Magnasonic 13D204MR User manual

TV
+
DVD
www.magnasonic.ca
For Customer Assistance Call:
1-800-663-5954
Instruction Manual
Thank you for your purchase of this Magnasonic product. Please read this Instruction Manual
carefully before using product to ensure proper use. Keep this manual in a safe place for future
reference.
13D204MR
13” TV/DVD Combination Colour Television With AC/DC Operation

PRECAUTIONS
FCC WARNING-This equipment may
generate or use radio frequency
energy.Changes or modifications to this
equipment may cause harmful
interference unless the modifications are
expressly approved in the instruction
manual.The user could lose the authority
to operate this equipment if an
unauthorized change or modification is
made.
LASER SAFETY
This unit employs a laser.Only a qualified
service person should remove the cover
or attempt to service this device,due to
possible eye injury.
CAUTION:USE OF CONTROLS OR
ADJUSTMENTS OR PERFORMANCE
OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY
RESULT IN HAZARDOUS RADIATION
EXPOSURE.
CAUTION:VISIBLE AND INVISIBLE
LASER RADIATION WHEN OPEN AND
INTERLOCK DEFEATED.DO NOT
STARE INTO BEAM.
LOCATION:INSIDE,NEAR THE DECK
MECHANISM.
CONTENTS
Before Operation
Basic operation
Warning and cautions...........................................................................
Installation..............................................................................................3
..............................................................................
Preparation of the remote control..........................................................3
Function buttons and ........................................
Front panel of the TV set.....................................................................4
Rear panel of the TV set.......................................................................4
Using the remote control......................................................................5
Menu
........................................................................29
Specifications .....................................................................................30
Warranty................................................................................................30
Antenna Connection
External Connections
Functions
Connection to the external audio and video equipment..................28
Troubleshooting guide
......................................................................................
DVD Operation
DVD Features.......................................................................................18
Advanced Playback..............................................................................19
Special Function Playback...................................................................20
DVD System Setup................................................................................22
Playable Discs.......................................................................................26
Disc Protection and DVD Characteristics..........................................27
Others
1
4
4
4
5
5
5
6
9
18
19
20
21
25
26
27
28
29

Important safety Instructions
WARNING:TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS APPLIANCE TO RAIN OR MOISTURE.
CAUTION
RISK OF ELECTRICSHOCK
DO NOT OPEN
CAUTION: TO REDUCETHE RISK OFELECTRIC
SHOCK, DO NOTREMOVE COVER (OR BACK).
NO USER SERVICEABLEPARTS INSIDE.REFER
SERVICING TOQUALIFIED SERVICE PERSONNEL
THIS SYMBOL INDICATES THATDANGEROUS
VOLTAGECONSTITUTING ARISK OF ELECTRIC
SHOCK IS PRESENTWITHIN THIS UNIT.
THIS SYMBOL INDICATES THATTHERE ARE
IMPORTANT OPERATING AND MAINTENANCE
INSTRUCTIONS IN THELITERATURE
ACCOMPANYING THEAPPLIANCE.
The important noteis located on the rear ofthe cabinet.
IMPORTANT SAFEGUARDS
1. READ INSTRUCTIONS
All the safetyand operating instructionsshould be readbefore the unitis operated.
2. RETAIN INSTRUCTIONS
The safety andoperating instructions shouldbe retained forfuture reference.
3. HEED WARNINGS
All warnings onthe unit andin the operatinginstructions should be adhered to.
4. FOLLOW INSTRUCTIONS
All operating anduse instructions shouldbe followed.
5. CLEANING
Unplug this unitfrom the walloutlet before cleaning.Do not useliquid cleaners or aerosol
cleaners.
Use a dampcloth for cleaningthe exterior cabinetonly.
6. ATTACHMENTS
The manufacturer ofthis unit doesnot make anyrecommendations for attachments,as they
may cause hazards.
7. WATER AND MOISTURE
Do not usethis unit nearwater. Forexample, near a bathtub, washbowl, kitchen sink,
laundry tub, ina wet basement,or near aswimming pool.
8. ACCESSORIES
Do not placethis unit onan unstable cart,stand, tripod, bracket,or table. The unit mayfall,
causing serious injury, and seriousdamage to theunit.
(symbol provided byRETAC)
8A. Anappliance and cartcombination should bemoved with care. Quick
stops, excessive force,and uneven surfacesmay cause theappliance and
cart combination tooverturn.
9. VENTILATION
Slots and openingsin the cabinetback or bottomare provided forventilation, and to ensure
reliable operation ofthe unit, andto protect itfrom overheating. These openings mustnot be
blocked or covered.The openings should never beblocked by placingthe unit ona bed,
sofa, rug, orother similar surface.This unit should never beplaced near orover a radiatoror
heat source. This unit shouldnot be placedin a built-ininstallation such asa bookcase or
rack unless properventilation is providedor the manufacturer'sinstructions have been
adhered to.
10. POWER SOURCE
This unit shouldbe operated onlyfrom the typeof power sourceindicated on the rating plate.
If you arenot sure ofthe type ofpower supply toyour home, consult your appliance dealer or
local power company. For unitsintended to operatefrom battery power, or other sources,
refer to therespective pages inthis Owner's Manualfor their operatinginstructions.
S3126A

Important safety Instructions
22
11. GROUNDINGOR POLARIZATION
This unit isequipped with a polarized alternating-current line plug (a plug having one blade
wider than theother). This plugwill fit intothe power outletonly one way. This isa safety
feature. If youare unable to insert the plug fully into the outlet, try reversing the plug. If the
plug should stillfail to fit, contact your electrician to replace your obsolete outlet. Instead of
the polarized alternating-current line plug, your unit may be equipped with a 3-wire
grounding-type plug (aplug having a third (grounding) pin). This plug will only fit into a
grounding-type power outlet.This too, isa safety feature.If you areunable to insert the plug
into the outlet,contact your electrician to replace your obsolete outlet. Do not defeat the
safety purpose ofthe grounding-type plug.
12. POWER-CORD PROTECTION
Power-supply cords shouldbe routed so that they are not likely to be walked on or pinched
by items placedupon or against them, paying particular attention to cords at plugs,
convenience receptacles, andthe point where they exit from the appliance.
13. LIGHTNING
Toprotect your unit from a lightning storm, or when it is left unattended and unused for long
periods of time,unplug it from the wall outlet and disconnect the antenna or cable system.
This will preventdamage to the unit due to lightning and power line surges.
14. POWER LINES
An outside antennasystem should not be located in the vicinity of overhead power lines or
other electric lightor power circuits, or where it can fall onto or against such power lines or
circuits. When installingan outside antenna system, extreme care should be taken to keep
from touching suchpower lines or circuits, as contact with them might be fatal.
15. OVERLOADING
Do not overloadwall outlets and extension cords, as this can result in a risk of fire or electric
shock.
16. OBJECT AND LIQUID ENTRY
Do not pushobjects through any openings in this unit, as they may touch dangerous voltage
points or shortout parts that could result in fire or electric shock. Never spill or spray any
type of liquidinto the unit.
17. OUTDOOR ANTENNA GROUNDING
If an outsideantenna or cable system is connected to the unit, be sure the antenna or cable
system is groundedto provide some protection against voltage surges and built-up static
charges, Section 810of the National Electrical Code (NEC), ANSI/NFPA70, provides
information with respectto proper grounding of the mast and supporting structure,
grounding of thelead-in wire to an antenna discharge unit, size of grounding conductors,
location of antennadischarge unit, connection to grounding electrodes, and requirements
for the groundingelectrode.
18. SERVICING
Do not attemptto service this unit yourself as opening or removing covers may expose you
to dangerous voltageor other hazards. Refer all servicing to qualified service personnel.

Important safety Instructions
19. DAMAGE REQUIRINGSERVICE
Unplug this unitfrom the walloutlet and referservicing to qualifiedservice personnel under
the following conditions:
a. When thepower-supply cord orplug is damaged.
b. If liquidhas been spilled,or objects havefallen into theunit.
c. If theunit has beenexposed to rainor water.
d. If theunit does notoperate normally byfollowing the operatinginstructions. Adjust
only those controlsthat are coveredby the operatinginstructions, as animproper
adjustment of othercontrols may resultin damage andwill often requireextensive
work by aqualified technician torestore the unitto its normaloperation.
e. If theunit has beendropped or thecabinet has beendamaged.
F.When the unitexhibits a distinctchange in performance,this indicates aneed for
service.
20. REPLACEMENT PARTS
When replacement partsare required, besure the servicetechnician uses replacementparts
specified by themanufacturer or thosethat have thesame characteristics asthe original part.
Unauthorized substitutions mayresult in fire,electric shock orother hazards.
21. SAFETY CHECK
Upon completion ofany service orrepairs to thisunit, ask theservice technician toperform
safety checks todetermine that theunit is inproper operating condition.
22. HEAT
The product shouldbe situated awayfrom heat sourcessuch as radiators,heat registers,
stoves, or otherproducts (including amplifiers)that produce heat.
23. DISC SLOT
Keep your fingerswell clear ofthe disc slotas it isclosing. It maycause serious personal
injury.
24. CONNECTING
When you connectthe product toother equipment, turnoff the power and unplugall of the
equipment from thewall outlet. Failureto do somay cause anelectric shock andserious
personal injury. Read theowner's manual ofthe other equipmentcarefully and followthe
instructions when makingany connections.
25. SOUND VOLUME
Reduce the volumeto the minimumlevel before youturn on theproduct. Otherwise, sudden
high volume soundmay cause hearingor speaker damage.
26. SOUND DISTORTION
Do not allowthe product outputdistorted sound fora longtime. Itmay cause speaker
overheating and fire.
27. LASER BEAM
Do not lookinto the openingof the discslot or ventilationopening of the product to see the
source of thelaser beam. Itmay cause sightdamage.
28. DISC
Do not usea cracked, deformed,or repaired disc.These discs are easily brokenand may
cause serious personalinjury and productmalfunction.
29. NOTE TO CABLE TVSYSTEM INSTALLER
This reminder isprovided to callthe Cable TV system installer'sattention toArticle 820-40 of
the NEC thatprovides guidelines forproper grounding and,in particular,specifies that the
cable ground shallbe connected tothe grounding systemof the building,as close tothe point
of cable entryas practical.

Installation
Antenna connection
Preparation for the remote control
Battery installation
Tips for remote operation
Remove the battery cover.
!When the remote control will not be used for a long period of time or when the
batteries are worn out, remove the batteries to prevent leakage.
!
Do not throw the batteries into fire. Dispose of used batteries in the specified
manner.
!
Do not drop, dampen or disassemble the remote control.
Insert two size AA batteries matching
the +/-polarities of the battery to the +/-
marks inside the battery compartment.
!
!
Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV
system or an outdoor antenna .In different places, the suitable antenna type and position
may vary.
Note:
* It is recommended that a 75 ohm coaxial antenna is used to avoid
interference.
*To avoid interference from electrical signals, do not bind the antenna cable
together with any mains lead.
AC power socket
Mixer
(not incl.)
Antenna/ CATV input
75 standard
coaxial type
DC power socket

Function Buttons and External
Connections
Rear panel of the TV set
Front panel the TV set
COAXIAL
Audio left channeloutput terminal
Coaxial terminal
Antenna/ CATV input socket
Video output terminal
Audio right channeloutput terminal
Video input terminal
Audio left channelinput terminal
Audio right channelinput terminal
DC IN
DC input socket

Using the Remote Control
Stand By
DVD Open/close
Calendar
Scan
TV Time Menu
Mute
Former Program
Call Screen Display
Program Number
(Not available)
TV/AV Exchange
(Not available)
TV/DVD
Volume/Channel Selection
MENU
Exit Screen Display
Picture Mode
DVD STOP
DVD SETUP
DVD PAUSE/STEP
DVD FAST REVERSE
DVD FAST FORWARD
DVD MENU
DVD NEXT
DVD PREVIOUS
DVD REPEAT
DVD PLAY/ENTER
DVD A-B REPEAT
DVD Cursor Move button
DVD SLOW
DVD ANGLE
DVD SEARCH
DVD Audio
DVD TITLE
DVD PROGRAM
DVD CALL
DVD SUBTITLE
Zoom
DVD 10+
(Not available)
TV Sleep button
CCD ( closed caption)
Buttons on the remote control
UP
DOWN
LEFT RIGHT
POWER TIME OPEN/CLOSE
SCAN RECALL DISPLAY MUTE
1234
5678
9900
TV/AV
TV/DVD
CH+
CH-
VOL
_
MENU
EXIT P.STD
STOP SETUP PAUSE/STEP
REV FWD .PREV NEXT
D.MENU REPEAT A-B
PLAY/ENTER SLOW
ANGLE TITLE/PBC SEARCH
AUDIO
SUBTITLE
D.CALL
CALENDAR
PROGRAM ZOOM
10+
SLEEP
VOL
+
CCD

Remote Features
Power Button:
To turn power ON or OFF , press power button on remote control.
System and ChannelDisplay Button:
This will show you the currentchannel number. System will also
be displayed if set.
TV/AV input Button:
This button hasfive setting A)Video1, B)Video 2,C)TV .
Pressing this button will cycle you through each option.
Mute Button:
Press mute button to turn off the TV volume.
CCD Button:
Press CCD button to set the C.Caption (Closed Captioned)
ON or OFF.
DVD/TV Button:
Press this buttonto change between TV and DVD.
OPEN/CLOSE Button:
Press this button to open or close the DVD disc tray .
POWER
DISPLAY
TV/DVD
TV/AV
MUTE
234
678
0
OPEN/CLOSE
Using the Remote Control (Continued)
CCD
Sleep Timer Button:
This feature allows you to turn off television in pre-selected
minutes (180.170,160, ........,10 and 0). To cancel, keep
pressing button untilyou exit out.
SLEEP
Selecting Channels using the Program Number
buttons:
To select a one-digit channel, press the 0 button and
then the desired channel button.
To select a two-digit channel, press the first digit and
then the second.
To select a three-digit channel, press the Channel
100+ button and then the first and second digits.

Channel (+/-) SelectButton:
You can go upand down thechannels by pressing CH (+)
button and CH (-) button. This button can also be used in adjusting the functions in
Menu Select Button:
You can select the menu by pressing the MENU button. You
can call onthe menu (PICTURE, TIME, TUNEand FUNCTION)
by pressing the corresponding button on the remote control.
the Menu Mode.
Volume (+/-) Select Button:
You can increase the volume by pressing VOL (+) button and
decrease VOL(-) button. This button can also be used in adjusting the function
selections in the Menu Mode.
Picture Preference SelectButton:
By pressing this exclusive personal preference button, you can
select different preset brightness shades for various viewing
environments.
Program Scan Button:
This feature automaticallyscans the available channels.
Pressing it again stops the channel scanning.
System and ChannelDisplay Cancel Button:
This button allows you to turn off the channel display and exit
system menus.
Last Channel RecallButton:
This feature allows you to recall the previously viewed channel.
Time Menu Button:
When pressed it displays Time Menu Screen.
10+ Button:
This button canalso be used to select 2digit channel numbers.
RECALL
P.STD
SCAN
EXIT
TIME
Using the Remote Control (Continued)
CH+
CH-
VOL
_
MENU VOL
+
10+
