malkans SF5A User manual

SF5A
Assembly Instructions
© malkans ltd

2
Warning
Do not overtighten screws. Overtightening will damage the head and
threads of the screws.
Case structure fragile during assembly. Construct with care and avoid
unnecessary movement.
Remove the protective layer from both sides of all case panels before
assembling the case.

3
Parts List
1
Front Panel
1
Top Panel
12
M3 x 8 mm
4
M5 x 10 mm
1
Right Panel
1
Bottom Panel
12
M3 x 6 mm
4
Case Feet
1
Back Panel
8
Aluminium Nut
4
M3 x 5 mm
Button Head
4
M3 x 8 mm
Button Head
1
Left Panel
Power Switch
4
6-32, 3/8”
4
Hexagonal Nut
1

4
Step 1
Use 4 M3 x 8 mm screws to attach 4 Aluminium Nuts to the Right
Panel, making sure that the corners of the Aluminium Nuts are
aligned with the corners of the panel.

5
Step 2
Install your CPU, CPU Cooler, RAM and M.2 SSD to your
Motherboard. (Refer to your motherboard instruction manual)

6
Step 3
Align your Motherboard with the standos on the Right Panel and
use 4 M3 x 5 mm Button Head screws to attach the Motherboard to
the Right Panel.

7
Step 4
Use 2 M3 x 8 mm screws to attach the Back Panel to the Right Panel.
Tip: The holes in the panels are slightly larger than the screws to allow for
adjustments. During the build, you may loosen screws, adjust panels and
retighten screws to ensure that all panel edges are correctly aligned.

8
Step 5
Use 2 M3 x 8 mm screws to attach 2 Aluminium Nuts to the Back
Panel.

9
Step 6
Attach the Power Switch to the Back Panel.

10
Step 7
Connect the power supply cables, and power switch cable to the
corresponding motherboard connectors. Refer to your power supply
and motherboard instructions manuals.

11
Step 8
Use 4 M5 x 10 mm screws to attach your 92 mm case fan to the
Bottom Panel.
Tip: The arrow on the side of your case fan indicates the direction of airow.
We recommend installing the fan so that it blows air into the case.
Tip: Refer to page 13 for further guidance regarding the position of the
bottom panel and fan.
Tip: Lay the case fan and bottom panel at for better stability to drive the
screw in straight and ensure that the screw head sits ush with the bottom
panel.

12
Step 9
Use 4 M3 x 8 mm Button Head screws and 4 Hexagonal Nuts to
attach 4 Case Feet to the Bottom Panel.

13
Step 10
Connect the case fan cable to the motherboard, and use 3 M3 x 6
mm screws to attach the Bottom Panel to the case.

14
Step 11
Use 4 6-32, 3/8” screws to attach your SFX power supply unit to the
Back Panel and connect the loose power cables to the Power Supply
Unit. Refer to your power supply instructions manual.
Tip: Use cable ties for a tidy look and to prevent cables obstructing any fans.

15
Step 12
Use 3 M3 x 6 mm screws to attach the Top Panel to the case.
Tip: Note the correct orientation of the top panel before attaching it to the
case.

16
Step 13
Use 2 M3 x 6 mm screws to attach 1 Aluminium Nut to the Bottom
Panel and 1 Aluminium Nut to the Top Panel.

17
Step 14
Use 4 M3 x 8 mm screws to attach the Left Panel to the case.

18
Step 15
Using both hands, lift and rotate the case onto its feet. Then use 4
M3 x 6 mm screws to attach the Front Panel to the case.

19
Disassembly Instructions
Cleaning and Care
Help and Feedback
Follow the instructions in reverse order to disassemble the case.
Use an air duster to blow out dust from the case, then wipe down
the case gently with a non-scratch microbre cloth.
[!]Use of cleaning chemicals may cause damage or discolouration.
[!]Use of liquids/chemicals may cause damage to metal parts.
[!]Always use both hands to support the case when moving.
For further assistance, or to provide feedback, please use the contact
form at www.malkans.com
