locking catch is in the unlocked position, pulling
out the interior door release (B) will open the
door.
The interior looking catch (A) on each of the
front doors will lock or unlock that door only.
Use this facility to lock front doors individually to
suit your own operating requirements.
The interior locking catch on the rear doors will
unlock (But not lock) the door on which the
catch is operated.
Driver's security Iocking switch
For added driver security, a switch (C) in the
driver's armrest allows the driver to lock or
unlock doors from within the vehicle when
operated in the following way:
1. A single short press and release of the
switch (C) will lock the rear doors.
2. Pressing and holding the switch down will
lock the rear doors immediately and within
two seconds will lock the front doors so that
all four are locked.
WARNING: Whenever the central door
locking system is used it will override
this security locking switch, which
must then be reset as required following the
instruction above.
Boot lid lock
For security reasons the boot lid lock is not
operated as part of the central locking system,
so that when closed the boot is always locked
and can only be opened with the ignition key.
Turn the key clockwise in the lock (D) to release
the lock.
CAUTION: The boot lid should always
be closed when the vehicle is
operated to prevent exhaust fumes
being drawn into the vehicle.The boot lid is
not designed to carry loads when fully open
or to support loads when partially open.
CAUTION: Never leave children
unattended in the driver's
compartment as they could lock the
vehicle, and if the ignition/starter key is not
available it would then be difficult to release
them from the vehicle
EIV 0004

EIV 0005
VEHICLE LOCKING & SECURITY
11
D
B
C
A
EURO 5 EURO 6A
Fuel tank filler cap
The fuel filler cap (A) is locked with the ignition
key. Turn the key anticlockwise to release the
filler cap. After filling the fuel tank, replace the
cap and turn the key clockwise until it is fully
engaged before removing the key. Always use
the type of filler cap specified for your vehicle.
CAUTION: Cold fuel from an
underground storage tank will expand
when in the vehicle. Do not attempt to
fill the fuel tank to the brim of the filler neck,
as this could lead to fuel loss as the fuel
expands.
Bonnet
The bonnet lock release is located adjacent to
the side trim of the driver's compartment. Pull
the handle (B) to release the bonnet which will
then spring up onto its safety catch.
Push in the safety catch lever (C) located below
the centre of the front edge of the bonnet to
release the catch and then raise the bonnet.
WARNING: Particular care must be
taken to ensure no loose clothing (a
tie, etc.) can get caught up in any
rotating parts while the bonnet is open.
WARNING: For safety reasons the
bonnet must always be completely
closed when the vehicle is
driving/operating. After closing it always
check that it is completely secured. The
bonnet must be flush with the adjacent
panels.
Should you notice that the bonnet is not
safely secured when the vehicle is moving,
stop the vehicle immediately and close the
bonnet properly.
Bonnet support
Secure the bonnet in its open position by
unclipping the bonnet support stay (D) and
inserting it in the receptacle on the underside of
the bonnet.
When closing the bonnet, release the bonnet
support and replace it in its securing clip, then
close the bonnet by allowing it to slam lock in
place. Check the bonnet is fully locked in
position before driving the vehicle.
EIV 0005

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
12
1. Fascia air vent
2. Fuse box cover
3. Rear compartment illumination
4. Front compartment illumination
5. Fascia air vents
6. Front fog lights (where fitted)
7. Rear fog lights
8. Hazard warning switch
9. Headlamp beam level control
10. Lights and indicator column switch
11. Temperature gauge
12. Fuel gauge
13. Warning lights
14. Speedometer
15. Wipers and washer column switch
16. Fascia vent
17. Radio/CD Player Audio System
18. Heater air distribution control
19. Heated rear screen switch
20. Air conditioning switch (where fitted)
21. Intercom volume control
22. Heater temperature control
23. Intercom switch (on/off)
24. Heater recirculation switch
25. Heater fan speed control
26. Panel illumination dimmer
27. Horn
28. Steering lock & ignition/starter switch
29. Exterior mirror adjustment control
30. Bonnet release
31. Fuel cut off inertia switch
2
1

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
13
F
F
O
0
1
2
EIV 0006
3 4 5
6 7
MPH
TOTAL
8 9
10 11 12 13 14 15 16
17 18 19 20 21 22 23 24 25 26 27 28 29 30 31
TOTAL
TRIP
MPH
20
40
60 80
100
H
C F
E
ABS
20
40
60
80
100 120
140
160
KM/H
EIV 0006

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
14
TOTAL
TRIP
MPH
20
40
60 80
100
H
C F
E
ABS
20
40
60
80
100 120
140
160
KM/H
EIV 0007
A
EIV 0007
EURO 9A
STEERING LOCK, IGNITION AND STARTER
SWITCH
The starter switch has four positions:
OOff - the key may only be inserted or
withdrawn in the 'O' position. Withdrawal of
the key will cause the steering to lock when
it is turned.
IDisengages the steering lock and allows the
following auxiliary equipment to be used:
Radio/CD audio system
Front and rear electric windows
Front wipers and washers
Rear wiper and washer
Front heater blower
Intercom system
II Switches on the complete electrical system
and energises engine glow plugs as
required.
III Engages starter motor (reached through
spring resistance with self return to position
II when released).
WARNING: The steering lock must be
disengaged before releasing the
handbrake and manoeuvring the
vehicle without using the engine. Never
push the vehicle without a qualified driver in
position and with the steering lock
disengaged. Remember that brake servo
assistance is not available unless the engine
is running. Free wheeling is not permitted.
INSTRUMENTS
Speedometer, odometer and trip meter
The speedometer indicates the vehicle speed in
miles or kilometres per hour. The odometer
indicates the total distance the vehicle has
travelled.
The trip meter records the distance of an
individual journey. Before each journey for which
a record is required, push and hold button (A)
until the trip has zeroed.
Should the odometer or trip meter display any
information other than mileage, an instrument
pack fault is indicated. Take your vehicle to an
authorised LTI dealer so that the fault can be
diagnosed.
Fuel Gauge
With the ignition switch on, the gauge indicates
the approximate amount of fuel in the tank. 'E'
indicates empty, 'F' indicates full.

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
15
CAUTION: To avoid the need to 'bleed'
air from the fuel system, always avoid
any possibility of allowing the fuel
tank to run dry. If the tank should run dry,
the fuel system must be primed to exclude
air (page 56) before attempting to restart the
engine.
Temperature gauge
With the ignition switch on, the gauge indicates
the temperature of the coolant in the engine. 'C'
indicates cold, 'H' indicates hot. In normal
operating conditions, the temperature gauge
needle will take up a position in the middle band
of the gauge.
WARNING: Should the indicator
remain in the red 'H' sector when
driving, stop the vehicle as soon as
safely possible so that the cause may be
investigated at once to prevent damage to
the engine. See the section "In case of
emergency" for the immediate action
required.
Never remove the cooling system reservoir
filler or radiator caps while the engine is hot
since there is a danger of being scalded by
coolant which may spurt out from the filler.
INSTRUMENT PANEL WARNING LIGHTS
Warning light check
Some of the more important warning lights
illuminate as a bulb check every time the ignition
switch is turned to position II and before the
engine is started. These warning lights include:
Electrical charge (red)
Brake system (red)
Oil pressure (red)
Motion locks system (green)
Anti-lock braking system (yellow)
Engine Electronics Function (yellow)
Engine Management System (red)
WARNING: If either the Engine
Electronics Function (yellow) or
Engine Management System (red)
lamp illuminates or flashes when driving,
immediately reduce the vehicle speed. If one
continues to flash, avoid heavy acceleration
or deceleration. The engine will continue to
operate but at reduced power. Have the
vehicle checked out by an LTI Dealer
immediately.
WARNING: If the Anti-lock braking
system (yellow) lamp illuminates have
the vehicle checked out by an LTI
Dealer immediately.
The green motion locks system light will only
come on with the footbrake off.
The glow plug warning light will extinguish within
a few seconds when the system is operating
correctly and the engine may be started.
The electrical charge and oil pressure lights will
extinguish when the engine is started if these
systems are operating satisfactorily.
When the engine is running, the brake warning
light will extinguish when the handbrake is
released provided the braking system is
operating satisfactorily.
WARNING: If any indicator light fails to
come on, it may indicate an inoperative
warning light or an open circuit in the
electrical system. The condition should be
investigated and rectified promptly.
MPH
20
40
60
H
C F
E
ABS
20
40
60
80
100 12
0
KM/H
EIV 0008
EIV 0008

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
16
High beam indicator
Right hand and hazard
indicator
Oil pressure indicator
EIV 0009
Direction indicators.
Either the left hand or right
hand warning lamp will flash
green in time with the indicator lamps in the
direction determined by the direction indicator
switch. Both lights will flash together when the
hazard warning switch is on.
CAUTION: If the warning light flashes
incorrectly this indicates that a bulb in
the indicator circuit (front, side
repeater or rear) may have failed and should
be replaced at the earliest opportunity.
High beam indicator
This blue light comes on when the
headlamp high beam is on, and goes
out when low beam is selected.
Engine electronics function
If this illuminates, an engine
management system malfunction is
indicated. This may be the failure of an engine
sensor that will not stop the engine but will
result in a loss of power, increased emissions
and fuel consumption. Have the vehicle
checked out by an LTI Dealer immediately.
Engine management system
If this illuminates, engine management
control module malfunction is
indicated. In addition to a loss of power,
increased emissions and fuel consumption, the
engine may begin to lose power and may
eventually fail to restart. You are advised to
stop driving the vehicle and have it checked out
by an LTI Dealer immediately.
Brake light bulb failure indicator
This will illuminate if either right or left
hand brake light bulbs has failed. You
should attend to this immediately. Note: this
does not indicate any failure in the high-level
rear brake light mounted in the heated rear
window or of any other bulb on the vehicle.
Note: This feature will always illuminate as a
self-test each time the ignition is turned on and
will cancel the first time the brakes are applied.
Water in fuel indicator
This will illuminate if a significant
presence of water is detected in the
bottom of the fuel filter cartridge. This should be
attended to immediately by the draining of the
fuel filter (see page x). if this does not rectify the
condition you should have it checked out by an
LTI Dealer immediately.
Seat belt indicator
Not used in this variant
Security LED
This indicates the status of the engine
security system. It will flash regularly
when the ignition key is removed to indicate that
the engine immobilizer is active. See security
system diagnosis on page 8 for further detail.
Lights continuously when the ignition key is
turned to position II. Extinguishes when the key
has been recognised. Flashes rapidly if fault is
present.
Left hand direction
indicator
Engine electronics function
Engine management
system
Brake light bulb failure
indicator
Water in fuel indicator
Seat belt indicator
Security LED
Windscreen washer
fluid level
ABS
Anti Lock Braking System
Indicator (ABS)
Braking system indicator
Electrical charge indicator
Glow plug indicator
Left hand rear door ‘open’
indicator
Right hand rear door
‘open’ indicator
Motion locks system
indicator
Low fuel level warning light

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
17
condition with the braking system which
requires immediate investigation before driving,
or after safely stopping the vehicle.
Firstly check the brake fluid level has not fallen
appreciably, indicating a leak in the brake
hydraulic system. If the level is incorrect, the
source of the leak must be corrected
immediately by a competent technician before
the vehicle is operated further.
If the brake fluid level and pedal effort are
correct, with the handbrake off, the light will
come on when the brake pedal is pressed to
indicate the front brake pads are worn and
should be replaced as soon as possible.
Electrical charge indicator
Glows red when the ignition is turned on
and goes out when the engine has been
started and the electrical system is being
charged by the alternator.
CAUTION: If the warning light fails to
go or comes on whilst driving, you
must stop the vehicle and consult your
LTI Dealer immediately who will arrange to
have it checked out.
Glow plug indicator
Glows orange when the engine glow
plugs are used prior to starting the
engine (see steering lock and starter switch
page 31). The light will go out when the engine
may be started.
Rear door 'open' indicators
With the ignition switched on,
the left hand or right hand
indicator will flash red when the related left hand
or right hand rear door is not closed,
Windscreen washer fluid level
Glows orange when the fluid reservoir
requires replenishment.
(Approximately 1.4l. remaining from 3.8l.)
Oil pressure indicator
Glows red when the ignition is turned on
and goes out when the engine has been
started and the oil reaches working pressure.
Should the indicator light not go out, or come on
at any time while the engine is running, the
engine should be stopped at the first available
opportunity and the reason for the low oil
pressure investigated.
CAUTION: Running an engine with the
warning light on could result in serious
damage to the engine.
Anti Lock Braking System Indicator
(ABS)
The ABS control module monitors the
operation of the system from ignition ON to
ignition OFF. If the lamp illuminates this will
indicate a fault in the anti lock braking system.
The braking system will continue to operate
conventionally and with the same standard as
vehicles not equipped with ABS.
CAUTION: If the warning light comes
on whilst driving, consult your LTI
Dealer immediately who will arrange to
have it checked out.
Braking system indicator
This light glows red with the ignition on
and the handbrake applied, and
normally goes out when the handbrake is
released. If the light glows at any other time with
the handbrake released, it indicates a potential
supplemented by an intermittent warning
buzzer. If the vehicle is moved with a rear door
open, the audible warning will be continuous
and of higher intensity.
Motion locks system indicator
With the ignition on, and the vehicle
stationary with the foot brake off, the
indicator will glow green when it is possible for
the rear door to be opened from the inside. As
soon as the footbrake is applied, or the vehicle
moves off, the green indicator light will go out.
The doors will remain locked until the footbrake
is released (see motion door locking system -
page 35)
Low fuel level warning light
If the fuel gauge indicates low fuel or the
low fuel warning light illuminates, please
refuel immediately.Some time after the low fuel
level warning light has illuminated, when the fuel
reaches a very low level, the engine will start to
run unevenly as an additional warning. Proceed
to the next filling station and refuel with at least
8 litres of fuel. Failure to refuel will result in the
engine running dry. This will lead to a difficult
restarting procedure which requires roadside
assistance. Also, serious engine damage may
occur.WARNING: If the green light remains
on when the footbrake is held on with
the rear doors closed, or when the
vehicle is in motion, the condition should be
investigated and corrected as soon as
possible. If the green light fails to come on
when the footbrake is released and the
vehicle is stationary, there is a fault in the
system which should be investigated.
ABS

DRIVER’S COMPARTMENT - INSTRUMENTS AND CONTROLS
18
WINDSCREEN WIPERS AND WASHERS
Push the switch arm down to operate the front
wipers.
Off
Timed interval wipe
Wipers operate at slow speed.
Wipers operate at fast speed.
Pull the lever towards you (A) against spring
pressure to operate the windscreen washers;
the wipers will operate for a number of sweeps
and will park when the lever is returned to the
'off' position.
Certain models have an optional feature that
switches the windscreen wipers to timed interval
wipe when slow speed wiper operation is
selected and the vehicle speed falls below
5 mph. This feature can be overridden by
turning the wipers off then immediately turning
them on again. After being overridden the
feature will be reset to operate again after the
vehicle speed next exceeds 5 mph/8 kmh.
REAR WINDOW WIPER AND WASHER
The additional switch (B) operates the rear
wiper.
OFF Off
Turn the switch clockwise to
first position to operate the rear wiper
intermittently at a single frequency,
2nd position for continuous operation.
Turn the switch anti-clockwise against spring
pressure to operate the rear wiper and washer.
On return to the 'off' position the rear wiper will
operate for a number of sweeps and then park.
Auto-rear wipe
The rear wiper will operate for two
wipes when reverse gear selected and
front wipers on.
CAUTION: Do not operate the
washers if the fluid reservoir is empty.
Always keep the windscreen washer
reservoirs topped up with clean water and a
proprietary washer fluid additive diluted in
line with the manufacturer's instructions. If
the low wash level warning light is on, the
rear washer is disabled.
OFF •
•
•
•
•
B
A
WARE 306
