MEGABAY Viento VE5 Assembly instructions

Step 1
Step 2
• Follow instructions carefully,
failure to do so will void warranty.
• Ensure installation complies with local law
and applicable standards.
• Input Voltage Range 40 - 55Vdc
• Only use a Megabay Optimo power supply unit
and Quick Connect cabling.
• Ensure mains input power is surge protected.
• Never make connections whilst the power is connected.
• Do not make modifications or alter the product.
• Keep luminaire clean and free of debris.
READ ALL SAFETY INSTRUCTIONS FIRST
DMX ONLY
INTERIOR + EXTERIOR
ARCHITECTURAL LINEAR LED PROJECTOR
INSTALLATION SHEET
Viento
Megabay 12- 14 Industrial Avenue Caloundra Qld 4551 Australia
1/ 3
Edition 3
Megabay reserves the right change this product at any time without prior notice and such modifications shall be www.megabay.com
1000mm
0.8m cableDMX terminator 0.6m cable 0.3m cable
1000mm500mm500mm
1000mm 1000mm500mm500mm
DMX Lighting
Control System
Maximum number of 32 fixtures in series when using DMX control
DMX IN
DMX IN
OUTPUT
OUTPUT
100 - 240V ac
mainspower
POWER SUPPLY TO LUMINAIRE TABLE
48V PSU with QUICK CONNECT INTERFACE QUICK CONNECT CABLE DMXTERMINATOR
320W DMX
240W
320W
150W
60W
320 watts
240 watts
150 watts
60 watts
NDM no dimming
DMX DMX
ITEM WATTS CONTROL
For DMX control only,
remove the END CAP and
use the terminator on the
end of the last fixture.
ITEM
48V Optimo
Power Supply
VE5 - 500mm VE10 - 1000mm
15W 30W 25W 50W
MLE-OM-48V-320W 18 9 11 5
MLE-OM-48V-240W 12 6 8 4
MLE-OM-48V-150W 7 3 5 2
MLE-OM-48V-60W 3 1 2 1
0.6M
5M
2M
1M
0.8M
0.6M
0.3M
10M
20M
50M
2 metres
1 metre
800mm
600mm
300mm
5 metres
10 metres
20 metres
50 metres
ITEM LENGTH
48V Optimo High Performance IP67 Power Supply Units
can power the maximum number of luminaries
Distributed in Qld by

Step 3 Step 4 Position the fixtures, and mark the location of
the mounting bracket. A bracket template is
provided on page 3.
Determine which way
the fixture will pivot
to suit the installation
requirements.
Step 6 Replace the fixture, and secure it with
suitable fixings to the supporting structure.
Use nylon washers to protect exterior
anodised finish.
Step 5 Mark the position of the fixing holes
through the bracket slots. Remove the fixture
to ensure no damage is caused to the
anodised finish during drilling.
Step 8
Step 11
Search for the terms
“spirit level”
“inclinometer”
“digital tiltmeter” or similar
to download a digital app.
Check Step 2 to ensure the correct Wiring Schematic has been followed.
Check Input Voltage Range is 40Vdc - 55Vdc
Apply power and check operation.
Step 9 Step 10
Only connect fixtures with the supplied
Quick Connect cables.
Always Terminate the unused end of the last fixture.
The Lighting Control System in use determines the
method to be used.
DMX
Use the supplied Megabay DMX Terminator
to connect to the last open connection.
Align both “indicator arrows” before making
the connection. A “click” sound will be
heard when locked correctly.
Step 7 Partially tighten the bracket screws at each end,
and pivot the fixture body as desired.
Use a Smartphone with an inclinometer app
to measure exact angles of rotation.
Bracket Screws
Fixings
Tighten bracket screws
to finalise angle.
INTERIOR + EXTERIOR
ARCHITECTURAL LINEAR LED PROJECTOR
INSTALLATION SHEET
Viento
Megabay 12- 14 Industrial Avenue Caloundra Qld 4551 Australia
2/ 3
Edition 3
Megabay reserves the right change this product at any time without prior notice and such modifications shall be
eective immediately. Visit www.megabay.com for the most current instructions. Megabay © 2015. www.megabay.com
Pivot point
pivot on LHS
125 degrees
0 degrees 0 degrees
15 degrees
LHS pivot
125 degrees
0 degrees
15 degrees 15 degrees
90 degrees
35˚

4829 48 29
22
8
CHECK THIS DIMENSION IF PRINTING FROM PDF
Always print with ACTUAL SIZE, do not use FIT TO PAGE.
267 mm
MOUNTING BRACKET FULL SIZE TEMPLATE
INTERIOR + EXTERIOR ARCHITECTURAL LINEAR LED PROJECTOR INSTALLATION SHEET
Viento
Megabay 12- 14 Industrial Avenue Caloundra Qld 4551 Australia
3/ 3
Edition 3
Megabay reserves the right change this product at any time without prior notice and such modifications shall be eective immediately. Visit www.megabay.com for the most current instructions. Megabay © 2015. www.megabay.com
