Maytag MAH650 series Manual

August 2006 1 16027402
©2006 Maytag Services
Front Load Washer⎯⎯
⎯⎯
⎯Technical Information
MAH6500*
• Due to possibility of personal injury or property damage, always contact an authorized technician
forservicingorrepairofthisunit.
• RefertoServiceManual16010061fordetailedinstallation,operating,testing, troubleshooting, and
disassembly instructions.
Allsafety information must be followed as provided in Service Manual 16010061.
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testing requires power.
CAUTION
!
!WARNING
.
Features MAH6500AW*

16027402 2 August 2006
©2006 Maytag Services
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
Component Testing Procedures
SERIES 10- 44
Machine Control Board INPUT/OUTPUT
Description Connector/
Pin Number Reference To
Connector/
Pin Number
Voltage Comments
Bleach water valve output P1(4) P6(2) 120 VAC
Cold water valve output P1(3) P6(2) 120 VAC 500-1K ohms
Door Lock output P1(1) P6(2) 120 VAC 60 millisecond pulse
Door lock switch input P4(5) P4(4) 24 VDC
Door switch input P8(4) P6(2) 120 VAC
Door unlock output P8(3) P6(2) 120 VAC 60 millisecond pulse
Drain pump output P8(1) P6(2) 120 VAC
High water level - input P1(6) P6(2) 120 VAC
Hot water valve output P1(2) P6(2) 120 VAC 500 - 1K ohms
L1- machine control board P6(1) P6(2) 120 VAC
L1- motor control P8(2) P6(2) 120 VAC
Lower water level - input P4(8) P4(4) 24 VDC
Motor control tach P4(2) P4(4) 24 VDC
Neutral (120 VAC) P6(2) Neutral
Unbalance input P3(4) P4(4) 24 VDC
Softener water valve P1(5) P6(2) 120 VAC
Torque PWM P4(3) P4(4) 24 VDC
Water valve thermistor P4(6) P4(7) (10K-85K ohms)
Heater P6(3) P8(4) 120 VAC
Thermistor-Heater P3(1) P3(2) 120 VAC 500 - 40K ohms
HighLevel Sense (HWL)
Softener Water Valve (SWV)
Bleach Water Valve ( BWV)
Cold Water Valve (CWV)
Hot Water Valve (HWV)
Door Lock Solenoid ( Lock or DL)
Door Switch (DS)
Door Unlock Solenoid (DUL)
Motor (MTR)
Drain Pump (DP)
L1
N
Lower Wash Level Sense (LWL) Valve Thermistor (WT) Valve Thermistor (WT) Door Lock Actuator Switch (DLS) +24 Volts (24V)
Torque PWM (PWM)
Motor Control Tach (Tach) Mtr Control Signal Common (Comm)
P3
+24 Volts (24V) Unbalanced Switches(UB)
Wiring Harness
Connections
Letters in parenthesis designate
markings on the Control Board
5
Heater (HTR)
Htr
34
Heater Thermistor (ST) Heater Thermistor (ST)
P4

August 2006 3 16027402
©2006 Maytag Services
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
SERIES 45 - current
Machine Control Board INPUT/OUTPUT
Description Connector/
Pin Number Reference To
Connector/
Pin Number
Voltage Comments
Bleach water valve output P1(4) P6(2) 120 VAC
Cold water valve output P1(3) P6(2) 120 VAC 500-1K ohms
Door Lock output P1(1) P6(2) 120 VAC 60 millisecond pulse
Door lock switch input P4(5) P4(4) 12 VDC
Door switch input P8(4) P6(2) 120 VAC
Door unlock output P8(3) P6(2) 120 VAC 60 millisecond pulse
Drain pump output P8(1) P6(2) 120 VAC
High water level - input P1(6) P6(2) 120 VAC
Hot water valve output P1(2) P6(2) 120 VAC 500 - 2K ohms
L1- machine control board P6(1) P6(2) 120 VAC
L1- motor control P8(2) P6(2) 120 VAC
Lower water level - input P4(8) P4(4) 12 VDC
Motor control tach P4(2) P4(4) 12 VDC
Neutral (120 VAC) P6(2) Neutral
Unbalance input P3(4) P4(4) 12 VDC
Softener water valve P1(5) P6(2) 120 VAC
Torque PWM P4(3) P4(4) 12 VDC
Water valve thermistor P4(6) P4(7) (10K-85K ohms)
Heater P6(3) P8(4) 120 VAC
Thermistor-Heater P3(1) P3(2) 120 VAC 500 - 40K ohms
Less than 10 ohms when closed
Less than 10 ohms when closed
Less than 10 ohms when closed
PWM signal between 0 & 100% duty cycle
500 - 2K ohms
Component Testing Procedures

16027402 4 August 2006
©2006 Maytag Services
Leaking
• Makesuresupply hoseconnectionsarenot
leaking. Check for rubber gasket damage
duetoovertightening.
• Makesureendofdrain hose is correctly
insertedandsecuredto drain facility.
• Avoidoverloadingwhich can pushthedoor
partiallyopen.
• Checkinternalhose connections
• Checktubcover. Remove, repositionand
reinstall the tubcoverseal.Seal seam must
beatthetop of thetubcover.
Display Lights Up When Door Opened
• This is normal behavior.
No Tumble
• Washerdoesnottumble for thefirst30
secondsafterthedoorhasbeen opened for
safetypurposes.
• Fabriccyclessuchas delicates and hand
wash onlytumblefora few seconds every30
seconds.
• Checkforlooseconnections at machine
controlboard,motorcontrol board and
motor.
• Perform Motor and Motor Control Test.
• Washerdoesnottumble during somedrains
andrinsefills.
No Water Fill
• Checktomakesurewatersupplyturnedon
fully.
• Normalwaterlevelisonly2.5to5inchesinside
thespinner.
• Checkforkinksin inlet hoses.
• Checkforcloggedinlet screens.
• Visuallycheckhot and coldseparatelyat
dispenserforproperflows.
• Go to No Fill Test page 11.
Noisy
• Clotheswashershould beleveledproperly
asoutlinedininstallationinstructions.
• Weakfloorscancause vibration andwalking.
• Checkforlooselower front bracket.
• Besurerubberfeet are installedonleveling
legs.
• Checkthatthe levelingleglocknuts are
tightened.
• Ifcomplaintisa high-pitched noiseduringfill
thendisconnectsupplyhosesandclean
screens.
• Checkforproperspringplacement of outer
tubsupportsprings.
• Checkstrutoperation.
Tub is completely full of suds
• Run the clothes washer through another
completecycleusingcoldwater and no more
detergent.
• Reducedetergentamountforthatspecificload
sizeandsoillevel. Towelloadshaveaminimal
amountofsoilpresentandtypicallycreatemore
suds.
• Use high efficiency or low sudsing detergent
speciallyformulatedfor frontloadwashers.
• Checkforrestricteddrain system.
• Check for loose wire connections at control
boardandpump.
• Checktoseeif belt fell offmotorand pulley.
• Perform Motor and Motor Control Test.
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.

August 2006 5 16027402
©2006 Maytag Services
Will Not Drain
• Checkforrestricteddrain system.
• Checklow andhighwaterlevels.GotoNo
Fill test page 11.
• Check for 120 VAC at the pump when a
spincycleisselected.
Wrong Water Temperature
• TooHot/TooCold; since thisproductuses
alowamount of water,theboard
regulatestheincoming flow totemperthe
actualtemperatureof thewaterin thetub.
Thismayappearto besignificantly
warmer/coolerthanexpected.
• Arebothfaucetsonfully?
• Makesuretemperatureselection is
correct.
• Makesurehosesareconnected to
correctfaucetsand inletconnections.
Flushwaterline beforefillingwasher.
• Check thewaterheater. Itshould beset
todeliveraminimum120°F (49°C) hot
wateratthetap. Alsocheckwaterheater
capacityandrecovery rate.
• Ifthewaterheater is locatedalong
distancefrom washer,waterline may
needtobe purged prior to starting wash
cycle.
• Disconnectinlethoses and clean
screens.
• Thiswashercansense if thefillhoses
havebeenreversed betweenhotand
cold.Ifthe fillhosesonthe washerwere
previouslyinstalled incorrectlyandthen
corrected,thewasher will needtoberun
throughaHot /Coldcycle. Ifnotresolved,
checkforproperresistance on the water
valvethermistor.(See Machine Control
Board INPUT/OUTPUT chart).
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
Wet Clothes
• Verysmallclothesloads cancause
unbalancesaddadditional towels.
• Excessivesudsmay havebeenpresent.
Check for diagnostic code 16.
• Checkunbalanceharness connectionsatall
switchesandatControl Board.
• Inertialunbalanceswitch trippedtoosoon,
resultinginlowerspin speeds. Run Quick
Spin Test to checkunbalanceswitchesand
ControlBoard.
• Checkforrestricteddrain system.
• Perform Motor and Motor Control Test.
Will Not Lock
• Doornotall the wayclosed.
• Checkelectricalconnectionsatlockassembly
andmachinecontrol board.Goto Door Lock
Test.
Will Not Unlock
• Unplugandreplugin power cord andwait2
minutestosee if machineunlocks.
• Check for door locked switch circuit to be
closed atmachine control. (See Machine
Control Board INPUT/OUTPUT chart).
• Checktomakesure belt hasnotfallenoff.
• Checkforlooseelectrical connections at
doorlockandatmachine control board.
• Perform Motor and Motor Control Test.
WillNot Start
• Plugcordintoliveelectricaloutlet.
• Checkfuseorresetcircuit breaker.
• Pushthestart/pausebuttontostarttheclothes
washer.
• Closedoorandpush the start/pause button
tostart theclotheswasher.start/pause LED
shouldchangefromflashingtooncontinuously.
• Check to see if the washer is in a pause or
soak period in the cycle. Wait briefly and it
maystart.
• Checkforrestricteddrain system.

16027402 6 August 2006
©2006 Maytag Services
System Diagnostics
SERVICE MODE
TheService Mode providesservicepersonnel
theabilityto verify theoperationof the washing
machine. The Service Mode canbeentered in
themiddleof any washcycle.Whilein theSer-
vice Mode,theservicercanstart a variety of
specialservicetests.
Accessing Service Mode:
Pressingdownthedelicates andheavy soil
keysfor3secondsplaces the machine inthe
Service Mode. Motor speed will be displayed
whenstarted.Toexit Service Mode,press
delicates andheavy soil keysfor3seconds
again.
Thefollowing tablelists the varioustestsavail-
ablewhileintheService Mode,which can be
accessedbypressingthe following keys:
retnEoT syeKsserP laicepS noitcnuF/tseT tixEoT noitcnuF
muideM rotoMswohS euqroT esuaP/tratS
eerFelknirW daPenar
bmeM kcehC ro.ces5tiaW eciwtffOsserp
kciuQ nwoDemiTtsaF tseT esuaP/tratS
nipStseTnipSkciuQesuaP/tratS
lioSthgiL
s
yalpsiD erawtfoS noisiveR rebmuN
esuaP/tratS
setacileD ecivreSkciuQ elcyC esuaP/tratS
esniR tuptuOdraoB tseT esua
P/tratS
kaoserP citsongaiD sedoC esuaP/tratS
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
Consumer Information Codes
Iftheconsumerobserves codes ondisplay, see
tablebelow:
Sd = Suds:Machinehasdetectedhigh
levelofsuds. Themachinewill alter
itscycleforthis situation. Use anHE
detergentorcut downonthe amount
ofdetergentslightly.Thiscanbe
morelikelyontowel loads, consider
HEdetergentespeciallyfor these
loads.
do = Door is Open: The door of the
machine is open. Please make sure
doorisfullyclosed before starting
cycle.
od = OpentheDoor:Thedoor has not
beenopenedsincetheend of the
lastcycle.Asa safety check thedoor
mustbeopenedatthe completion of
everycycle.
nF = Nofill:Themachinehas tried to fill
butcannot.SeeNo Water Fill.
PF = Power failure: Power to the ma-
chinehasbeen lost duringthelast
cycle.Thismay occur onstartupof a
newmachinedue tofactorytesting.
LO = Locked: Door is locked (failed to
unlock)-the machinehasrepeatedly
triedtounlock butcannot.Pushdoor
closedtomakesure nothing from
the inside is pressing against the
doorwhichmakekeepit from un-
locking.
FL = Failed to lock: The machine has
repeatedlytriedtolockthe door but
cannot.Makesure the doorisshut
completely
nd = No drain: The machine has tried to
drainbutcannot.
Lr = LockedRotor: The machine has
repeatedlytriedto turnthemotorbut
cannot.

August 2006 7 16027402
©2006 Maytag Services
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
DIAGNOSTIC CODES:
Whenaproblem with thewashsystemis
detected a diagnostic code is assigned and
loggedintothe control boardmemorywiththe
lastcyclecountat which itoccurred. Anas-
signed diagnostic code indicates the washer
mustbeserviced. Thecontrol boardwillallow
as many diagnostics as possible for the ma-
chinetocontinuerunning. Insomecases,
whenthe washershutsdown,somethingshall
bedisplayedon thedisplayuntilthe consumer
selects the off key. See the table for specific
actionsorreferencesto where the proper
action is defined.
Accessing Diagnostic Codes
Afterthemachineisin the service mode,
pressing presoakkeywilldisplaya ‘d’ and turn
theLEDonabovethepresoakkey. The
diagnostic codes can be viewed by using the
arrowkeys. Thedown arrow willgodownthe
list.
Clearing Diagnostic Codes
Whileviewingthediagnostic code listing, the
diagnostic code list can be cleared from
memorybypressingtheheavy soil and
presoak keysfor3seconds.
Number of Cycles Since Code Assigned
WhiletheDiagnostic codeis displayed,ifthe
cotton/sturdy keyispressedandheld,the
machineshalldisplaythenumberofcyclesago
the codeoccurredwhilethekeyisheld. Also,
whilethiskeyisbeingheld,thekeywillturnonthe
LED. Whenthiskeyisletup,thenthecodeis
againdisplayed. Iftherearenocodesavailable,
‘--‘ willbedisplayedwhilethiskeyispressed. If
thecodeisover99cyclesago, then‘--‘willbe
displayed.
DIAGNOSTIC CODES:
Diag.
Code Description Trigger Action to be Taken
nd
Will Not Drain
LO
Will Not Unlock
nF
No Fill
FL
Will Not Unlock
Wet Clothes
Lr
Motor and Motor Control Test , ”

16027402 8 August 2006
©2006 Maytag Services
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
DIAGNOSTIC CODES (Continued):
Diag.
Code Description Trigger Action to be Taken
08 Water sensor level
fault The low water level is not satisfied before the
high water level
contacts are opened
in the pressure switch
Go to "
No Water Fill ” page 3.
09 (Not Used)
10 Low rpm
unbalanced load Never reached 400 rpm due to an
unbalanced load
Go to "
Wet Clothes " page 4.
11 Non-volatile
memory error Difficulty in reading memory 1. Go to "
Clearing Diagnostic Codes ”
page 6.
2. Unplug and replug in power cord
washer at power supply outlet
3. If a condition still exists, replace
machine control board.
12-14 (Not Used)
15 Stuck key A key is sensed to be
pressed for more than
75 seconds, the key
shall be assumed to
be stuck
Replace console/membrane switch.
16 High speed not
achieved due to
high motor torque
Speed never went over
400rpmduringamain
wash cycle because
the maximum torque
was seen for too long
Go to "
Wet Clothes " page 4.
17 Door actuator
switch was not
seen open since
the last final spin
The door has not been
opened after a
complete wash cycle.
Will display "
od "
Check for:
- Customer may have tried to repeat
wash cycle without opening door
-Goto"
Door Lock Test " page 10.
18 Door lock switch
seen open during
cycle
Door lock switch is
read as open with
motor running
- Clear the diagnostic code, page 6.
recheck;
-Go to "
Door Lock Test "page10..

August 2006 9 16027402
©2006 Maytag Services
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
DIAGNOSTIC CODES (Continued):
Diag.-
Code Description Trigger Action to be Taken
19 Door lock sense or
motor control relay
failed
Door lock sense switch
on machine control
board is read as open
with motor running
See list for diagnostic code 18
20 Door switch input
seen open during
cycle
Door switch is open Go to "
Door Lock Test ", page 10.
21 Door sense switch
failed on machine
control board
Door sense switch is
read as open and the
door locked switch is
read as locked
Go to
"Door Lock Test ", page 10..
22 Door switch seen
open during cycle Door switch is read as open and the door
locked switch is read
as locked
Go to "
Door Lock Test ", page 10.
23 Door failed to
unlock Door lock is locked andausertriesto
start a cycle
Go to "
Will Not Unlock "page4.
24 Motor over speed Motor tach signal is
seen at maximum
speed
-Replacemotorcontrolboard
25 Motor tach signal
exists without
motor running
Tach signal exists
without torque
commanded.
-Replacemotorcontrolboard
26-27 (Not Used)
28 Valve thermistor
failure
Abnormal high/low
temperature or ohm
resistance seen
Go to "
Wrong Water Temperature "page
4.
29 Sump thermistor
failure Check harness connections, check
continuity of sump thermistor
Abnormal high/low
temperature or ohm
resistance seen

16027402 10 August 2006
©2006 Maytag Services
Troubleshooting Procedures
!WARNING
To avoid risk of electrical shock, personal injury or death; disconnect power to washer before servicing, unless
testingrequires power.
Membrane Pad Check Test
While in Service Mode, pressing the wrinkle
free key will start a membrane pad switch check.
The membrane check involves turning all the
embedded LED lights on the membrane pad
except for the wrinkle free key. All the LEDs
can be toggled by pressing the key associated
with the LED. Atany point, if there are 10 min-
utes of inactivity, then this test will exit. Press the
off key twice within 30 seconds to cancel test.
Fast Time Down Test
While in Service Mode, pressing the quick key
will advance the program to the next wash cycle.
The following Quick Spin Test steps are as follows:
1) Lock thedoor.
2) Spin to 350 rpm and hold for 6 seconds.
3) Spin to 550 rpm and hold for 6 seconds.
4) Spin to 600 rpm and hold for 6 seconds.
5) Spin to 650 rpm and hold for 6 seconds.
6) Spin to 800 rpm and hold for 6 seconds.
If the spin key is pressed again during the Quick
Spin Test, the current speed will be held indefinitely.
Pressing the spin key again will allow the quick test to
proceed as listed above.
foegatS elcyChsaW oTsecnavdA
kaoserPkaoserPfodnE
hsaW fosetuniM5yrevE emiThsaW
niarD/nipSehTfopetSyrevE eliforP
nipS
esniResniRfodnE
Quick Spin Test
While in Service Mode, the pressing of spin key shall
start the washer in the Quick Spin Test mode.
egnaRdeepSdeyalpsiD
mpr99-0)a )lautca(99-0
mpr999-001)b 01/deepS
Quick Service Cycle
While in Service Mode, pressing the delicates key
will start a Quick Service Cycle. This will be a
quick check of all systems.
The following steps will be followed.
1. Energizethe coldandbleach watervalves. Fill to
Low level, then turn bleach and cold off.
2. Energize the hot and fabric softener water valves.
Fillto highlevel, thenturn allvalves off.
3. Lock the door.
4. Tumble using 7/3 tumble pattern for 12 sec.
5. Turn the drain on.
6. Spin to 800 RPM using default rates.
7. End spin and coast down.
8. Unlock the door when the RPM is zero.
9. Display a ‘PA’ (Passed) on continuously for 10
seconds if no diagnostic codes were logged during
this test.
The up arrow if pressed will advance to the next
step. The right most dot will be turned on as an
indication of failure and stay on until Quick Service
Cycle test has reached the end. Any diagnostic
code logged during this test will result in failure of
the test, but will not necessarily stop the test. While
in Quick Service Cycle, the pressing of the hand
wash will suspend the machine at this step for 30
minutes until the hand wash key is pressed again.
All LED’s will flash on and off while the cycle is
suspended, or on hold.
Motor Drive System
To check the system, check the board for proper
output to the motor control. Performing a Motor
and Motor Control Test does this.
When the washer is in the Service Mode, the speed
will be displayed as a two digit number or a letter/
number.
