MFR60PN
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
RIGID-MOUNT FRONT-LOAD WASHER
CLP766A
CLEANS BETTER WITH
LESS WATER
TO CUT UTILITY COSTS
EASY TO USE
EXTERNAL HOOKUPS
FOR CHEMICAL INJECTION
* Compared to previous Maytag®MFR washers. Total savings may vary by model.
visit maytagcommerciallaundry.com
or call 800-662-3587
LEGENDARY MAYTAG DEPENDABILITY
Maximizing your equipment investment for over a half century.
MICROPROCESSOR CONTROLS
Maytag®microprocessor controls offer 15 preprogrammed
cycles, plus the capability to create multiple unique cycles.
Also, one-touch cycle selection and multilingual readouts
make these controls easy for everyone to operate.
CHEMICAL INJECTION SYSTEM
Designed to make chemical installation faster, simpler and
more precise, the Maytag®Commercial Laundry Chemical
Injection System features easy-access connections on the
outside of the machine. This eliminates the need for having to
open up the washer on routine visits. The new system also
provides chemical supply companies and the machine’s users
with clear visibility on how detergent, bleach, softener and
other chemicals are being dispersed.
FOR YOUR OPERATION:
• Inverter Drive Technology For Longer Life
• Big-Load Design With Oversized Door Opening
• Easy-To-Operate Microprocessor Controls
• Adjustable Water Temperatures And Levels
• TurboWash™ System Cuts Water Usage By Up To 44%*
• Manual 3-Bay Detergent and Softener Dispenser
• External Chemical Supply Hookup
• 8 Chemical Supply Signals
• Extra-Large Drain Valve
• Extra-Large Door And Handle
• Easy Service Access
• Programmable LCD Digital Display Shows English, Spanish
And French. Additional Languages Available.
BUILT-TO-LAST ™FEATURES:
• Commercial-Duty Door Handles, Belts And Frame
• Extra-Large Drain Valve
• Durable Sealed Bearings
• Stainless Steel Top, Front And Sides

MAYTAG®LIMITED WARRANTY
3 YEARS — ALL PARTS; 5 YEARS — SHELL, WELDED FRAME
ASSEMBLY, BASKET, SHAFT ASSEMBLY, BEARINGS AND SEALS
For a period from the date of original purchase through the time listed above, the designated parts
that fail in normal commercial use will be repaired or replaced free of charge for the part itself,
with the owner paying all other costs, including labor, transportation and customs duty. Chemical
damage is excluded from all warranty coverage. See complete warranty for details.
WASHER SPECIFICATIONS
MODEL MFR60PN
MOTOR
Inverter drive •
Variable speed •
HP (kw) 3 (2.2)
Voltage 208 – 240V
Single-Phase/Three-Phase
BREAKER SIZE — amps 20
SPEED
Wash speed — rpm 42
Extract speed — maximum rpm 490
Extract speed — maximum g-force 100
WATER INLET/HOSE
Water inlet — in. (mm) .75 (19.05)
Operating pressure — psi (mpa) 14.5 – 116 (0.1 – 0.8)
Drain size — in. (mm) 3.0 (76) O.D.
CAPACITY
Lbs. (kg) 60 (27)
Cylinder volume — cu. ft. (liters) 9.5 (270)
Cylinder diameter — in. (mm) 29.5 (749.3)
Cylinder depth — in. (mm) 24.0 (610)
COLOR
Stainless Steel •
APPROXIMATE WEIGHT
Crated — lbs. (kg) 1,037 (470)
Uncrated — lbs. (kg) 904 (410)
DIMENSIONS
A) Height — in. (mm) 54.33 (1380)
B) Width — in. (mm) 34.25 (870)
C) Depth — in. (mm) 40.95 (1040)
D) Floor to bottom of door — in. (mm) 15.3 (389)
E) Depth including door handle and air vent
on back — in. (mm)
44.88 (1140)
F) Floor to drain outlet center — in. (mm) 3.46 (88)
G) Side to drain outlet center — in. (mm) 17.13 (435)
Door Opening — in. (mm) 19.8 (503)
See specific instructions for proper installation. Because of continuous product improvement, Maytag reserves
the right to change specifications without notice.
At Maytag, we believe durable goods should remain just that.
That’s why every Maytag®product is constructed of the
highest-quality materials and with the utmost in precision
craftsmanship. It’s also why we stand behind our equipment
with solid service and support from our professional Maytag
laundry suppliers. Simply put, when you choose Maytag®
products, you ensure your peace of mind.
OUR COMMITMENT
TO DEPENDABLE qUALITY
9/12
MFR60PN
MAYTAG®COMMERCIAL
ENERGY ADVANTAGE™
RIGID-MOUNT
FRONT-LOAD
WASHER
Maytag®Commercial Energy Advantage™
Rigid-Mount Front-Load Washer
MICROPROCESSOR NON-COIN
