Majorcom: EMAGP16 User manual

www.majorcom.fr
EMAGP16
USER
MANUAL
Manual to download in PDF format on

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
23
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
INDEX
1. IMPORTANT REMARK................................................................................................. 3
2. IMPORTANT SAFETY INSTRUCTIONS ...................................................................... 3
3. IMPORTANT NOTE ...................................................................................................... 5
4. INTRODUCTION ................................................................................................... 5
5. INSTALLATION...................................................................................................... 6
5.1. Installation with ePXN1616 matrix ................................................................... 6
5.2. Installation with PXN88 matrix ......................................................................... 9
5.2.1. Installaon and wiring.............................................................. 9
5.2.2. Compability terms and external power supply requirements................. 12
6. OPERATING THE UNIT.............................................................................................. 14
1.1 SENDING MESSAGES ........................................................................................ 14
1.2 DISPLAY AND USER KEYS ................................................................................. 14
1.3 LED INDICATORS ................................................................................................ 15
1.4 PRIORITIES FOR SENDING MESSAGES........................................................... 16
7. NOTES........................................................................................................................ 18
8. PART NAMES............................................................................................................. 19
9. TECHNICAL SPECIFICATIONS ................................................................................. 20
10. BLOCK DIAGRAM ................................................................................................... 21
11. CONFIGURATION DIAGRAM ................................................................................. 22
12. PACKAGE CONTENTS ........................................................................................... 23
1. IMPORTANT REMARK
The lightning ash with arrowhead symbols, within an equilateral triangle,
is intended to alert the user to the presence of uninsulated “dangerous vol-
tage” within the product’s enclosure that may be of sucient magnitude
to constute a risk of electric shock to persons.
The exclamaon point within an equilateral triangle is intended to alert the
user to the presence of important operang and maintenance (servicing)
instrucons in the literature accompanying the appliance.
WARNING (If applicable): The terminals marked with the symbol of “ ” may be
of sucient magnitude to constute a risk of electric shock. The external wiring connec-
ted to the terminals requires the installaon by an instructed person or the use of ready-
made leads or cords.
WARNING: To prevent re or shock hazard, do not expose this equipment to rain or
moisture.
WARNING: An apparatus with Class I construcon shall be connected to a mains
socket-outlet with a protecve earthing connecon.
2. IMPORTANT SAFETY INSTRUCTIONS
1. Read these instrucons.
2. Keep these instrucons.
3. Heed all warnings.
4. Follow all instrucons.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any venlaon openings. Install in accordance with the manufacturer’s
instrucons.

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
45
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other appa-
ratus (including ampliers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and
a third grounding prong. The wide blade or the third prong are provided for your safety. If
the provided plug does not t into your outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord from being walked on or pinched parcularly at the plugs, conve-
nience receptacles, and at the point where they exit from the apparatus.
11. Only use aachments/accessories specied by the manufacturer.
12. Unplug the apparatus during lightening sorts or when unused for long periods of me.
13. Refer all servicing to qualied personnel. Servicing is required when the apparatus has been
damaged in any way, such as power supply cord or plug is damaged, liquid has been spilled
or objects have fallen into the apparatus, the apparatus has been exposed to rain or mois-
ture, does not operate normally, or has been dropped.
14. Disconnecng from mains: Switching o the POWER switch all the funcons and light in-
dicators of the amplier will be stopped, but fully disconnecng the device from mains is
done unplugging the power cord from the main input socket. For this reason, it always shall
remain readily operable.
15. Equipment is connected to a socket-outlet with earthing connecon by means of a power
cord.
16. The marking informaon is located at the boom of apparatus.
17. The apparatus shall not be exposed to dripping or splashing and that no objects lled with
liquids, such as vases, shall be placed on apparatus.
NOTE: This equipment has been tested and found to comply with the
limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy
and, if not installed and used in accordance with the instruction manual,
may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in
which case the user will be required to correct the interference at his own
expense.
WARNING: This product must not be discarded, under any
circumstance, as unsorted urban waste. Take to the nearest elec-
trical and electronic waste treatment center.
MAJORCOM. accepts no liability for any damage that may be caused to
people, animals or objects due to failure to comply with the warnings above.
3. IMPORTANT NOTE
Thank you for choosing our MAJORCOM EMAGPE16digital paging station!
It is VERY IMPORTANT to carefully read this manual and to fully understand its contents before
any connecon in order to maximize your use and get the best performance from this equipment.
To ensure opmal operaon of this device, we strongly recommend that its maintenance be car-
ried out by our authorized Technical Services.
MAJORCOM EMAGPE16comes with an X-year warranty.
4. INTRODUCTION
EMAGPE16is a desktop paging staon compable with MAJORCOM ePXN1616 digital audio ma-
trix and with PXN88, PXN88SG and PXN1212SG MAJORCOMNet matrices (Note: from February
2019). With its buons, LED indicators, electronic ink technology zone name display and goose-
neck microphone, it is possible to select the desnaon zones for voice messages, nd out if
these zones are already controlled elsewhere, capture the voice message and send it in real me
to the desnaon zones.
The main features of the EMAGPE16staon are:
• 20 mechanical keys with integrated LED status indicators (paging zone selecon mana-
gement)
• 1 mechanical key with adjacent LED indicators (message acvaon, PAGE key)
• Electronic ink display (shows paging zone names)
• Gooseneck microphone, with standard XLR connector
• Management of up to 16 paging zones
• RJ45 connector for single CAT5 or higher cabling (point-to-point), including power, au-
dio output signal (picked up by the microphone) and digital control bus between the
ePXN1616 unit (RS-485 bus) or PXN matrices (CAN bus) and the EMAGPE16staon
• Compable with CAN bus communicaon (supporng in this mode PXN88, PXN88SG
and PXN1212SG MAJORCOMNet matrices)
• Connector for backup power supply (oponal)
• Two EMAGPE16units, with dierent or equal priority levels, can work simultaneously
on the same ePXN1616 matrix
• Four EMAGPE16units, with dierent or equal priority levels, can work simultaneously
on the same PXN88 matrix

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
67
EMAGP16 EMAGP16
0
0
::::@
@ ::::
@
@
@
@
@
@
@
Usermanual V1.1 Usermanual V1.1
• Three EMAGPE16units, with dierent or equal priority levels, can work simul-
taneously on the same PXN88SG or PXN1212SG matrix
• programming of paging staon(s) funconality from the web applicaon embedded
in the ePXN1616 matrix: enabled paging zones, chime melodies, priories, pro-
grammable keys, etc.
5. INSTALLATION
5.1. Installation with ePXN1616 matrix
To install an EMAGPE16unit, connected to an ePXN1616 matrix (RS-485 bus connecon),
follow these steps:
• Remove the back cover of the unit by unscrewing the screws that hold it to the chassis
to gain access to the connectors inside:
o RJ45 connector (1): connect a CAT5 or higher cable from this connector direct-
ly (point-to-point wiring) to the PAGER A or PAGER B port of the ePXN1616 unit.
o Power connector (2): connect a backup power supply (WP24-PSU model)
if necessary (see maximum cable length and recommendaons below)
o Check that both jumpers shown in the diagram below are
posioned in the 485 position
• Screw the back cover back onto the unit chassis.
• Insert the supplied microphone into the XLR connector on the front panel

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
89
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
• Program the operaon and sengs of the paging console unit from
the PAGERS/DUCKERS tab of the ePXN1616 web applicaon (see
ePXN1616 web applicaon manual)
• For maximum sound quality and minimum background noise, use
a screwdriver to set the ADJ control on the side of the unit to a
high level (increase it by turning clockwise) and the GAIN control
on the rear panel of the ePXN1616 (the one associated with the
PAGER A or B port to which the staon is connected) to a low
level. You can start from a state with ADJ to maximum and GAIN
to minimum and adjust them following the above indicaons
unl you get the desired signal levels to broadcast the paging
messages in the desnaon zones.
The maximum lengths for CAT5 or higher cabling connecng a staon to
an ePXN1616 unit depend on the AWG category of the cable used. Exa-
mples:
AWG24 Cable AWG23 Cable AWG22 Cable
Max. length 90 me-
ters
Max. length
110 meters
Max. length
140 meters
If the cable is too long, the paging staon may work properly but noise will be superimposed on
the signal picked up by the microphone. The soluon to this possible problem is to supply the
paging staon with an external power supply. WP24-PSU model. The digital data exchange
between the ePXN1616 unit and the EMAGPE16paging staon, using an external power supply
and good quality CAT5E cable, has been successfully tested with a wiring distance of 600 me-
ters.
1.1. Installation with PXN88 matrix
1.1.1. Installaon and wiring
To install an EMAGPE16unit, connected to a PXN88, PXN88SG or PXN1212SG unit,
in CAN bus mode, follow these steps:
• Remove the back cover of the unit by unscrewing the screws that
hold it to the chassis to gain access to the connectors inside:
o RJ45 connector (1): connect a CAT5 or higher cable from
this connector to the REMOTE 1 or REMOTE 2 port of the
PXN88, or to the REMOTE port of PXN88SG or PXN1212SG
matrices. If other EMAGPE16or WPTOUCH digital devices
must be connected to the same port, in daisy chain topo-
logy, the included RJ45 to screw terminals adapter can be
used.
REMOTE ports in the back panel of PXN matrices

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
10 11
EMAGP16 EMAGP16
The remaining cable pair (N.C.) can be
used to
double the +12V - GND pair,
in
order to reach higher cable efficiency.
N.C.
N.C.
+12V
GND
OUT -
OUT +
CAN L
CAN H
N.C.
N.C.
+12V
CAN L
GND
OUT -
OUT +
CAN L
CAN H
GND
+12V
CAN L
CAN H
GND
+12V
Usermanual V1.1 Usermanual V1.1
Both possibilities of connection between EMAGPE16and the
REMOTE ports in PXN matrices. Left- with the RJ45 to screw
terminals adapter / Right – without it, when no daisy-chained
units share the same REMOTE line
EMAGPE16RJ45 connector pinout diagram CAN bus mode
o Connect as well the audio from the paging console micro-
phone (Audio signal + and - / OUT+ and -) to the + and –
terminals of one balanced audio input in the PXN matrix
(ground is common with CAN bus data ground). This will
be the input used in the PAGERS/DUCKERS module under
control by the paging staon
o Power connector (2): if necessary, connect a backup power
supply (WP24-PSU model) (see secon 5.2.2. Compati-
bility terms and external power supply requirements
for further details)
• Check that both jumpers shown in the diagram below are positioned
in the CAN position. If the unit is the last one in the CAN bus
wiring line, insert as well J111-J112 jumper, 120 ohm terminal
resistor ON (closed contact position)

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
12 13
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
• Screw the back cover back onto the unit chassis.
• Insert the supplied microphone into the XLR connector on the front panel
• Program the operaon and sengs of the paging console unit from the PAGERS/DUC-
KERS tab of the PXN matrix in the MAJORCOMNet Manager project (see MAJOR-
COMNet Manager manual for extended informaon)
• For maximum sound quality and minimum background noise, use a screwdriver to set
the ADJ control on the side of the unit to a high level (increase it by turning clockwise)
and the GAIN control in the aected input of the PXN matrix in the MAJORCOMNet
Manager project (the input to which the audio of the paging staon microphone is
connected to) to a low level. You can start from a state with ADJ to maximum and
GAIN to a minimum and adjust them following the above indicaons unl you get
the desired signal levels to broadcast the paging messages in the desnaon zones.
5.2.2. Compability terms and external power supply requirements
It’s possible to connect several EMAGPE16units to the same PXN matrix, considering the fol-
lowing condions:
• Each EMAGPE16unit needs a minimum DC supply of 8V (measured locally, at the unit’s DC
input terminals) to work properly. A console with a measured DC supply (coming
from the PXN88, PXN88SG or PXN1212SG matrix REMOTE port DC wiring)
lower than 8 VDC will always need an external WP24-PSU power supply.
• Generally speaking, the REMOTE port(s) of a PXN matrix can directly feed DC supply
to a maximum of 2 EMAGPE16units, but when wiring distances are really long, the
inrush current peak when the system is powered ON may result on the EMAGPE16units
not working (blocked, unsuccessful power up sequence) and CAN bus errors detected
in the PXN matrix (registered in the log report in MAJORCOMNet Manager):
o Cable qualies and condions may vary a lot and make it dicult to predict with
precision whether a distant EMAGPE16unit may work properly or not with direct
DC supply from the PXN matrix REMOTE port
o The DC voltage measurement (minimum 8 VDC) will be the only trustworthy me-
thod to troubleshoot a dubious case and decide to apply a soluon.
• To resolve the above limitaon, two possible countermeasures may be applied
o Option 1 - 100% reliable, always working: the addion of external power
supplies (WP24-PSU model) connected to the EMAGPE16units which do need
it. EMAGPE16units with direct supply from the REMOTE ports of the PXN matrix
and others with external power supply can coexist in the same CAN bus wiring
line
o Option 2: use the spare NC (Not Connected) twisted pair in the Cat5 cable to
double the DC supply line wiring from the REMOTE port in the PXN matrix to the
EMAGPE16unit, thus reducing the wiring line resistance and DC voltage drop
along it
Note 1: a hot connecon of a new EMAGPE16unit to a working PXN system (with the system
powered ON) may result in a reboot sequence of other digital remote controls aached to it, taking
some seconds to recover the normal working condions of them all.
Note 2: WP24-PSU is the optional external power supply compatible with the EMAGPE-
16paging console. WP-PSU model is the one compatible with the MPAGE16 paging sta-
tion and WPTOUCH digital control. Never use one of these two power supplies with
devices not compatible with it.

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
14 15
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
6. OPERATING THE UNIT
6.1. SENDING MESSAGES
Sending voice messages via an EMAGPE16paging staon is done according to the following
procedure:
1. Visual check of the available/busy status of the zones (LED indicators)
2. Select the message desnaon zones by pressing the corresponding keys
3. Press and hold the PAGE key for the duraon of the voice message
4. Release the PAGE key
5. Press the CLR (CLEAR) key if you want to cancel the last zone selecon.
However, this process and its funconal results when sending messages depend on the
programming of the messaging module (PAGERS/DUCKERS) in the ePXN1616, PXN88,
PXN88SG or PXN1212SG matrix unit to which the EMAGPE16paging staon is connec-
ted. This programming is done through the web applicaon embedded in ePXN1616 or
with MAJORCOMNet Manager when used with PXN matrices. Refer to the ePXN1616
Web Applicaon manual / MAJORCOMNet Manager user manual for more informaon.
6.2. DISPLAY AND USER KEYS
The electronic ink display on the front panel shows the names of the zones enabled for paging.
These names are automacally imported from the names assigned to the outputs of the ePXN1616
or PXN matrix unit to which the EMAGPE16paging staon is connected. In the case of zones not
enabled for paging, the display will show “---”.
There are 21 user keys on the front panel of the unit:
• Keys for selecng the message desnaon zones. They behave like a “toggle” switch, i.e.
successive keystrokes acvate and deacvate the selecon of a zone. In the ePXN1616
web applicaon or MAJORCOMNet Manager applicaon (for PXN matrices), the zones
you can send your messages to (zones enabled for each paging staon connected to an
ePXN1616 or PXN unit) are programmed, so that non-enabled zone keys are unavailable
from these keys in the paging staon.
• “F1” and “F2” keys: zone group selecon keys
• “ALL” key: selects all zones that are enabled for the paging staon (equivalent to pressing
individually all enabled-zone keys)
• “CLR” key: disables all selected zones, leaving the paging staon with no zones selected.
• “PAGE” key: when pressed and held down, it acvates the voice message transmission
funcon to the selected desnaon zones. If a “ding-dong” or “chime” melody has
been programmed in the paging staon, it is emied when the PAGE key is pressed,
and it is advisable to wait unl it is nished before starng the voice message.
Note: all funcons of the above keys are congured from the ePXN1616 web applicaon or
MAJORCOMNet Manager applicaon (for PXN units).
6.3. LED INDICATORS
Two-color LED indicators for zone selecon keys (1 to 16). Possible states and their meaning:
• Unlit: free zone (not used by another paging staon or priority module, if any)
• Lit in green: zone selected by the paging staon to broadcast the next message
• Lit in red: zone not selected in the paging staon, but hold by another paging staon
or module with higher priority
• Flashing in orange: zone selected by the paging staon, but hold by another paging
staon or module with higher priority
• Lit in orange: the broadcast of a message has been interrupted by another paging
staon or priority module, totally or parally, and this lit LED warns the user that
the message has not been fully broadcasted in that desnaon zone (regardless of
whether it has been broadcasted in other zones or not). The LED status is reset by
pressing the corresponding zone selecon key, the ALL key or the CLR key.
• Temporarily ashing in green: indicates a zone not enabled for selecon from the pa-
ging staon
Two-color LED indicators on the PAGE key. Lights while holding down the PAGE key to indi-
cate that the paging staon is in a message send mode:
• Lit in orange: when you start sending a message (pressing and holding the PAGE key),
it indicates that the chime melody is playing (as determined with the web control appli-
caon), then turns green when the chime has nished playing. Thus, the speaker knows
when the chime ends and can start its message without the risk of being covered by
the chime (*)
• Lit in green: paging funcon acvated, with voice message broadcasng to selected
desnaon zones

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
16 17
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
• Lit in red: the page staon is not operaonal (not acvated from the ePXN1616 unit, not
connected to the control bus, etc.)
(*) Note: the LED is also permanently lit in orange when updang the unit’s rmware from
the web applicaon or MAJORCOMNet Manager, accompanied by a message «UPGRADING
FIRMWARE» on the electronic ink display.
Green LED indicator for ALL and CLR keys:
• Lit in green: while the keys are pressed
Green LED indicator for zone selecon group keys, F1 and F2:
• O: the funcon assigned to the key is disabled (OFF)
• Lit in green: funcon assigned to the key is enabled (ON)
• Flashing in green: key funcon not available (nothing assigned to the key from the
web applicaon)
6.4. PRIORITIES FOR SENDING MESSAGES
From the ePXN1616 web applicaon, you can set a certain priority level, from 1 (highest prio-
rity) to 4 (lowest priority), for each of the 4 available priority modules, including 2 PAGER/
DUCKER modules (PAGER type is always associated with paging staons) and the other 2 only
DUCKER modules (triggered by priority signal level detecon).
In the PXN88 matrix, there are 4 PAGER/DUCKER modules available (and 4 priority levels), and
in the PXN88SG and PXN1212SG matrices, 3 of them (and 3 priority levels).
In a conguraon with two paging staons having dierent priority levels, the paging staon
with the highest priority may interrupt the staon with the lowest priority if messages are sent
simultaneously to the same desnaon zones (i.e. while the zones are busy). This interrupon
can be total or paral in terms of message duraon, and only aects those zones where there
is overlap.
Selecng a zone (by pressing keys 1 to 16) does not imply taking them busy – for that it is
necessary to select it and to press the PAGE key. Thus, while the PAGE key is held down on
the highest priority paging staon and the message is transmied to the desnaon zones it
selected, the following occurs on the lowest priority staon:
• LED indicators light up red for the zones to which the highest priority paging staon
is transming the message, and which were not also selected on the
Lowest priority staon. When the PAGE key is released on the priority paging staon,
the red LEDs go out.
• LED indicators ash orange for the zones to which the highest priority paging staon
is transming the message and which were selected on the lowest priority staon.
When the PAGE key is released on the priority paging staon, the LEDs light up green.
• If the non-priority paging staon is broadcasng a message (or starts broadcasng
while the priority staon is broadcasng its message), it will be interrupted in all
zones where the priority staon is broadcasng (overlapping) and will connue to
broadcast in the other zones (not overlapping). The LED indicator for zones where
the message has been interrupted (or not broadcast) will light up orange.
Aer the priority message has been broadcast, the LED for that zone will remain lit in orange,
alerng the user that the message has not been broadcast in its enrety in that desnaon
zone (whether or not it has been broadcast in other zones). This status is reset by pressing any
of the following keys:
• Key of the zone in queson selected (green)
• ALL key, leaving this zone and all others selected (green)
• CLR key, deselecng all zones
When the two paging staons have the same priority level, the rst one that holds a zone (or
several) has priority for the duraon of its message, holding the zone(s) up to their release
(end of the message). If, while this paging staon is broadcasng a message, the other staon
tries to broadcast another message to a zone hold by the rst staon (overlapping zones and
zones hold by the rst staon), the LED indicator for zones where the message has not been
broadcast will light up orange. Aer the priority message has been broadcast, the LED for that
zone will light orange, alerng the user that the message has not been broadcast in its enrety
in that desnaon zone (whether or not it has been broadcast in other zones). This status is
reset by pressing any of the following keys:
• Key of the zone in queson selected (green)
• ALL key, leaving this zone and all others selected (green)
• CLR key, deselecng all zones
As long as you press PAGE, it is not possible to change the zone selecon, and therefore the
ePXN1616 / PXN unit will ignore all messages related to zone selecon.
The funcons of the ALL, CLEAR, F1 and F2 keys will also be ignored during this me.

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
18 19
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
7. NOTES
• When connecng an EMAGPE16unit to an ePXN1616 matrix, the EMAGPE16unit will
check whether its rmware needs to be updated, and if so, automacally performs
update, without external manual intervenon. This process takes a few seconds to be
carried out, while the message «UPGRADING FIRMWARE» will be displayed, accompa-
nied by the orange LED on the PAGE key.
• When connecng an EMAGPE16paging staon to the PAGER port of a running (powered
on) ePXN1616 unit, it is normal to have to restart all other connected eMCONTROL1
staons and controls, a process that takes a few seconds to complete, and aer which
all eMCONTROL1 staons and controls become fully funconal.
• Press the CLR key for 5 seconds to display the unit name and rmware version.
8. PART NAMES
1. XLR female connector
2. Paging zone selecon
keys
3. Electronic ink display
4. CLR key
5. ALL key
6. F1 key
7. F2 key
8. Paging indicator LED
9. PAGE key
10. Kensington security slot
11. RJ45 connector access

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
20 21
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
9. TECHNICAL SPECIFICATIONS
Analog characteriscs:
Microphone type Removable gooseneck condenser microphone
(eMCN1).
Polar paern Unidireconal
Microphone frequency response 50Hz – 18KHz (-10dB)
Phantom Voltage 48VDC, always ON
Output level with eMCN1 MICROPHONE -5dBV @ 94dB SPL with ADJ MAX.
-10dBV @ 94dB SPL with ADJ MID.
-20dBV @ 94dB SPL with ADJ MIN.
Digital characteriscs:
Number of paging zones 16
Addional control keys F1, F2, All, Clear
Indicators Green LED on All and Clear keys, Bicolor LED on
other keys
Display Acve Matrix Electrophorec Display - 296x128
Pixels
Communicaon Standard RS485 and CAN, internally selectable by JUMPER
Supply characteriscs:
Nominal Power supply From RJ45 Remote input: 12VDC
From External Input: 24VDC
Minimum External Power supply From RJ45 Remote Input: 9.5VDC
From External Input: 9.5VDC
Maximum Power Consumpon From RJ45 Remote Input: 180mA
From External Input: 180mA
Miscellaneous:
Connector RJ45 Remote port
Dimensions (microphone excluded) W 150mm x D 180mm x H 50mm
Weight 900g
Included accessories Windscreen for Microphone.
10. BLOCK DIAGRAM

56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
22 23
EMAGP16 EMAGP16
Usermanual V1.1 Usermanual V1.1
11. CONFIGURATION DIAGRAM
CAN / 485 jumpers: 485 posion for ePXN series (factory default) / CAN
posion for PXN series
J111-J112: insert jumper to enable 120Ω terminal line resistor (just re-
quired in CAN bus mode, for PXN series operaon)
12. PACKAGE CONTENTS
• EMAGPE16unit
• Condenser gooseneck microphone
• RJ45 to screw terminals adapter (CAN bus daisy chain adapter)
• User quick guide
• Warranty card

EMAGP16
56, chemin de la Flambère · 31300 Toulouse · FRANCE · T é l . 3 3 (0)5 61 31 86 87
F a x 3 3 ( 0 ) 5 6 1 3 1 8 7 7 3 · [e-mail] · www.majorcom.fr
User manual V1.1
