Magnavox MRD210 User manual

FM Antenna
AM Loop
Antenna
Front Speaker
(Right)
Front Speaker
(Left)
MRD210
12
PUSH
OUT
PUSH
IN
MAGNAVO
X
Center Speaker
Rear Speaker
(Surround Right)
Rear Speaker
(
Surround Left
)
Passive
Subwoofer
P r / C r
P b / C b
Y
L
R
OPTICAL COAXIAL
DIGITAL OUT
AUDIO IN AUDIO OUT
TVAUX
AM/FM
ANTENNA
P-SCAN
OFF ON
VIDEO
OUT
S-VIDEO
OUT
Pr/Cr Pb/Cb
Y
COMPONENT
VIDEO OUT
Connecting Speaker Cable
Printed in China
First connect ...
... then play
(see next page)
Helpful Hints
To obtain a better picture quality effect, you can
choose to connect an extra video connection if
your TV has the same input connector: Aor B.
If your TV has
this video input jack(s)
A
B
Use this
video cable(s)
not supplied
S-VIDEO
IN
ComponentVideo
ANTENNA IN
Do not switch the P-SCAN to ‘ON’ position, unless you have
connected the DVD system to a Progressive Scan TV using the
Component (Pr Pb Y) video jacks.
When listening toTV programs, press TV/AV button on the remote to
set the DVD system to TV/AV mode in order for the sound to be heard.
For connecting to a VCR, see page 9 in the owner’s manual for more
details.
P-SCAN
ON OFF
If your TV has only
a single Antenna In
jack, you will need an
accessory RF
modulator. The RF modulator
converts the video from the
DVD system so it can play
through the TV’s Antenna
connector. Refer to your
owner’s manual for proper
connection (refer to page 9 in
the owner’s manual.)

Detailed playback features and additional functions are described in the
accompanying owner’s manual.
STANDBY
ON VOLUME
OPEN•CLOSE
PREV NEXT SOURCE
PLAY•PAUSE STOP PROGRAM
DVD VIDEO DIGITAL SURROUND SYSTEM
AV IN
PROGRESSIVE SCAN
1
4
5
4 CHANNEL 3
2
3
Make sure your DVD system and
TV are connected and turned on!
Playing a disc
1Press DISC on the remote control.
You can also press the SOURCE button on the front panel until “DISC” appears on the display panel.
2Turn on the TV and select the correctVideo In mode.
You should see the blue Philips DVD background screen on the TV (if no disc in the DVD system).
3Press OPEN•CLOSE 0on the front of the DVD system and load a disc, then
press the OPEN•CLOSE 0again to close the disc tray.
Make sure the disc label is facing up. For double-sided discs, load the side you want to play face up.
4Playback will start automatically. If not, press ÉÅ button.
If a disc menu appears, use 3412buttons on the remote to make the necessary selection, then press
OK to confirm. Or, use the numeric keypad on the remote to select features. Follow the instructions
given in the disc menu.
5To stop playback, press STOPÇ.
Region Codes
DVDs must be labeled for ALL regions or Region 1, in order
to play on this DVD system. ALL 1
1) Press SYSTEM MENU button.
The icon will be highlighted in the
menu bar on the TV screen.
2) Press 4button to select the Picture Setup
Menu item .
3) Press 2button to enter the Menu.
4) Press 4button to select ‘VIDEO OUT’
and 2button to enter the Menu.
5) Press 34 to select and highlight :
S-VIDEO - if you use the S-Video connection.
PR PB Y/SCART - if you use the Component
Video Pr/Cr Pb/Cb Y
6) Press OK button to confirm.
DVD system Video Output Selection for
Proper Playback
S-VIDEO
PR PB Y / SCART
Note: SCART control not
available for use with your
DVD system.
got sound, no picture!!
Check the AV (Audio/Video) mode on
your TV.
* Usually this channel is between the lowest and
highest channels and may be called FRONT,
A/V IN, or VIDEO.
* Or, you may go to channel 1 on your TV, then
press the Channel down button repeatedly
until you see the Video In channel.
* Or, your TV remote control may have a button
or switch that chooses different video modes.
* Do not use channel 3 or 4 on the TV unless
you are using an RF modulator.
* See yourTV manual for more details.

1
SMART. VERY SMART.
User guide
DVD VIDEO DIGITAL SURROUND SYSTEM
Need help? Call us!
Magnavox representatives are ready to help you with any
questions about your new product. We can guide you
through Connections, First-time Setup, or any of the Features.
We want you to start enjoying your new product right away!
CALL US BEFORE YOU CONSIDER
RETURNING THE PRODUCT!
1-800-705-2000
or
Visit us on the web at www.magnavox.com
S
E
E
W
H
Y
I
N
S
I
D
E
I
M
P
O
R
T
A
N
T
!
Return
your Warranty
Registration Card
within 10 days
