MAGBEAST 5 Operation and maintenance manual

_____________________________________________________
Operator’s manual for MAGBEAST 5 Drilling Machine
- 1 -
SAFETY INSTRUCTIONS
AND OPERATOR’S MANUAL
FOR
DRILLING MACHINE
MAGBEAST 5
JEI Solutions LTD
Unit 30 & 31 New Hall Hey Business Park
New Hall Hey Road, Rawtenstall, Rossendale, Lancashire
BB4 6HR United Kingdom
Tel: [phone] Fax: [phone]
E-mail: [e-mail] Web: www.jeiuk.com

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 2 -
IMPORTANT SAFETY INSTRUCTIONS
WARNING
When using electric tools, basic safety precautions should always be followed to reduce risk of fire,
electric shock and personal injury.
READ AND SAVE ALL INSTRUCTIONS FOR FUTURE REFERENCE
Before use, be sure everyone using this machine reads and thoroughly understands this manual as
well as any labels or warning attached to this machine.
1. Keep Work Area Clean
2. Consider Work Area Environment
Do not expose power tools to rain.
Do not use power tools in damp or wet locations.
Keep work areas well lit.
Do not use tool in presence of flammable liquids or gases.
3. Guard against Electric Shock
Prevent body contact with grounded surfaces. For example: pipes, radiators, ranges,
refrigerator enclosures.
4. Keep Children Away
Do not let visitors contact tool or extension cord.
5. Store Idle Tools
When not in use, tools should be stored in dry and high or locked-up place, out of reach of
children.
6. Do Not Force Tool
It will do the job better and safer at the rate for which it was intended.
7. Use Right Tool
Do not force small tool or attachment to do the job of a heavy-duty tool.
Do not use tool for purpose not intended - for example; do not use a circular saw for cutting
tree limbs or logs.
8. Dress Properly
Do not wear loose clothing or jewellery; they can be caught in moving parts.
Rubber gloves and non-skid footwear are recommended when working outdoors.
Wear protective hair covering to contain long hair.
9. Use Safety Glasses
Also use face or dust mask if cutting operation is dusty.
10. Do Not Abuse Electrical Cord
Never carry tool by cord or yank it to disconnect from receptacle.
Keep cord from heat, oil and sharp edges.
11. Secure Work
Use clamps or a vice to hold work. It is safer than using your hand and it frees both hands to
operate tool.
12. Do Not Overreach
Keep proper footing and balance at all times.
13. Maintain Tools with Care
Keep tools sharp and clean for better and safer performance.
Follow instructions for lubricating and changing accessories.
Inspect tool cords periodically and if damaged, have repaired by authorized service facility.
Inspect extension cords periodically and replace if damaged.
Keep handles dry, clean and free from oil and grease.
14. Disconnect Tools
Unplug when not in use, before servicing and when changing accessories, such as blades,
bits and cutters.
15. Remove Adjusting Keys and Wrenches
Form habit of checking to see that keys and adjusting wrenches are removed from tool before
turning it on.
16. Avoid Unintentional Starting
Do not carry plugged-in tool with fingers on switches.
Be sure switches are off when plugging in.

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 3 -
17. Outdoor Use Extension Cords
When tool is used outdoors, use only extension cords intended for use outdoors and so
marked.
18. Stay Alert (Do not use when taking medications that may cause drowsiness.)
Watch what you are doing. Use common sense. Do not operate tool when you are tired.
19. Check Damaged Parts
Before further use of the tool, a guard or other part that is damaged should be carefully
checked to determine that it operates properly and perform its intended function. Check for
alignment of moving parts, binding of moving parts, breakage of parts, mounting and any other
conditions that may effect its operation. A guard or other part that is damaged should be
properly repaired or replaced by an authorized service centre. Do not use this tool if
switches do not turn it on and off. Have defective switches replaced by authorized
service centre.
WARNING: SPECIAL INSTRUCTIONS
1. Read and follow operator's manual thoroughly. If you cannot locate your operator's manual
FAX JEI Solutions LTD at 00 44 1706 830496 for an additional FREE copy.
2. DO NOT touch rotating cutter or parts.
3. Always stop machine completely and unplug from power source before changing cutters,
cleaning clips, refilling lubrication or performing adjustments.
4. Never wear loose clothing or gloves when working near cutting area or machine arbor.
5. Always wear eye protection. Any tool can shatter.
6. Always use safety chain or strap provided with machine.
7. Always use proper tooling, keep cutters securely fastened.
8. DO NOT use dull or broken cutters.
9. Beware of ejected slugs at end of cut, they become HOT during the cut.
10. Magnet will not hold properly on thin materials under 3/8" (9.5mm), rough or dirty surfaces.
11. Keep all safety features functioning and working properly.
12. Keep bottom of magnet burr free and clear of chips and debris.
13. To reduce the risk of electrical shock, DO NOT remove or alter electrical panels or use
machine in damp areas.
14. Use only authorized service centres for repairs.
Grounding Instructions
Warning! READ ALL INSTRUCTIONS
MAGBEAST 5 drilling machine must be connected to "protected power source" which is properly
grounded.
Improperly connecting the grounding wire can result in the risk of electrical shock. Check with a
qualified electrician if you are in doubt as to whether the outlet is properly grounded. Do not modify
the plug provided with the tool. Never remove the grounding prong from the plug. Do not use tool if
the cord or plug is damaged, have it repaired before using. If the plug will not fit the outlet, have a
proper outlet installed by a qualified electrician. The MAGBEAST 5 must be plugged into an
appropriate outlet, properly installed and grounded in accordance with all codes and ordinances. If in
doubt of proper grounding, call a qualified electrician.

_____________________________________________________
Operator’s manual for MAGBEAST 5 Drilling Machine
- 1 -
Specifictions
Maximum hole cutting capacity
diameter
Ø200mm
Maximum tapping capacity
diameter
M52
Spindle bore
Morse taper 5
Speed
4 gear - variable
28 - 450 RPM
Motor
Single phase 230V - 25-60Hz
Total power consumption
(motor and magnet)
3000W
Width
(with handles)
300 mm
Length
540 mm
Height
(min / max)
710 mm / 975 mm
Stroke
305 mm
Weight
(nett weight)
53 kg.
Magnet
+
Magnet dimensions
(width x length)
140 mm x 295 mm
Magnetic deadlift
(min 25mm plate thickness
and 20°C)
2300 kg
Vibration Level
< 2,5 m/s2
List of Contents with Magnetic Drill Unit
Wooden Box
Magnetic Drill Unit
Operators Mannual

_____________________________________________________
Operator’s manual for MAGBEAST 5 Drilling Machine
- 1 -
Eyebolt
For easy lifting and
handling of the machine
Lifting Handle
For easy handling and
moving of the machine
Motor
3000W
Capstan Arm
With large Gear
Ratio. Fast attach
conection for both
right and left slide
Morsetaper 5
Control Panel
Stabliser
For easy handling
and moving of the
machine
Powerful Magnet
2300kg deadlift. Adjustable
(distance from the magnet to the
spindle can be adjusted)

_____________________________________________________
Operator’s manual for MAGBEAST 5 Drilling Machine
- 1 -
Stopping &Starting the machine
Variable SpeedControl

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 2 -
Use of CuttingFluid
Magbeast 5 has 5 Morse Taper spindle drilling. To be used with metal cutters,
there is a necessity to use a 1.1/4’’ adapter. For this use the 1 1 / 4 ”Weldon
shank is the most common. This shank has a dimension of Ø31, 75 x 60mm
and has two surfaces for the locking screws.
When using large cutter dimensions, it is extremely important that the cutter is
properly fastened in the adapter before drilling begins. Incorrect attachment can
cause damage to cutter and adapter. Always make sure to use the following
procedure to fasten the cutter:
•Always disconnect the power supply when you change cutter or doing
adjustments to the machine.
•Insert cutter with pilot into the spindle. Make sure that the two locking
surfaces are appropriate in relation to the 2 screws. Press the cutter
completely skank completely into the adapter.
•First tighten one single screw gently so that the screw turns the cutter
into position. Help rotating the cutter if necessary.
•Tighten the screw, release and tighten the screw again.
Tighten the second screw properly.
Then after tightening the first screw again.
1 ¼” Weldon Shank

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 3 -
Adjustment of slide
Tips for keeping your machine in correct working order
In order to ‘get the best life’ out of your magnetic drill machine, always keep in good working order. A well
maintained machine is a happymachine.
A number of items must always be checked on magnetic drilling machines.
Always before startinganyjob, makesurethemachineis in goodworkingorderandthat there are no damaged or
loose parts. Anyloose parts must be tightened.
Before proceeding with anymaintenance work, be certain that the power supply is disconnected.
Everyday
Once a Week
Once a Month
Visual check on machine for damage
X
Operation of machine
X
Check of magnetic base
X
Check of brush wear
X
Check Alignment of machine
X
Check of grease
X
Check armature
X

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 4 -
Visually check the machine for damage.
Machine mustbe checkedbeforeoperation for anysigns ofdamage that will affectthe operation of the machine.
Particularnoticemustbetaken of the mains cable, if the machine appears to be damaged it should not be used
failure to do so maycause injuryor death.
Check operation of the machine.
The machines operation must be checked to ensure that all components are working correctly.
Machines Carbon Brushes.
The Machines Brushes should be checked to make sure there is no abnormal wear present. This should be
checked at least once a week if used frequently. If the brush has worn more than 2/3 the original length the
brushes should be changed. Failure to do so maycause damage to the machine.
Machines Magnetic base.
Before every operation the magnetic base should be checked to make sure that the base is flat and there is no
damage present.An uneven magnetbasewillcausethemagnetnotto hold as efficientlyand maycause injuryto
the operator.
Adjustment of slide and bearing bracket Alignment.
An essential requirement of the machine is thatthe slide can move in a smooth and controlled manner,free of
lateral movement and vibration.
This situation can be maintained byperiodic adjustment of the slide and is accomplished.
Check machines grease.
The gearboxgrease should be checked once a month to ensure all moving components are covered to prevent
wear. The grease should be changed at least once a year to ensure you gain the best from the machine.
Check Armature of the machine.
This should be checked at least 1 per month to see that there are visual signs of damage to the bodyor to the
commutator.Somesignsof wear will be seen on the commutator over a period of time.This is normal as this is
the part that comes in contact with the brushes but any signs of abnormal damage and the part should be
replaced.

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 5 -
Solutions for Drilling Problems

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 6 -
Neither Magnet or Motor is working
The magnetic switch is not powered
Damaged or defective wiring
Damaged or defective fuse
Faulty magnetic switch
Defective control box
Faulty power supply
Magnet is active, but motor does not turn
Damaged or defective wiring
Brushes are stuck or too worn
Faulty magnetic switch
Defective stop/start switch
Defective control box
Defective armature or field
Motor runs but magnet is not getting
activated
Fauly magnet
Defective control box
The cutter breaks and/or making holes
larger than the size ofthe cutter
Clearance in the machines controls and/or slide function
Bent or sprung shaft
Curved centre point
Faulty or insufficent magnetic holding power
Contact between the magnetand workpiece
The motoris pulling heavilyand/or stops
Bent or warped shaft
Bearing bracket adjusted incorrectly
Contamination between spindle and bearing bracket
Noise in the motor/gearbox
Worn bearing between gearboxand motor
Damaged drives in the gearbox
Low amount of grease in the gearbox
Troubleshooting Magbeast 5

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 7 -
The motorscores,brushfires andlittle or
no power
Damaged Armature
Damaged Field
Damaged or Worn Brushes
The motor does not start or stop
Damaged or defective wiring
Contaminated reader
Defective or loose magnet in reader for speed control
Damaged or defective brushes
Heavy feed motion
Slide adjustments are tightened too hard
The slides, sliding surfaces are too dry
Shaft/Rack are contaminated
Magnetic holding power is too low
Damaged or decetive wiring
The work area/surface is not clean and/or dry
The work area/surface has poor magnetic ability
The work area/surface is not flat
The work area/surface is too thin (thinner than 10mm)
Motor onlyruns at maximum RPM
Damaged or defective wiring
Faulty control box
The operator recieves an electric shock
Damaged or defective wiring
Faulty magnet
The motor is heavilypolluted
Fuse blows when magnet is activated
Damaged or defective wiring
Faulty magnet switch
Defective control box
Faulty magnet
Fuse blows when starting the motor
Damaged or defective wiring
Defective armature and/or field
Motors running too fast
Worn brushes
Defective control box
Troubleshooting Magbeast 5 (cont.)

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 8 -
Magbeast 5 Parts Diagram
Magbeast 5 Parts diagram

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 9 -
Parts Breakdown

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 10 -

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 11 -

MAGBEAST5
Operator’s manual for MAGBEAST5 Drilling Machine
- 12 -
JEI Six (6) month limited warranty
JEI Solutions warrants the Magbeast 5 Drilling machine to be free of defects in material and
workmanship under normal use for a period of six months from date of purchase. This
warranty does not cover damage or wear which arise from misuse, accident, tampering or
any other causes not related to defects in workmanship or materials. This warranty is
conditioned upon the prepaid return of the Magbeast 5 Machine to JEI Solutions Ltd, Unit
30, Newhallhey Business Park, Rossendale, Lancs. Or our International representative for our
international customers for examination and verification of the claimed defects. If defect is
verified, JEI Solutions Ltd will replace, free of charge, any defective parts. If inspection of the
machine does not disclose any defect in workmanship or materials, the original purchaser
will be notified by JEI Solutions Ltd, or its representative, of the costs of necessary repairs. If
repairs are authorized, repairs will be made and the costs of repair and return transportation
will be billed through the customer’s distributor.
THIS WARRANTY IS EXCLUSIVE, AND IS IN LIEU OF ANY OTHER WARRANTIES (EXPRESSED OR
IMPLIED) INCLUDING WARRANTY OF MERCHANT ABILITY OR FITNESS FOR A PARTICULAR
PURPOSE, SPECIAL AND CONSEQUENTIAL ARE EXPRESSLY EXCLUDED AND DENIED
JEI SOLUTIONS LTD
UNIT 30, NEWHALLHEY BUSINESS PARK
NEWHALLHEY RD, RAWTENSTALL
ROSSENDALE, LANCASHIRE
BB4 6HR
TEL: [phone] FAX: [phone]
EMAIL: [e-mail] Website: www.jeiuk.com
