Magma Catalina II A10-1218-2 User manual

Gourmet Series Marine Gas Grill
Model A10-1218-2
OWNER’S MANUAL
™
For questions regarding performance, assembly,
operation, parts, or returns, contact the experts
at MAGMA by calling [phone]
7:00 a.m. - 5:00 p.m. Pacific Time Monday thru
Friday or e-mail us at [e-mail]
IMPORTANT, read these instructions carefully before use. Familiarize yourself with the appliance
before connecting it to its gas container. Keep these instructions for future reference.

s53%/54$//23/.,9
s$/./453%4()3!00,)!.#%).3)$%4(%"/!4/2!.9%.#,/3%$30!#%
s'2),,32!$)!4%(%!4#,%!2!.#%&2/-#/-"534)",%3v3)$%3!.$"!#+.%6%253%5.$%2
!7.).'30!4)/#/6%23%4#
s53%02/0!.%'!3/.,9&5%,34/2!'%3(/5,$"%).#/-0,)!.#%7)4(4(%!-%2)#!."/!4!.$
9!#(4#/5.#),!"9#34!.$!2$3!-!2).%,)15)&)%$0%42/,%5-'!3,0'3934%-3
s&/2.!452!,'!3!00,)#!4)/.#/.4!#4-!'-!
s!,7!93,)'(4'2),,7)4(,)$/0%.
s.%6%2,%!6%(/4'2),,5.!44%.$%$
s53%(/40!$7(%.(!.$,).'
s!,7!93452.'2),,/&&!&4%253%
s.%6%2,%!6%'!3#9,).$%23!.$2%'5,!4/2#/..%#4%$7(%.34/7%$
s34/2%'!3#9,).$%23).7%,,6%.4),!4%$!2%!
s$/./434/2%'!3#9,).$%23).$//23).$)2%#435.,)'(4"%,/7$%#+3/."/!43/2).,/#+%23
./4!002/6%$&/2"54!.%/202/0!.%34/2!'%
s#!54)/.#(%#+&/2'!3,%!+3%!#(4)-%#9,).$%2)3#(!.'%$
s.%6%2#(%#+&/2'!3,%!+37)4(!&,!-%
s$/./4",/#+2%342)#4/2/4(%27)3%/"3425#4#/-"534)/./26%.4),!4)/.
!)2/0%.).'3
s$/./4-/$)&94()3!00,)!.#%
s#(%#+4(!46!,6%3%!,).'7!3(%2!)3).0,!#%!.$).'//$#/.$)4)/.
"%&/2%#/..%#4).'4(%'!3#/.4!).%2
s).34!,,#!.)34%23).7%,,6%.4),,!4%$!2%!!.$!7!9&2/-/0%.&,!-%(%!4
3/52#%/230!2+3+%%0!7!9&2/-/4(%20%/0,%/2&,!--!",%-!4%2)!,3
IMPORTANT SAFETY WARNINGS
INSTALLATION INSTRUCTIONS
READ ALL INSTRUCTIONS BEFORE OPERATING.

Each Magma
®
Gas Grill is individually fire tested before it leaves the factory.
For this reason, the burner on your grill may be slightly discolored.
CONTROL VALVE REGULATOR
s5SESSTANDARDLBDISPOSABLEPROPANECANISTERS$/4.2#
s0RIORTOINSTALLINGVALVEBECOMEFAMILIARWITHTHEVALVEFUNCTIONANDGRAPHICS
ONVALVEKNOB.EVERFORCETHEKNOB!LWAYSTURNORPUSHGENTLY
s4URNCONTROLVALVETOhLOCKvANDINSTALLGASCANISTERBEINGCAREFULNOTTO
CROSSTHETHREADS#HECKFORLEAKSPRIORTOUSEBYBRUSHINGSOAPYWATER
SOLUTIONAROUNDTHREADSANDORIFICEHOLECHECKINGFORBUBBLES
s0OSITIONVALVEWITHGASBOTTLEASSHOWN(A)'ENTLYINSERTVALVESTEMINTO
VALVECHAMBER2OTATEUNTILVALVESTEMKEYALIGNSWITHLOCKDETENTALLOWING
VALVETOFULLYINSERT2OTATEGASCANISTERDOWNSOKNOBFACESYOU(B) OR
STRAIGHTUP(C) DEPENDINGONAPPLICATION
(A)
(B)
(C)
!
Valve will feel loose and will rotate easily. Even though the valve feels loose, it will not leak.
The valve was designed to be loose fitting in order to allow safe, easy installation and removal
of the propane canister and so it easily swings without resistance to fit all applications.

3
Burner
Lid Lock
Grill Grates
Radiant Plate
Outer Shell
Liner
Match Light
Hole
Mount Support
Pad with
Folding Legs
Valve Chamber
Electronic
Ignition
Slide Out
Grease Tray
Control Valve
Regulator
Type 1
Low-Output
See Magma website for
replacement part numbers
and valve applications.
www.MagmaProducts.com
Single mount non-through-bolt
applications, including Style 1 “Levelock”
4 Hex head bolts & lock washers.
MOUNT HARDWARE
Fasteners are supplied for both Single Mount and Dual Mount grill mounting
options. See Magma Catalog or Website for best mount selection.
Dual mount applications
4 Carriage bolts & lock nuts. Only 4 bolts
required for grill mounting. Place bolts (2 per
side) diagonally from each other as shown.
Hex head bolt
& lock washer
Carriage bolt
& lock nut
Single mount through-bolt applications
4 Carriage bolts & lock nuts.
Thermometer
Warming Rack

4
OPERATE ONLY ON “LOW” WHEN LID IS CLOSED.
ALWAYS OPERATE WITH GREASE TRAY IN PLACE.
WARNING: Do not overheat grill. Magma Grills do not require pre-heating. Stainless Steel loses
anti-corrosive characteristics when subjected to extreme heat. Most grilling is done on low
temperature with the lid closed. If medium or high heat is required, grill with lid open.
LIGHTING INSTRUCTIONS
s/PENLIDDURINGLIGHTING
s$EPRESSKNOBANDROTATECOUNTERCLOCKWISETOTHEh()'(v flame position.
s0USH%LECTRONIC)GNITERs6ISUALLYCONFIRMIGNITIONs4URNKNOBTOADJUSTFLAME
s)FGRILLDOESNOTLIGHTSEEPAGE
s
)FELECTRONICIGNITIONFAILSTOIGNITETHEGASSEE-!4#(,)'(4).').3425#4)/.3
NOTE:"EFORELIGHTINGLIDLOCKMUSTBEPOSITIONEDNOTTOENGAGE/PENLIDANDTURNLOCKTO
LOCKEDPOSITION
NOTE:%LECTRONICIGNITIONCOMESEQUIPPEDWITHBATTERYPREINSTALLED2EPLACEWITHh!!!v
ALKALINEBATTERYONLY
MATCH LIGHTING INSTRUCTIONS
(Back up system allows use of grill until piezo ignition system is repaired.)
s/PENLIDDURINGLIGHTINGs0LACEFLAMEUPTOBURNERTHROUGHTHEMATCHLIGHTHOLE
s$EPRESSVALVEANDTURNCOUNTERCLOCKWISETOTHEh()'(vflame position.
s6ISUALLYCONFIRMIGNITION
TO REDUCE FLARE-UP
s%MPTYANDCLEANGREASETRAYPRIORTOEACHUSE
s4RIMEXCESSFATSFROMMEATs5SENONOILBASEDMARINADES
s2EDUCEHEATs5SEWATERSPRAYDIRECTLYONFLAREUPS
FOLDING LEGS
&ORSTORAGETRANSPORTORWHILEUSINGOTHERMOUNTINGOPTIONS&OLDUPBACKLEGSFIRSTTHENFRONT
LEGSASSHOWN)FLEGSBECOMELOOSETHEYCANBETIGHTENEDWITHAv(EX+EY7RENCH
PRACTICAL HINTS:
Before lighting your grill, be sure that …
s 'RILLISSECUREANDPROPERLYMOUNTED
s )NTERNALCOMPONENTSANDGREASETRAYARECLEANANDCORRECTLYPOSITIONED
s 9OUHAVEPLENTYOFGASINTHECANISTER
s 'ASCANISTERISATTACHEDPROPERLYANDTHEREARENOGASLEAKS
s ,IDLOCKHASBEENSETNOTTOENGAGE
s 9OUHAVEAWATERSPRAYBOTTLEHANDYTOCOOLAHOTGRILLORSTOPANYFLAREUPS
STOWING TIPS
s!LWAYSDISCONNECTTHEFUELCANISTERFROMTHEVALVEPRIORTOSTOWING
s3TOWTHEVALVEINACLEANDRYAREATOPROTECTFROMCORROSIONTOVALVE
s
!LWAYSSTOREPROPANEINASEALEDPROPANESTORAGELOCKERTHATALLOWSLEAKAGETOVENTOVERBOARD
or use Magma Propane Storage/Locker Tote Bag..EVERSTOWBELOWDECKS
OPERATING PROCEDURES

ELECTRODE SPARK ADJUSTMENT
CAUTION: Spark can cause small shock. Do not leave
fingers on or near electrode wire while engaging igniter.
s%LECTRODEWIRESHOULDBE
approximately 1/8” from gas
EXITHOLEINBURNER
. Carefully adjust wire if required.
5
Retaining pin
Right
side
slot
Locking
Indents
A
Outer Shell
Liner
Liner Lip
Disconnect
wire
DISASSEMBLY & RE-ASSEMBLY
s ,IFTRADIANTPLATEUPOUTOFLEFTSLOTSEE"ANDREMOVEBYSLIDINGITOUTOF
right slot (see C).
s2EMOVEBURNERRETAINERPINSEE"REMOVEBURNER)NSPECTBURNERREMOVEANY
OBSTRUCTIONS#!54)/.7(%.2%0,!#).'"52.%2#543,/43)."52.%2
-534&!#%$/7.
s
To remove liner from outer shell you must disconnect the electrode wire (see
$&IRSTREMOVETHETWOSCREWSONVALVECHAMBERSEE$ANDREMOVETHE
COVERPLATE'ENTLYPULLWIREOFFCONNECTORSEE$)TISNOTNECESSARYTO
remove electrode from liner.
s 2EMOVE,IDANDLINERBYREMOVINGHINGESCREWSANDLOCKNUTSWITHvHEX
key wrench (supplied) and 1/2” wrench or pliers. CAUTION: LOCK NUTS
-534"%).34!,,%$7)4(,/#+).').$%.4-!2+33(/7).'SEE%
)-02/0%2).34!,,!4)/.7),,$!-!'%4(%().'%3#2%7!.$,/#+.54
s ,IFTLINEROUTOFOUTERSHELLBYLIFTINGUPONLINERLIPONBACKSIDEOFLINERSEE
&7HENREPLACINGLINERBESURETOPLIPOFLINERINSTALLSOVERTOPEDGEOF
outer shell (start with corners of lip and work in).
s#LEANASINDICATEDIN-AINTENANCEPAGE
s4OREASSEMBLEREVERSETHEPROCEDUREABOVE
BCD
Screws
EF
Electrode
Left
side
slot
Radient Plate

6
MAINTENANCE
Stainless steel contrary to popular belief can rust. Most commonly, deposits on surface of the product will trap moisture.
It is this moisture that robs stainless steel of oxygen. Oxygen is the element that reacts with stainless steel to form a
protective layer of chrome oxide. Robbed of oxygen, this reaction does not take place and “crevice corrosion” or “surface
rusting” occurs. To minimize this effect, thoroughly clean your grill with soap and water, rinse with fresh water, and dry.
Avoid using stainless steel polishes on grill exterior as most leave a residue that may discolor when grill is heated.
Additionally, stainless steel that is exposed to high heat will change color and texture over time. The “amber” color of
grill exterior and internal components is not a failure of the stainless steel and will not affect products operation. When this
happens, we recommend using “Magma Magic” Grill Restorer to remove the “amber” color and return grill to its original
luster. However, prolonged exposure to extreme high heat will cause chromium and nickel to “burn out” of stainless steel. At
this point stainless steel will become more susceptible to corrosion and will start to deteriorate. We recommended
replacement of internal components as they become seriously deteriorated.
We recommend thoroughly cleaning grill and internal components after each outing. Disassemble interior components
and remove all food residue. Use a “Scotch Brite” pad or similar product and “Easy-Off” oven cleaner for cleaning grills
interior components, followed by thoroughly washing with soap and water, rinse with fresh water & dry. AVOID CONTACT
OF OVEN CLEANER WITH SKIN, CONTROL VALVE, IGNITOR ELECTRODE & WIRE, AND BOAT SURFACE. CAUTION: DO NOT
USE ANY TYPE OF ABRASIVE PAD ON EXTERIOR MIRROR FINISH AS IT WILL SCRATCH SURFACE, USE ONLY A SOFT CLOTH.
We recommend covering grill between uses. Grill covers are available at Magma retailers or directly from Magma. See our
website, www.magmaproducts.com After cooking Do Not turn grill to high heat to burn off grilling residue. The grill is
not a self cleaning oven & this extreme heat can damage stainless steel components.
Grill Grates -Clean with brass wire brush while grill is warm. Use Oven & Grill cleaner for burnt-on residue. Wash with
soapy water and dry prior to storage.
Ceramic Electrode - Located just beside the burner, it should be kept clean of grease and debris. Be careful not to
damage the ceramic insulation or the wire. See page 5 for electrode spark adjustment.
Control Valve -All valves are set and tested at our factory. Do not attempt to adjust or disassemble the valve in any way.
Call Magma if you suspect it is not adjusted properly. Clean valve with a cloth and remove any debris obstructing the orifice.
Repair/Replacement Parts - All replacement parts are readily available at your Magma Retailers or directly from Magma.
For a complete list of replacement parts visit our website www.MagmaProducts.com.
USING GRILL WITH ON-BOARD LPG (PROPANE) SYSTEMS
Propane (LPG) Gas Regulator
A10-225 LPG (Propane)
10' Gas Grill Connection Kit
To other LPG
appliance
or use cap
Shut off
valve
Cylinder Valve
Gauge
Type 3
Valve
Solenoid
Gourmet
Gas Grill
Typical Marine &
R.V. Application
Align valve stem key
to valve chamber
lock detent and rotate
Gourmet
Gas Grill
Gourmet
Gas Grill
Type 3
Valve
s-AGMA/N"OARD,0'0ROPANE6ALVES
Hose Kits allow Magma Grills to be installed
within a boats existing on-board, pre-regulated
LOWPRESSURE,0'0ROPANESYSTEM
s5SEONLYMagma Type 3 Low Pressure LPG
(Propane) Valves. See our Valve Application
Guide at www. MagmaProducts.com for
correct valve.
s)N.ORTH!MERICAUSEMagma A10-225 LPG
10' Gas Grill Connection Kit in conjunction
with Type 3 Valve. Outside North America check
your local dealer for proper hose and fittings.
In Australia & New Zealand LPG fuel
systems must be installed by a certified
gas technician.
s!PRIMARYSHUTOFFVALVE(supplied with Gas
Grill Connection Kit) must be used with this
control valve at point of connection into your
system. This allows shut off of gas supply to hose
leading to grill.

7
USING GRILL WITH ON-BOARD CNG (NATURAL GAS) SYSTEMS
Magma's grills are designed for use with small disposable propane canisters or with pre-regulated
low-pressure propane and optional low-pressure valves. Running high-pressure propane fuel supply
lines on a boat is in violation of American Boat & Yacht Council (ABYC) guidelines and is not
considered a safe application. Additionally, impurities found in larger refillable propane tanks may
clog the small orifices in the high-pressure control valve/ regulator causing it to lose performance
capabilities and eventually fail. Regulating these tanks to 1/2 PSI and using this pre-regulated
propane with the correct low-pressure valve will insure safe, efficient performance of the grill.
)-0/24!.4s$/./4#/..%#4!()'(02%3352%3500,9(/3%
FROM A NON-REGULATED TANK DIRECTLY TO GRILL.
s-AGMAONBOARD#.'NATURALGASVALVESALLOW-AGMAGRILLSTOBEINSTALLEDTOANEXISTINGONBOARD
PREREGULATEDLOWPRESSURE#.'NATURALGASSYSTEM
s5SEONLY-AGMA4YPE,OW0RESSURE#.'NATURALGASCONTROLVALVES6ISITOUTWEBSITEAT
www.MagmaProducts.com to view valve application guide. See your local dealer for proper hose and fittings.

Problem
Electrode covered with grease or residue
Igniter/electrode too far from burner
Electrode wire loose, disconnected, or
corroded
Wire is shorted causing spark from wire
before electrode
No spark being generated
No gas flow
Obstructed gas flow
Excessive cooking temperature
Grease and/or residue build-up
Excessive fat in meats
Excessive oils in marinades
Obstructed gas flow
Flame too low
Wind directly on burner
Obstructed gas flow
Grill not level
Grease or residue build-up
Excessive fat in meats
Excessive oil in marinades
Clean electrode
Adjust electrode until proper spark appears
(see page 5)
Clean, adjust & reconnect wire between
igniter & electrode, see Complete
Disassembly (page 5)
Replace Igniter, Electrode & Wire
See website for part number
Adjust electrode until proper spark appears.
Unscrew igniter push button, remove/
inspect “AAA” battery, replace “AAA” alkaline
battery if necessary, reinstall & re-assemble
push button
Replace Igniter, Electrode & Wire
See website for part number
Check fuel level, replace canister or
refill cylinder
Clean burner and valve orifice.
Remove debris/spider webs
Operate only on low when lid is closed
Reduce flame level
Leave lid open
Use water spray to cool
Clean components
Trim fat from cuts of meat before grilling
Use non-oil based marinades
Clean burner and valve orifice.
Remove debris/spider webs
Increase flame
Block wind when opening lid
Clean burner and valve orifice.
Remove debris/spider webs
Level Grill
Clean components
Trim fat from cuts of meat before grilling
Use non-oil based marinades
Hot Spots
Blow-out
Yellow sooty
flame
Flare-up
Burner will
not light even
with match
Burner will
not light with
igniter
TROUBLE SHOOTING GUIDE
Possible Solution Possible Cause
7

LIMITED WARRANTY
Contents
x 4 x 4
A
B
C
x 4x 4
A) (1) 3/16” Hex key wrench for lid removel.
B) Pack of (4) 1/4”-20 x 5/8” hex head screws
and internal lock washers for “Levelock”
single mount application.
C) Pack of (4) 1/4”-20 x 5/8” carriage bolts and
lock nuts for dual mount and single mount
applications and table legs.
Magma Products, Inc. guarantees this product to be free from defects in materials or workmanship to the original consumer. This guarantee
is for the periods herein specified when used under normal and reasonable conditions, one (l) year from the date of original purchase. This war-
ranty does not include the cost of property damage or any inconvenience due to the failure of the product. Nor does it cover damage due to
misuse, abuse, accident, or damage resulting from transportation of the product. Nor does it include damage resulting from the commercial use
of this product. Nor does it include, on stainless steel products, "Surface Rust'; Excessive Corrosion due to exposure to salt water; or Discoloration
or Corrosion caused by exposure to excessive heat or failure to properly clean and care for the stainless steel surfaces. If the product fails to oper-
ate due to a defect in materials or workmanship during the warranty period, the defective part will be repaired or replaced at Magma's option.
If you wish to obtain performance under this limited warranty, you should contact Magma's Customer Service Department via telephone at
[phone], or via e-mail at [email protected], or via U.S. Postal Service mail at "Magma Products, Inc., Attention Customer Service,
3940 Pixie Ave. Lakewood, CA, 90712". The defective part, along with proof of purchase, must be returned postage prepaid to Magma Products,
Inc. We suggest that you keep your purchase receipt as we may require reasonable proof of purchase.
In the state of California only, if refinishing or replacement of the product is not commercially practicable, the retailer selling the product, or
Magma Products, Inc., will refund the purchase price paid for the product, less the amount directly attributable to use by the original consumer
prior to the discovery of the nonconformity. In addition, in the state of California only, you may take the product to the retail establishment from
which it was purchased or to any retail establishment selling this product in order to obtain performance under this warranty. All implied war-
ranties, including the implied warranties of merchantability and fitness for a particular purpose, are limited in duration to the express warranty
periods specified herein for the parts described herein. Some states do not allow limitations on how long an implied warranty lasts, so the above
limitation may not apply to you. Neither Magma dealers, nor the retail establishment selling this product has any authority to make any warran-
ties or to promise remedies in addition to or inconsistent with those stated above. Magma's maximum liability shall not exceed the purchase price
of the product paid by the original consumer. Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation orexclusions may not apply to you. The warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
MAGMA and the Magma logo are registered trademarks of Magma Products, Inc.
Catalina is a trademark of Magma Products, Inc.
Patent pending.
Magma Products, Inc.
0IXIE!VENUE,AKEWOOD#!s53!
0HONEsEMAILMAIL -AGMA0RODUCTSCOM
www.MagmaProducts.com
83-1218-2 1114
CALIFORNIA PROPOSITION 65 – WARNING – The burning of gas cooking fuel generates some by-products, which are on the list of
substances, which are known by the State of California to cause cancer or reproductive harm. California law requires businesses to warn
customers of potential exposure to such substances. To minimize exposure to these substances, always operate this unit according to the use
and care manual, ensuring you provide good ventilation when cooking with gas.
