Magellan® Maestro™ 3250
Reference Card
Keep this Reference Card handy in your glove box for quick
reference to the basic operation of the Magellan Maestro.
•
olHl-,
SO / MMC Card Slot
On /Off Button (press and hold
for afew seconds to turn the
receiver on or off)
Reset.
FM Antenna Input (Used for traffic
information)
USB port. (External Power
Connection)
© 2007 Magellan Navigation, Inc. All rights reserved.
The Magellan logo, Magellan, and Maestro are trademarks of Magellan Navigation, Inc.
Magellan® Maestro™ 3250
Reference Card
Keep this Reference Card handy in your glove box for quick
reference to the basic operation of the Magellan Maestro.
•
SO /MMC Card Slot __ --1
On /Off Button (press and hold -J
for afew seconds to turn the
receiver on or off)
Reset.
FM Antenna Input (Used for traffic
information)
USB port. (External Power
Connection)
© 2007 Magellan Navigation, Inc, All rights reserved.
The Magellan logo, Magellan, and Maestro are trademarks of Magellan Navigation, Inc.

Main Menu
View Map Screen
Create aroute to
an
~~ address
Create aroute to a
point of interest
Route to home
address
Main Menu (while routing)
Create aroute with
multiple destinations
Search for POls
on
approaching off-ramps
=:;=, Select user options
Access BlueTooth
functions
Accesses AAA
Roadside Assistance
Screen
Return to Map
Screen
Iiiii~' Search for POls
on approaching
1Joo!~'" off-ramps
_"'It"""':1 Cancel existing
route
Detour
on existing
route
Access BlueTooth
functions
Accesses
AAA
Roadside Assistance
Screen
Main Menu
Main Menu (while routing)
Access BlueTooth
functions
Accesses AAA
Roadside Assistance
Screen
Create aroute with
multiple destinations
Search for POls
on
approaching off-ramps
:;:::;=, Select user options
View Map Screen
Create aroute to
an
~~ address
Create aroute to a
point of interest
Route to home
address
Return to Map
Screen
Iiiiii~' Search for POls
on approaching
""""~... off· ra m ps
_"'r""':1 Cancel existing
route
Detour
on existing
route
Access BlueTooth
functions
Accesses
AAA
Roadside Assistance
Screen

Map Screen Details
EEverqreen A I:!
B
o
In: 0.8 mi
E ;.;....-"'!'" F
'slance: 16 mi
-....;.;.;;;.. G
ACurrent street name.
BDirection of travel. Tap to display Locate screen.
C Zoom out.
o Turn instructions for next manuever. Tap to display maneuver
list. (Available only when routing.)
ECurrent time. While routing, displays distance to next
maneuver
and if tapped, repeats last manuever.
FAccess Main Menu.
GPresent speed. While routing, displays distance of route,
time remaining
on the route or estimated time of arrival.
HStreet name for next maneuver. (Available only when
routing.)
IVolume control.
J Zoom in.
KSatellite Status. Tap to display additional satellite
information.
Reading the
information bar
......-,..-,;,;,,;E_la;,.Rd·~.l m',
In: 1.1 mi mv..."
Left turn in 1.1 miles on N. Ela Rd. Will arrive at final
destination
in 4.1 miles.
Map Screen Details
EEverqreen AJ!
oS rlmro·
'slance: 16 mi
""'--......;..;..;.;.;.; G
F
A, Myrtle Ave
•
,n: 0.8 mi
E
B
o
ACurrent street name.
BDirection of travel. Tap to display Locate screen.
C Zoom out.
o Turn instructions for next manuever. Tap to display maneuver
list. (Available only when routing.)
ECurrent time. While routing, displays distance to next
maneuver
and if tapped, repeats last manuever.
FAccess Main Menu.
GPresent speed. While routing, displays distance of route,
time remaining
on the route or estimated time of arrival.
HStreet name for next maneuver. (Available only when
routing.)
IVolume control.
J Zoom in.
KSatellite Status. Tap to display additional satellite
information.
Reading the
information bar
/-:;;.&.,;,;,,;E;,;;la;,.Rd ............
mv
.1 m',
In: 1.1 mi rnv..."
Left turn in 1.1 miles on N. Ela Rd. Will arrive at final
destination
in 4.1 miles.

Satellite Signals
4bars green: Strong signal.
Blank:
No satellite signals.
Unable to compute position.
Tap on the satellite status
icon to get avisual
representation of the
satellites and signal strength.
GPS Status
For detailed GPS information, access the MFG GPS Status screen.
Main
Menu> User Options> GPS Options> GPS Status.
Tips on improving satellite signal strength
.. Leave the garage or parking structure so the GPS receiver has a
clear view of the
sky .
.. Move away from large structures or overhanging trees that may
interfere with satellite reception.
.. You may need to relocate the Magellan Maestro in your vehicle to
have abetter view of the sky.
This receiver may not be able to get satellite signals while indoors. If you
are not getting strong satellite signals, go outside and follow the tips
provided above.
Satellite Signals
4bars green: Strong signal.
Blank:
No satellite signals.
Unable to compute position.
Tap on the satellite status
icon to get avisual
representation of the
satellites and signal strength.
GPS Status
For detailed GPS information, access the MFG GPS Status screen.
Main
Menu> User Options> GPS Options> GPS Status.
Tips on improving satellite signal strength
l1li Leave the garage or parking structure so the GPS receiver has a
clear view of the
sky.
l1li Move away from large structures or overhanging trees that may
interfere with satellite reception.
l1li You may need to relocate the Magellan Maestro in your vehicle to
have abetter view of the sky.
This receiver may not be able to get satellite signals while indoors. If you
are not getting strong satellite signals, go outside and follow the tips
provided above.

Routing to an Address by City
ENTER
CITY
-
.'<~<I.~
I , • • ... • 0 •
Select City Nam.
an Diego, CA
San Di.go, 1)(
San Dimas, CA
.-~ .. ~.~
~~.>o(" .
- -. .
~ .... ~: ...
•
..... ~at~3..-........
Select Strffl Nam.
N. lone Hili Ave
Keypad: Type in the first .I
few characters of the city. ~
(
I~E~~~~ Keypad: Enter the
street name. You
.,
do not need to add
---+ .direction prefixes
(N,
E, W, S, etc.) but you can if
desired to
limit the number of
streets displayed.
100·699
The Map screen will be
displayed and you wi II be
provided routing instructions.
Please refer to the User Manual on the
CD-ROM for more information on using
the keypad feature of the Magellan
Maestro.
Routing to an Address by City
ENTER
CITY
-
.. <~.,.~
I I • I ... • 0 •
Select City Nam.
an Diogo, CA
San Di.go, 1)(
San Dimas, CA
~E·' 'C" "
- -. ,
~-. ~
_~~at(he~ 3-........
Select S11ff1 Nam.
N. I.on. Hili Av.
Keypad: Type in the first .I
few characters of the city. ~
(
'I~I~~~~ Keypad: Enter the
•• street name. You
do not need to add
---+ . direction prefixes
(N,
E, W, S, etc.) but you can if
desired to limit the number of
streets displayed.
100·699
The Map screen will be
displayed and you
wi II be
provided routing instructions.
Please refer to the User Manual on the
CD-ROM for more information on using
the keypad feature of the Magellan
Maestro.

User 0rtions . System Settin~.s _
User Options
Region
System Settings
+ Trip Computer
POI Selection
Address Book Option s
Volume: Tap 'Mute' to turn the speaker on or off.
Tap on the slider bar to change the speaker volume.
Brightness: Tap on the slider bar to change the
display brightness. Select 'On-battery dimming
(75%)' to conserve battery life while not connected
to external power.
Power: Select the duration that the receiver will turn
off
if not moving or the touchscreen is not touched.
Language: Choose the language that will be used to
display information and voice prompts.
Time Zone: Choose your local time lone. Select
'Daylight Savings' when applicable to your area.
(Note: the Magellan Maestro does not automatically
change the daylight savings setting.)
Units of Measure: Select either 'Miles/Feet' or
'Kilometers/Meters' to assign the units of measure.
System Status: Tap the' Next' button to access the
System Status where
you can view product
information or run diagnostics.
605-0008-001 A
User Options· System Settin~.s _
User Options
Region
System Settings
+ Trip Computer
POI Selection
Address Book Option s
Volume: Tap 'Mute' to turn the speaker on or off.
Tap on the slider bar to change the speaker volume.
Brightness: Tap on the slider bar to change the
display brightness. Select 'On-battery dimming
(75%)' to conserve battery life while not connected
to external power.
Power: Select the duration that the receiver wi II turn
off
if not moving or the touchscreen is not touched.
Language: Choose the language that will be used to
display information and voice prompts.
Time Zone: Choose your local time lone. Select
'Daylight Savings' when applicable to your area.
(Note: the Magellan Maestro does not automatically
change the daylight savings setting.)
Units of Measure: Select either 'Miles/Feet' or
'Kilometers/Meters' to assign the units of measure.
System Status: Tap the' Next' button to access the
System Status where
you can view product
information or run diagnostics.
605-0008-001 A

~ Planner
Use Address, Address
Book,POls or Intersection to
select destination. Repeat
123 yZ
OK
...
ABC 0 E F G H
K l M N 0 P
QR STU V W x
Trip N~me
-~ - - -
---- ------
Add Address to Trip
New Trip: SAMPLE
JOHNS
Cancel
Tap on
Add
~
cII5tIMtiOIIIn
Mov.Up
liSt \0 Ilriq& ..
Move Down
menu.
D~ete
Guide Me
Use the 'Guide Me' button to
access
this trip.
~ Planner
---- ------
Repeat
123 Y 2
OK
Use Address, Address
Book,POls or Intersection to
select destination.
QR STU V W x
...
ABC 0 E F G H
K L M N 0 P
Trip N~me
Add Address to Trip
New Trip: SAMPLE
JOHNS
Cancel
Tap on
Add
~
destillltiOft In
Mov.Up
liSt \0 briq& tIP
Move Down
menu.
Defete
Guide Me
SAMPLE
Use the 'Guide Me' button to
access this trip.

Exit POls
Exit POls can be accessed ONLY while travelling on a
freeway. If
you try to use Exit POls while not on afreeway, a
warning
Will be displayed indicating that it is not available.
--~----------------~-
Exit (mil Select Exit
1.0
TI »
I!:!l
1.0
TI
» I!:!l
~
3.l
TI
It I!:!l
45
TI
~
6.0
TI D
I!:!l
The Magellan Maestro takes the upcoming exits and
computes which restaurants,
gas stations, and hotels are
near the exit.
If there are no POls for acategory near
the exit, the icon for that category will not
be shown.
Tap on the icon for the category and the exit you want to use:
POI Selection
t1.0 lIli
~ 1110 WGlad,ton, Sl 909 S91 SJ71
.-
Ch~ron
Mobil
Arco
Gas stations at 1.0 mi exit
POI SfiKtion
- O.5ml
104 Villag. (I 909 S99 lJ61
I
Red Root Inn-San Dimas
Ertended Stayamt'rica
Comtort Suites-San Dimas
Hotels at 1.0 mi exit
Tapping
on a POI in the list brings up the Route Method
screen.
To create aroute to the POI chosen, tap on the
orange "Calculate Route" icon.
Exit POls
Exit POls can be accessed ONLY while travelling on a
freeway. If
you try to use Exit POls while not on afreeway, a
warning
Will be displayed indicating that it is not available.
Exit (mil Select Exit
1.0
TI »
I!:!I
1.0
TI
D I!:!I
~
3.l
TI
It I!:!I
45
TI
~
6.0
TI
It I!:!I
The Magellan Maestro takes the upcoming exits and
computes which restaurants,
gas stations, and hotels are
near the exit.
If there are no POls for acategory near
the exit, the icon for that category will not
be shown.
Tap on the icon for the category and the exit you want to use:
POI Selection
t1.0 lIli
,
11110WGlad,toll,SI 909 S91 SJ71
.-
Ch~ron
Mobil
NCO
Gas stations at 1.0 mi exit
POI SfiKtion
- O.5ml
,704 Villag, (I 909 S99 2361.
Red Root Inn-San Dimas
Ext.nd.d Stayam.rica
Comtort Suites-San Dimas
Hotels at 1.0 mi exit
Tapping
on a POI in the list brings up the Route Method
screen.
To create aroute to the POI chosen, tap on the
orange "Calculate Route" icon.

AAA Roadside Assistance
(u rrent Locati on
Save E
F
Current street or highway and current city.
Next and previous exit
or intersection from your
current location.
Latitude and Longitude for your current position.
Time and Date.
Save button to quickly store your location into your
address book
Speedometer.
Compass and elevation.
AAA Roadside Assistance
Current Locati on
Save E
F
Current street or highway and current city.
Next and previous exit
or intersection from your
current location.
Latitude and Longitude for your current position.
Time and Date.
Save button to quickly store your location into your
address book
Speedometer.
Compass and elevation.

RoutinQ to a POI
Select Category
D Gas Stabons
TI
COHPf
Restaurants
Select sub Category
Thai Food
Alrican Food
American Food
South American Food
(if subcategories are available)
~-- I
American Food
Cask N deavllr
Roady's Restaurant
Longhorn Call'
~1.1ml
l:ilI W BOlIIla AVQ
ls... D .... ~ <A -
~
Please refer to the User Manual
on the CD-ROM for more
information
on routing to POls.
RoutinQ to a POI
Select Category
D Gas Stabo"s
TI
CoHee
Restaurants
-I
Select sub Category
Thai Food
Alrican Food
Afm~rican Food
South American Food
(if subcategories are available)
{" I
American Food
Cask N deaver
Roady's Restaurant
Langham Cale
~ 1.1 Inl
l:ilI W Boda Ave
~.D.u.{A
~ .
Please refer to the User Manual
on the CD-ROM for more
information
on routing to POls.
