PREFACE
Note:
MAQ Sonar makes every effort to ensure the information contained within this document
is correct. However, our equipment is continuously updated, so we cannot assume
liability for errors, which may occur.
Warning:
MAQ Sonar disclaims any responsibility for damage or injury caused by improper
installation, use or maintenance of the equipment.
References:
This Technical Manual is intended as a reference only. The information contained in this
document is to be used in conjunction with the shipyards own vessel drawings,
documentation and engineers. Standards for installation are to be certified by the
installing shipyard, engineers and dealers. Further information about MAQ Sonar can be
found in the MAQ Sonar Operators Manual.
Manuals:
This manual must be kept aboard the vessel at all times. The information contained
herein is subject to change without notice.
Introduction:
The main purpose of this manual is to provide the information and basic drawings
required for installation of the MAQ Sonar system. In addition this manual contains
technical information which may be required in the future.
The MAQ Sonar electronics is capable of driving three different frequency transducers.
This is a generalized manual for all three types of transducers.
Responsibilities:
The installer is responsible for the equipment during the installation. The warranty is only
valid when the installation is made in accordance with this manual.
iii
