Marshalltown Company Shockwave Power Screed User manual

Marshalltown, I
A
P
hone 800-888-0127
/
641-753-0127
F
ax 800-477-6341
/
641-753-634
1
www
.
M
AR
S
HALLT
O
WN.
com
W
S5
7
0
/0%2!4)/.3-!.5!,
!.$0!243"//+

2;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com
TABLE OF CONTENTS
Common Components ...........................................3
AssemblyInstructions .........................................4-6
MachineAdjustments............................................7
PartsBreakdown .............................................8-9
Wet Screeding ................................................10
Form to Form Screeding ........................................11
Technical Data/Capacities .......................................12
Maintenance Schedule..........................................12
HowtoOperate ............................................13-14
Warranty.....................................................15
This machine was built with user safety in mind, however, it can present hazards if improperly operated and serviced. Follow
operating instructions carefully and use good judgement when operating!
If you have questions about operating or servicing this equipment, please contact your Marshalltown distributor or Marshalltown
Company at 800-888-0127 or 641-753-0127.

;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com 3
2
4
3
5
20
69
8
10
11
12 12
14
18
15
16
19
COMMON COMPONENTS
Start/Stop Switch 1.
Engine 2.
Recoil Starter 3.
Oil Cap 4.
Gas Cap 5.
Throttle Lever 6.
Handle Bar Mounting Blocks 7.
Handle Bars 8.
Adjustable Hand Grips 9.
Kickstand 10.
Drive Shaft 11.
Vibration Dampeners 12.
Blade 13.
Eccentric Weight Cover 14.
Frame 15.
Lifting Bar 16.
Tachometer/Hour Meter 17.
Board Mounting Plate 18.
Throttle Cable 19.
Air Filter 20.
1
7
17
13
ThePremier Line

4
;
VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.
com
ASS
EMBLY IN
S
TRU
C
TI
O
N
S
Your Shockwave™ Screed power unit ships in two boxes, one containing the
handle bars and the other containing the power uni
t
.
Assembly is easy,
f
ollowing these steps
:
I
N
S
TALLIN
G
HANDLE BAR
S
AND KI
C
K
S
TAND
:
S
te
p
1
–Remove the 4 hex screws
(
A
)
that hold down the two
h
an
dl
e mount
i
n
g
bl
oc
k
s.
S
tep 2 –
S
lide kickstand arm onto kickstand end and fasten
with nut & bolt (B) as show
n
S
te
p
4 – Makin
g
sure all mountin
g
block and
f
rame holes are
aligned, insert hex screws and tighten with 7/16" wrench or
s
o
c
k
e
t
.
Step 3 – Place handle bars into mounting blocks, making sure
handle bars are centered evenly across the mountin
g
blocks
.
A

;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com 5
INSTALLING THROTTLE CABLE:
Step 1 – Remove carburetor cover by pressing clips.
Step 4 – Attach the throttle lever to the “T” grip handle,
as shown above.
Step 3 – Fasten the throttle cable as shown. Make sure
there is a nut on each side of plastic fitting. Made sure the
cable does not work itself out of the plastic fitting
while tightening.
Step 2 – The throttle has a rotating silver peg (A) with a slot
on one side of it. One end of the throttle cable has a metal
barrel (B) that fits into this slot. Insert barrel into the slot so
when the throttle cable is pulled, it will pull the throttle open
(toward the base plate of the screed).
ASSEMBLY INSTRUCTIONS
A
B

6;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com
Step 7 – Secure throttle cable using clips,
as shown above.
Step 6 - Once cable is through throttle lever, return the
lever to the “idle” position shown above. Using pliers, pull
all extra slack out of the cable, making sure you are not
actually opening the throttle at the carburetor. Once all
slack is removed, tighten locking screw.
Note – the plastic housing of the throttle cable will fit up into
the throttle cable housing.
ATTACHING BLADE
Attach blade as shown,
making sure that blade
is positioned on the
“front side” of the base
extrusion.
Make sure bolts
are tight before
each use.
Step 5 – Thread the exposed metal end of the throttle cable
into the throttle lever. The lever will need to be “opened” to
expose the hole it fits into. Back out the set screw to allow
the cable to pass through.
ASSEMBLY INSTRUCTIONS
!

;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com 7
MACHINE ADJUSTMENTS
HANDLES
Your Shockwave™ screed has handles that can be
adjusted for a customized fit.
The grips can also be moved to accommodate wider
and narrower grips, as well as flipped to the inside of the
machine for an even narrower grip.
ECCENTRIC WEIGHTS
The factory weight set-
ting will provide sufficient
board vibration for most
jobs. For jobs where low
slump or dry concrete is
being poured, the weight
can easily be adjusted to
allow for more vibration at
lower RPM.
Using a slotted screw-
driver remove the
eccentric cover. Using a
7/16" socket, loosen the
eccentric weight tightening
bolt (A). You will need
to wedge a screwdriver
against the weight to keep
it from turning while
loosening bolt.
ADJUSTABLE
The height of the handle can be adjusted right
below the motor
ADJUSTABLE
;OLWP[JOVM[OLNYPWZJHUILHKQ\Z[LKá]LY[PJHSS`
DECREASE
INCREASE
Increase vibration, increase the gap between the weights
by spreading them apart.
Decrease vibration, decrease the gap between the
weights. If imbalance is increased then use less engine
RPM. Note: Always check and retighten the eccentric
weights every 10 hours of use.
CAUTION !!
Always make sure engine is stopped with switch in "OFF"
position before making adjustments.

8;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com
4
33
19
39
7
8
29
9
11
30
35
32
27
31
12
34
28
40
DET. QTY. DESCRIPTION
1 1 GX35 HONDA MOTOR
2 8 HANDLEBAR CLAMP
3 1 HANDLEBAR ASSEMBLY
4 1 BASE EXTRUSION
5 1 TACHOMETER
6 1 KILL SWITCH
7 4 VIBRATION ISOLATOR
8 1 ECCENTRIC WEIGHT #1
9 1 ECCENTRIC WEIGHT #2
10 1 ECCENTRIC SHAFT
11 1 ECCENTRIC WEIGHT BUSHING
12 1 WEIGHT ADJUSTMENT CAP
13 1 LOWER BEARING HOUSING
14 1 COUPLING DRIVE SHAFT
15 1 CLUTCH
16 1 FLEX SHAFT
17 1 HANDLEBARS, L-GRIP
18 1 HANDLEBARS, T-GRIP
19 2 BLADE ATTACHMENT NUT
20 1 BLADE
21 1 KICKSTAND END
22 1 KICKSTAND ARM
23 2 KICKSTAND EYEBOLT
24 1 KICKSTAND END CAP
25 1 SPRING
26 1 FRAME
27 1 ECCENTRIC COVER
28 1 ECCENTRIC COVER CAP
29 3 DRIVETRAIN BASE MOUNTING SCREW
30 1 ECCENTRIC WEIGHT JAM NUT
31 1 ECCENTRIC TIGHTENING CAP BOLT
32 2 BLADE ATTACHMENT BOLT
33 4 ECCENTRIC COVER MOUNTING SCREW
34 4 ECCENTRIC CAP SCREW
35 8 VIBRATION ISOLATOR NUT
36 4 WELD NUT FOR HANDLEBAR CLAMPS
37 2 TACHOMETER MOUNTING SCREW
38 2 TACHOMETER MOUNTING NUT
39 4 VIBRATION ISOLATOR NUT
40 2 BLADE ATTACHMENT LOCK WASHER
41 8 HANDLEBAR CLAMP BOLT
42 2 KICKSTAND NUT
43 2 KICKSTAND BOLT
44 1 REPLACEMENT DRIVESHAFT CORE (NOT PICTURED)
45 1 THROTTLE LEVER ( FRICTION STYLE)
46 4 ENGINE MOUNTING BOLTS
47 2 HANDLEBAR GRIPS
48 1 THROTTLE CABLE
49 1 KILL SWITCH WIRING
REPLACEMENT PARTS INDEX
EDI PART# DESCRIPTION DETAILS INCLUDED
13308 13308 HANDLES WITH GRIPS 17, 18, 47
13309 13309 GRIPS 47
13310 ENG-HONDA HONDA ENGINE 1, 46
13312 13312 THROTTLE LEVER 45
13313 13313 THROTTLE CABLE 48
13314 13314 HANDLEBARS 3
13315 13315 HANDLEBAR CLAMPS W/HARDWARE 2, 41
13316 13316 HANDLEBAR CLAMP HARDWARE ONLY 41
13317 13317 ON/OFF SWITCH W/WIRES 6, 49
13318 13318 ON/OFF SWITCH WIRES 49
13319 13319 TACHOMETER 5, 37, 38
13320 13320 ECCENTRIC COVER W/HARDWARE 27, 28, 33, 34
13321 13321 KICKSTAND 21, 22, 23, 24, 25, 42, 43
13322 13322 KICKSTAND HARDWARE 23, 25, 42, 43
13323 13323 DRIVE TRAIN 10, 13, 14, 16, 29, 44
13324 13324 CLUTCH 15, 46
13325 13325 VIBRATION DAMPENING KIT 7, 35, 39
13330 13330 ECCENTRIC WEIGHTS & HARDWARE 8, 9, 11, 12, 30, 31
13331 13331 ECCENTRIC WEIGHT HARDWARE ONLY 11, 12, 30, 31
13332 13332 MACHINE BASE 4
13333 13333 BLADE LOCKING HARDWARE 19, 32, 40
13334 13334 DRIVE SHAFT 44
13335 13335 DRIVE SHAFT HOUSING 10, 13, 14, 16
12951 12951 FRAME ONLY 26
12952 12952 ECCENTRIC COVER HARDWARE ONLY 33, 34
PARTS BREAKDOWN

;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com 9
A
16
46
44
20
45
3
1
17
5
22
24
47
47
2
23
43
26
48
17
18
2
2
15
21
10
13
14
33
25
37
38
41
36
42
49
6
PARTS BREAKDOWN
BLADE SIZE CHART
EDI Part # SIZE-FT. SIZE-M
13336 SWSBLADE4 4 1.2
13281 SWSBLADE6 6 1.8
13283 SWSBLADE8 8 2.4
13284 SWSBLADE10 10 3.0
13287 SWSBLADE12 12 3.7
13290 SWSBLADE14 14 4.3
13291 SWSBLADE16 16 4.9
12950 SWSBLADE16P2 16 (2 sets of mounting holes) 4.9

10 ;VVYKLY!7OVUL!-H_!=PZP[V\Y>LIZP[LH[^^^MARSHALLTOWN.com
SETTING ELEVATION OF SLAB
Use grade pins (A) to set height of slabs
in the middle of the pour.
Chalk line or expansion joint setss
elevation around walls.
Form boards set elevation wheres
there are no walls.
MAKING WET PADS
Using hand float, make wet pads around all grade1.
pins (A).
Note: Make sure all wet pad distances
are shorter than the length of board
being used.
Use board to stretch from wet pad to wet pad form-2.
ing rows (B).
Once rows are formed, run screed board off of the3.
two rows leveling the previously untouched con-
crete (C) in between.
NOTE: Height of concrete in area (C)
must be slightly higher than wet
pad rows (B) prior to striking off.
Once floated, wet pads (B) and concrete (C) will all be the
same height
1Blade Length
12-18 inches
2
3
HOW TO WET SCREED
12-18 in.
