Quick Start Guide
SD Transcoder - Quick Start Guide - P/N S16986 RA
1. ASI output: connect the ASI cable to the rear of the SD encoder, on port 2 .
2. Connect an Ethernet cable to the rear of the SD transcoder on eth0 for management and UI access .
3.a. For installations using IP outputs (with or without ASI output):
• Connect an Ethernet cable from eth2 of the main transcoder to the IP switch.
• Connect an Ethernet cable from eth2 of the SD transcoder to the same IP switch
3.b. For installations using ASI outputs only:
• Connect an Ethernet cable from eth2 of the main transcoder to eth2 of the SD transcoder .
4. Connect the power cord to the back of the SD encoder . Plug the power cord into the grounded outlet, then
power up the appliance.
1
2
3
3
4
Step 1: Connections/Power
1. Launch a web browser:
HTTP://{IP-Address} where {IP-Address} is the Management network address set in Step 2.
2. When the Login page displays, login with username admin and password admin.
3. Navigate to the Services Page.
4. Click the button to configure each Transcoder service:
5. On the Input tab, set the multicast destination to that set on the output of the main transcode receiver.
The default is 239.0.95.99 port 5000:
IMPORTANT: Do not change any other parameters.
6. Click Save and Exit.
Result: The transcoder service will restart.
7. Repeat steps #4 to #6 for each of the transcoders.
IMPORTANT: Set them to the same multicast destination.
Result: MPTS output containing all the SD programs is now available on the ASI output.
Step 3: Log in to the unit and set up the Transcoder inputs
The Ethernet interfaces can be configured using the LCD panel:
1. Navigate to the Main menu > Network submenu using the UP, DOWN, LEFT and RIGHT buttons.
2. Select Eth0 for the Management network address then use the UP and DOWN buttons to adjust the value.
3. Select Eth2 for the Data network address then use the UP and DOWN buttons to adjust the value.
4. Press ENTER to apply the new values.
Step 2: Configure the network interfaces
NOTE: See back panel connector locations on next page.
The SD transcoder receives the MPTS output of the main transcoder receiver via IP multicast.

SD Transcoder - Quick Start Guide - P/N S16986 RA
NOTE: The back panel components are SELV (Safety Extra Low Voltage) components.
ASI Output - port 2
1 GbE - eth0 for Management
Quad 1GbE - eth2 for input multicast from the main transcoder
Power input
An electronic copy of this document is available for download at:
https://www.mediakind.com/rx1-quick-start-guide
Scan to connect to
MediaKind website and
get this Quick Start
Guide.
1
2
3
4
SD Transcoder back panel
  
eth5 eth4 eth3 eth2
PSU1 PSU2
Eth0 Eth1
1 Gbe (default: Eth 0 for management,Eth1 for input/output

PSU1 PSU2eth0 eth1
12 3 4 5
