M&S Systems MCD6 User manual
This booklet contains the information you need to get the most enjoyment from your
Model MCD6 digital compact disc player as well as important warranty information.
Retain this booklet for future reference.
_
CONTENTS
ABOUT YOUR SYSTEM . . , . . . , . . . . . . . . . . . . . . . . . . . 2
CONTROLS AND FEATURES . . . . . . . . . . . . . . . . . . . . . . 3
FUNCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
HANDLING DISCS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
LOADING DISCS
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
5
UNLOADING DISCS
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
a
.
.
.
.
.
.
.
.
.
.
.
.
.
6
LOADING DISC MAGAZINE . . . . . . . . . . . . . . . . . . . . . . 6
UNLOADING DISC MAGAZINE
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
7
CARE AND MAINTENANCE
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
8
TROUBLESHOOTING TIPS
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
.
8
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NOTES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
NOTE: Product specifications are subject to change without notice.
Copyright
c,
1997 by M&S Systems, Inc.
1
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
ABOUT YOUR SYSTEM
The MCD6 from M&S Systems is a high-quality CD player designed to compliment your
built-in M&S Systems musical intercom system. Your
MC66
digital compact disc player
includes these outstanding features:
l
One 6-disc magazine (additional 6-disc magazines available)
Random track/disc selection
Highly visible backlighted LCD display
l
Elapsed time display for selected track
Numeric indicator for selected track
Graphic indication of
Track search forward
Pause/resume feature
.
selected disc and installed discs
and reverse
l
Next/previous track selection
0
Compatible with all M&S Systems musical intercoms
0Plays all
5”
compact discs labeled with
DIGITAL
AUDIO
Additional 6-disc magazines are available. Fill one magazine with your favorite Jazz CD’s,
another with Rock ‘n Roll, and another with Classical. Contact your local M&S dealer or
call 214-358-3196.
Like all M&S Systems products, the MCD6 compact audio disc player is designed to make
your home atmosphere more enjoyable. M&S Systems is committed to producing high
quality products for your home. If you have any questions about the operation of your
system, please call us at (214) 358-3196.
2
-
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
CONTROLS AND FEATURES
The illustration below shows the controls and features you use to operate the Model
MCD6.
El
Display
-
Provides
visual indication of the
MCD6’s
status and
operational settings.
Display light control
-
If you do
not wish to have the display
light
come on, you may disable it by
pressing Track up and Mode at
the
same
time and holding for 3
seconds.
Pressing
this
combination of buttons again for
3 seconds will return the display
light to normal operation.
000
Currently Disc is
selected installed but
disc not selected
Q
A
Status/operating mode
indicators
0
:
Disc indicators
@6@
01)
EI
Disc is not
installed
(blank)
,
LI
,
RANDOM REPEAT
SONG DISC ALL
MCD6 display legends
0
Track number
0
@
Track elapsed time
R
6-disc
magazine
-
Removable magazine that holds 6 compact discs.
PI
Controls
-
Used to operate and setup the MCD6 compact disc player.
13
4
Eject
-
Button used to eject the disc magazine
R
Door slide
-
Used to access the disc magazine
3
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
FUNCTIONS
The illustration below shows
the controls and features of your Model MCD6. You may
need to refer to the operating
guide for your music-intercom for additional information.
II
R
El
0
4
TRACK
DOWN/SEARCH-Pressing and
holding this button fast reverses toward
the beginning of the current track. You
/
will also hear short samples of the track as
1
it reverses through the selected track.
Momentarily pressing this button returns
’
play to the beginning of the current track.
A double press of this button will jump to
q
the previous track.
*SEARCH
PLAY
b
SEARCH
b
L2
,bLz
=
TRACK
bi
I1
!\I
0
NU4T
D’SC
MODE
’
POW R
F
NEXT DISC
-
Press this button to advance to the next disc. A particular disc may be
selected by pressing this button repeatedly until the desired disc is indicated on the
display.
PLAY/PAUSE
-
Press this button to alternately pause or play the CD.
MODE
-This button cycles the CD player through each of its five different modes as
described below. Additionally, holding the mode button down will display the total
number of tracks and total time of the CD.
Each track is
Dlaved
in order before
advancina
to the next
disc.
’Repeats the current track
Plays the current disc sequentially and then starts over at
1
track
1.
Plays tracks from the current disc in random order.
Plays tracks randomly from all discs.
POWER
-
This button turns the power to the
MCD6
ON or OFF.
TRACK UP/SEARCH-Momentarily pressing this button advances play to the next
track. Pressing and holding this button will fast forward through the currently selected
track.
4
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
HANDLING DISCS
Compact discs are optically read plastic discs which require no maintenance. However,
care must be taken to insure the readable surface is not contaminated by dirt, grime
fingerprints, etc. Avoid touching the side opposite the label. This is the side that contains
the digital information read by the
MCD6’s
laser. Compact discs should only be handled
by the outer edges or center hub.
LOADING DISCS
The 6-disc magazine used with the
MCD6 contains 6 slots used to align
each compact disc. These slots are
numbered l-6 starting from the bottom.
The magazine does not have to have a
disc loaded in each slot. The MCD6 will
automatically sense which discs are
installed and will accept play options for
the installed discs only. Each disc must
be installed with the label up as shown
below.
.
L.,__J/’
6-Disc magazine
A 3
It
/8cm7
disc can be
daved
with the use of an
oDtional
adapter. (Contact
L
M&&leaier).
Only
onk 3
‘:[8CM]
disc can be in&-ted
installed in the number one slot only.
Insert disc with
label
u
/4+
\
,-’
into the MCD6 and it must be
STEP 1
-
Insert disc into vacant
slot (label up)
vow
local
STEP 2 -Push disc in (disc shown fully seated)
until it is fully seated and
flush with the magazine
5
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
UNLOADING DISCS
A disc can be removed by moving the lever on the side of the disc magazine as shown
below. Moving the lever corresponding to the desired disc will eject the disc by
approximately
l/2”.
The disc can then be fully removed.
STEP
I
-Move lever
corresponding to the disc
to be removed.
STEP
2 - Remove disc from
magazine.
LOADING DISC MAGAZINE
The MCD6 plays discs installed in the disc magazine supplied with it.
magazine, slide the access door all the way to the right. Gently, insert
into the exposed slot oriented as shown below. The access door can now be closed.
To install the disc
the disc magazine
STEP
I
-
Open magazine door and
STEP 2
-
Press the magazine
gently insert the magazine oriented in until it locks in place. Slide
as shown. access door closed.
6
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
UNLOADING DISC MAGAZINE
Unloading the disc magazine is performed by
fast
sliding the access door to the right.
Next, press the eject button located below the window on the magazine. Pressing this
button will activate the magazine release mechanism. When ejected, the magazine will
extend outward 1”. You may then pull the disc magazine out completely.
STEP 1
-
open magazine door and
press the eject button.
Eject
butt2
\\
‘-
. . . .
\
STEP 2
-
Wait for the magazine to
,/“\,
extend and stop (approximately 1
’
inch outward).
STEP 3
-
Pull the
from the MCD6 player
the sliding door.
magazine
and close
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
CARE AND MAINTENANCE
No maintenance is required to provide reliable operation. The MCD6 can be cleaned using
a slightly dampened cloth. No chemicals should be used to clean the face panel
components. Many common household chemicals may damage or discolor the face panel
components. Use care when cleaning the display window.
TROUBLESHOOTING TIPS
Will not power on
Magazine will not eject
“Err 07” displays when
disc is selected for play
“Err 07” displays while
disc is playing
Display does not light
“Err 01” displays
Display shows disc is
playing but nothing is
heard
Check for tripped circuit breaker.
Sliding door not opened fully.
Disc is not readable or is installed in the magazine
upside down. Disc must be installed with the label up.
Disc is dirty, damaged, or scratched.
Press Track up and Mode at the same time and hold
for 3 seconds to enable.
Disc is jammed. Try ejecting the magazine.
Shipping screws have not been removed upon
installation.
AUX is not selected on the radio-intercom master.
Check to see if FM or AM plays on the radio
intercom. If not, refer to troubleshooting section in
the owner’s guide for the radio-intercom master.
Manual Reset Procedure
In some cases, performing a reset on the MCD6 may resolve your problem. First try
resetting the MCD6 player by pressing the
TRACK UP
and
POWER
buttons at the same
time. If that does not work, remove the plastic front cover by pulling straight out and press
the
RESET
button below the keypad. If your MCD6 player still does not operate, please
contact your dealer or M&S Systems at (214).358-3 196.
8
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
CONGRATULATIONS!
‘four
purchase of an M&S audio product an investment that will provide
yeair
of enjoyment and service for your
customer.
M&S
audio products are backed with more than 40 years of experience in the design and manufacture of quality audio
equipment for
the home. To ensure that your customer receives the high-quality music reproduction that the system
is designed to deliver, it is important that each step of the installation be done carefully. If you follow the step-by-step
illustrated instructions below, the result will be a successful professional-quality installation. In the event you need
troubleshooting assistance, please
call our technical staff at I -800-366-9422.
Tools required: Phillips screwdriver X2,
rr”
I Flat bladed
screwdriver
(MC06
only).
The finish-our installation should be made after the
application of wall covering material.
Th?se
instructions
should be used in conjunction with the master
unit’s finish-
out instructions.
u
u
u
u
USE ONLY M&S SYSTEMS BRAND
CABLE as called out in these instructions and
included in the listed wallhousings. The cable is
designed and constructed with electrical
specifications
necessary for proper audio
performance.
IMPORTANT:
THE USE OF NON
M&S SYSTEMS’ BRAND CABLE OR CABLE
SUBSTITUTION WILL VOID PRODUCT
WARRANTY.
Note:All
M&SSystems’cabfe
has
M&S
Systems
and the part number
pnhted
on
it!
Connect the audio cables included with the wall housing to
the master unit and
MCD6.
to Aux
In
lert
on
master unit
Power
connector
DO NOT power up cassette or compact disc
player until all audio cables are connected.
Figure 2
-
Audio cable hookup for mono
radio-intercom master units
DO ensure that all rough-in instructions have
been followed before power is applied to
system.
DO NOT SPLICE CABLES. Splices are
unreliable and may adversely affect audio
qua1.v.
CONNECTING THE EQUIPMENT
Remove any cardboard or
protective coverings from
the
MC06
as shown.
Figure
I
-
MC06
Bottom view
Figure
3
-
Audio cable hookup for
stereo
radio-intercom master units
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
After- all wiring
is
completed between the
master unit and the MCD6, connect the
poww
cord
from
the
TEZD
transformer to
&I
&I
TROUBLESHOOTING
the
power
connector on the MCD6. DO
ry
x5
NOT PLUG POWER CORD IN
j-$
BACKWARDS. Connect the power to
v
the master unit as described in the finish-out
Wrong! Right!
instructions for your master unit.
Figure 4
Mount the
cassette/CD*player
to the wall housing using the
two
#6
screws provided.
Unit
v.;!:
n3;
po;*:e:
up’
?ower
not
supplied to wall
housing
tzz_x$ormer.
Open
center
tap
on transformer
Display
ltght
for display does
not
light
up Display light is turned off. Press
Trcck> and Mode at the same time
to turn on
“Err
07”
displays on initial
play of selected disc
Note: A wood trim ring is required
to
mount the
MC06
model for both single and combination wallhousing
applications.
Follow the operating procedures included
with your
marter
and
MC06
to assure your installation is correct,
After system
.
operation is confirmed, install the face panel insert.
“Err
07” displays during play
of the currently selected
disc
‘Err 0
I
”
displays on initial
Dower
u?
‘Err 0
I
”
dis?kys
Jnit
S:~OWS
piay but nothing
s
heard
Disc is inserted upside down. Label
should be up.
Disc is not
%!a
compatible
Disc is scratched, dirty or otherwise
7ot
readable
3isc
is not
@!!!
compatible
Shipping screws on mechanism have
IO:
been removed
3sc
improperly inserted into disc
ncgazine
3isc
is jammed.
Ldio-intercom master unit is not
ource
selected properly.
Set source
o
AUX mode.
+ddio
cables are not properly
+
onnected
or defective.
If
you encounter any problems with the equipment, verify
the hookup against these installation instructions
as
welt as
the installation instructions for the
master
unit. Most
malfunctions are caused by installation errors. If,
after
checking your installation, you are unable to determine the
cause of the problem, contact our technical support
depafiment
at I-800-366-9422. Be sure to have the exact
model number, serial number and the nature of the
proble;n
ready. If possible, CALL FROM THE SITE. We
cannot
ektively
troubleshoot your installation if you are not
calling iron the location where the equipment is installed.
SYSTEMS, INC.
A
l oa?cR
CoYC**v
115824
Rev-
M&S
sm::j
~-YEA).
‘h!O
FAULV
IJM~
WMJUW
M&S
+zems. Inc.
wara~ts
fcv
~.t’o
)~LY
(2)
2:.
zc:---
~3ry
pc&ck
t:,
x
free
of
haorp:auseC
lefeects in
frdznal
and
‘+orlvnaxhip.
M&S
Systems.
kc.
w:ll
regair
or reptace. at
is
o@on.
parts and materials at no charge.
regbleu
of the problem. This v/r,‘?--
_
.,J
Me-tj
to LX
orighl
purcrver
of
the
proc!uci
ar.d
to
each
s&rquent
owner
of
the
+ckt
dkg
me
!c-
of
CIS
wamnty.
Tais
tt0
FAULT
vnmnty
cove
only
t:e
l&W
detikl
abo&dnd
does
not
incke
110’5;
!or
Ir.cidental
cr
conztiential
damages. NOTE: Some states do
cot
al!Ow
tie
exchon
or
limitaloft
0’r:iderd
or CanjquenDJ
&,?*g&
30
LCIe
a*e
limbbon or exclusion
may not
appIy
to you.
SMARTHOME.COM(TM) 1-800-SMART-HOME 949-221-9200 http://www.smarthome.com Order #5076
Other manuals for MCD6
1
Table of contents
Other M&S Systems CD Player manuals
