Publication details
Internet
Further information about Mercedes-Benz vehi‐
cles and about Mercedes‑Benz AG can be found
on thefollowing websites:
https://www.mbusa.com (USA only)
https://www.mercedes-benz.ca (Canada only)
Documentation team
©Mercedes‑Benz AG: Not to be reprinted, trans‐
lated or otherwise reproduced, in whole or in
part, without written permission from
Mercedes‑Benz AG.
Vehicle manufacturer
Mercedes‑Benz AG
Mercedesstraße 120
70372 Stuttgart
Germany
As at 02.04.20

Thank youfor purchasing a Mercedes-AMG
Before youfirst drive off, read this Operator's
Manual carefully and familiarize yourself with
your vehicle. Foryour own safety and a longer
operating lifespan of thevehicle, follow the
instructions and warning notices in this Opera‐
tor's Manual. Disregarding them may lead to
damage to thevehicle or injury to people.
Damage to thevehicle resulting from the disre‐
gard of the instructions is not coveredby the
Mercedes-Benz Limited Warranty.
The standard equipment and product description
of your vehicle may vary and depends on thefol‐
lowing factors:
RModel
ROrder
RNational version
RAvailability
Mercedes-AMG reservestheright to introduce
changes in thefollowing areas:
RDesign
REquipment
RTechnical features
The equipment in your vehicle may therefore dif‐
fer from that shown in the descriptions and illus‐
trations.
The following documents are integral parts of
thevehicle:
RDigital Operator's Manual
RPrinted Operator's Manual
RMaintenance Booklet
REquipment-dependent Supplements
Keep these documents in thevehicle at all
times. If you sell thevehicle, always pass all of
the documents on to the new owner.
Mercedes-Benz USA, LLC
Mercedes-Benz Canada, Inc.
A Daimler Company
2575844203
2575844203

Symbols ........................................................ 3
At aglance .................................................... 4
Cockpit ........................................................... 4
General notes............................................... 6
Operator's Manual .......................................... 6
Operating safety .............................................6
Qualified specialist workshop .........................7
Correct use of thevehicle ...............................7
Limited Warranty ............................................ 8
Driving and parking ...................................... 9
Driving ............................................................ 9
DYNAMIC SELECT switch .............................. 10
Automatic transmission ................................ 11
Driving and driving safety systems ................12
Function of the AMG steering-wheel but‐
tons .............................................................. 17
Instrument Display and on-board
computer.................................................... 19
Notes on the Instrument Display and on-
board computer ............................................ 19
Operating the on-board computer ................19
Calling up displays on thePerformance
menu ............................................................ 21
Function of the Head-up Display ...................23
MBUX multimedia system ......................... 25
AMG TRACK PACE ........................................ 25
Wheels and tires ........................................ 31
Changing a wheel .........................................31
Cover of jack support points ......................... 31
Technical data ............................................ 32
Operating fluids ............................................ 32
Vehicle data .................................................. 33
Display messages and warning/indi‐
cator lamps ................................................ 36
Display messages .........................................36
Warning and indicator lamps ........................ 37
Index ........................................................... 40
2Contents

In this Operator's Manual, you will find thefol‐
lowing symbols:
&DANGER Danger due to not observing
thewarning notices
Warning notices draw your attention to haz‐
ards that may endanger your health or life, or
the health or life of others.
#Observe thewarning notices.
+ENVIRONMENTAL NOTE Environmental
damage due to failure to observe envi‐
ronmental notes
Environmental notes include information on
environmentally responsible behavior or envi‐
ronmentally responsible disposal.
#Observe environmental notes.
*NOTE Damage to property due to failure
to observe notes on material damage
Notes on material damage inform you of
risks which may lead to your vehicle being
damaged.
#Observe notes on material damage.
%These symbols indicate useful instructions
or further information that could be helpful
to you.
#Instruction
(/page)Further information on a topic
Display Information on the multifunction dis‐
play/media display
4Highest menu level, which is to be
selected in the multimedia system
5Relevant submenus, which are to be
selected in the multimedia system
*Indicates a cause
Symbols 3

Left-hand-drive vehicles
4At aglance – Cockpit

1Steering wheel paddle shifters →11
2Instrument Display →19
3Start/stop button →9
4öAMG Performance exhaust system →9
5åESP®→12
6äAMG adaptive sport suspension sys‐
tem +
→15
7BManual gearshifting →11
8DYNAMIC SELECT switch →10
9AMG steering-wheel buttons →17
At aglance – Cockpit 5

Operator's Manual
This Supplement provides information on all the
important functions of your AMG vehicle that are
either not described or differ from the descrip‐
tions in thevehicle Operator's Manual. This
information supplements or replaces the corre‐
sponding sections in thevehicle Operator's Man‐
ual. Under no circumstances does the Supple‐
ment replace the Operator's Manual.
This Supplement describes all models, and
standard and optional equipment foryour vehi‐
cle, as available at the time of going to press.
Country-specific differences are possible. Bear
in mind that your vehicle may not feature all
functions described here. This is also the case
for systems and functions relevant to safety.
Therefore, the equipment on your vehicle may
differ from that in the descriptions and illustra‐
tions.
The original purchase contract documentation
foryour vehicle contains a list of all of the sys‐
tems in your vehicle.
Should you have any questions concerning
equipment and operation, please consult an
authorized Mercedes-Benz Center.
The Operator's Manual, the Supplement and the
Maintenance Booklet are important documents
and should be kept in thevehicle.
Operating safety
&WARNING Risk of accident due to mal‐
functions or system failures
To avoid malfunctions or system failures:
#Always have the prescribed service and
maintenance work as well any required
repairs carried out at a qualified spe‐
cialist workshop.
&WARNING Risk of accident or injury due
to incorrect modifications on electronic
component parts
Modification of electronic components, their
software or wiring could impair their function
and/or the function of other networked com‐
ponent parts or safety-relevant systems.
This can endanger the operating safety of the
vehicle.
#Nevertamper with the wiring and elec‐
tronic component parts or their soft‐
ware.
#You should have all work on electrical
and electronic components carried out
at a qualified specialist workshop.
Observe the "On-board electronics" section in
"Technical data" in thevehicle Operator's Man‐
ual.
&WARNING Risk of fire due to flammable
materials on hot parts of theexhaust
system
Flammable material such as leaves, grass or
twigs may ignite if they come into contact
with hot parts of theexhaust system.
6General notes

#When driving on unpavedroads or off-
road, regularly check thevehicle under‐
side.
#Remove trapped plants or other flam‐
mable material, in particular.
#If there is damage, consult a qualified
specialist workshop immediately.
*NOTE Damage to thevehicle
In thefollowing situations, in particular, there
is a risk of damage to thevehicle:
RThe vehicle becomes grounded, e.g. on a
high curb or an unpavedroad
RThe vehicle is driven toofast over an
obstacle, e.g. a curb, speed bump or pot‐
hole
RA heavy object strikesthe underbody or
chassis components
In situations such as this, the body, the
underbody, chassis components, wheels or
tires could be damaged without the damage
being visible. Components damaged in this
way can unexpectedly fail or, in the case of
an accident, may not absorb the loads that
arise as intended.
If the underbody paneling is damaged, flam‐
mable materials such as leaves, grass or
twigs can collect between the underbody and
the underbody paneling. These materials may
ignite if they come into contact with hot
parts on theexhaust system.
#Have thevehicle checked and repaired
immediately at a qualified specialist
workshop.
or
#If driving safety is impaired while con‐
tinuing your journey, pull over and stop
thevehicle immediately in accordance
with the traffic conditions, and contact
aqualified specialist workshop.
Qualified specialist workshop
An authorized Mercedes-Benz Center is a quali‐
fied specialist workshop. It has the necessary
special skills, tools and qualifications to cor‐
rectly carry out thework required on your vehi‐
cle. This particularly applies to safety-relevant
works.
Forthefollowing, always have your vehicle
checked at an authorized Mercedes-Benz Cen‐
ter:
RSafety-relevant works
RService and maintenance work
RRepair work
RModifications as well as installations and
conversions
RWork on electronic components
Mercedes‑AMG recommends a Mercedes‑Benz
service center.
Correct use of thevehicle
If youremove any warning stickers,you or others
could fail to recognize certain dangers. Leave
warning stickers in position.
Observe thefollowing information in particular
when driving your vehicle:
Rthe safety notes in this manual
General notes 7

Rtechnical data forthevehicle
Rtrafficrules and regulations
Rlaws and safetystandards pertaining to
motorvehicles
Limited Warranty
*NOTE Damage to thevehicle arising
from violation of these operating instruc‐
tions.
Damage to thevehicle can arise from viola‐
tion of these operating instructions.
This damage is not covered either by the
Mercedes-Benz implied warranty or by the
New‑ or Used-Vehicle Warranty.
#Follow the instructions in these operat‐
ing instructions on proper operation of
your vehicle as well as on possible vehi‐
cle damage.
8General notes

Driving
Function of Emotion Start
#Start thevehicle with thestart/stop button
and simultaneously pull one of thesteering
wheel gearshift paddles 1or 2.
RThe idle speed is increased briefly when
starting the engine.
RThe exhaust gasflaps are opened (sporty
characteristic) (/page 9).
Follow the instructions forstarting thevehicle in
thevehicle operating instructions.
AMG Performance exhaust system
Function of the AMG Performance exhaust
system
Changing the position of theexhaust gasflaps
allows youto select the sound characteristics of
the AMG Performance exhaust system:
RBalanced: closed exhaust gasflaps for a
comfortable sound characteristic
RPowerful: open exhaust gasflaps for a
sporty sound characteristic
Operating the AMG Performance exhaust
system
#Press button 1.
The sporty characteristic (powerful) is selec‐
ted when indicator lamp 2lights up.
Driving and parking 9

DYNAMIC SELECT switch
Function of theDYNAMIC SELECT switch
Use theDYNAMIC SELECT switch to change
between thefollowing drive programs.
The drive program selected appears in the multi‐
function display of the on-board computer.
oSlippery
ROptimized pulling away and driving character‐
istics in wintry and slippery road conditions
AComfort
RComfortable driving style
RBalance between traction and stability
RRecommended for city driving and stop-and-
go traffic
=Individual
RIndividual settings
CSport
RSporty driving characteristics
RBalance between stability and sportiness
ROnly suitable for good road conditions, a dry
road surface and a clear stretch of road
BSport+
RParticularly sporty driving characteristics
RAccentuatesthevehicle's own understeering
and oversteering characteristics
ROnly suitable for good road conditions, a dry
road surface and a clear stretch of road
Depending on the drive program selected, the
following vehicle characteristics will change:
RDrive
RAMG Dynamics
-The agility functions are automatically
selected depending on the drive program.
-The steering, shift timing point, drive and
stabilization functions are adaptedto the
selected drive program.
RPosition of theexhaust gasflaps
RSuspension tuning
RAvailability of glide mode
R4MATIC+ all-wheel drive
%You can change thefollowing vehicle charac‐
teristics using the buttons in the center con‐
sole:
RPosition of theexhaust gasflaps
RSuspension tuning
RESP®
Displaying dynamic data
Multimedia system:
4AMG Performance 5Vehicle
#Select Dynamic Data.
Dynamic data is displayed, e.g.:
RG-force values
RTorque distribution
RBoost effect
RCurrent power output
RVariable all-wheel drive
10 Driving and parking

Automatic transmission
Rocking thevehicle free
Rocking thevehicle free may help to free the
vehicle if it has become stuck in slush or snow.
To rock thevehicle free, move the DIRECT
SELECT lever upwards and downwards past the
pressure point in order to switch between trans‐
mission positions hand k.
%The maximum design speed when switching
between hand kis 6 mph (9 km/h).
Manual gearshifting
#To activate/deactivate:press button 1.
If indicator lamp 2is lit, manual gearshift‐
ing is activated. The current gear is displayed
in the multifunction display.
%To permanently shift thegears manually in
drive program=using thesteering wheel
gearshift paddles, select theM(Manual) set‐
ting forthe transmission.
*NOTE Damage to the engine due to shift‐
ing up too late
The automatic transmission does not shift up
in manual mode even when the engine's lim‐
iting speed is reached.
The fuel supply is interrupted in order to pre‐
vent the engine from overrevving.
#Shift up before the engine speed rea‐
ches thered area in thetachometer.
Driving and parking 11

#To shift up: pull steering wheel gearshift
paddle 2.
#To shift down: pull steering wheel gearshift
paddle 1.
If the engine speed is too high or too low, you
cannot change gear using thesteering wheel
gearshift paddles. In this case, segments 1
light up red.
Glide mode function
With an anticipatory driving style, Glide mode
helps youto reduce fuel consumption.
Glide mode is characterized by thefollowing:
RThe combustion engine is switched off. All of
thevehicle functions remain active.
RThe Jsymbol appears in the multifunc‐
tion display.
Glide mode is activated if thefollowing condi‐
tions are met:
RThe ECO start/stop function is switched on.
RDrive program =is selected with the
drive setting "Moderate" or "Reduced".
RThe speed is within a suitable range.
RThe road's course is suitable, e.g. no steep
uphill or downhill inclines or tight curves.
RThe charge level of the battery is sufficient.
RYou are no longer depressing the accelerator
or brake pedal.
Glide mode is deactivated again if one of the
conditions is no longer met.
Driving and driving safety systems
Functions of ESP®
&WARNING Risk of skidding if ESP®is
malfunctioning
If ESP®is malfunctioning, ESP®cannot carry
out vehicle stabilization. In addition, other
driving safety systems are switched off.
#Drive on carefully.
#Have ESP®checked at a qualified spe‐
cialist workshop.
You can select between thefollowing modes of
the Electronic Stability Program (ESP®):
RESP®ON
RESP®SPORT
RESP®OFF
Characteristics when ESP®is activated
ESP®monitors and improves driving stability and
traction, particularly in thefollowing situations:
RWhen pulling away on wet or slippery road.
12 Driving and parking

RWhen braking.
RIn strong side winds when you are driving
faster than 47 mph (75 km/h).
ESP®can stabilize thevehicle by intervening in
thefollowing ways:
ROne or more wheels are braked.
RThe engine output is adapted according to
the situation.
ESP®is activated every time the engine is star‐
tedregardless of whether ESP®was in ESP®
SPORT or deactivated before the engine was
switched off.
If the÷ESP®warning lamp flashes in the
instrument cluster, one or severalvehicle wheels
has reached its grip limit:
RAdapt the driving styleto suit the prevailing
road and weather conditions.
RDo not deactivate ESP®under any circum‐
stances.
ROnly depress the accelerator pedal as far as
is necessary.
Characteristics of ESP®SPORT
&WARNING Risk of skidding if ESP®
SPORT is used incorrectly
When you activate ESP®SPORT, there is an
increased risk of skidding and having an acci‐
dent.
#Activate ESP®SPORT only in the cir‐
cumstances described below.
When ESP®SPORT is activated, theåand
Æwarning lamps light up continuously in the
instrument cluster.
Select ESP®SPORT when thevehicle's own
oversteering and understeering characteristics
are desired, e.g. on cordoned off roads.
Driving with ESP®SPORT or with ESP®deactiva‐
tedrequires an extremely qualified and experi‐
enced driver.
If ESP®SPORT is activated and one or more
wheels start to spin, the÷ESP®warning
lamp on the instrument clusterflashes. ESP®
then only stabilizes thevehicle to a limited
degree.
ESP®SPORT also has thefollowing characteris‐
tics:
RESP®only improves driving stability to a limi‐
ted degree.
RETS/4ETS traction control is still active.
RThe engine's torque is only restricted to a
limited degree and the drive wheels can spin.
The spinning of the wheels results in a cut‐
ting action for better traction on loose surfa‐
ces.
RESP®continues to provide assistance when
the brakes are firmly applied.
RCrosswind Assist is no longer active.
Characteristics when ESP®is deactivated
&WARNING Risk of skidding if ESP®is
deactivated
If you deactivate ESP®, ESP®cannot carry
out vehicle stabilization.
Driving and parking 13

#ESP®should only be deactivated in the
following situations.
When ESP®is deactivated, theåand ¤
warning lamps light up continuously in the
instrument cluster.
Deactivating ESP®has thefollowing effects:
RDriving stability will no longer be improved.
RThe drive wheels could spin.
RETS/4ETS traction control is still active.
RCrosswind Assist is no longer active.
%Even when ESP®is deactivated, you are still
assistedby ESP®when braking hard.
It may be best to activate ESP®SPORT or deacti‐
vate ESP®in thefollowing situations:
RWhen using snow chains.
RIn deep snow.
ROn sand or gravel.
%Spinning the wheels results in a cutting
action, which enhances traction.
%Activate ESP®as soon as the situations
described above no longer apply. ESP®will
otherwise not be able to stabilize thevehicle
if thevehicle starts to skid or a wheel starts
to spin.
If the÷ESP®warning lamp lights up continu‐
ously even when ESP®is activated, ESP®is not
available due to a malfunction.
Observe any information which is displayed in
the instrument cluster:
RIndicator and warning lamps
RDisplay messages
ETS/4ETS (Electronic Traction System)
ETS/4ETS traction control is part of ESP®.
ETS/4ETS can improve thevehicle's traction by
intervening in thefollowing ways:
RThe drive wheels are braked individually if
they spin.
RMore drive torque is transferred to the wheel
or wheels with traction.
Activating/deactivating ESP®(Electronic Sta‐
bility Program)
#To activate ESP®SPORT: briefly press but‐
ton1.
The åand Æwarning lamps appear in
the instrument cluster.
14 Driving and parking

#To deactivate ESP®:press and hold button
1until theåand ¤warning lamps
appear in the instrument cluster.
#To activate ESP®:briefly press button 1.
The å,Æand ¤warning lamps go
out.
Observe the information on warning lamps and
display messages which are shown in the instru‐
ment cluster.
AMG adaptive sport suspension system +
Function of the AMG adaptive sport suspen‐
sion system +
The AMG adaptive sport suspension system + is
an air suspension system with variable damping
for improved driving characteristics. The all-
round level control system ensures the best pos‐
sible suspension and constant ground clearance,
even with a laden vehicle. When driving at
speed, thevehicle is lowered automatically to
improve driving safety and to reduce fuel con‐
sumption. You also have the option of manually
adjusting thevehicle level.
The damping is set individually for each wheel
and is affected by thefollowing factors:
RDriving style, e.g. sporty
RRoad condition, e.g. bumps
RThe individual selection of Sport,Sport + or
COMFORT
The AMG adaptive sport suspension system +
includes thefollowing components and func‐
tions:
RAir suspension with variable spring rate and
automatic level control
RSpeed-dependent lowering to reduce fuel
consumption
RManually selectable high-level setting for
greater ground clearance
RADS PLUS (Adaptive Damping System with
constant damping force adjustment)
RDYNAMIC SELECT switch and level button
RSuspension setting button
Suspension setting and vehicle level per
drive program
Drive programs oand A:
RThe suspension setting is comfortable.
RThe vehicle is set to the normal level.
RWhen driving at speeds of 100mph
(160 km/h) or above,thevehicle is lowered.
RWhen driving at speeds below 87 mph
(140 km/h), thevehicle is raised again.
Drive programCand B:
RThe suspension setting is firmer.
RThe vehicle is set to the low level.
RThe vehicle is not lowered any further if you
are traveling at higher speeds.
%When the engine is started again, theCOM‐
FORT setting is activated automatically.
Driving and parking 15

Selecting the AMG adaptive sport suspen‐
sion system+ setting
#COMFORT suspension setting: press but‐
ton1repeatedly until indicator lamps 2
and 3go out.
The AMG Suspension System COMFORT
message appears in the multifunction dis‐
play.
The driving characteristics of your vehicle are
comfortable.
#SPORT suspension setting: press button
1repeatedly until indicator lamp 3lights
up.
The AMG Suspension System SPORT mes‐
sage appears in the multifunction display.
The suspension is adaptedto be firmer.
#SPORT+ suspension setting: press button
1repeatedly until indicator lamps 2and
3light up.
The AMG Suspension System SPORT + mes‐
sage appears in the multifunction display.
The vehicle is loweredto low level and the
suspension is set to very firm.
Setting thevehicle level
&WARNING Risk of accident because
vehicle level is too high
Driving characteristics may be impaired.
The vehicle can drift outwards, forexample,
when steering or cornering.
#Choose a vehicle level which is suited
to the driving style and theroad surface
conditions.
&WARNING Risk of entrapment from vehi‐
cle lowering
When lowering thevehicle, people could
become trapped if their limbs are between
thevehicle body and the tires or underneath
thevehicle.
#Make sure no one is underneath the
vehicle or in the immediate vicinity of
the wheel arches when thevehicle is
being lowered.
&WARNING Risk of becoming trapped
due to thevehicle lowering
Vehicles with AIR BODY CONTROL or
level control system: when you unload lug‐
gage or leave thevehicle, thevehicle first
rises slightly and then returns to the set level
shortly afterwards.
16 Driving and parking

You or anyone else in the vicinity of the
wheel arches or the underbody could thus
become trapped.
The vehicle can also be lowered after being
locked.
#When leaving thevehicle, make sure
that nobody is in the vicinity of the
wheel arches or the underbody.
Requirements:
RThe vehicle has been started.
RThe vehicle must not be moving faster than
40 mph (65 km/h).
Multimedia system:
4©5Settings 5Quick Access
Raising thevehicle
#Select É.
The vehicle is raised to the high level.
Your selection is saved.
The vehicle lowers itself back down to the height
of the most recently active drive program:
RWhen driving faster than 62 mph
(100 km/h).
RWhen driving between 50 mph (80 km/h)
and 62 mph (100 km/h) for approximately
three minutes.
RAfter selecting a drive program using the
DYNAMIC SELECT switch.
Lowering thevehicle
#Select É.
The vehicle is adjustedto the height of the
last active drive program.
Function of the AMG steering-wheel but‐
tons
The AMG steering-wheel buttons are two addi‐
tional control elements on thesteering wheel.
You can assign two vehicle functions of your
choice to the left control element. You can
change between theavailable functions by
pressing the display switches 2repeatedly.
Display switch 2shows the currently selected
functions.
The following functions are available:
RESP®(/page 12)
Driving and parking 17

RAMG adaptive sport suspension system +
(/page 15)
RAMG Performance exhaust system
(/page 9)
RManual gearshifting (/page 11 )
RAMG Dynamics (/page 10)
RECO start/stop function (see thevehicle
Operator's Manual)
If you have assigned a function to one of display
switches 2,you can operate this function with
corresponding button 1.
The assignment of display switch 2remains
stored even after a new engine start, but the
operating status of therespective function is
reset to the basic setting.
You can change between the drive programs
with control knob 3. The drive program selec‐
ted appears in display switch 4. Press display
switch 4to go directly to the drive program
=(/page 10).
18 Driving and parking
