Meinberg ADU/GPS-1-12 User manual

SETUP GUIDE
ADU/GPS-1-12
GPS Antenna Distribution Unit
December 19, 2022
Meinberg Funkuhren GmbH & Co. KG

Table of Contents
1 Imprint 1
2 Change Log 2
3 Copyright and Liability Exclusion 3
4 Introduction 4
5 Presentation Conventions in this Manual 5
5.1 Conventions for the Presentation of Critical Safety Warnings . . . . . . . . . . . . . . . . . . . . . 5
5.2 Secondary Symbols Used in Safety Warnings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
5.3 Conventions for the Presentation of Other Important Information . . . . . . . . . . . . . . . . . . . 6
5.4 GenerallyApplicableSymbols ....................................... 6
6 Important Safety Information 7
6.1 AppropriateUsage .............................................. 7
6.2 ProductDocumentation ........................................... 8
6.3 Safety when Installing the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
6.4 Safety when Maintaining and Cleaning the Device . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
7 Important Product Information 11
7.1 CEMarking.................................................. 11
7.2 UKCAMarking ................................................ 11
7.3 Ensuring the Optimum Operation of Your Device . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
7.4 Disposal.................................................... 12
8 ADU/GPS-1-12 Connectors 14
8.1 AntennaInput:GPS-AV........................................... 15
8.2 GPSAntennaOutput-Master....................................... 16
8.3 GPSAntennaOutput-Slave........................................ 16
9 Installation of a GPS Antenna 17
10 Before you start 22
10.1RequiredTools ................................................ 22
10.2PreparingInstallation ............................................ 22
10.3ContentsofDelivery............................................. 23
11 System Installation 24
11.1ConnectingtheSystem ........................................... 25
12 Technical Appendix 26
12.1 Technical Specifications: Chassis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12.2 Technical Specifications: MBG S-PRO Surge Protector . . . . . . . . . . . . . . . . . . . . . . . . 28
12.2.1 MBG S-PRO: Physical Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
12.2.2 InstallationandGrounding..................................... 30
12.3 Technical Specifications: Antenna Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
13 RoHS Conformity 31
14 Declaration of Conformity for Operation in the European Union 32
Date: December 19, 2022 ADU/GPS-1-12

1 Imprint
1 Imprint
Meinberg Funkuhren GmbH & Co. KG
Lange Wand 9, 31812 Bad Pyrmont, Germany
Phone: + 49 (0) 52 81 / 93 09 - 0
Fax: + 49 (0) 52 81 / 93 09 - 230
Website: https://www.meinbergglobal.com
Email: [email protected]
Date: December 13, 2022
ADU/GPS-1-12 Date: December 19, 2022 1

2 Change Log
Version Date Revision Notes
1.0 07/23/2021 Initial version
1.01 12/15/2022 Revision based on new standardized setup guide structure
2 Date: December 19, 2022 ADU/GPS-1-12

3 Copyright and Liability Exclusion
3 Copyright and Liability Exclusion
Except where otherwise stated, the contents of this document, including text and images of all types and transla-
tions thereof, are the intellectual property and copyright of Meinberg Funkuhren GmbH & Co. KG (“Meinberg”
in the following) and are subject to German copyright law. All reproduction, dissemination, modification, or ex-
ploitation is prohibited unless express consent to this effect is provided in writing by Meinberg. The provisions
of copyright law apply accordingly.
Any third-party content in this document has been included in accordance with the rights and with the consent
of its copyright owners.
A non-exclusive license is granted to redistribute this document (for example, on a website offering free-of-
charge access to an archive of product manuals), provided that the document is only distributed in its entirety,
that it is not modified in any way, that no fee is demanded for access to it, and that this notice is left in its
complete and unchanged form.
At the time of writing of this document, reasonable effort was made to carefully review links to third-party
websites to ensure that they were compliant with the laws of the Federal Republic of Germany and relevant
to the subject matter of the document. Meinberg accepts no liability for the content of websites not created or
maintained by Meinberg, and does not warrant that the content of such external websites is suitable or correct
for any given purpose.
While Meinberg makes every effort to ensure that this document is complete, suitable for purpose, and free
of material errors or omissions, and periodically reviews its library of manuals to reflect developments and
changing standards, Meinberg does not warrant that this specific document is up-to-date, comprehensive, or
free of errors. Updated manuals are provided at www.meinbergglobal.com.
You may also write to [email protected] to request an updated version at any time or provide feedback
on errors or suggested improvements, which we are grateful to receive.
Meinberg reserves the right to make changes of any type to this document at any time as is necessary for
the purpose of improving its products and services and ensuring compliance with applicable standards, laws &
regulations.
ADU/GPS-1-12 Date: December 19, 2022 3

4 Introduction
This Setup Guide is a systematically structured guideline to assist you with the set-up of your Meinberg product.
ADU/GPS-1-12 is an antenna splitter which distributes the intermediate frequency of 35.4 MHz coming from a
Meinberg GPS antenna to up to 12 Meinberg GPS reference clocks via individual coaxial antenna connections.
The ADU/GPS-1-12 must be mounted inside a building and connected to a Meinberg GPS antenna via a
coaxial cable (included when ordering a GPS antenna).
The ADU/GPS-1-12 system requires an externally supplied voltage to supply the connected antenna for op-
eration. The voltage is supplied via the master output, which must be connected to a running reference clock
(e.g. in an IMS system).
The system is suitable for retrofitting existing Meinberg GPS systems. The following GPS reference clocks are
suitable for use with ADU/GPS-1-12:
•IMS GPS reference clocks (e.g. IMS-GPS182, GNS181-UC)
•GPS slot cards (e.g. GPS180PEX)
•GPS top-hat rail systems (e.g. GPS180XHS)
Older reference clocks are also supported:
•GPS163
•GPS164
•GPS165
•GPS167
•GPS168
•GPS169
•GPS170
Information:
The GPS166 is not supported.
Manual Revisions
Meinberg products are subject to ongoing development even after their market release, with new features
and enhancements added on a regular basis. Meinberg also revises its product manuals to account for these
feature updates.
4 Date: December 19, 2022 ADU/GPS-1-12

5 Presentation Conventions in this Manual
5 Presentation Conventions in this Manual
5.1 Conventions for the Presentation of Critical Safety Warnings
Warnings are indicated with the following warning boxes, using the following signal words, colors, and symbols:
Caution!
This signal word indicates a hazard with a low risk level. Such a notice refers to a procedure or other
action that may result in minor injury if not observed or if improperly performed.
Warning!
This signal indicates a hazard with a medium risk level. Such a notice refers to a procedure or other
action that may result in serious injury or even death if not observed or if improperly performed.
Danger!
This signal word indicates a hazard with a high risk level. Such a notice refers to a procedure or
other action that will very likely result in serious injury or even death if not observed or if improperly
performed.
5.2 Secondary Symbols Used in Safety Warnings
Some warning boxes may feature a secondary symbol that emphasizes the defining nature of a hazard or risk.
The presence of an "electrical hazard" symbol is indicative of a risk of electric shock or
lightning strike.
The presence of a "fall hazard" symbol is indicative of a risk of falling when performing
work at height.
ADU/GPS-1-12 Date: December 19, 2022 5

5.3 Conventions for the Presentation of Other Important Information
Beyond the above safety-related warning boxes, the following warning and information boxes are also used
to indicate risks of product damage, data loss, and information security breaches, and also to provide general
information for the sake of clarity, convenience, and optimum operation:
Important!
Warnings of risks of product damage, data loss, and also information security risks are indicated with
this type of warning box.
Information:
Additional information that may be relevant for improving efficiency or avoiding confusion or misunder-
standings is provided in this form.
5.4 Generally Applicable Symbols
The following symbols and pictograms are also used in a broader context in this manual and on the product.
The presence of the "ESD" symbol is indicative of a risk of product damage caused by
electrostatic discharge.
Gleichstrom (Symboldefinition IEC 60417-5031)
Wechselstrom (Symboldefinition IEC 60417-5032)
Erdungsanschluss (Symboldefinition IEC 60417-5017)
Schutzleiteranschluss (Symboldefinition IEC 60417-5019)
6 Date: December 19, 2022 ADU/GPS-1-12

6 Important Safety Information
6 Important Safety Information
The safety information provided in this chapter as well as specific safety warnings provided at relevant
points in this manual must be observed during every installation, set-up, and operation procedure of
the device, as well as its removal from service.
Any safety warnings affixed to the device itself must also be observed.
Any failure to observe this safety information, these safety warnings, and other safety-critical operating
instructions in the product documentation, or any other improper usage of the device may result in
unpredictable behavior from the product, and may result in injury or death.
Depending on your specific device configuration and installed options, some safety information may not
be applicable to your device.
Meinberg accepts no responsibility for injury or death arising from a failure to observe the safety
information, warnings, and safety-critical instructions provided in the product documentation.
It is the responsibility of the operator to ensure that the product is safely and properly used.
Should you require additional assistance or advice on safety-related matters for your product, Mein-
berg’s Technical Support team will be happy to assist you at any time. Simply send a mail to techsup-
[email protected].
6.1 Appropriate Usage
The device must only be used appropriately in accordance with the specifications of the product
documentation! Appropriate usage is defined exclusively by this manual as well as any other relevant
documentation provided directly by Meinberg.
Appropriate usage includes in particular compliance with specified limits! The device’s operating
parameters must never exceed or fall below these limits!
ADU/GPS-1-12 Date: December 19, 2022 7
