Magnavox MC132EMG - 13' Tv/vcr Combination Operating manual

Connections
1Connect an antenna or a Cable TV signal
to the ANT(enna) jack on the rear of the
TV/VCR.
2Plug in the TV/VCR’s power cord.
3Press POWER to turn on the TV/VCR.
ANT.
ANT.
There are different ways to connect your TV/VCR to receive TV channels.This Quick-Use
Guide shows the easiest Antenna or Cable TV signal connection. Other hookups, including
those with a Cable Box or Satellite Receiver, are explained in the owner’s manual.
Antenna or
Cable TV signal
TIME SEARCH
MUTE
RECORD
SPEED RESET
0
8 97
5 64
2 31
PAUSE/STILL
+100
STOP
F.FWD
PLAY
REW
VOL.
DISPLAY
MENU
POWER SLEEP/WAKE UP
CH.
ALT.CH
Setting Up TV Channels
You will be using the remote control. Make sure you
have batteries in it.
1Press MENU.
2Press PLAY/oor STOP/pto select
CHANNEL SET UP. Press F.FWD/B.
3Press PLAY/oor STOP/pto select
AUTO CH PROGRAMMING.
Press F.FWD/Bto start saving TV channels.
When complete, the TV/VCR will go to the
lowest available channel. Use CH o/pto
select other channels.
– M E N U –
TIMER PROGRAMMING
PICTURE CONTROL
SETTING CLOCK
BCHANNEL SET UP
USER’S SET UP
V-CHIP SET UP
LANGUAGE [ENGLISH]
CAPTION [OFF]
ZERO RETURN
TIME SEARCH
1
2-3
Quick-Use Guide
–CHANNEL SET UP –
ADD / DELETE CH (CATV)
BAUTO CH PROGRAMMING

Playing a Videotape
1Insert a tape in the TV/VCR’s cassette com-
partment.The power will come on. If the tape’s
record tab is missing, play should start.
2If play does not start, press PLAY/o.
3Press STOP/pto stop play.
4Press REW/{to rewind the tape.
5When the tape finishes rewinding, press
STOP/EJECT on the front of the TV/VCR to
remove the tape.
Recording a Current TV Program
1Turn on the TV/VCR and insert a recordable
videotape. See page five of the owner’s manual.
2Press SPEED to select a recording speed. See
page 10 of the owner’s manual.
3Use CH o/por the Number buttons to select
a channel to record.
4Press RECORD to start recording. The red
REC/OTR light will flash on the front of the TV/VCR.
5To pause recording, press PAUSE/STILL. PAUSE
will appear on the screen. To resume recording,
press PAUSE/STILL or RECORD.
6To stop recording, press STOP/p.
MC132EMG/17
EL6575E001
T5506UG / 0EMN02477*****
TIME SEARCH
MUTE
RECORD
SPEED RESET
0
8 97
5 64
2 31
PAUSE/STILL
+100
STOP
F.FWD
PLAY
REW
VOL.
DISPLAY
MENU
POWER SLEEP/WAKE UP
CH.
ALT.CH
2
4
3
TIME SEARCH
MUTE
RECORD
SPEED RESET
0
8 97
5 64
2 31
PAUSE/STILL
+100
STOP
F.FWD
PLAY
REW
VOL.
DISPLAY
MENU
POWER SLEEP/WAKE UP
CH.
ALT.CH
2
3
5
6
Quick-Use Guide
4
