Marks Electrical MEFR9247W User manual

Distributed by Marks Electrical Ltd
King Richards Road, Leicester, LE3 5QG
www.markselectrical.co.uk
Operating Instructions
MEFR9247W - Refrigerator
PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE USE
WHEN USING ANY ELECTRICAL APPLIANCE, BASIC SAFETY PRECAUTIONS
SHOULD ALWAYS BE FOLLOWED
IMPORTANT –If the mains lead of this appliance becomes damaged then it must be
replaced by the manufacturer’s service agent, or a suitably qualified person using the same
rated cable in order to avoid a hazard.

Getting to know your refrigerator
DO NOT TURN ON THE REFRIGERATOR FOR 2 HOURS
After the refrigerator is in place it needs to be left for 2 hours, to allow the coolant fluid time
to settle.
Installation
Location
When selecting a position for your refrigerator, you should make sure the floor is flat and
firm, and the room is well ventilated with an average room temperature of between 12°C
and 32°C.
Specification

This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not play with the freezer.
Cleaning and user maintenance shall not be made by children without supervision.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
WARNING: Keep ventilation openings, in the appliance enclosure or in the
built-in structure, clear of obstruction.
WARNING: Do not use mechanical devices or other means to accelerate the
defrosting process, other than those recommended by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food storage
compartments of the appliance, unless they are of the type recommended by
the manufacturer.
Do not store explosive substances such as aerosol cans with a flammable propellant in this
appliance.
The instructions shall include the substance of the following:
This appliance is intended to be used in household and similar applications such as
Staff kitchen areas in shops, offices and other working environments;
Farm houses and by clients in hotels, motels and other residential type
environments;
Bed and breakfast type environments;
Catering and similar non-retail applications.
This appliance is not intended for use by persons including children with reduced physical, sensory, or
mental capabilities, or lack of experience and knowledge, unless they have been given supervision or
instruction concerning use of the appliances by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
THERE ARE NO USER SERVICEABLE PARTS INSIDE AND THE CASING SHOULD NOT
BE OPENED BY AN UNQUALIFIED PERSON
THIS APPLIANCE IS INTENDED FOR DOMESTIC USE ONLY
Electrical Connection
Ensure your supply is rated at 220~240v and 50/60Hz before operating the appliance. This refrigerator
is fitted with a rewirable plug incorporating a 13amp fuse. In addition this appliance must be earthed or
connected to an earthed supply. In the event of the fuse needing replacement then a 13amp fuse
approved by ASTA to BS1362 MUST be used.
IMPORTANT: If the plug fitted is not suitable for your socket, then the 13amp plug supplied should be
removed. Before wiring the appropriate plug, please note that the wires in this mains lead are coloured
in accordance with the following code:
BLUE: Neutral
BROWN: Live
GREEN & YELLOW: Earth
As the colours in the mains lead may not correspond to the coloured markings in your plug, proceed as
follows:
Connect the BROWN wire to the terminal marked ‘L’ or coloured RED, connect the BLUE wire to the
terminal marked ‘N’ or coloured BLACK, and connect the GREEN & YELLOW wire to the terminal marked
‘E’ or coloured GREEN or GREEN AND YELLOW. If in doubt consult a suitably qualified electrician.

Avoid locating your refrigerator near a heat source, e.g. cooker, boiler or radiator. Also
avoid direct sunlight in sun lounges or conservatories. If you are placing your refrigerator in
an out-building such as a garage or annex ensure that the refrigerator is placed above the
damp course, otherwise condensation will occur on the refrigerator cabinet.
Never place the refrigerator in a wall recess or into fitted cabinets or furniture. When your
refrigerator is working, the grill at the back may become hot and the sides warm. It must
therefore be installed so that there is at least 7cm (2 2/3”) of free space at the back, sides
and above the refrigerator
The refrigerator door can be fitted to open to either the right or the left, depending on its
location.
Levelling the Refrigerator
Once the refrigerator is sited in its final location, make sure it is level. To do this use the two levelling feet
at the front of the refrigerator. (If the refrigerator is not level, the doors and magnetic seal alignments will
be affected.)
Cleaning before use
Wipe the inside of the refrigerator with warm water using a soft cloth. Wipe completely dry before
replacing the shelves and baskets.
Before using your Refrigerator
Check that you have your power outlet is compatible with the plug supplied with the refrigerator. If not,
see the section called ELECTRICAL CONNECTION at the back of this booklet.
DO NOT SWITCH ON UNTIL TWO HOURS AFTER MOVING THE REFRIGERATOR to allow the coolant
fluid time to settle.
Before placing any food in your refrigerator, turn the refrigerator on and wait for 24 hours, to make sure
it is working properly and to allow the refrigerator to fall to the correct temperature.
Using Your Fridge
Switching on your refrigerator:
1) Before connecting the refrigerator to the mains supply make sure that the Temperature
Control located inside the refrigerator is set between 3and 4, which is the correct setting for
use in a room of average temperature.
2) Wait 24 hours before placing food in the cabinet to allow for the refrigerator to fall to the
correct temperature.
Adjusting the temperature
The internal temperature of your refrigerator is controlled by the Temperature Control. There are 6
settings. Position 6 makes the refrigerator coldest. Position 1 makes it the warmest. To adjust the
temperature, turn the Temperature Control to the preferred setting.
The temperature of the refrigerator is best maintained around 0°C to + 5°C. Avoid setting the
thermostat too high otherwise this may reduce the temperature to a point where certain fresh foods
may begin to freeze.
Noises inside the Refrigerator
If you have not owned a refrigerator before, you may notice that it makes some rather unusual noises.
Most of these are perfectly normal, but you should be aware of them!
GURGLING, WHOOSHING
These noises are caused by the circulation of the refrigerant liquid in the cooling system. It has become
more pronounced since the introduction of CFC free gases. This is not a fault and will not affect the
performance of your refrigerator.
HUMMING, PURRING OR PULSATING
This is the compressor motor working, as it pumps the refrigerant around the system.
Defrosting
After a period of time frost will build up in the icebox. Regular defrosting will therefore be necessary to
maintain the efficiency of the refrigerator. This should be carried out if the frost build up begins to
interfere with the food storage. Choose a time when the stock of frozen food is low and proceed as
follows:
1) Take out the frozen food, turn the refrigerator off at the mains supply and leave the door
open. Ideally the frozen food should be put into another refrigerator or refrigerator. If this is
not possible wrap the food, firstly in several sheets of newspaper or large towels and then a
thick rug or blanket and keep it in a cool place.
2) To speed up the defrosting process bowels of hot water can be placed inside the refrigerator
to raise the air temperature.
3) When all traces of ice have been removed and defrosting is completed, remove the tray to
empty any water and wipe dry
4) Clean your refrigerator as described below, plug in switch the refrigerator back on, allowing it
time to fall the correct temperature before replacing food.

Cleaning
Cleaning inside the Refrigerator
You should clean the refrigerator internally with warm water using a soft cloth. Wipe the refrigerator dry
before replacing the food. Plug in and switch on the mains supply.
Cleaning the outside of the Refrigerator
Use standard furniture polish to clean the refrigerator exterior. Make sure that the doors are closed, to
prevent polish getting on the magnetic door seal or inside. The grille of the condenser at the back of the
refrigerator and the adjacent components can be vacuumed using a soft brush attachment.
Cleaning tips
• Defrost and clean when food stocks are low.
