MULTIQUIP hhn34tvdtcsl4 User manual

OperatiOn Manual
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
SerieS
MODel hhn34tvDtcSl4
MODel hhn34tvDtcSl5
riDe-On trOwel
(vanGuarD DM 954 DieSel enGine)
Revision #2 (01/10/11)
pn: 21729

PAGE 2 — HHN34TVD RIDE-ON TROWEL • OPERATION MANUAL — REV. #2 (01/10/11)
prOpOSitiOn 65 warninG
Engine exhaust and some of
its constituents, and some dust created
of California to cause cancer, birth
defects and other reproductive harm.
by power sanding, sawing, grinding,
drillingandotherconstructionactivities
contains chemicals known to the State
Some examples of these chemicals are:
Leadfromlead-basedpaints.
Crystallinesilicafrombricks.
Cementandothermasonryproducts.
Arsenicandchromiumfromchemically
treatedlumber.
Your risk from these exposures varies,
dependingonhowoftenyoudothis type
of work. To reduce your exposure to
these chemicals: work in aALWAYS
well ventilated area, and work with
approved safety equipment, such as
dust masks that are specially designed
to filter out microscopic particles.

HHN34TVD RIDE-ON TROWEL • OPERATION MANUAL — REV. #2 (01/10/11) — PAGE 3
Grinding/cutting/drilling of masonry, concrete, metal and
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis. In addition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentioned above.
WARNING
Grinding/cutting/drilling of masonry, concrete, metal and
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity, or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations. Water should be used for dust
suppression when wet cutting is feasible. When the
hazards from inhalation of dust, mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHA for
the materials being used.
WARNING
SILICOSIS WARNING RESPIRATORY HAZARDS
SilicOSiS/reSpiratOry warninGS

PAGE 4 — HHN34TVD RIDE-ON TROWEL • OPERATION MANUAL — REV. #2 (01/10/11)
table Of cOntentS
hhn34tvD riDe-On
trOwel
Proposition 65 Warning ........................................... 2
Silicosis/Respiratory Warnings ................................ 3
Table Of Contents .................................................... 4
Training Checklist ..................................................... 6
Daily Pre-Operation Checklist ................................. 7
Safety Information .............................................. 8-13
Specifications (Trowel) ........................................... 14
Specifications (Engine) .......................................... 15
General Information ............................................... 16
Components ..................................................... 18-19
New Machine Setup .............................................. 20
Basic Engine .......................................................... 21
Inspection .............................................................. 22
Operation .......................................................... 23-24
Maintenance ..................................................... 25-41
Maintenance (Old Style Clutch) ...................... 28-32
Maintenance (New Style Clutch) .................... 33-35
Troubleshooting ................................................ 42-43
NOTICE
Specifications are subject to change without notice.

HHN34TVD RIDE-ON TROWEL • OPERATION MANUAL — REV. #2 (01/10/11) — PAGE 5
nOteS
