Martin Audio Two-way Passive System Screen 2P User manual

Screen 2P
Tw o -way passive system
features
!Tw o -way passive design
!Very shallow profile
!High SPL
!Low distortion
applications
!Behind screen placement
!For rooms up to 150 seats
Century Point, Halifax Road, Cressex Business Park,
High Wycombe, Buckinghamshire HP12 3SL, England.
Telephone: [phone] Facsimile: [phone]
E-mail: [email protected]
All information is Copyright © 2003 Martin Audio Ltd.
The Screen 2P Cinema system has been developed to
accommodate the various digital formats of modern films,
providing the essentials of low distortion, wide bandwidth, with
uniform coverage for the smaller room. This makes the Screen
2P ideally suited for small cinemas, preview theatres, screening
rooms and post production suites.
A 1.2kHz internal passive crossover network ensures smooth
transition between the LF and HF sections.
cinema
www.martin-audio.com
overall dimensions
technical specifications
TYPE Two-way passive screen system
DRIVERS 1 x 15" (380mm) low frequency
1 x 1" (25mm) exit HF compression driver
FREQUENCY RESPONSE (1) 45Hz-20kHz ±3dB
RATED POWER (2) 400W AES, 1600W peak
SENSITIVITY (3) 98dB
CROSSOVER 1.2kHz passive
IMPEDANCE 8 ohms
DISPERSION (-6dB) 90˚ horizontal, 90˚ vertical
DIMENSIONS LF: (W) 650mm x (H) 765mm x (D) 307mm
(W) 26ins x (H) 30ins x (D) 12ins
HF: (W) 285mm x (H) 344mm x (D) 185mm
(W) 11.2ins x (H) 13.5ins x (D) 7.3ins
INSTALLED DIMENSIONS (W) 650mm x (H) 1080mm x (D) 350mm
(W) 26ins x (H) 42.5ins x (D) 13.8ins
WEIGHT LF: 40kg (88.2lbs)
HF: 4.5kg (9.9lbs)
