Menumaster CFSP70 User manual

1
Menumaster
Commercial
Microwave Oven
Use and Care
Manual
CFSP70
GSAND-7D
SAND-7D
SAND-700
Keep these instructions for future reference. If the
microwave oven changes ownership, be sure this
manual accompanies microwave oven.

2
Keep a copy of sales receipt for future reference or in case warranty service is required.
If something is operating incorrectly, read “Before Calling for Service” section on page 9. Any
further questions or to locate an authorized servicer, call 1-800-843-0304.If outside U.S.A. call
1-319-622-5511. We recommend contacting an authorized servicer if service is required.
Care and Cleaning 8
Interior, Exterior and Door 8
Splatter Shield 8
Air Intake Filter 8
Mechanical 9
Oven Light 9
Before Calling for Service 9
Model Identification
Complete the enclosed registration card and promptly return card to Menumaster's Product
Registration department. If registration card is missing, call our Consumer Affairs department at
1-800-843-0304. If outside U.S.A. call 1-319-622-5511.
When contacting Menumaster, provide product information. Product information is located on the
appliance nameplate on the right interior oven wall. Record the following information:
Model Number:
Serial Number:
Date of purchase:
Dealer’s name and address:
Model Identification 2
Safety 3
Electrical Requirements 5
Grounding 5
Microwave Power 5
Installation 5
Usage 6
CFSP70 6
GSAND-7D, SAND-7D, SAND-700 7
Utensils to Use 8
Utensil Check Test 8
Basic Cooking Principles 8

3
IMPORTANT SAFETY INSTRUCTION
Recognize this symbol as a SAFETY message
WARNING
WHEN USING ELECTRICAL APPLIANCES, BASIC SAFETY PRECAUTIONS SHOULD
BE FOLLOWED TO REDUCE THE RISK OF BURNS, ELECTRICAL SHOCK, FIRE,
INJURY TO PERSONS, OR EXPOSURE TO EXCESSIVE MICROWAVE ENERGY:
7. Aswithanyappliance,CLOSESUPERVISION
is necessary when used by CHILDREN.
8. DO NOT operate this appliance if it has a
damaged cord or plug, if it is not working
properly,orifithasbeendamagedordropped.
9. This appliance should be serviced ONLY by
qualified service personnel. Contact nearest
authorized service facility for examination,
repair or adjustment.
10. DO NOT cover or block any openings on the
appliance.
11. DO NOT store this appliance outdoors. DO
NOTusethisproductnearwater-forexample,
nearakitchensink,inawetbasement,ornear
a swimming pool, and the like.
12. DO NOT immerse cord or plug in water.
13. Keep cord AWAY from HEATED surfaces.
14. DO NOT let cord hang over edge of table or
counter.
15. See door cleaning instructions on page 8.
1. READ all instructions before using the
appliance.
2. READ AND FOLLOW the specific
“PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE
ENERGY” found on page 4.
3. This appliance MUST BE GROUNDED.
Connect only to properly grounded outlet.
See “GROUNDING INSTRUCTIONS” on
page 5.
4. Install or locate this appliance ONLY in
accordance with the provided installation
instructions.
5. Someproductssuchaswholeeggsandsealed
containers - for example, closed glass jars -
mayexplodeandSHOULD NOTbeHEATED
in this oven.
6. Use this appliance ONLY for its intended use
as described in this manual. Do not use
corrosivechemicalsorvaporsinthisappliance.
This type of oven is specifically designed to
heat or cook. It is not designed for industrial
or laboratory use.
TO REDUCE THE RISK OF FIRE IN THE OVEN CAVITY:
a. DO NOT overcook food. Carefully attend appliance if paper, plastic, or other combustible materials
are placed inside the oven to facilitate cooking.
b. Remove wire twist-ties from paper or plastic bags before placing bag in oven.
c. If materials inside the oven should ignite, keep oven door closed, turn oven off, and disconnect the
power cord, or shut off power at the fuse or circuit breaker panel.
IF THE DOOR IS OPENED THE FIRE MAY SPREAD!
d. DO NOT use the cavity for storage purposes. DO NOT leave paper products, cooking utensils, or
food in the cavity when not in use.
THIS APPLIANCE MUST BE SERVICED ONLY BY QUALIFIED SERVICE PERSONNEL. CONTACT
YOUR NEAREST AUTHORIZED SERVICE FACILITY FOR EXAMINATION, REPAIR OR
ADJUSTMENT.
SAVE THESE INSTRUCTIONS

4
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a) DO NOT attempt to operate this oven with
thedooropen since open-dooroperationcan
result in harmful exposure to microwave
energy. Itis important notto defeat ortamper
with the safety interlocks.
(b) DO NOT place any object between the oven
frontfaceandthe door orallowsoilorcleaner
residue to accumulate on sealing surfaces.
(c) DO NOT operate the oven if it is damaged.
It isparticularly important thatthe ovendoor
close properly and that there is no damage
to the: (1) Door (bent), (2) hinges and
latches (broken or loosened), (3) door seals
and sealing surfaces.
(d) The oven should NOT be adjusted or
repairedbyanyoneexcept properly qualified
service personnel.
WARNING
To avoid personal injury or property damage,
observe the following:
1. Briskly stir or pour liquids before heating
to prevent spontaneous boiling or
eruption. Do not overheat. If air is not
mixed into a liquid, liquid can erupt in
oven or after removal from oven.
2. Do not heat sealed containers or plastic
bags in oven. Food or liquid could
expand quickly and cause container or
bag to break. Pierce or open container
or bag before heating.
Caution
To avoid personal injury or property damage,
observe the following:
1. If food smokes or ignites:
·Do not open door.
·Turn oven off.
·Disconnect power cord.
·Shut off power at fuse or circuit breaker.
2. Do not deep fat fry in oven. Fat could
overheat and be hazardous to handle.
3. Do not cook or reheat eggs in shell or
with an unbroken yolk. Pressure may
buildup and erupt. Pierce yolk with a
fork or knife before cooking.
4. Use only popcorn in packages designed
and labeled for microwave use. Pop
according to package directions,
beginning with the minimum amount of
time recommended. Do not continue to
heat after popping has stopped.
Popcorn will scorch or burn. Do not
leave oven unattended.
5. Do not heat baby bottles in oven.
6. Do not use regular cooking
thermometers in oven. Most cooking
thermometers contain mercury and may
cause “arcing”, malfunction, and/or
damage to oven.
7. Do not use metal utensils in oven
except when recommended by
microwave food manufacturers. Heat
food in containers made of glass,
plastic, paper, or china.
8. Never use newspapers in oven since
paper may ignite.
9. Do not use paper towels which contain
nylon or other synthetic fibers. Heated
synthetics could melt and cause paper to
ignite.
10. Containers may become hot. Pot
holders may be needed.

5
Electrical Requirements
GROUNDING INSTRUCTIONS
Installation
Unpacking Oven
•Inspect microwave oven for damage such as
dents in door or dents inside oven cavity.
•Report any dents or breakage to source of
purchase immediately. Do not attempt to
use oven if damaged.
•Remove all materials from oven interior.
•If oven has been stored in extremely cold
area, wait a few hours before plugging in.
DO NOT UNDER ANY
CIRCUMSTANCES CUT OR
REMOVE THE ROUND
GROUNDING PRONG FROM
THE PLUG OR BEND THE
POWER PRONGS TO FIT A
RECEPTACLE OTHER THAN
THE ONE SHOWN FOR YOUR
OVEN. SUCH ABUSE OF THE
PLUG CAN RESULT IN
ELECTRICAL SHOCKS OR
OVERHEATING.
120V-15AMP
Microwave Power
Models CFSP70, GSAND-7D, SAND-7D and SAND-700 deliver 750 watts of cooking power to the
oven cavity.
Oven Placement
•Do not install microwave oven next to or above
source of heat, such as pizza oven or deep fat
fryer.This could cause microwave oven to
operate improperly and could shorten life of
electrical parts.
•Allow air flow around unit. Air flows around
electriccomponents. Atleastoneinchofclearance
is required at top and sides of unit to provide
properventilation. With restrictedairflowunitwill
notoperateproperlyandlifeofelectricalpartswill
shorten.
WARNING - IMPROPER USE OF THE GROUNDING
PLUG CAN RESULT IN A RISK OF ELECTRIC SHOCK OR
DEATH.
This appliance MUST be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance
isequipped witha cordhaving agrounding wirewith agrounding
plug. The plug must be plugged into an outlet that is properly
installed and grounded. DO NOT use a two-prong adapter.
Consult a qualified electrician or serviceman if the grounding
instructions are not completely understood, or if doubt exists as
to whether the appliance is properly grounded.
Do not use an extension cord. If the product power cord is too
short, have a qualified electrician install a three-slot receptacle.
This oven should be plugged into a separate 60 hertz circuit with
the electrical rating as shown in the appropriate drawing at left.
When a microwave oven is on a circuit with other appliances, an
increase in cooking times may be required and fuses can be
blown.

6
Usage
CFSP70
1. Open oven door, place food in oven, and
close door.
2. Set Vari-Power control to desired power
level by turning clockwise.
3. Set timer knob to desired cooking time by
turning clockwise. Oven starts cooking.
4. When time has elapsed signal sounds and
oven shuts off.
To stop oven during operation:
1. Open oven door. Oven will stop cooking.
Timer maintains current time setting.
2. Cooking resumes when door is closed.
Turn timer knob counterclockwise to "0" to
clear all cooking time.

7
GSAND-7D, SAND-7D and SAND-700
1. Open oven door, place food in oven and
close door.
2. Set timer knob to desired cooking time by
turning clockwise. Cooking starts.
3. When time has elapsed signal sounds and
oven shuts off.
To stop oven during operation:
1. Open oven door. Oven stops cooking.
Timer maintains current time setting.
2. Cooking resumes when door is closed.
Turn timer knob counterclockwise to "OFF"
to clear all cooking time.

8
Care and Cleaning
Interior, Exterior and Door
If interior walls, floor and door of microwave oven
become splattered, clean with mild detergent in
warm water using soft sponge or cloth. Wring
sponge or cloth to remove excess water before
wiping unit. If desired, boil a cup of water in
microwave oven to loosen soil before cleaning.
•Do not use abrasive cleansers or cleaners
containing ammonia. These could damage
finish.
•Never pour water into microwave oven
bottom.
•Do not use water pressure type cleaning
systems.
Splatter Shield
Splatter shield keeps top of microwave oven
and antenna from getting dirty. Remove soil
from shield with damp cloth or clean with mild
detergent and water.
Air Intake Filter
Clean air intake filter weekly for proper air flow.
Filter is located below oven door. Remove by
pulling filter tab. Wash filter in hot water and
mild detergent. Do not use oven without filter in
place.
Utensils to Use
Utensil Check Test
Use the following test to check utensils for
microwave safeness:
1. Place glass measuring cup of water next to
empty dish to be tested in unit.
2. Heat on full power for one minute.
3. Check temperature of tested dish.
If dish remains cool and water is hot, dish is
microwave safe. If dish is slightly warm, use for
short term cooking only. If dish is hot and water
is cool, do not use. Dish remains cool if not
absorbing microwaves and microwaves are
being absorbed by water. Dish becomes hot if
absorbing microwaves.
Safe utensils:
Non-recycled paper
Glass
Glass-ceramic
Plastic
Wood
Shells
Natural fiber cloth
Unsafe utensils:
Recycled paper
Metal
Newspapers
Grocery bags
Aluminum foil
Metallic trimmed china
Lead crystal
Basic Cooking Principles
Decrease cooking times when:
Foods are high in fat and sugar.
Foods are porous.
Foods are flat, thin or prepared in shallow pan.
Increase cooking times when:
Foods are thick and dense.
Foods are frozen or refrigerator temperature.
Food volume increases.

9
Mechanical
Oven Light
Caution
To avoid electrical shock
hazardunplug power cord
or open circuit breaker to
microwave oven before
replacing light bulb.
After replacing light bulb,
reconnect power.
Tools needed--
•protective gloves
•flat head screwdriver
Important! Wear gloves to protect hands
should bulb break. If hot, allow bulb to cool.
To change oven light:
1. Remove screw from and open cover on
access door on back of oven.
2. Remove bulb by turning counter- clockwise,
being careful not to burn fingers or break
bulb.
3. Replace bulb with:
CFSP70--T-6, 15-watt, 120-volt. candelabra
base bulb
GSAND-7D ,SAND-7D and SAND-700-
120-volt, 40-watt candelabra base bulb (blunt
tip, decorative)
available at hardware store.
4. Close access door and replace access
screw.
5. Plug in microwave oven.
WARNING
To avoid electrical shock, personal injury or death, do not remove outer case at any
time. Only authorized servicer should remove outer case. If removed by another
person, warranty is void.
Any questions or to locate an authorized Menumaster servicer, call 1-800-843-0304.If outside
U.S.A. call 1-319-622-5511. Contact an authorized Menumaster servicer if service is required.
When contacting us, provide product information including model and serial numbers and date of
purchase. Model and serial numbers are located on appliance nameplate.
If microwave oven does not operate:
•Confirm unit is plugged into dedicated
circuit.
•Confirm unit is on grounded and
polarized circuit.
•Check fuse or circuit breaker. Determine if
circuit is operable by plugging another item
in outlet.
If oven light does not work:
•Confirm light bulb is screwed in tightly.
•Confirm light bulb is not defective.
If unit operates intermittently:
•Check inlet and discharge areas for
obstructions.
•Confirmunitwasnotoperatedemptyorwith
metal utensils.
If unit operates, but will not heat food:
•Place one cup cool water in unit.
Heat for one minute. If water temperature
does not rise, unit is operating incorrectly.
Before Calling for Service

10
NOTES

11

12
Part No. 10808605
Printed in U.S.A. 1994 Amana Refrigeration, Inc. Amana, Iowa 52204
