Mark Web Module User manual

Installation manual
Installationsanleitung
Manuel d’installation
Installatiehandleiding
Instrukcja instalacji
Manual de instalare
DE
WEB MODULE (0629187)
0664049_R01
EN
FR
NL
PL
RO

2
Read this document before
installing the heater
1 General
1.1 Subject to change
The manufacturer is committed to constantly improving its products and reserves the right to make changes
in the specications without prior notice. The technical details are considered correct but do not form the
basis for a contract or warranty. All orders are accepted according to the standard terms of our general
sales and delivery conditions (available upon request). The information in this document is subject to change
without notice. The most recent version of this manual is always available at www.markclimate.com/
downloads.
1.2 General warnings
Installation must comply with applicable local and / or national codes. Therefore, have the connection box
installed by a skilled and qualied installer in compliance with national and international regulations. The
warranty will lapse in the event of incorrect installation, adjustment, modication, maintenance or repair.
Warning
Incorrect installation, adjustment, alteration, repair or maintenance work may lead to material damage or
injury. All work must be carried out by certied, qualied professionals. If the appliance is not positioned in
accordance with the instructions, the warranty shall be rendered void. This appliance is not intended for use
by children or persons with a physical, sensory or mental handicap, or who lack the required experience
or expertise, unless they are supervised or have been instructed in the use of the appliance by somebody
who is responsible for their safety.Children must be supervised to ensure that they do not play with the
appliance.

EN
3
2 Preparation
2.1 Contents (Image 1)
1 Web Module
2 Power cable
Input: AC 100-230V 50-60Hz 0.6A
Output: DC 5V 3.0A
Length: 1,9 meter
3 Cat 5E cable
Length: 1,5 meter
2.2 Open Web Module
Carefully open the Web Module with a screwdriver (saw cut) at the black arrow in Image 3.
2.3 MAC-address
The MAC address can be found on the sticker of the Web Module (see Image 4). Make a note of this for
yourself, you will use it later during the installation process.
2
1
3
Image 1
Image 2 Image 3
Image 4
xx xx xx xx xx

4
3 Connect
3.1 Connections Web Module (Image 5)
Connection to print Description
1J2 Web-RJ45 connection
2- Do not connect (other application)
3J9 Bus connection for Optitherm+
(0619185) and the rst air heater
4J1 Supply: DC 5V 3.0A
Image 5
1 2 2 2 3
4

EN
5
3.2 Connect to one air heater (Image 6)
Only use a shielded data/signal cable according to table [2]. See $3.2 in the technical manual of the Optith-
erm+ thermostat and images [26] in the technical manual of the GS+ / GSX air heater.
3.3 Connect to multiple air heaters* (maximum 8) (Image 7)
Only use a shielded data/signal cable according to table [2]. See $3.2 in the technical manual of the Optith-
erm+ thermostat and images [25] and [26] in the technical manual of the GS+ / GSX air heater.
For the jumper positions (burner control) see gure [25] and [26] in the technical manual of the GS+ / GSX
air heater (Image 8).
* If you want to read out fault messages and history of each air heater via
the app, you need a separate Optitherm+ thermostat (0629185) and Web
module (0629187) for each air heater.
Image 6
Image 7
Image 8

6
4 Installing and using the app
1. Open the Google Play Store or the Apple App Store (this instructi-
on is based on Android)
2. Search for “RemoteVision”
3. Select RemoteVision.
Press install.
Open the application.

EN
7
The Main Screen:
If you are using the application for the rst time, press “Register”.
Known users can log in with the information they provide.
You can also go to “Demo mode” from this screen.
Note: The “Demo mode” is based on a boiler.
1. Choose a username and enter it below Username.
2. Enter your own e-mail address below E-mail address.
3. Choose a password and enter it under Password.
4. Repeat this password under Conrm password.
5. Enter the MAC address found on the Web module.
(see $ 1.1 of this guide)
Press “Apply” (bottom left)

8
Click on the Appliance name to begin.
In this Status screen you can see the daily setpoint of the connected
units.
“Swipe” left for the next day set point setting screen.
Color Status of Appliance
Green Online and the unit works well
Red Online and the unit has a fault
White Ofine

EN
9
In this screen you can see the basic data of the Web module.
The data for the following elds is xed:
Project, Appliance name, Reference and logo.
You can change the other elds by clicking on them and changing the
text.
Example completed elds.

10
If you want to add an extra Web module, choose “Add Appliance”
(bottom left).
Appliance refers to the Optitherm + thermostat, you enter the MAC
address of the Web module to access it.
Press: “Apply” (bottom left)

EN
11
Swipe left for the next day setpoint setting screen.
In this Status screen you can set the day setpoint of the connected
units by using the Up and Down buttons.
Note:
It may take a while before a changed day setpoint becomes active
in the Appliance and will actually be seen on the display of the
Optitherm+ thermostat.
For more information about the unit, press the “Info” button

12
In this screen you can see all other settings of the rst connected
appliance.
This screen is refreshed every 10 seconds.
Parameters shown in dark blue can be adjusted by clicking on them.
Note:
It may take a while before a changed value becomes active in the
Appliance and will actually be seen on the display of the Optitherm+
thermostat.
If you want to change a value from the “Info” screen, you will enter
this screen.
A new value can be set by means of scroll through the values.
You can save the selected value with the “Apply” button.
Click the “Cancel” button to leave the value unchanged.
After clicking one of the two buttons you will return to the Info
screen.
Note:
It may take a while before a changed value becomes active in the
Appliance and will actually be seen on the display of the Optitherm+
thermostat.

EN
13
Click on the “History” button to request the history of the unit.
In this screen you can see the history of the unit.
Then scroll down ...
Then you will see even more history of the unit.
Press “Appliance” to return to the appliance screen.

14
Lesen Sie dieses Dokument sorgfältig
durch, bevor Sie das Gerät installieren
1 Allgemeines
1.1 Änderungen vorbehalten
Der Hersteller strebt eine kontinuierliche Verbesserung der Produkte an und behält sich das Recht vor, ohne
vorherige Mitteilung Änderungen an technischen Daten vorzunehmen. Die technischen Angaben werden als
korrekt angenommen, bilden aber keine Grundlage für einen Vertrag oder Gewährleistungsansprüche. Alle
Bestellungen werden gemäß den Standardkonditionen in unseren AGB’s (auf Anfrage erhältlich) angenommen.
Die Informationen in diesem Dokumente können sich ohne vorherige Ankündigung ändern. Die neuste
Version dieses Handbuches nden Sie immer auf unserer Interseite unter www.mark.de/downloads.
1.2 Allgemeine Warnhinweise
Die Installation muss den geltenden lokalen und/oder nationalen Vorschriften entsprechen. Deshalb lassen Sie
die Anschlussbox von einem fachkundigen und qualizierten Installateur unter Einhaltung der nationalen und
internationalen Vorschriften montieren. Bei unsachgemässer Installation, Einstellung, Änderung, Wartung oder
Reparatur erlischt die Gewährleitung.
Warnhinweis
Fehlerhaft durchgeführte Installationen, Einstellungen, Änderungen, Reparaturen oder Wartungsmaßnahmen
können zu Sachschäden und Verletzungen führen. Alle Arbeiten müssen von geprüften, qualizierten Fachleuten
durchgeführt werden. Falls das Gerät nicht vorschriftsgemäß aufgestellt wird, erlischt die Garantie.
Dieses Gerät ist nicht für den Gebrauch durch Personen (einschließlich Kindern) mit verminderter
körperlicher, Sinnes- oder geistiger Leistungsfähigkeit, mangelnder Erfahrung und mangelnder Kenntnissen
bestimmt, sofern sie nicht unter Aufsicht stehen oder durch eine Person, die für Ihre Sicherheit verantwortlich
ist, im Gebrauch des Gerätes angeleitet werden. Kinder müssen vom Gerät ferngehalten werden.

DE
15
2 Vorbereitung
2.1 Inhalt (Abbildung 1)
1 Web Module
2 Stromkabel
Eingabe: AC 100-230V 50-60Hz 0.6A
Ausgabe: DC 5V 3.0A
Länge: 1,9 Meter
3 Cat 5E Kabel
Länge: 1,5 Meter
2.2 Web-Modul öffnen
Öffnen Sie das Web-Modul vorsichtig mit einem Schraubendreher (Schlitz) am schwarzen Pfeil, wie in Bild 3.
2.3 MAC-Adresse
Die MAC-Adresse nden Sie auf dem Aufkleber des Web-Moduls (siehe Abbildung 4). Notieren Sie es für sich
selber, da Sie es während des Installationsvorgangs benötigen.
2
1
3
Abbildung 1
Abbildung 2 Abbildung 3
Abbildung 4
xx xx xx xx xx

16
3 Verbinden
3.1 Web-Verbindungen (Abbildung 5)
Verbindung auf Druck Beschreibung
1J2 Web-RJ45-Verbindung
2- Keine Verbindung herstellen (andere Anwendung)
3J9 Busanschluss für Optitherm+ (0619185) und den er-
sten Lufterhitzer
4J1 Versorgung: DC 5V 3.0A
Abbildung 5
1 2 2 2 3
4

DE
17
3.2 An einen Lufterhitzer anschliessen (Abbildung 6)
Verwenden Sie nur ein geschirmtes Daten-/Signalkabel gemäss Tabelle [2]. Siehe $ 3.2 im technischen Hand-
buch der Optitherm+ Thermostats und Bilder [26] im technischen Handbuch des GS+/GSX Lufterhitzers.
3.3 Anschluss an mehrere Lufterhitzer* (maximal 8) (Abbildung 7)
Verwenden Sie nur ein geschirmtes Daten-/Signalkabel gemäss Tabelle [2]. Siehe $ 3.2 im technischen Hand-
buch der Optitherm+ Thermostats und Bilder [25] + [26] im technischen Handbuch des GS+/GSX Lufter-
hitzers.
Zu den Jumperpositionen (Brennerregelung) siehe Abbildung [25] und [26] im technischen Handbuch des
Lufterhitzers GS+/GSX (Abbildung 8).
* Wenn Sie Störmeldungen und Historie der einzelnen Lufterhitzer über die
App auslesen wollen, benötigen Sie eine separates Optitherm+ Thermostat
(0629185) und Webmodul (0629187) für jeden Lufterhitzer.
Abbildung 6
Abbildung 7
Abbildung 8

18
4 Installieren und Verwenden der App
1. Öffnen Sie den Google Play Store oder den Apple App Store (diese
Anleitung basiert auf Android)
2. Suche nach “RemoteVision”
3. Wählen Sie RemoteVision.
Drücken Sie Installieren
Öffnen Sie die Anwendung.

DE
19
Der Hauptbildschirm:
Wenn Sie die Anwendung zum ersten Mal verwenden, drücken Sie
“Registrieren”.
Bekannte Nutzer können sich mit den von Ihnen bereitgestellten
Informationen einloggen.
Sie können auch in den “Demo-Modus” wechseln.
Hinweis: Der “Demo-Modus” basiert auf einem Zentralheiz-Gerät.
1. Wählen Sie einen Benutzernamen und geben Sie ihn unter
Username ein.
2. Geben Sie Ihre eigene E-Mail-Adresse unterhalb der E-mail
address ein.
3. Wählen Sie ein Passwort und geben Sie es unter Password ein.
4. Durch wiederholen des Passwortes dieses bestätigen.
5. 5. Geben Sie die im Webmodul gefundene MAC-adres ein.
(siehe $ 1.1 dieser Anleitung)
Drücken Sie “Anwenden” (unten links)

20
Klicken Sie auf den Gerätenamen, um zu beginnen.
Auf diesem Status-Bildschirm sehen Sie den Tages-Sollwert der ange-
schlossenen Geräte.
“Wischen” Sie nach links um den nächsten Tag einzustellen.
Farbe Status des Gerätes
Grün Online und das Gerät funktioniert gut
rot Online und das Gerät hat eine Störung
Weiß Ofine
