Maytag MLG20PDCGW User manual

INSTALLATION
INSTRUCTIONS
CommerCial StaCked
WaSher/dryer
GaS or eleCtriC
INSTRUCTIONS
D’INSTALLATION
lave-linGe/SèChe-linGe SuperpoSéS
àuSaGe CommerCial
à Gaz ou éleCtrique
INSTRUCCIONES
DE INSTALACIÓN
lavadora/SeCadora ComerCialeS
apiladaS a GaS oeléCtriCaS
ISTRUZIONI
D’INSTALLAZIONE
lavatriCe/aSCiuGatriCe
CommerCiale aColonna
a GaS oelettriCa
www.maytagcommerciallaundry.com
W10335466C
MLE20PD
MLG20PD
MLE20PN

2
TABLE OF CONTENTS
(Australia and New Zealand Installations)
Page
Stacked Washer/Dryer Safety.................................................................. 3
Stacked Washer/Dryer Disposal............................................................. 6
Tools & Parts ..................................................................................................... 7
Alternate Parts and Accessories............................................................. 8
Dimensions/Clearances ............................................................................. 9
Stacked Washer/Gas Dryer Installation Requirements .......... 10
Stacked Washer/Electric Dryer
Installation Requirements ....................................................................... 13
Dryer Venting Requirements ................................................................. 15
Dryer Gas Supply Requirements ......................................................... 17
Installing Stacked Washer/Dryer......................................................... 18
Washer Drain System ................................................................................ 21
Leveling ............................................................................................................. 22
Complete Installation ................................................................................. 23
Reversing Dryer Door Swing .................................................................. 24
Stacked Washer/Dryer Maintenance Instructions ...................... 26
If You Need Assistance ............................................................................. 27
Technical Specifications – Gas Dryer ................................................ 28
Electronic Control Setup Instructions ............................................... 29
Warranty ........................................................................................................... 35
TABLE DES MATIÈRES
Page
Sécurité du lave-linge/sèche-linge superposés........................... 36
Élimination du lave-linge/sèche-linge superposés..................... 39
Outils et pièces .............................................................................................. 40
Pièces supplémentaires et accessoires ........................................... 41
Dimensions/Distances de dégagement ........................................... 42
Exigences d’installation pour
le lave-linge/sèche-linge à gaz superposés ................................... 43
Exigences d’installation pour le lave-linge/sèche-linge
électriques superposés ............................................................................ 46
Exigences concernant l’évacuation du sèche-linge .................... 48
Spécifications de l’alimentation en gaz du sèche-linge ........... 51
Installation du lave-linge/sèche-linge superposés .................... 52
Système d’évacuation du lave-linge .................................................... 55
Nivellement .......................................................................................................56
Achever l’installation ....................................................................................57
Inversion du sens d’ouverture de la porte du sèche-linge ......58
Instructions d’entretien du lave-linge/
sèche-linge superposés ...........................................................................60
Si vous avez besoin d’assistance .........................................................61
Fiche technique – sèche-linge à gaz .................................................. 62
Instructions de réglage du tableau
de commande électronique ..................................................................... 63
Garantie .............................................................................................................. 70
ÍNDICE
Página
Seguridad de la lavadora/secadora apiladas................................. 71
Eliminación de la lavadora/secadora apiladas .............................. 74
Herramientas y piezas................................................................................. 75
Piezas y accesorios adicionales ........................................................... 76
Dimensiones y espacios libres .............................................................. 77
Requisitos de instalación de la lavadora/secadora
a gas apiladas ................................................................................................. 78
Requisitos de instalación de la lavadora/
secadora eléctricas apiladas .................................................................. 81
Requisitos de ventilación de la secadora ........................................ 83
Requisitos del suministro de gas de la secadora ....................... 86
Instalación de la lavadora/secadora apiladas................................ 87
Sistema de desagüe de la lavadora..................................................... 90
Nivelación ...........................................................................................................91
Complete la instalación ............................................................................. 92
Cómo invertir el cierre de la puerta de la secadora ....................93
Instrucciones de mantenimiento
de la lavadora/secadora apiladas .........................................................95
Si necesita ayuda ...........................................................................................96
Especificaciones técnicas – secadora a gas ................................. 97
Instrucciones de programación del control electrónico ........... 98
Garantía ........................................................................................................... 105
INDICE
Pagina
Sicurezza della lavatrice/asciugatrice impilati........................... 106
L’eliminazione della lavatrice/asciugatrice impilati.................. 109
Attrezzi e componenti ............................................................................. 110
Parti ed accessori alternati.................................................................... 111
Dimensioni/spazi ...................................................................................... 112
Requisiti dell’installazione della lavatrice/asciugatrice
a gas impilati ............................................................................................... 113
Requisiti dell’installazione della lavatrice/asciugatrice
elettrica impilat ........................................................................................... 116
Requisiti di scarico dell’asciugatrice .............................................. 118
Requisiti di alimentazione del gas dell’asciugatrice .............. 120
Installazione della lavatrice/asciugatrice impilati..................... 121
Sistema dello scolo della lavatrice .................................................. 124
Livellamento ................................................................................................. 125
Completamento dell’installazione ................................................... 126
Inversione della rotazione di apertura dell’asciugatrice ...... 127
Istruzioni di manutenzione della lavatrice/
asciugatrice impilat.................................................................................... 129
Se avete bisogno dell’assistenza ..................................................... 130
Dati tecnici – asciugatrice a gas ....................................................... 131
Configurazione dei controlli elettronici ......................................... 132
Garanzia ......................................................................................................... 139

3
STACKED WASHER/DRYER SAFETY
nIt is recommended that the owner post, in a prominent location, instructions for the customer’s use in the event the customer
smells gas. This information should be obtained from your gas supplier.
nPost the following warning in a prominent location.
FOR YOUR SAFETY
1. DO NOT USE OR STORE PETROL OR OTHER FLAMMABLE MATERIALS IN THIS APPLIANCE OR NEAR THIS APPLIANCE.
2. DO NOT SPRAY AEROSOLS IN THE VICINITY OF THIS APPLIANCE WHILE IT IS IN OPERATION.
3. DO NOT MODIFY THIS APPLIANCE.

4
STACKED WASHER/DRYER SAFETY

5
STACKED WASHER/DRYER SAFETY
nIf drum rotation is blocked due to trapped textiles,
disconnect the dryer from the electrical supply before gently
removing the blockage.
nIf the dryer is not heating, or appears to be defective or
damaged, do not use it. Contact the owner.
nDo not install or store the washer/dryer where it will be
exposed to the weather.
nDo not tamper with controls.
nClean dryer lint screen before or after each load.
nDo not use this dryer without the lint screen in place.
nUnder certain conditions, hydrogen gas may be produced
in a hot water system that has not been used for 2 weeks
or more. HYDROGEN GAS IS EXPLOSIVE. If the hot water
system has not been used for such a period, before using
the washer, turn on all hot water faucets and let the water
flow from each for several minutes. This will release any
accumulated hydrogen gas. As the gas is flammable, do not
smoke or use an open flame during this time.
nDo not repair or replace any part of the washer/dryer or
attempt any servicing unless specifically recommended
in this Use and Care Guide or in published user-repair
instructions that you understand and have the skills to
carry out.
nDo not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric
softener or product.
nDo not use heat to dry articles containing foam rubber
or similarly textured rubber-like materials.
nThe final part of a tumble dryer cycle occurs without heat
(cool-down cycle) to ensure that the articles are left at a
temperature that ensures that the items will not be damaged.
nWARNING: Never stop a tumble dryer before the end
of the drying cycle unless all items are quickly removed and
spread out so that the heat is dissipated. (Avoids risk of
spontaneous combustion).
nIn case of electrical supply failure, remove the load quickly
and spread it out to avoid risk of spontaneous combustion.
nKeep area around the exhaust opening and adjacent
surrounding areas free from the accumulation of lint, dust,
and dirt.
nThe fresh air ventilation openings into the room and into
the dryer must not be blocked or sealed.
nEmergency stop control: The mains plug should be removed
in an emergency.
nThe interior of the dryer and dryer exhaust vent should be
cleaned periodically by qualified service personnel.
nSee “Electrical Requirements” section of the Installation
Instructions booklet for grounding instructions.
IMPORTANT SAFETY INSTRUCTIONS
WARNING: To reduce the risk of fire, electric shock, or injury to persons when using the washer/dryer, follow basic precautions,
including the following:
SAVE THESE INSTRUCTIONS
nRead all instructions before using the washer/dryer.
nThis dryer is intended only for drying clothes and textiles
that have been washed in water. Do not use for any other
purpose.
nWARNING: If you smell gas, do not use the dryer or any
electrical equipment nearby. Warn other people to clear the
area. Contact the dryer owner immediately.
nDo not place items exposed to cooking oils in your dryer.
Items contaminated with cooking oils may contribute to
a chemical reaction that could cause a load to catch fire.
nIf it is unavoidable that fabrics that contain vegetable or
cooking oil or that have been contaminated by hair care
products be placed in a tumble dryer, they should first be
washed in hot water with extra detergent – this will reduce,
but not eliminate the hazard.
nDo not wash or dry articles that have been previously
cleaned in, washed in, soaked in, or spotted with petrol,
dry-cleaning solvents, other flammable, or explosive
substances as they give off vapors that could ignite or
explode.
nItems that have been soiled with substances such
as acetone, alcohol, petrol, kerosene, spot removers,
turpentine, waxes, and wax removers should be washed
in hot water with extra detergent before being dried in
the dryer.
nDo not add gasoline, dry-cleaning solvents, or other
flammable, or explosive substances to the wash water.
These substances give off vapors that could ignite or
explode.
nDo not dry unwashed items in the dryer.
nDo not use this dryer if industrial chemicals have been used
for cleaning. The possible presence of residual quantities
of aggressive or decomposed chemicals in the load may
produce damage to the dryer and harmful fumes.
nDo not allow children to play on or in the washer/dryer.
Close supervision of children is necessary when the
washer/dryer is used near children.
nThis dryer is not intended for use by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience or knowledge, unless they
have been given supervision or instruction concerning use
of the dryer by a person responsible for their safety.
nBefore the washer/dryer is removed from service
or discarded, remove the doors to the washer/dryer
compartments.
nDo not reach into the washer/dryer if the tub, agitator
or drum is moving.
nDo not open door while dryer is in operation. It will stop.
nWhen loading or re-loading the dryer, avoid touching hot
metal parts of the drum (burn risk).

6
STACKED WASHER/DRYER DISPOSAL
MODEL NOMENCLATURE:
MLE – Maytag Electric PD – Electronic Control – Coin Drop Enabled
MLG – Maytag Gas PN – Electronic Control – Non-Pay
20 – Model Type Number
EU - DECLARATION OF CONFORMITY
CE - DECLARATION DE CONFORMITE
We BAUKNECHT HAUSGERÄTE GmbH, D-73614 Schorndorf
representing WHIRLPOOL EUROPE S.r.l I-21025 COMERIO
declare under our sole responsibility that the product
Commercial stacked pair MAYTAG MLE 20PD
washer / dryer MAYTAG MLE 20PN
to which this declaration relates is in conformity with the following standard(s) or other
normative document(s)
EN 60335-1:2002+A1+A2+A11+A12+A13+A14+A15
EN 60335-2-7:2010
EN 60335-2-11:2010
EN 62233:2008
EN 61770:1999+A1:2004+A2:2006
EN ISO 10472-1:2008
EN ISO 10472-2:2008
EN ISO 14121-1:2007
EN 55014-1:2006+A1:2009
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-11:2000
following the provisions of Directive(s):
2006/42/EC MACHINERY DIRECTIVE
2004/108/EC ELECTROMAGNETIC COMPATIBILITY DIRECTIVE
2011/65/EU ROHS DIRECTIVE
2002/96/EC WEEE DIRECTIVE
represented by
Schorndorf, 28.02.2012 Micael Zirondi Karl-Dieter Klingenstein
Place and date: Director PDC FC EMEA Product Approval
GPO, Schorndorf
Name and signature of aurthorised person
Nom et signature de la personne autorisée
EU - DECLARATION OF CONFORMITY
CE - DECLARATION DE CONFORMITE
We BAUKNECHT HAUSGERÄTE GmbH, D-73614 Schorndorf
representing WHIRLPOOL EUROPE S.r.l I-21025 COMERIO
declare under our sole responsibility that the product
Commercial gas dryer MAYTAG MLG 20PD
to which this declaration relates is in conformity with the following standard(s) or other
normative document(s)
EN 60335-1:2002+A1+A2+A11+A12+A13 (+A14+A15 only electrical part)
EN 60335-2-11:2010
EN 60335-2-102:2006+A1
EN 62233:2008
EN 12752-1:1999
EN ISO 10472-1:2008
EN ISO 10472-4:2008
EN ISO 14121-1:2007
EN 55014-1:2006+A1:2009
EN 55014-2:1997+A1:2001+A2:2008
EN 61000-3-2:2006+A1:2009+A2:2009
EN 61000-3-11:2000
following the provisions of Directive(s):
2006/42/EC MACHINERY DIRECTIVE
2009/142/EC EUROPEAN GAS APPLIANCE DIRECTIVE
2004/108/EC ELECTROMAGNETIC COMPATIBILITY DIRECTIVE
2011/65/EU ROHS DIRECTIVE
2002/96/EC WEEE DIRECTIVE
represented by
Schorndorf, 19.04.2012 Micael Zirondi Karl-Dieter Klingenstein
Place and date: Director PDC FC EMEA Product Approval
GPO, Schorndorf
Name and signature of aurthorised person
Nom et signature de la personne autorisée

7
Parts Supplied:
Water Inlet Hoses (2) Inlet Hose Washers (4) U-Shaped Hose Form Transit Bolt Hole Plug (4)
Beaded Tie Strap
Drain Hose/Clamp
Tools Needed:
203 mm (8") 203 mm (8") or 254 mm (10") Flat-Blade Screwdriver Phillips Screwdriver
or 254 mm (10") Adjustable Wrench
Pipe Wrench that opens to 25 mm (1")
Torx®† T-20 Security 25 mm (1") Hex-Head 8 mm (5/16") Socket Wrench Pliers
Screwdriver or Bit Socket Wrench (that open to 39 mm [19/16"])
Level Utility Knife 6 mm (1/4") Nut Driver Locking Pliers
Caulk Gun and Caulk Vent Clamps Pipe-Joint Compound 686 mm (27") Wood Block
(for installing new exhaust vent) suitable for gas type
Flashlight (optional) 13 mm (1/2") and 14 mm Ruler or Measuring Tape
(9/16") Open-End Wrenches
TOOLS & PARTS
†® TORX is a registered trademark of Saturn Fasteners, Inc.

8
ALTERNATE PARTS AND ACCESSORIES
Alternate Parts
Your installation may require additional parts. If you are interested
in purchasing one of the items listed here, call the toll-free number
in the “If You Need Assistance” section.
If You Have You Will Need to Buy
Overhead sewer Standard 76 L (20 gal.) 990 mm
(39") tall drain tub or utility sink, sump
pump and connectors (available from
local plumbing suppliers)
25 mm (1") standpipe 51 mm (2") diameter to 25 mm (1")
diameter Standpipe Adapter
Part Number 3363920
Connector Kit Part Number 285835
Drain hose too Extension Drain Hose Part
short Number 285863
Connector Kit Part Number 285835
Lint clogged drain Drain Protector Part Number 367031
Connector Kit Part Number 285835
Floor drain system Siphon break, Part Number 285834
Connector Kit (x2) Part Number
285835
Extension Drain Hose Part
Number 285863
Water faucets 2 longer water fill hoses:
beyond reach 1.8 m (6 ft.) 90° bend hose
of fill hoses Part Number 76314
3.0 m (10 ft.) Part Number 350008
Accessories
Enhance your washer/dryer with these premium accessories.
For more high-quality items or to order, contact your authorized
Maytag distributor.
Part Number Accessory
8212526 Washer drip tray, fits under all
31682 All-purpose appliance cleaner
1903WH Laundry supply storage cart
279818 3-way dryer venting kit
285834 Siphon break kit

9
DIMENSIONS/CLEARANCES
Front View Side View Back View
Dimensions
Clearances
Side Clearances Back/Top Clearances

10
Selecting the proper location for your washer/dryer improves
performance and minimizes noise and possible washer “walk.”
Your washer/dryer can be installed in a basement, laundry room,
or recessed area. See “Drain System.”
Companion appliance location requirements should also be
considered.
IMPORTANT: Do not install or store the washer/dryer where it will
be exposed to the weather. Do not store or operate the washer/
dryer in temperatures at or below 0°C (32°F). Some water can
remain in the washer and can cause damage in low temperatures.
Proper installation is your responsibility.
You will need:
nA water heater set to deliver 49°C (120°F) water to the washer.
nA grounded electrical outlet located within 1.8 m (6 ft.) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
nHot and cold water faucets located within 1.2 m (4 ft.)
of the hot and cold water fill valves, and water pressure
of 137.9–689.6 kPa (20–100 psi).
nA level floor with a maximum slope of 25 mm (1") under
entire washer/dryer. Installing the washer/dryer on soft floor
surfaces, such as carpets or surfaces with foam backing, is not
recommended.
nA sturdy and solid floor to support the washer/dryer with a total
weight (water and load) of 204 kg (450 lbs).
nA floor drain under the bulkhead. Prefabricated bulkheads with
electrical outlets, water inlet lines, and drain facilities should be
used only where local codes permit.
Stacked Washer/Gas Dryer Location
STACKED WASHER/GAS DRYER INSTALLATION REQUIREMENTS
(Australia and New Zealand – for full details of installation requirements refer to AS/NZS 5601.1 – Gas Installations)
Stacked washer/gas dryer installation clearances
nThe location must be large enough to allow the washer and dryer
doors to be fully opened.
nAdditional spacing should be considered for ease of installation
and servicing. The doors open more than 180°. The washer door
is not reversible.
nAdditional clearances might be required for wall, door, and floor
moldings.
nAdditional spacing of 25 mm (1") on all sides of the washer/dryer
is recommended to reduce noise transfer.
nCompanion appliance spacing should also be considered.
When installing a gas dryer:
IMPORTANT: Observe all governing codes and ordinances.
nCheck code requirements: Some codes limit or do not permit
installation of clothes dryers in garages, closets, or sleeping
quarters. Contact your local building inspector.
NOTE: For installation in Australia and New Zealand, install
dryer in accordance with AS/NZS 5601.1 and local governance
codes.
nMake sure that lower edges of the cabinet, plus the back and
bottom sides of the washer, are free of obstructions to permit
adequate clearance of air openings for combustion air. See
“Recessed Area and Closet Installation Instructions” below for
minimum spacing requirements.
nDo not install on carpet.
Recessed Area and Closet Installation Instructions
This washer/dryer may be installed in a recessed area or closet.
This washer/dryer must not be installed behind a lockable door,
a sliding door, or a door with a hinge on the opposite side to that
of the washer/dryer. For recessed area and closet installations,
minimum clearances can be found on the warning label on the rear
of the dryer or in “Dimensions/Clearances.”
The installation spacing is in millimeters and is the minimum
allowable. Additional spacing should be considered for ease
of installation, servicing, and compliance with local codes
and ordinances.
If closet door is installed, the minimum unobstructed air opening in
the top and bottom is required. Louvered doors with equivalent air
openings are acceptable.
The dryer must be exhausted outdoors.
No other fuel-burning appliance may be installed in the same closet
as the washer/dryer.
NOTE: For installation in Australia and New Zealand, refer to
AS/NZS 5601.1 for ventilation requirements.

11
STACKED WASHER/GAS DRYER INSTALLATION
REQUIREMENTS
Stacked Washer/Gas Dryer Electrical Requirements
EARTHING INSTRUCTIONS
SAVE THESE INSTRUCTIONS
IMPORTANT: Observe all governing codes and ordinances.
You will need an earthed electrical outlet located within 610 mm
(2 feet) of either side of the washer/dryer.
This washer/dryer is supplied/fitted with an electrical supply cord
and plug. It should be connected to electrical supply socket at
the voltage shown on the rating plate. The minimum supply fuse
capacity should be 5A. The washer/dryer must be positioned so
that the plug is clearly visible and accessible. This plug also provides
the function of an emergency stop control for the user. If the fitted
plug is not used, the electrical connection must be carried out by a
competent electrician in accordance with local or national codes.
If the supply cord is damaged, it must be replaced with a specially
terminated cord by an authorized service agent or a similarly
competent person in order to avoid a hazard.
Do not use an adapter.
Do not use an extension cord.
NOTE: In accordance with the European EMC Directive
(2004/108/EC), the maximum electricity supply system impedance
to which the gas dryer should be connected is declared to be 0.054
Ohm + j0.034 Ohm.
NOTE: Electrical safety standards: The manufacturer has chosen
compliance with IEC/EN.60335 standards as the most appropriate
for this product.
If codes permit and an additional earth bond wire is used, it is
recommended that a qualified electrician determine that the earth
bond path is adequate.
Using the universal cord included with this dryer:
The gas dryer is equipped with a universal cord with
interchangeable plugs.
1. To use the universal cord, select the plug end that fits your
electrical outlet, and plug it into the adapter on the supply cord.
2. Secure the plug end in place on the cord by aligning the 2 cover
halves over the cord adapter and clipping them together.

12
STACKED WASHER/GAS DRYER INSTALLATION
REQUIREMENTS
Stacked Washer/Gas Dryer Gas Supply Requirements
IMPORTANT: Observe all governing codes and ordinances.
In Australia and New Zealand, refer to AS/NZS 5601.1 – Gas
Installations.
Gas Supply
Before installation, check that the local gas distribution conditions,
nature of gas and pressure, and the adjustment of the appliance
are compatible. Burner information will be found on the model/
serial rating plate in the door recess of the dryer. If this information
does not agree with the type of gas available, see your dealer.
Natural Gas:
This dryer is factory adjusted for use with NATURAL GAS (G20),
and no further adjustment should be required at installation.
L.P. Gas:
This dryer is also certified for use with L.P. (propane or butane)
gases with appropriate conversion. No attempt shall be made to
convert the appliance from the gas specified on the model/serial
rating plate for use with a different gas without consulting the
serving gas supplier.
Conversion must be done by a competent service technician. Gas
conversion kit (European Country), part number W10233219,
is available for purchase from your dealer. Gas conversion kit
(Australia), part number W10315369, is available for purchase
from your dealer. Full instructions are supplied with the kit.
Natural gas (France/Belgium):
This dryer is also certified for France/Belgium for use with G20/
G25 gases (20 mbar/25 mbar) with appropriate conversion.
No attempt should be made to convert this appliance from the
gas specified on the gas rating label for use with a different gas
without consulting the serving gas supplier. Gas conversion must
be done by a qualified gas service technician. Conversion kit, part
number (W10181947) is available for purchase from your dealer.
Full instructions are supplied with the kit.
Supply line requirements:
Provide a rigid gas supply line to the washer/dryer location. It
should be minimum 12.5 mm (1/2") ID. When acceptable to the
gas supplier and local codes, 10 mm (3/8") ID rigid supply line
may be used for lengths under 6.1 m (20'). Pipe-joint compounds
resistant to the action of L.P. gas must be used.
NOTE: For installation in Australia and New Zealand, refer to
AS/NZS 5601 for pipe sizing details. All piping is to be in
accordance with AS/NZS 5601.1 – Gas Installations.
Gas connection to the dryer itself should be made by means
of a flexible gas hose suitable for the appliance and gas category
in accordance with national installation regulations. If in doubt,
contact the gas supplier. It should be minimum 10 mm (3/8") ID.
A means of restraint should be used between the washer/dryer
and the wall to avoid straining of the rigid gas supply when the
washer/dryer is moved. An appropriate length of chain and a wall
hook is recommended.
The dryer gas inlet connection is a 3/8" NPT thread. An adapter is
supplied for conversion to standard ISO.228-1 thread (3/8" BSP).
Check for leaks by using an approved noncorrosive leak-detection
solution. Bubbles will show a leak. Correct any leak found. A
pressure measurement tapping is provided on the gas valve within
the dryer, accessible after removal of the lower front panel.
The dryer must be disconnected from the gas supply piping
system during any pressure testing of that system.

13
NOTE: In Australia and New Zealand, refer to AS/NZS 5601.1 –
Gas Installations.
Selecting the proper location for your washer/dryer improves
performance and minimizes noise and possible washer “walk.”
Your washer/dryer can be installed in a basement, laundry room, or
recessed area. See “Drain System.”
Companion appliance location requirements should also be
considered.
IMPORTANT: Do not install or store the washer/dryer where it will
be exposed to the weather. Do not store or operate the washer/
dryer in temperatures at or below 0°C (32°F). Some water can
remain in the washer and can cause damage in low temperatures.
Proper installation is your responsibility.
You will need:
nA water heater set to deliver 49°C (120°F) water to the washer.
nA grounded electrical outlet located within 1.8 m (6 ft.) of
where the power cord is attached to the back of the washer.
See “Electrical Requirements.”
nHot and cold water faucets located within 1.2 m (4 ft.)
of the hot and cold water fill valves, and water pressure
of 137.9–689.6 kPa (20–100 psi).
nA level floor with a maximum slope of 25 mm (1") under
entire washer/dryer. Installing the washer/dryer on soft floor
surfaces, such as carpets or surfaces with foam backing, is not
recommended.
nA sturdy and solid floor to support the washer/dryer with a total
weight (water and load) of 204 kg (450 lbs).
nA floor drain under the bulkhead. Prefabricated bulkheads with
electrical outlets, water inlet lines, and drain facilities should be
used only where local codes permit.
Stacked Washer/Electric Dryer Location
STACKED WASHER/ELECTRIC DRYER INSTALLATION
REQUIREMENTS
Stacked washer/electric dryer installation clearances
nThe location must be large enough to allow the washer
and dryer doors to be fully opened.
nAdditional spacing should be considered for ease of installation
and servicing. The doors open more than 180°. The washer door
is not reversible.
nAdditional clearances might be required for wall, door, and floor
moldings.
nAdditional spacing of 25 mm (1") on all sides of the washer/dryer
is recommended to reduce noise transfer.
nCompanion appliance spacing should also be considered.
Recessed Area and Closet Installation Instructions
This washer/dryer may be installed in a recessed area or closet.
This washer/dryer must not be installed behind a lockable door,
a sliding door, or a door with a hinge on the opposite side to that
of the washer/dryer. For recessed area and closet installations,
minimum clearances can be found on the warning label on the rear
of the dryer or in “Dimensions/Clearances.”
The installation spacing is in millimeters and is the minimum
allowable. Additional spacing should be considered for ease
of installation, servicing, and compliance with local codes and
ordinances.
If closet door is installed, the minimum unobstructed air opening in
the top and bottom is required. Louvered doors with equivalent air
openings are acceptable.
The dryer must be exhausted outdoors.
No other fuel-burning appliance may be installed in the same closet
as the washer/dryer.

14
STACKED WASHER/ELECTRIC DRYER INSTALLATION
REQUIREMENTS
Stacked Washer/Electric Dryer Electrical
Requirements
This is 3-wire appliance which must be earthed.
This washer/dryer is supplied without an electric cord and plug. It
must be connected by a competent electrician to a single-phase
electricity supply at the voltage shown on the dataplate, using
a suitable fixed wiring installation in accordance with local and
national wiring regulations.
nA 3-wire circular cord of minimum conductor size 2.5 mm2
cross-section area should be used.
nA 30A supply fuse should be used, and a switch having
a contact separation in both poles that provides full
disconnection under over-voltage category III conditions must
be incorporated into the fixed wiring in accordance with local
wiring regulations. The washer/dryer should be positioned
so that the disconnection switch is clearly visible and easily
accessible to the user. This disconnection switch also provides
the function of an emergency stop control for the user.
nA cord clamp bush is provided on the washer/dryer, and
should be tightened on completion of wiring. The electrical
mains terminals are located behind the small rear access panel
(terminal block cover), and connections should be made in
accordance with the terminal markings. Remember to replace
the terminal access panel (terminal block cover).
NOTE: In accordance with the European EMC Directive
(2004/108/EC), the maximum electrical supply system impedance
to which the electric dryer should be connected is declared to be
0.054 Ohm + j0.034 Ohm.
NOTE: Electrical safety standards: The manufacturer has
chosen compliance with IEC/EN.60335 standards as the most
appropriate for this product.
If codes permit and an additional earth bond wire is used, it is
recommended that a qualified electrician determine that the earth
bond path is adequate.
Recommended Earthing Method
It is your responsibility to contact a qualified electrical installer
to ensure that the electrical installation is adequate and in
conformance with all local codes and ordinances.

15
DRYER VENTING REQUIREMENTS
WARNING: To reduce the risk of fire, this dryer MUST BE
EXHAUSTED OUTDOORS.
IMPORTANT: Observe all governing codes and ordinances.
In Australia and New Zealand, refer to AS/NZS 5601.1 – Gas
Installations.
■Following these venting requirements will minimise ducting air
noise.
■Adequate ventilation has to be provided to avoid the backflow
of gases into the room from appliances burning other fuels,
including open fires (i.e. available airflow into the room should
match airflow out from the room).
■Dryer exhaust must not be connected into any gas vent,
chimney, wall, ceiling, attic, crawlspace, or a concealed space
of a building. Only rigid or flexible metal vent shall be used for
exhausting.
■Do not use an exhaust hood with a magnetic latch.
■Only a 4" (102 mm) heavy, metal exhaust vent and clamps may
be used.
■Do not use plastic or metal foil vent.
Rigid metal vent:
■Recommended for best drying performance and to avoid
crushing and kinking.
Flexible metal vent: (Acceptable only if accessible to clean)
■Must be fully extended and supported in final dryer location.
■Remove excess to avoid sagging and kinking that may result in
reduced airflow and poor performance.
■Do not install in enclosed walls, ceilings, or floors.
■The total length should not exceed 73⁄4ft. (2.4 m).
■An exhaust hood should cap the vent to keep rodents and
insects from entering the building.
NOTE: If using an existing vent system, clean lint from entire length
of the system and make sure exhaust hood is not plugged with
lint. Replace plastic or metal foil vents with rigid metal or flexible
metal vents. Review “Vent System Chart” and if necessary, modify
existing vent system to achieve best drying performance.
102 mm
( 4" )
102 mm (4") Heavy, Metal Exhaust Vent
Elbows:
■45° elbows provide better airflow than 90° elbows.
■Plan installation to use the fewest number of elbows and turns.
■Allow as much room as possible when using elbows or making
turns. Bend vent gradually to avoid kinking.
■Vent outlet is located at the center of the bottom dryer back.
■The vent can be routed up, down, left, right, behind the dryer,
or straight out the back of the dryer.
Clamps:
■Use clamps to seal all joints.
■Exhaust vent must not be connected or secured with screws
or other fastening devices that extend into interior of duct and
catch lint. Do not use duct tape.
Improper venting can cause moisture and lint to collect
indoors, which may result in:
Moisture damage to woodwork, furniture, paint, wallpaper,
carpets, etc.
Housecleaning problems and health problems.
Better
Good

16
12" min.
(305 mm)
102 mm (4") Diameter Exhaust Hoods
Box Hood Louvered Hood Angled Hood
Vent Hoods
DRYER VENTING REQUIREMENTS
(In Australia and New Zealand, refer to AS/NZS 5601.1 – Gas Installations)
Exhaust hood must be at least 305 mm (12") from the ground or
any object that may be in the path of the exhaust (such as flowers,
rocks, bushes, or snow).
Maximum Vent Length/Vent Connection
Maximum length of vent system depends upon the type of vent
used, number of elbows, and type of exhaust hood.
Vent System Chart (Rigid Metal Vent)
No. of Box and Angled
90˚ Turns Louvered Hood Hood
0 39.6 m (130 ft.) 39.3 m (129 ft.)
1 38.1 m (125 ft.) 36.3 m (119 ft.)
2 35.1 m. (115 ft) 33.2 m (109 ft.)
3 32.3 m (106 ft.) 30.5 m (100 ft.)
4 29.9 m (98 ft.) 28.0 m (92 ft.)
For vent systems not covered by the vent specification chart, see
your parts distributor.
Provision must be made for enough air for combustion and
ventilation. (Check governing codes and ordinances.) See
“Recessed Area and Closet Installation Instructions” in the
“Stacked Washer/Gas Dryer Location” and “Stacked Washer/
Electric Dryer Location” sections.
A 102 mm (4") outlet hood is preferred. However, a 64 mm
(21⁄2") outlet exhaust hood may be used. A 64 mm (21⁄2") outlet
creates greater back pressure than other hood types. For
permanent installation, a stationary vent system is required.
Connect Vent
1. If connecting to existing vent, make sure the vent is clean.
2. Using a 102 mm (4") clamp, connect vent to exhaust outlet in
dryer.
NOTE: Do not remove vent collar.
Vent System Length
3. Tighten hose clamp with Phillips screwdriver.
4. Make sure the vent is secured to exhaust hood with a 102 mm
(4") clamp.
5. Move dryer into final position. Do not crush or kink vent. Make
sure dryer is level.
Vent Collar
305 mm min.
(12")

17
The outside end of main vent should have a sweep elbow directed
downward.
If main vent travels vertically through the roof, rather than through
wall, install a 180° sweep elbow on end of vent at least 610 mm
(2 ft.) above surface of roof.
The opening in wall or roof shall have a diameter 13 mm (1⁄2")
larger than vent diameter. Vent should be centered in opening.
Do not install screening over end of vent for best performance.
A main vent can be used for venting a group of dryers. The main
vent should be sized to remove 5663 l/min. (200 CFM) of air per
dryer. Large-capacity lint screens of proper design may be used in
main vent if checked and cleaned frequently. The room where the
dryers are located should have make-up air equal to or greater than
CFM of all the dryers in the room.
Back-draft Damper Kit, Part No. 3391910, is available from your
distributor and should be installed in the vent of each dryer to
keep exhausted air from returning into dryers and to keep exhaust
in balance within main vent. Unobstructed return air openings are
required.
Each vent should enter the main vent at an angle pointing in the
direction of the airflow. Vents entering from the opposite side
should be staggered to reduce the exhausted air from interfering
with the other vents.
The maximum angle of each vent entering the main vent should be
no more than 30°.
Keep air openings free of dry cleaning fluid fumes. Fumes create
acids which, when drawn through the dryer heating units, can
damage dryers and items being dried.
A clean-out cover should be located on the main vent for periodic
cleaning of the vent system.
If an Exhaust Hood Cannot be Used Multiple Dryer Venting
DRYER VENTING REQUIREMENTS
(In Australia and New Zealand, refer to AS/NZS 5601.1 – Gas Installations)
30˚ max.
air ow
*Minimum clearance above any
accumulation of snow, ice, or
debris such as leaves
1. Remove red cap from gas pipe.
2. Connect gas supply to dryer. If the flexible gas hose has
10 mm (3/8") BSP thread, use the supplied conversion thread
adapter. Use pipe-joint compound resistant to the action of L.P.
gas for gas connections.
If necessary for service, open the toe panel. Use a putty knife
to press on the 2 toe panel locks located at the top of the toe
panel. Pull downward on the toe panel to open. Toe panel is
hinged at the bottom.
3. Open the shut-off valve in the gas supply line.
4. Test all connections by brushing on an approved noncorrosive
leak-detection solution. Bubbles will show a leak. Correct any
leaks found.
Make Gas Connection
DRYER GAS SUPPLY REQUIREMENTS
(All piping is to be in accordance with AS/NZS 5601.1 – Gas Installations)

18
4. Models with separate washer power cords: Push the power
cord plug into the opening on the right side of the rear panel and
pull the power cord through the opening on the left side of the
rear panel and close holes with the attached cap. Do not pull
plug end of power cord through the right side hole.
NOTE: To avoid damage to internal washer parts or the power
cord, if the cord does not pull out of the washer rear panel easily,
do not force it. Remove the washer rear panel and guide the
power cord around the obstruction and out the hole on the left
side of the rear panel.
5. Close the bolt holes with the 4 transport bolt hole plugs.
IMPORTANT: If the washer/dryer is to be transported, call your
product distributor or installer. To avoid suspension and structural
damage, your washer/dryer must be properly set up for relocation
by a trained professional.
INSTALLING STACKED WASHER/DRYER
Remove Transport System
NOTE: Slide washer/dryer onto cardboard or hardboard before
moving to avoid damaging floor covering.
IMPORTANT: Position the washer/dryer so that the rear of the
washer is within approximately 900 mm (3 ft.) of its final location.
There are four shipping bolts in the rear panel of the washer that
support the suspension system during transportation. These bolts
also retain the power cord inside the washer until the bolts are
removed.
IMPORTANT: Remove the four shipping bolts at the rear of the
washer before operation.
1. Keep the washer/dryer in the upright position while removing the
shipping bolts.
2. Using a 13 mm (1/2") wrench, loosen each of the bolts.
3. Once the bolt is loose, move it to the center of the hole
and completely pull out the bolt, including the plastic spacer
covering the bolt. Once all 4 bolts are removed, discard the
bolts and spacers.

19
INSTALLING STACKED WASHER/DRYER
Connect Inlet Hoses
Insert new hose washers (supplied) into each end of the inlet
hoses. Firmly seat the washers in the couplings.
Connect Inlet Hoses to Water Faucets
Make sure the washer drum is empty.
1. Attach a hose to the hot water faucet. Screw on coupling
by hand until it is seated on the washer.
2. Attach a hose to the cold water faucet. Screw on coupling
by hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten or use tape or sealants on the valve.
Damage to the valves can result.
Clear Water Lines
nRun water through both faucets and inlet hoses, into a laundry
tub, drainpipe, or bucket, to get rid of particles
in the water lines that might clog the inlet valve screens.
n Check the temperature of the water to make sure that the hot
water hose is connected to the hot water faucet and that the
cold water hose is connected to the cold water faucet.
CouplingWasher
Connect Inlet Hoses to Washer
1. Attach the cold water hose to the washer’s cold water inlet
valve. Screw on coupling by hand until it is seated on the
washer.
2. Attach the hot water hose to the washer’s hot water inlet valve.
Screw on coupling by hand until it is seated on the washer.
3. Using pliers, tighten the couplings with an additional
two-thirds turn.
NOTE: Do not overtighten. Damage to the valve can result.
4. Turn on the water faucets completely and check for leaks.
NOTE: Replace inlet hoses after 5 years of use to reduce the
risk of hose failure. Record hose installation or replacement
dates on the hoses for future reference.
Periodically inspect and replace hoses if bulges, kinks, cuts,
wear, or leaks are found.

20
INSTALLING STACKED WASHER/DRYER
Route Drain Hose
Proper routing of the drain hose avoids damage to your floor due
to water leakage. Read and follow these instructions.
Remove drain hose from the washer drum
1. Using locking pliers, squeeze hose clamp tabs together and
insert over the end of the drain hose.
2. Slide the drain hose onto the washer connection.
Laundry tub drain or standpipe drain
Connect the drain hose form to the corrugated drain hose.
Snap either end of the drain hose form to the drain
hose at the point where the corrugation begins.
Bend drain hose over drain hose form and snap
into place.
NOTE: Hose must not extend more than
25 mm (1") past the end of the U bend.
To keep drain water from going back into the washer:
nDo not straighten the drain hose, do not force excess drain
hose into standpipe. Hose should be secure, but loose enough
to provide a gap for air.
nDo not lay excess hose on the bottom of the laundry tub.
Floor drain
You may need additional parts. See “Alternate Parts.”
Secure Drain Hose
1. Drape the power cord over the washer top.
2. Move the washer to its final location.
3. Place the drain hose
in the laundry tub or
standpipe as shown.
4. Secure the drain hose using
the supplied beaded tie
strap.
3. Once the drain hose is in place, release the pliers.
4. The washer drain system can be installed using a floor drain,
wall standpipe, floor standpipe, or laundry tub.
5. If the washer faucets and the drain
standpipe are recessed, put the
hooked end of the drain hose in
the standpipe as shown.
NOTES:
nDo not force excess drain hose
back into the rear of the washer.
nTo avoid siphoning, do not seal the
drain hose into the standpipe.
