Mellerware Cook Master User manual
PLEASE READ ALL INSTRUCTIONS BEFORE USE
2 year guarantee
EXECUTIVE
COOK MASTER MINI OVEN
Model:
27800
3400W
MAX
complies with
INTERNATIONAL
IEC60335
SAFETY SPECIFICATIONS
New IM.indd 1 07/04/2011 10:43:31
Dear customer,
Many thanks for choosing to purchase a MELLERWARE brand product. Thanks to its technology, design
and operation and the fact that it exceeds the strictest quality standards, a fully satisfactory use and long
product life can be assured.
Description
A- Big hotplate
B- Small hotplate
C- Temperature dial of oven
D- Cord
E- Power plug
F- Power light
G-Temperature dial of small hotplate
H-Temperature dial of big hotplate
I-Selector
J-Door handle
K-Glass window
L-Bake Rack
M-Bake Pan
B
C
G
H
J
K
I
L
M
D A
F
E
fig. 1
fig. 2
fig. 3
New IM.indd 2 07/04/2011 10:43:31
SAFETY ADVICE AND WARNINGS
• Read all instructions carefully before using this
appliance.
• DO NOT TOUCH hot surfaces during operation,
strictly use the handle & allocated knobs.
• To prevent electric shock, DO NOT IMMERSE
the cord, plug or the appliance in water or any
other liquid.
• This appliance is not intended for use by
persons (including children) with a reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they
have been given supervision or instruction
concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that
they do not play with the appliance.
• Unplug the appliance when not in use or before
undertaking any cleaning of the appliance.
CAUTION! Allow appliance to cool down
completely before cleaning.
• Do not operate the appliance if the plug or
cord is damaged, or if the appliance has
malfunctioned. Take the appliance to an
authorized service center and seek advice.
• Only use supplied accessories in conjunction
with the appliance to avoid malfunctioning
and/or electric shock.
• This appliance is intended for household use
only. Do not use this appliance for industrial or
outdoor applications.
• Do not allow any part of the appliance or the
supply cord hang over the edge of the surface on
which the appliance is mounted. The appliance
can fall from the surface and malfunction or even
be destroyed. Refer to fig.4 for ideal placement.
• Do not place appliance or supply cord on rough
or hot surfaces.
• Use only approved oven gloves when handling
the oven accessories during use of the oven.
• Ensure the appliance is switched off before
inserting or removing the plug from the wall
socket.
• In the event of the contents inside the oven
getting burnt, turn off the appliance immediately
and remove the plug from the wall socket.
• Do not use the cord to pull, carry or lift up the
appliance.
• Do not use the cord to remove the plug from the
wall socket.
• Do not insert any contents into the oven which
are larger than the capacity of the oven.
• Do not place any objects on top of the appliance
during use, unless when using the small and big
plates of the stove top.
• Do not operate the appliance using wet hands.
• Do not touch the plug with wet hands.
• Always use this appliance in a well ventilated
area.
Model Cook Master Mini Oven
Rated Power 220 - 240V
Rated frequency 50Hz
Oven power 1600W
Hob Power Big Hob 1000W
Small Hob 700W
Total power 3150 - 3400W
Dimentions
(W x D x H)
Outer dimentions 504X325X355mm
Inner dimentions 361X270X275mm
N.W 9KGS
SPECIFICATION:
New IM.indd 3 07/04/2011 10:43:31
• Ensure that no objects are beneath the
appliance during use.
• Ensure that the surface on which the appliance
is mounted is stable, secure and even.
• If the surrounding surfaces consists of wood,
vinyl or resin, the distance between surfaces
should be greater than the distances in fig.4.
• CAUTION! The oven door is made from glass.
Exercise extreme caution when opening and
closing the oven door.
Top: more than 10cm
Rear: more
than 5cm
Side: more
than 5cm
fig. 4
Use a single outlet that matches the power rating of the
unit. Heat generated when plugging in multiple appliances
into one outlet may result in fire.
Plug in directly
16A. 220-240V AC
fig. 5
Do not touch the metallic parts or the glass window
during or immediately after use. There is danger of getting
burnt. Make sure that the Oven is not hot before performing
maintenance. fig. 6
Clean dust from the power plug regularly. A build-up of dust
on the plug will attract condensation, which could cause cable
damage resulring in fire. Remove the plug and clean with a
dry cloth. fig. 7
NO wet hands.
Do not connect or disconnect the power plug with wet
hands. This may result in electric shock. fig. 8
Do not put oil into the pan.
There is danger of a fire hazard. fig. 9
Disassembly is
prohibited.
Never try to disassemble, repair or remodel the Cook Oven.
There is danger of fire malfunction, causing injury.
About repair, consult the store from which the Oven was
purchased. fig. 10
New IM.indd 4 07/04/2011 10:43:31
HOW TO USE THE OVEN:
1. Insert the plug into the wall socket. Ensure
that the voltage supply of the wall socket is the
same as the voltage on the rating label.
2. Once the plug is inserted, the power indication
lamp will illuminate.
3. When using the oven for the first time, preheat
the oven for 10-15 minutes without any contents
inside the oven. If a slight odour or smoke
appears, do not be alarmed as this is normal.
4. To use the oven, follow the below instructions:
• Turn the selector knob to the oven setting.
• Set the oven to the desired temperature
by turning the temperature dial knob in a
clockwise direction.
• Preheat the oven for 10-15 minutes with glass
oven door closed.
• Use the oven gloves to insert bake pan or bake
rack containing food contents.
• Once contents have finished cooked or baked,
use the oven gloves and carefully remove the
bake pan/rack. Exercise extreme caution when
removing contents as the surrounding surfaces
are extremely hot and can cause extensive
burn injuries.
• If the oven or any other part of the appliance is
no longer required, turn down the temperature
dial knob to the lowest setting.
• Turn the selector knob to the “OFF” setting.
• Remove the plug from the wall socket and
allow the appliance to completely cool down.
Do not allow children to use the Oven. Do not use the Oven
within the reach of children. There is danger of getting burnt,
and electric shock injury. fig. 11
Do not use the Oven near flammable materials such as
curtains. It may cause fire risk. fig. 12
DO NOT place the Oven near any liquid. AVOID ANY
WATER SPLASHES. It may cause electric shock
NO WETTING!
fig. 13
Upper heating Lower heating
Upper and Lower heating
SELECTOR
OFF
fig. 14
100
180
OVEN
200
250
fig. 15
New IM.indd 5 07/04/2011 10:43:31
CLEANING:
• Before using the appliance for the first time,
wipe down appliance as well as interior of oven
with a damp cloth.
• When cleaning the appliance, use a soft damp
cloth. Do not use abrasive materials to clean
the appliance as this can cause harm to the
appliance.
• Before undertaking any cleaning of the
appliance, ensure that the appliance is off, the
plug has been removed from the wall socket,
and the appliance has completely cool down.
• Turn the selector knob to the stove setting.
• Select which plate to use or both plates may be
used together.
• Select the desired or required heat level.
• Place pot/pan on plate/s.
• When no longer required, turn off plate/s.
• Carefully remove pot/pan from plate/s.
• Allow plate/s to completely cool down and
remove plug from wall socket before cleaning.
HOW TO USE THE STOVE TOP:
REPAIRS:
If the appliance does not work, please consult the
following points:
• Check that the wall socket is working correctly.
• Ensure that the electricity supply is fully
operational.
• Ensure that the appliance plug and cord is
connected and in a safe operating condition.
If the appliance is still not able to operate, take the
appliance to an authorized technical assistance
center for further advice.
1
2
3
4
5
1
2
3
4
5
OFF
MAXMAX
BIG SMALL
OFF
fig. 16
New IM.indd 6 07/04/2011 10:43:32
New IM.indd 7 07/04/2011 10:43:32
27 Nourse Avenue Epping 2 Cape Town
P.O. Box 975 Eppindust 7475 South Africa
Tel: +27 21 534 8114 Fax: +27 21 534 8086
Service Centre Share Call: 086 111 5006
web: www.creativehousewares.co.za
New IM.indd 8 07/04/2011 10:43:32
